2AB6Z-WL0239300Mbps Wireless N Dual Band USB Adapter

Put into the CD Double-click the CD drive letter, choose the corresponding model No., then click “Install”. Click “Next”. Wait for a few seconds. Choose one language and click “Next” The installation will take a few seconds. We recommend you choose “Yes...”to restart your computer now.Click “Finish”, the driver program is installed successfully. Switch wireless LAN Adapter configuration program Wireless LAN adapter provides two wireless LAN adapter connection configuration programs, one is TOTOLINK wireless LAN adapter connection configuration program, another is Windows wireless LAN adapter connection configuration program. Instruction of Install LAN Adapter Driver LAN Adapter Physical Connection Diagram LAN Adapter Windows Search Connection WEP Encryption Network Diagram LAN Adapter Windows Search Connection No Encryption Network Diagram Right-click “My Network Places”, and choose “Properties” Right-click “Wireless Network Connection”, choose “View available wireless connection” Confirm the SSID name of wireless network, choose the wireless network which you would like to connect and click “Connect” When the wireless network is connected, then you can access Internet. Right-click “My Network Places”, and choose “Properties” Right-click “Wireless Network Connection”, choose “View available wireless connection” Confirm the SSID name of wireless network, choose the wireless network which you would like to connect and click “Connect” When the wireless network is connected, then you can access Internet. Input WEP secret key, click “Connect” Note Computer found the wireless LAN adapter hardware, have to install the driver. Website: http://www.totolink.net Method One: Connect the adapter and your computer with the provided USB cable. Method Two: Insert the adapter to the USB port of your computer directly. Thanks very much for purchasing TOTOLINK Wireless LAN USB Adapter. Before you connect this adapter to computer, you must prepare a wireless router or AP to make it work. Different Wireless router or AP may use different connection mode. Quick Installation Guide 300Mbps Wireless N Dual Band USB Adapter Model: WL0239 N500UM N500UM TOTOLINK Choose the wireless network which you would like to connect and click “Connect” Input WPAPSK secret key, click “Connet” Have connected the wireless network. Windows 7/Vista Connection Network Diagram LAN Adapter Windows Search Connection WPAPSK Encryption Network Diagram Right-click “My Network Places”, and choose “Properties” Right-click “Wireless Network Connection”, choose “View available wireless connection” Right-click “Network”,choose “Properties”. Click “Connect to a network”. Win 7/Vista PCTOTOLINK TOTOLINK TOTOLINK TOTO LINK TOTOLINK Connect to No Encrytion Network Connect to Encrytion Network (WEP / WPAPSK) Finish Finish TOTOLINK LAN Adapter Configuration Tool Search Connection Network Diagram Click this icon, the wireless configuration connection window will pop out. TOTOLINK TOTOLINK Type in the encryption key to the marked area. Wireless network is connected. Choose the wireless network which you would like to connect, and then click “Connect”. Connect Wireless Network Steps Wireless network is connected. Choose one SSID and enter the encryption key to connect. By default, 2.4G+5G is selected. please click “Advanced” to change it to 2.4G. How to use 2.4G band to connect WLAN Wireless network is connected. Choose one SSID and enter the encryption key to connect. Back to Advanced page, change the Wireless mode to 5G. How to use 5G band to connect WLAN Note Before you go on with this step, you must know the SSID and the key your Router or AP has been set. FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement This device complies with FCC radiation exposure limits set forth for an uncontrolled environment and it also complies with Part 15 of the FCC RF Rules. This equipment must be installed and operated in accordance with provided instructions and the antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provide with antenna installation instructions and consider removing the no-collocation statement. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Caution! Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

Project No.: 1408C228 Page 2 of 7 Project No.: 1408C228 Page 3 of 7 Project No.: 1408C228 Page 4 of 7

Trade Name: HUNG WAI Model Name: WL0239 FCC ID: 2AB6Z-WL0239 Product Name: 300Mbps Wireless N Dual Band USB Adapter 40*15mm

Project No.: 1408C228 Page 5 of 7 Project No.: 1408C228 Page 6 of 7 Project No.: 1408C228 Page 7 of 7

