2AB6Z-1859ATMBAndroid player Main board with wireless module

User Manual For Android player Main board with wireless module This user manual pertains to Android player Main board with Wireless module. The Main board can be assembled in the Android based Advertising Media Player and Android based Advertising Set-Top-Box listes as below; 00RGHO00RGHO'HVFULSWLRQ '7$6$QGURLGQRQWRXFK/&'0HGLD3OD\HU '7$&$QGURLGWRXFK/&'0HGLD3OD\HU '7$6$QGURLGQRQWRXFK/&'0HGLD3OD\HU '7$&$QGURLGWRXFK/&'0HGLD3OD\HU '7$6$QGURLGQRQWRXFK/&'0HGLD3OD\HU '7$&$QGURLGWRXFK/&'0HGLD3OD\HU '7$6$QGURLGQRQWRXFK/&'0HGLD3OD\HU '7$&$QGURLGWRXFK/&'0HGLD3OD\HU '7$6$QGURLGQRQWRXFK/&'0HGLD3OD\HU '7$&$QGURLGWRXFK/&'0HGLD3OD\HU '7$6$QGURLGQRQWRXFK/&'0HGLD3OD\HU '7$&$QGURLGWRXFK/&'0HGLD3OD\HU ,Q9LVLRQ$,QYLVLRQ$QGURLG$GYHUWLVLQJ6HW7RS%R[ 1. Specifications: PCBA dimension: 87.5 X 143mm Assemble method: the module will be screwed on the housing and used as a Main board for Android based Advertising Media Player and Android based Advertising Set-Top-Box Input port: 1pc 5.5mm female barrel jack - for +12V power input 1pc DTCN-A-15F – 15-pin female connector for additional control PCBA connection 1pc SD Card Slot - for SD 1pcs I2C interface for resistive/ capacitive touch screen Output port: 1group of connector for LCD Screen of the Media Player, 1200 x 800 resolution or greater 2pcs Antenna connector for 2.4G + 5G WiFi network 1pc 3.5mm headphone jack - for 85mW audio 2pcs DTCN-A-2F - 2-pin female connector for SP1-SP2 Other ports: 2pcs Antenna connector for 2.4G + 5G WiFi network seperately 1pc DTCN-A-4F - 4-pin female connector for UART connection 1pc RJ45 jack - for hardwired network compatibility 1pc mini USB receptacle 2pcs USB-A standard USB receptacle Antennas: Removable antennas with 2.5dBi gain. Provided by Lian Chuang Xin (Shenzhen) Ltd, Co. P/N: ANT-1569SMA20-00-A Operation temperature:-10ć ć-60ć Voltage(AC /60Hz):102-138V/ AC Frequency Stability: +/-3.2 ppm FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. The modular can be installed or integrated in mobile or fix devices only. This modular cannot be installed in any portable device, for example, USB dongle like transmitters is forbidden. This modular complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This modular must be installed and operated with a minimum distance of 20 cm between the radiator and user body. The device is indoor use only. If the FCC identification number is not visible when the module is installed inside another device, then the Operation temperature:-20ćto +50ć External omni direction antenna reversed polarity non standard antenna portwith 2.5dBi gain. Provided by Lian Chuang Xin (Shenzhen) Ltd, Co. P/N:ANT-1569SMA20-00-A outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: 2AB6Z-1859ATMB Or Contains FCC ID: 2AB6Z-1859ATMBā when the module is installed inside another device, the user manual of this device must contain below warning statements; 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. The device is indoor use only The devices must be installed and used in strict accordance with the manufacturer's instructions as described in the user documentation that comes with the product Any company of the host device which install this modular with limit modular approval should perform the test of radiated emission and spurious emission according to FCC part 15C 15.247 and 15.209 requirement Only if the test result comply with FCC part 15C 15.247 and 15.209 requirementthen the host can be sold legally. Any company of the host device which install this modular with limit modular approval should perform the test of radiated emission and spuri…

Text truncated - open the document above for the full version.

