2AB3E-ISP51Wireless Speaker with Synchronized LED Party Lights

Box Contents: Party Starter, USB Charging Cable, Quickstart Guide. Charging Party Starter: Use the included micro-USB cable to connect Party Starter to (A) a USB power adapter connected to a power outlet or (B) your computer (powered on) for 3 hours. Controls: (1) Party Light Switch (2) 1/8” Aux Input (3) Bluetooth ® Disconnect / Call Answer (4) Bluetooth Pairing Light (5) Micro-USB Charging Port (6) Power LED / Battery Light (7) Microphone (8) Volume - / Previous Track (9) Power / Play / Pause (10) Volume + / Next Track Getting Started: (1) Press and hold the Power button for 2 seconds to power on Party Starter. (2) Open Bluetooth settings on your music device (smartphone, tablet, etc.). (3) Connect to Party Starter. (4) Play music and adjust Party Starter's volume using the Volume - and Volume + buttons. (5) Adjust the Party Light switch to the desired setting. For best party light results, use in a dark room. (6) To receive an incoming phone call, press the Call Answer button. To end an active call, press the button again. For the complete user guide, visit ionaudio.com. Button Functions: • Power / Play / Pause: Press and hold this button for 2 seconds to power Party Starter on/off. Press this button to play/pause a paired Bluetooth device. • Bluetooth Reset / Call Answer: When there is no incoming phone call, or no active call, press this button to disconnect a previously paired Bluetooth device. Press this button to answer an incoming phone call or press to end an active call. • Volume - / Previous Track: Press this button to skip to the beginning of the playing track (or the previous track depending on the player or position in the song). Press and hold this button to decrease the track volume. • Volume + / Next Track: Press this button to skip to the next track. Press and hold this button to increase the volume. Party Light Switch Settings: Turns the LED lights on and off, or puts Party Starter into Demo mode. • Off: LEDs are not lit. Party Starter will power down after 5 minutes if no audio is being played. • On: LEDs are lit immediately when powered on. LED lightshow synchronizes to the music. Party Starter will power off after 15 minutes if no audio is being played. • Demo: LEDs are lit immediately when powered on. LED lightshow synchronizes to the music. Party Starter will power off after 2 minutes if no audio is being played. 1 2 3 45 6 7 8 9 10 Contenu de la boîte : Party Starter, câble de rechargement USB, guide de démarrage rapide. Rechargement de la batterie du Party Starter : Lorsque l’intensité du voyant d’indication de charge de la batterie diminue, la batterie doit être rechargée. Utilisez le câble micro-USB inclus afin de brancher le party Starter à (A) un adaptateur d’alimentation USB branché à une prise secteur, ou (B) à un ordinateur (sous tension) pendant 3 heures. Commandes : (1) Interrupteur d’éclairage : (2) Entrée auxiliaire 3,5 mm (⅛ po) (3) Déconnexion Bluetooth/appel-réponse (4) Témoin de jumelage Bluetooth (5) Port de rechargement micro-USB (6) DEL d’alimentation/Batterie (7) Microphone (8) Volume -/Piste précédente (9) Interrupteur d’alimentation/ Lecture/Arrêt de lecture (10) Volume +/Piste suivante Mise en route : (1) Maintenez l’interrupteur d’alimentation enfoncé pendant 2 secondes afin de mettre le Party Starter sous tension. (2) Accédez aux paramètres Bluetooth de votre lecteur de musique (téléphone intelligent, tablette, etc.). (3) Connectez-le au Party Starter. (4) Faites jouer de la musique et réglez le volume du Party Starter avec les touches Volume - et Volume +. (5) Réglez l’interrupteur d'éclairage à la position souhaitée. Pour de meilleurs résultats, utilisez-le dans une pièce sombre. (6) Appuyez sur la touche d'appel-réponse pour prendre un appel. Appuyez de nouveau sur la touche pour mettre fin à l’appel. Pour le guide de l'utilisateur complet, veuillez visiter le site ionaudio.com. Fonctions des touches : • Interrupteur d’alimentation/Lecture/Arrêt de lecture : Maintenez cette touche enfoncée pendant 2 secondes afin de mettre le Party Starter sous et hors tension. Appuyez sur cette touche afin de lancer/arrêter la lecture de la musique sur l’appareil Bluetooth jumelé. • Déconnexion Bluetooth/appel-réponse : Lorsqu’il n’y a aucun appel entrant ou en cours, cette touche permet de déjumeler un appareil Bluetooth. Appuyez sur cette touche pour prendre un appel ou pour mettre fin à un appel en cours. • Volume -/Piste précédente : Cette touche permet de passer au début de la piste (ou à la piste précédente selon le lecteur ou la position dans la piste). Maintenir cette touche enfoncée pour diminuer le volume. • Volume +/Piste suivante : Appuyez sur cette touche pour avancer à la piste suivante. Maintenir cette touche enfoncée pour augmenter le volume. Réglages de l’interrupteur d’éclairage : Cet interrupteur permet d’allumer et d’éteindre le jeu de lumière du Party Starter, ou de le mettre en mode démonstration. • Off (désactivé) : Les DEL sont éteintes. Party Starter s’éteint après 5 minutes d’inactivité. • On (activé) : Les DEL s’allument immédiatement lors de la mise sous tension. Le jeu de lumière se synchronise à la musique. Party Starter s’éteint après 15 minutes d’inactivité. • Demo (démonstration) : Les DEL s’allument immédiatement lors de la mise sous tension. Le jeu de lumière se synchronise à la musique. Party Starter s’éteint après 2 minutes d’inactivité. 1 2 3 45 6 7 8 9 10 Contenido de la caja: Party Starter, cable USB de carga, guía de inicio rápido. Cómo cargar el Party Starter: Cuando la luz de carga de la batería comience a atenuarse, cargue el Party Starter. Use el cable micro USB incluido para conectar el Party Starter a (A) un adaptador de alimentación USB conectado a un tomacorriente o (B) su ordenador (encendido) durante 3 horas. Controles: (1) Interruptor de las luces de fiesta (2) Entrada auxiliar de 1/8 pulg. (3) Desconectar Bluetooth / Atender llamada (4) Luz de apareamiento Bluetooth (5) Puerto de carga Micro-USB (6…

Text truncated - open the document above for the full version.