FCC RF EXPOSURE REPORT FCC ID: 2AB6Z-WL0239 Project No. Equipment : 1408C228 300Mbps Wireless N Dual Band USB Adapter Model : WL0239 Applicant : HUNG WAI PRODUCTS LIMITED Address : Unit 11, 12/F., New Commerce Centre, 19 On Sum Street, Shatin, Hong Kong According: : FCC Guidelines for Human Exposure IEEE C95.1 BTL INC. No.3, Jinshagang 1st Road, Shixia, Dalang Town, Dongguan, China. TEL: +86-769-8318-3000 FAX: +86-769-8319-6000 Table for Filed Antenna 2.4G Ant. Manufacturer Model NameAntenna TypeConnector Gain(dBi) 1 N/A N/A printed N/A 3.60 2 N/A N/A printed N/A 2.50 5G Ant. Manufacturer Model NameAntenna TypeConnector Gain(dBi) 1 N/A N/A printed N/A 3.20 2 N/A N/A printed N/A 2.10 GENERAL CONCULUSION: Maximum measured transmitter power: OutputPower (dBm) Output Power (mW) Limit (mW) 9.81 9.6 10 According to FCC KDB447498 D01 General RF Exposure Guidance v05r02, Appendix A, SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm The maximum measured output peak power of this EUT is 9.6mW, less than 10mW at 5mm distance. Conclusion: No SAR evaluation required since transmitter power is below FCC threshold