(8) The module must comply with RF exposure requirements Answer ˖Yes ˗ Transmitter meets MPE calculation of 47 CFR 1.1307 . Refer to MPE Reports and Refer to modular installation manual Declaration of LMA The user manual of the modular have described that “The modular can be installed or integrated in mobile or fix devices only. This modular cannot be installed in any portable device, for example, USB dongle like transmitters is forbidden. This modular complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This modular must be installed and operated with a minimum distance of 20 cm between the radiator and user body.”and “The devices must be installed and used in strict accordance with the manufacturer's instructions as described in the user documentation that comes with the product” We, HUNG WAI PRODUCTS LIMITED STATE that full compliance of the end product is always ensured if end product install and use the modular in strict accordance with the modular manufacturer's instructions as described in the user documentation that comes with the modular. The user manual of the modular have described that “The modular can be installed or integrated in mobile or fix devices only. This modular cannot be installed in any portable device, for example, USB dongle like transmitters is forbidden. This modular complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This modular must be installed and operated with a minimum distance of 20 cm between the radiator and user body.The device is indoor use only”and “The devices must be installed and used in strict accordance with the manufacturer's instructions as described in the user documentation that comes with the product” We, HUNG WAI PRODUCTS LIMITED STATE that full compliance of the end product is always ensured if end product install and use the modular in strict accordance with the modular manufacturer's instructions as described in the user documentation that comes with the modular.

Answer ˖Yes ˗ Device is equipped with external antenna (with reversed polarity unique antenna port) . Answer ˖ Yes ˈdistance between modular and all AEs are longer than 10cm ˈrefer to setup photo. (8) The module must comply with RF exposure requirements Answer ˖Yes ˗ Transmitter meets MPE calculation of 47 CFR 1.1307 . Refer to MPE Reports and Refer to modular installation manual

HUNG WAI PRODUCTS LIMITED FCC Statement DATE : 2015-7-27 FCC ID: 2AB6Z-1859ATMB __ Product Name: Android player Main board with wireless module We declare that the USB connector of the device only used for upgrading softwareˈcan’t communite date with PC Signature˖ Name/Title: Qinhong Liao/Manager Tel. No.: (852)90907758 Fax No.: (852)90907758 Company Name: HUNG WAI PRODUCTS LIMITED Date :2015-07-27 We declare that the USB connector of the device only used for upgrading softwareˈcan’ communite date with PC when normal working.

The information within this section of the Operational Description is to show compliance against the Software Security Requirements laid out within ASSY-1859ATMBA-00 U-NII Security. The information below describes how we maintain the overall security measures and systems so that only: 1. Authenticated software is loaded and operating on the device 2. The device is not easily modified to operate with RF parameters outside of the authorization General Description 1. Describe how any software/firmware update will be obtained, downloaded, and installed. Software that is accessed through manufacturer’s website or device’s management system, must describe the different levels of security. User can download the new FW and the update tool from official WEB page . 2. Describe all the radio frequency parameters that are modified by any software/firmware without any hardware changes. Are these parameters in some way limited, such that, it will not exceed the authorized parameters? All the parameter limitations are hard-coded into special permanent memory space to not exceed the authorized limits. Professional installer has no access to change radio parameter limits. 3. Describe in detail the authentication protocols that are in place to ensure that the source of the software/firmware is legitimate. Describe in detail how the software is protected against modification Yes. Platform goes through a secure boot process every time it is powered. System verifies the root of trust to verify all the software components are signed with right set of keys 4. Describe in detail the verification protocols in place to ensure that installed software/firmware is legitimate Yes, System Control Unit the software which runs first when the device boots up verifies all the software components are signed with the right keys. If the component is signed with a wrong key or altered, system will not boot. 5. Describe in detail any encryption methods used to supp ort the use of legitimate software/firmware. Header of each firmware component is encrypted with an RSA private key 6. For a device that can be configured as a master and client (with active or passive scanning), explain how the device ensures compliance for each mode? In particular if the device acts as master in some band of operation and client in another; how is compliance ensured in each band of operation? Since the software can work in both modes (Master and Client) software was developed to update limitations, during configuration, instantly to meet compliance in any operating mode. Only authorized operating bands are allowed to configure by the professional installer. 3rd Party Access Control 1. Explain if any third parties have the capability to operate a US sold device on any other regulatory domain, frequencies, or in any manner that is in violation of the certification. Not aware of any such method/ capabilities today for 3rd parties 2. What prevents third parties from loading non -US versions of the software/firmware on the device? Describe in detail how the device is protected from “flashing” and the No prevention present today to load non-U.S. version of software/firmware on a U.S. version of the same device For FCC ID: 2AB6Z-1859ATMB installation of third-party firmware 3. For Certified Transmitter modular devices, describe how the module grantee ensures that hosts manufactures fully comply with these software security requirements for U -NII devices. If the module is controlled through driver software loaded in the host, describe how the drivers are controlled and managed such that the modular transmitter parameters are not modified outside the grant of authorization Certified transmitter modules have sufficient level of security to ensure that when integrated into a permissible host the device parameters are not modified outside those approved in the grant of authorization. This requirement includes any driver software that may be installed in the host, as well as, any third party software that may be permitted to control the module. A full description of the process for managing this should be included in the filing. SOFTWARE CONFIGURATION DESCRIPTION GUIDE ?USER CONFIGURATION GUIDE 1. To whom is the UI accessible? (Professional installer, end user, other.) Professional installer a. What parameters are viewable to the professional installer/end-user? “Settings” menus offered by Android OS and other Software Applications. It includes selection of available WiFi networks and related passwords. b. What parameters are accessible or modifiable by the professional installer? None i) Are the parameters in some way limited, so that the installers will not enter parameters that exceed those authorized? Parameters for settings in “Settings” menu are controlled/ checked by Android OS and SW Apps ii) What controls exist that the user can not operate the device outside its authorization in the U.S.? WLAN driver follows IEEE 802.11d standard protocols, the country code settings are automatically configured according to the AP or Network. c. What parameters are accessible or modifiable to by the end-user? “Settings” menus offered by Android OS and other Software Applications. It includes selection of available WiFi networks and related passwords i) Are the parameters in some way limited, so that the installers will not enter parameters that exceed those authorized? Parameters for settings in “Settings” menu are controlled/ checked by Android OS and SW Apps ii) What controls exist that the user cannot operate the device outside its authorization in the U.S.? The end user has no access to parameter settings. The device automatically adjusts to the appropriate authorized bands for each country managed by the AP or Network infrastructure based on IEEE 802.11d standard protocols. d. Is the country code factory set? Can it be changed in the UI? The country code is set in the initial OS setup, once the user chooses the country of preference there is no way to change th…

