SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 AAI TECHNOLOGY （HK）LIMITED 2014-12-26 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, __ AAI TECHNOLOGY （HK）LIMITED _hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product： tablet PC Trade Name： AAI,Supersonic,vital Model Name： SC-3007 Serial Model： Vital Mini 74A, AAI-27DAW, AAI-710QAW,AAI-716QM, AAI-760QR,AAI-708DAW,AAI-708DI,AAI-708QMI,AAI-706QMI, AAI-708QAW,AAI-708OAW, AAI-27QAW, AAI-716DAW, AAI-716DM, AAI-716DR ,AAI-716QR, AAI-708DM, AAI-708OM,AAI-708QI, AAI-708DR, AAI-716QR, AAI-708OR, AAI-708DAT, AAI-708QAT, AAI-708OAT,AAI-706QI, AAI-707QI, AAI-711LT FCC ID： 2AB6DAAI708QAW Sincerely, Signature Client’s name / title : lianfu zhu / manage Contact information / address : RM5,6/F SHING CHUEN IND. BLDG.,25-27 SHING WAN ROAD, TAI WAI, SHATIN,N.T.,HONG KONG.

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 AAI TECHNOLOGY (HK) LIMITED 2014-12-26 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AB6DAAI708QAW We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Signature Client’s name / title : lianfu zhu / manage Contact information / address : RM5,6/F SHING CHUEN IND. BLDG.,25-27 SHING WAN ROAD, TAI WAI, SHATIN,N.T.,HONG KONG.

AAI TECHNOLOGY (HK) LIMITED Model Difference FCC ID: 2AB6DAAI708QAW Model : SC-3007, Vital Mini 74A, AAI-27DAW, AAI-710QAW,AAI-716QM, AAI-760QR,AAI-708DAW,AAI-708DI,AAI-708QMI,AAI-706QMI, AAI-708QAW,AAI-708OAW, AAI-27QAW, AAI-716DAW, AAI-716DM, AAI-716DR ,AAI-716QR, AAI-708DM, AAI-708OM,AAI-708QI, AAI-708DR, AAI-716QR, AAI-708OR, AAI-708DAT, AAI-708QAT, AAI-708OAT,AAI-706QI, AAI-707QI, AAI-711LT All the model are the same circuit and RF module, except the model name and colour. Client’s signature Client’s name / title : lianfu zhu / Manager Contact info rmation / address : RM5,6/F SHING CHUEN IND. BLDG.,25-27 SHING WAN ROAD, TAI WAI, SHATIN,N.T.,HONG KONG.

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 ANT Photo 3 Photo 4 Photo 5 Photo 6 Photo 7