Report No.: BTL-FCCP-2-1408C228 Page 1 of 175 FCC Radio Test Report FCC ID:2AB6Z-WL0239 This report concerns (check one): Original Grant Class II Change Project No. : 1408C228 Equipment : 300Mbps Wireless N Dual Band USB Adapter Model Name : WL0239 Applicant : HUNG WAI PRODUCTS LIMITED Address : Unit 11, 12/F., New Commerce Centre, 19 On Sum Street, Shatin, Hong Kong Date of Receipt : Aug. 27, 2014 Date of Test : Aug. 27, 2014 ~ Sep. 05, 2014 Issued Date : Sep. 10, 2014 Tested by : BTL Inc. Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory : (Steven Lu) BTL INC. No.3, Jinshagang 1st Road, Shixia, Dalang Town, Dongguan, Guangdong, China. TEL: +86-769-8318-3000 FAX: +86-769-8319-6000 Report No.: BTL-FCCP-2-1408C228 Page 2 of 175 Declaration BTLrepresents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C., or National Institute of Standards and Technology (NIST) of U.S.A. BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTLshall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTLissued reports. BTL’s reports must not be used by the client to claim product endorsement by the authorities or an y agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and BTL-self, extracts from the test report shall not be reproduced except in full with BTL’s authorized written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Report No.: BTL-FCCP-2-1408C228 Page 3 of 175 Table of Contents Page 1 . CERTIFICATION 6 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 3 . GENERAL INFORMATION 9 3.1 GENERAL DESCRIPTION OF EUT 9 3.2 DESCRIPTION OF TEST MODES 11 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 12 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 13 3.5 DESCRIPTION OF SUPPORT UNITS 13 4 . EMC EMISSION TEST 14 4.1 CONDUCTED EMISSION MEASUREMENT 14 4.1.1 POWER LINE CONDUCTED EMISSION 14 4.1.2 TEST PROCEDURE 14 4.1.3 DEVIATION FROM TEST STANDARD 14 4.1.4 TEST SETUP 15 4.1.5 EUT OPERATING CONDITIONS 15 4.1.6 EUT TEST CONDITIONS 15 4.1.7 TEST RESULTS 15 4.2 RADIATED EMISSION MEASUREMENT 16 4.2.1 RADIATED EMISSION LIMITS 16 4.2.2 TEST PROCEDURE 17 4.2.3 DEVIATION FROM TEST STANDARD 17 4.2.4 TEST SETUP 17 4.2.5 EUT OPERATING CONDITIONS 18 4.2.6 EUT TEST CONDITIONS 18 4.2.7 TEST RESULTS (9K TO 30MHz) 19 4.2.8 TEST RESULTS (BETWEEN 30 TO 1000 MHz) 19 4.2.9 TEST RESULTS (ABOVE 1000 MHz) 19 5 . 26dB SPECTRUM BANDWIDTH 20 5.1 APPLIED PROCEDURES / LIMIT 20 5.1.1 TEST PROCEDURE 20 5.1.2 DEVIATION FROM STANDARD 20 5.1.3 TEST SETUP 20 5.1.4 EUT OPERATION CONDITIONS 20 5.1.5 EUT TEST CONDITIONS 20 5.1.6 TEST RESULTS 20 6 . MAXIMUM CONDUCTED OUTPUT POWER 21 Report No.: BTL-FCCP-2-1408C228 Page 4 of 175 Table of Contents Page 6.1 APPLIED PROCEDURES / LIMIT 21 6.1.1 TEST PROCEDURE 21 6.1.2 DEVIATION FROM STANDARD 22 6.1.3 TEST SETUP 22 6.1.4 EUT OPERATION CONDITIONS 22 6.1.5 EUT TEST CONDITIONS 22 6.1.6 TEST RESULTS 22 7 . ANTENNA CONDUCTED SPURIOUS EMISSION 23 7.1 APPLIED PROCEDURES / LIMIT 23 7.1.1 TEST PROCEDURE 23 7.1.2 DEVIATION FROM STANDARD 23 7.1.3 TEST SETUP 23 7.1.4 EUT OPERATION CONDITIONS 23 7.1.5 EUT TEST CONDITIONS 23 7.1.6 TEST RESULTS 23 8 . POWER SPECTRAL DENSITY TEST 24 8.1 APPLIED PROCEDURES / LIMIT 24 8.1.1 TEST PROCEDURE 24 8.1.1 DEVIATION FROM STANDARD 24 8.1.2 TEST SETUP 24 8.1.3 EUT OPERATION CONDITIONS 24 8.1.4 EUT TEST CONDITIONS 25 8.1.5 TEST RESULTS 25 9 . FREQUENCY STABILITY MEASUREMENT 26 9.1 APPLIED PROCEDURES / LIMIT 26 9.1.1 TEST PROCEDURE 26 9.1.2 DEVIATION FROM STANDARD 26 9.1.3 TEST SETUP 27 9.1.4 EUT OPERATION CONDITIONS 27 9.1.5 EUT TEST CONDITIONS 27 9.1.6 TEST RESULTS 27 10 . MEASUREMENT INSTRUMENTS LIST 28 11 . EUT TEST PHOTO 30 ATTACHMENT A - CONDUCTED EMISSION 34 ATTACHMENT B - RADIATED EMISSION (9KHZ TO 30MHZ) 37 ATTACHMENT C - RADIATED EMISSION (30MHZ TO 1000MHZ) 39 ATTACHMENT D - RADIATED EMISSION (ABOVE 1000MHZ) 52 ATTACHMENT E - BANDWIDTH 117 Report No.: BTL-FCCP-2-1408C228 Page 5 of 175 Table of Contents Page ATTACHMENT F - MAXIMUM OUTPUT POWER 130 ATTACHMENT G - ANTENNA CONDUCTED SPURIOUS EMISSION 137 ATTACHMENT H - POWER SPECTRAL DENSITY 148 ATTACHMENT I - FREQUENCY STABILITY 173 REPORT ISSUED HISTORY Issued No. Description Issued Date BTL-FCCP-2- 1408C228 Original Issue. Sep. 10, 2014 Report No.: BTL-FCCP-2-1408C228 Page 6 of 175 1. CERTIFICATION Equipment : 300Mbps Wireless N Dual Band USB Adapter Brand Name : HUNG WAI Model Name : WL0239 Applicant : HUNG WAI PRODUCTS LIMITED Manufacturer : ZIONCOM ELECTRONICS (SHENZHEN) LTD. Address : Building A1~A2, Lantian Science and Technology Park, Xinyu Road Xinqiao Henggang Block Shajing Street, Baoan District, Shenzhen City, China Factory : ZIONCOM ELECTRONICS (SHENZHEN) LTD. Address : Building A1~A2, Lantian Science and Technology Park, Xinyu Road Xinqiao Henggang Block Shajing Street, Baoan District, Shenzhen City, China Date of Test : Aug. 27, 2014 ~ Sep. 05, 2014 Test Sample : ENGINEERING SAMPLE Standard(s) : FCC Part15, Subpart E(15.407) / ANSI C63.4: 2009 FCC KDB 789033 D02 General UNII Test Procedures New Rules v01. The above equipment has been tested and found compliance with the requirement of the relative st…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-1-1408C228 Page 26 of 147 10. EUT TEST PHOTO Conducted Measurement Photos Report No.: BTL-FCCP-1-1408C228 Page 27 of 147 Radiated Measurement Photos 9KHz to 30MHz Report No.: BTL-FCCP-1-1408C228 Page 28 of 147 Radiated Measurement Photos 30MHz to 1000MHz Report No.: BTL-FCCP-1-1408C228 Page 29 of 147 Radiated Measurement Photos Above 1000MHz