Text truncated - open the document above for the full version.

Report No: CCIS15060045601 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150600456RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 64 of 67 8 EUT Constructional Details Report No: CCIS15060045601 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150600456RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 65 of 67 Report No: CCIS15060045601 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150600456RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 66 of 67 Report No: CCIS15060045601 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS150600456RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 67 of 67 ------End of report------ Label and label location Label label location Label location

Label and label location Label label location Label location

3 7 . 5 0 m m 74.00 mm FCC ID: 2AB6Z-1859ATMB

Prediction of MPE at a given distance 1. Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Frequency range (MHz) Electric field strength (V/m rms) Magnetic field strength (A/m rms) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3-3.0 614 1.63 *(100) 6 3.0-30 1842/f 4.89/f *(900/f2) 6 30-300 61.4 0.163 1.0 6 300-1500 f/300 6 1500-100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3 –1.34 614 1.63 *(100) 30 1.34 –30 824/f 2.19/f *(180/f 2 ) 30 30-300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1 30 2. Test Procedure Equation from page 18 of OET Bulletin 65, Edition 97-01 Where: S = power density P = power input to the antenna G = numeric gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the centre of radiation of the antenna 3. Result for Transmitters used in mobile exposure conditions for standalone operations Frequency (MHz) Maximum Output power (dBm) Maximum Output power (mW) Antenna Gain (dBi) Antenna Gain (numeric) Distance (cm) Result (mW/cm 2 ) Limits for General Population/ Uncontrolled Exposure (mW/cm 2 ) BLE (worse case) 2480 -4.10 0.39 2.5 1.78 20.00 0.000138 1 Bluetooth (worse case) 2441 -2.33 0.58 2.5 1.78 20.00 0.000205 1 2.4 GHz WIFI (worse case) 2462 13.74 23.66 2.5 1.78 20.00 0.00838 1 5.8 GHz WIFI (worse case) 5825 10.82 12.08 2.5 1.78 20.00 0.00428 1 4. Results for Transmitters used in mobile exposure conditions for simultaneous transmission operations According to KDB 447498 D01v05r02 section 7.2, simultaneous transmission MPE test exclusion applies when the sum of the MPE ratios for all simultaneous transmitting antennas incorporated in a host device, based on the calculated/estimated, numerically modeled or measured field strengths or power density, is ≤ 1.0. The MPE ratio of each antenna is determined at the minimum test separation distance required by the operating configurations and exposure conditions of the host device, according to the ratio of field strengths or power density to MPE limit, at the test frequency. MPE Ratios (MPE/MPE Limit) BLE Bluetooth 2.4GHz WiFi 5.8GHz WiFi 0.000138 0.000205 0.00838 0.00428 For this device, 2.4GHz WiFi, Bluetooth and BLE share the same antenna, and so, they cannot simultaneous transmission with each other. And 2.4GHz WiFi cannot simultaneous transmission with 5.8GHz WiFi. The simultaneous transmission combinations see below table. Simultaneous Transmission Consideration Combinations ƩƩMPE ratios Limit 5.8GHz WiFi + BLE 0.004418 ≤ 1.0 5.8GHz WiFi + Bluetooth 0.004485 So, Simultaneous transmission MPE is exclusion. Worse case ˖ 0.00838+0.00428=0.013<1
