Bluetooth Calling Smart Watch 2206 User Manual Introduction 2206 is a smart health watch which can monitor multiple body vital signs under many different activity modes. Note: the watch is not a medical device. The test results and suggestions are for reference only. 24/7 Heart Rate Monitor Music Control SpO2 Blood Pressure HRV Stress Temperature Bluetooth Calling Multi-Sport Mode SOS Call & SMS Sleep Tracking Find Phone Waterproof IP68 Activity Tracking What’s Included in the Box (1) Watch with detachable band (2) Magnetic USB charger (3) User manual (4) Gift box Magnetic USB Charger Home Button Heart Rate Sensor Temperature Sensor SpO2 Sensor 1. Download the APP · Scan the QR code below or search JCLife on Google Play or iOS App Store to download our JCHealth App. · Make sure the Bluetooth of your mobile device is on. · Choose device identified in App and connect to your smart watch device. +$MJGF Note: Please ensure that your Android version is 4.3 or later, iOS version is 9.0 or later. The watch supports Bluetooth 5.1 connection. Magnetic Charging Pins Low Battery Charging 2. Charge the Battery Your device is powered by a rechargeable battery. If the battery is less than 5%, the low battery icon will appear to remind you to charge the device. Please use the magnetic USB charger to recharge the device. The display will light on for 10 seconds during charging, then turns off automatically. It takes about 1.5 hours to be fully charged. Note: 1. Please prevent the USB charger port from coming into contact with conductive materials, such as liquids, dust, metal powders and pencil leads. 2. The other functions except time doesn’t working during charge. If you want to play the watch, please stop charging first. ?øĪĄøĪÂĈ Ąê©Č·ԩĈÏ 3. Activate and Bind the Device 3.1 When out of the factory, the watch is set into hibernation mode to save the battery. Before use, please charge to activate your watch. After activation, the watch will start charging. Please use your watch only after it is fully charged. 3.2 After the device is activated, you can use the “JClife” APP to scan the QR code on the watch screen to bind. Or use the “JClife” APP to scan the device ID to bind. Moreover, you can press the skip button to enter the watch homepage. For subsequent use, you can scan the device ID in the APP to bind, or find the QR code in the watch About interface, and use the APP to scan the QR code to bind. 4. Basic Operation Swipe up: Quick setting, can set time format, silent mode, brightness level, lift wrist, music control, find phone, checking battery level, etc. Swipe down: Different social notifications. Swipe left: Check detailed daily activity and sleep reports, to start different Multi-sports mode. Swipe right: Check detailed operation for different functions, e.g. real-time Heart Rate Monitor, SpO2 MonitorHRV/Stress/ Blood Pressure Monitor, and more function settings. Home button: Return to the main screen, or return to the previous screen by pressing the button. Swipe right from home screen to find the Heart Rate icon. The device will automatically start heart rate monitoring. Please wear tightly for accurate heart rate monitoring, otherwise the device will gently vibrate to remind you to wear tightly. 5. Function Operation 5.2 Heart Rate Monitor Swipe left from home screen to find the Bluetooth Calling screen. Owing to its powerful inbuilt speaker and microphone, you can directly make & receive phone calls directly from your watch, anywhere and anytime. 5.1 Bluetooth Calling Swipe right from home screen to find the Vitals icon. Tap it to measure blood pressure, HRV and stress level. Please keep still while measuring. After the measurement, you can slide to check the report. Swipe right from home screen to find the SpO2 icon. Tap to start SpO2 monitoring. Please wear tightly for accurate SpO2 monitoring, otherwise the device will gently vibrate to remind you to wear tightly. Please keep still while measuring. 5.3 SpO2 Monitor 3 During the measurement, keep the screen facing up and your body still. The SpO2 measurement will be paused if you move your arm and the screen will show “Don’t Move”. Please always keep still to get accurate measurement. Each measu- rement lasts for about 1 minute, and the displayed SpO2 is updated every second. 09:30AM SpO2 5.4 How to measure blood oxygen level (SpO2), HR and other vital signs correctly? 1 For better accuracy, do keep your arm still, fasten the strap tightly, and make sure the screen is facing up. Please make sure the watch is worn on the correct position of the wrist, which is at least one-index-finger-width away from the carpal bone. 2 If you are not wearing your band, or wearing it incorrectly, an error message will be displayed. Please read the onscreen instructions for how to wear it correctly and touch Retry to restart the measurement. 4 The SpO2 measurement will be interrupted while receivinga notification for an incoming call or alarm. 5 Make sure the sensor area on the back of the watch is clean, dry and free from foreign objects. 6 In case in low temperature environment (such as high altitude, winter and other low temperature scenes), please take off the watch, try to rub the wrist to stimulate blood circulation, and then wear the watch again for measurement. 7 Thick hair, tattoos might affect the measurement of SpO2/Vital Signs, please try to avoid wearing the watch on those areas. 8 In order to make the measurement more accurate, it is recommended that you wear it for 3-5min before measuring SpO2/Vital Signs. 9 The watch supports oxygen saturation measurements in the range of 70% to 100%. Swipe left from home screen to find the Exercise icon, slide down to find Relaxation icon. Tap to start breath training. 5.6 Breath Training Wear on wrist to get 24H real-time temperature monitoring: wear the smart watch normally and keep the back pressed against your wrist. It can automatically measure your 24H real-time wrist …