FCC Test Report FCC ID:2AB6DAAI708QAW Product： tablet PC Trade Name： AAI,Supersonic,vital Model Number： SC-3007 Serial Model： Vital Mini 74A, AAI-27DAW, AAI-710QAW, AAI-716QM, AAI-760QR,AAI-708DAW, AAI-708DI,AAI-708QMI,AAI-706QMI, AAI-708QAW,AAI-708OAW, AAI-27QAW, AAI-716DAW, AAI-716DM, AAI-716DR , AAI-716QR, AAI-708DM, AAI-708OM, AAI-708QI, AAI-708DR, AAI-716QR, AAI-708OR, AAI-708DAT, AAI-708QAT, AAI-708OAT,AAI-706QI, AAI-707QI, AAI-711LT Report No.： NTEK-2014NT12162298F2 Prepared for AAI TECHNOLOGY （HK）LIMITED RM5,6/F SHING CHUEN IND.BLDG.,25-27 SHING WAN ROAD, TAI WAI, SHATIN,N.T., HONG KONG. Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website: www.ntek.org.cn Page 2 of 23 Report No.: NTEK-2014NT12162298F2 TEST RESULT CERTIFICATION Applicant’s name ................. : AAI TECHNOLOGY （HK）LIMITED Address ................................. : RM5,6/F SHING CHUEN IND.BLDG.,25-27 SHING WAN ROAD, TAI WAI, SHATIN,N.T., HONG KONG. Manufacturer's Name .......... : AAI Technology （HuiZhou） Co., LTD. Address ................................. : AAI Technology HuiZhou industrial Park，longhai 3 rd Road, Xiangshui River, Dayawan E & T Development Zone, Huizhou Product description Product name ........................... : tablet PC Model and/or type reference : SC-3007 Standards ............................. : FCC Part15B:01 Oct.2014 ANSI C63.4:2003 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with Part 15 of FCC Rules. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test ............................................ : Date (s) of performance of tests ............. : 16 Dec. 2014 ~23 Dec. 2014 Date of Issue ........................................... : 23 Dec. 2014 Test Result ............................................... : Pass Testing Engineer : (Kyle Xu) Technical Manager : (Brown Lu) Authorized Signatory : (Bill Yao) Page 3 of 23 Report No.: NTEK-2014NT12162298F2 Table of Contents Page 1 . TEST SUMMARY 4 1.1 TEST FACILITY 5 1.2 MEASUREMENT UNCERTAINTY 5 2 . GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 DESCRIPTION OF TEST SETUP 8 2.3 DESCRIPTION TEST PERIPHERAL AND EUT PERIPHERAL 9 2.4 MEASUREMENT INSTRUMENTS LIST 10 3 . EMC EMISSION TEST 11 3.1 CONDUCTED EMISSION MEASUREMENT 11 3.1.1 POWER LINE CONDUCTED EMISSION 11 3.1.2 TEST PROCEDURE 12 3.1.3 TEST SETUP 12 3.1.4 EUT OPERATING CONDITIONS 12 3.1.5 TEST RESULTS 13 3.2 RADIATED EMISSION MEASUREMENT 15 3.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT 15 3.2.2 TEST PROCEDURE 15 3.2.3 TEST SETUP 16 3.2.4 EUT OPERATING CONDITIONS 17 3.2.5 TEST RESULTS 18 3.2.6 TEST RESULTS(1000~12400MHz) 21 4 . EUT TEST PHOTO 22 Page 4 of 23 Report No.: NTEK-2014NT12162298F2 1. TEST SUMMARY Test procedures according to the technical standards: EMC Emission Standard Test Item Limit Judgment Remark FCC Part15B:2014 ANSI C63.4: 2003 Conducted Emission Class B PASS Radiated Emission Class B PASS NOTE: (1) ’N/A’ denotes test is not applicable in this Test Report (2) For client’s request and manual description, the test will not be executed. Page 5 of 23 Report No.: NTEK-2014NT12162298F2 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration Number:238937; IC Registration Number:9270A-1 CNAS Registration Number:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %. A. Conducted Measurement : Test Site Method Measurement Frequency Range U，(dB) NOTE NTEKC01 ANSI150 KHz ~ 30MHz 3.2 B. Radiated Measurement : Test Site Method Measurement Frequency Range U，(dB) NOTE NTEKA01 ANSI30MHz ~ 1000MHz 4.7 1GHz ~12.4GHz 5.0 Page 6 of 23 Report No.: NTEK-2014NT12162298F2 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment tablet PC Model Name SC-3007 Additional Model Number(s) Vital Mini 74A, AAI-27DAW, AAI-710QAW, AAI-716QM, AAI-760QR,AAI-708DAW, AAI-708DI,AAI-708QMI,AAI-706QMI, AAI-708QAW,AAI-708OAW, AAI-27QAW, AAI-716DAW, AAI-716DM, AAI-716DR , AAI-716QR, AAI-708DM, AAI-708OM, AAI-708QI, AAI-708DR, AAI-716QR, AAI-708OR, AAI-708DAT, AAI-708QAT, AAI-708OAT,AAI-706QI, AAI-707QI, AAI-711LT Model Difference All the model are the same circuit and RF module, except the model name and colour. Product Description The EUT is a tablet PC. Connecting I/O port:USB Operation Frequency: WIFI: 802.11b/g/n(20MHz): 2412~2462MHz 802.11n(40MHz):2422~2452MHz Modulation Type: WIFI: CCK/OFDM/DBPSK/DAPSK Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specification, please refer to the User's Manual. Power Source DC Voltage Adapter Model:WRP2U-050200U Input: 100-240V~,50/60 Hz,0.4A Max Output: 5V , 2A Battery DC 3.7V ,2250mAh Page 7 of 23 Report No.: NTEK-2014NT12162298F2 2.1.1 DESCRIPTION OF TEST MODES To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mode or test configuration mode which possible have effect on EMI emission level. Each of these EUT operation mode(s) or test configuration mode(s) mentioned above was evaluated respectively. Pretest Mode Description Mode 1 Data Exchange Mode 2 Playing+chagring Mode 3 REC Mode For Conducted Test Final Test Mode Description…