DATE :2014-12-23 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint below company and person: Name Jamy Yu Position Manager Company Name Dongguan Dongdian Testing Service Co.,Ltd. Address 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808 Tel / Fax Tel: +86-0769-22891499 fax:+86-0769-22895596 E-Mail [email protected] to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with: Applicant name ION Audio, LLC Address 200 Scenic View Drive, Suite 201 Cumberland, RI 02864, U.S.A. Yours sincerely, Signatory Name Andy Wu Position Compliance PM Company Name ION Audio, LLC Address 200 Scenic View Drive, Suite 201 Cumberland, RI 02864, U.S.A. Tel / Fax +866-2-2717-2389 E-Mail [email protected]

DATE :2014-12-23 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AB3E-ISP51 Product Name: Wireless Speaker with Synchronized LED Party Lights Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: Exhibit Type Description ☒ Schematics All circuitry of devices and component values ☒ Block Diagrams Details of device showing the frequency of all oscillators ☒ Operational Description Description of the circuit functions These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Yours sincerely, Signatory Name Andy Wu Position Compliance PM Company Name ION Audio, LLC Address 200 Scenic View Drive, Suite 201 Cumberland, RI 02864, U.S.A. Tel / Fax +866-2-2717-2389 E-Mail [email protected]

东莞市东电检测技术有限公司 Dongguan Dongdian Testing Service Co.,Ltd Tel: 0769-22891499 http://www.dgddt.com IEIE Public Laboratory Page 1 of 1 RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Worse case is as below: [2480MHz, 0.75dBm (1.19mW) output power] (1.19/5) ·[√2.480(GHz)]= 0.375 <3.0 for 1-g SAR Then SAR evaluation is not required Jamy Yu 2014-12-25

Dongguan Dongdian Testing Service Co., Ltd Report No: DDT-REN140426 Page 1 of 81 FCC CERTIFICATION TEST REPORT FOR Issued By: Dongguan Dongdian Testing Service Co., Ltd. Add: No. 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808 Tel: +86-0769-22891499 Http://www.dgddt.com Applicant : Ion Audio, LLC Address : 200 SCENIC VIEW DRIVE, SUITE 201 CUMBERLAND, RI 02864, U.S.A. Equipment under Test : Wireless Speaker with Synchronized LED Party Lights Model No : Party Starter Trade Mark : ION FCC ID : 2AB3E-ISP51 Manufacturer : Ion Audio, LLC Address : 200 SCENIC VIEW DRIVE, SUITE 201 CUMBERLAND, RI 02864, U.S.A. Report No: DDT-REN140426 Issued Date: Dec. 23, 2014 Dongguan Dongdian Testing Service Co., Ltd Report No: DDT-REN140426 Page 2 of 81 TABLE OF CONTENTS Test report declares......................................................................................................................4 1. Summary of test results ............................................................................................................... 5 2. General test information .............................................................................................................. 6 2.1. Description of EUT ..................................................................................................................... 6 2.2. Accessories of EUT..................................................................................................................... 6 2.3. Assistant equipment used for test ................................................................................................ 6 2.4. Block diagram of EUT configuration for test ............................................................................. 6 2.5. Test environment conditions ....................................................................................................... 7 2.6. Test laboratory............................................................................................................................. 7 2.7. Measurement uncertainty ............................................................................................................ 7 3. Maximum Peak Output Power ....................................................................................................8 3.1. Test equipment ............................................................................................................................ 8 3.2. Block diagram of test setup ......................................................................................................... 8 3.3. Limits .......................................................................................................................................... 8 3.4. Test Procedure............................................................................................................................. 8 3.5. Test Result................................................................................................................................... 9 4. 20dB Bandwidth........................................................................................................................ 10 4.1. Test equipment .......................................................................................................................... 10 4.2. Block diagram of test setup ....................................................................................................... 10 4.3. Limits ........................................................................................................................................ 10 4.4. Test Procedure........................................................................................................................... 10 4.5. Test Result................................................................................................................................. 11 4.6. Original test data ....................................................................................................................... 11 5. Carrier Frequency Separation.................................................................................................... 15 5.1. Test equipment .......................................................................................................................... 15 5.2. Block diagram of test setup ....................................................................................................... 15 5.3. Limits ........................................................................................................................................ 15 5.4. Test Procedure........................................................................................................................... 15 5.5. Test Result................................................................................................................................. 15 5.6. Original test data ....................................................................................................................... 16 6. Number Of Hopping Channel ...................................................................................................17 6.1. Test equipment .......................................................................................................................... 17 6.2. Block diagram of test setup ....................................................................................................... 17 6.3. Limits ........................................................................................................................................ 17 6.4. Test Procedure........................................................................................................................... 17 6.5. Test Result................................................................................................................................. 17 Dongguan…

Text truncated - open the document above for the full version.
