2AB7I-FEEDER01Remote Control Animal Feeder/Trainer

1 PET TUTOR USER MANUAL 2 Smart Animal Training Systems, LLC 133 W Market St. Suite 360 Indianapolis IN 46204-2801 www.SmartAnimalTraining.com Copyright © 2014 Smart Animal Training Systems LLC All rights reserved. Pet Tutor User Manual April 2014 3 CONTENTS COMPANY STATEMENTS ............................................................................................................................................................ 5 VISION ................................................................................................................................................................................................................. 5 MISSION .............................................................................................................................................................................................................. 5 VALUES ............................................................................................................................................................................................................... 5 HOW THE PET TUTOR WORKS ............................................................................................................................................ 6 WHAT’S IN THE BOX? .................................................................................................................................................................. 7 THE FEEDER ...................................................................................................................................................................................................... 8 About the Buttons on the Feeder .................................................................................................................................................... 10 The Pet Tutor pre-programmed factory settings ............................................................................................................... 11 THE REMOTE: ................................................................................................................................................................................................. 12 The Remote Functions: ................................................................................................................................................................................. 14 (Button actions: Quick press=1 beep, hold=2 beeps, long hold=3 beeps) ............................................................................. 14 Remote Buttons Quick Reference ..................................................................................................................................................... 16 THE FLOOR BASE:.......................................................................................................................................................................................... 18 THE UNIVERSAL CRATE MOUNT:................................................................................................................................................................ 18 PREPARING THE PET TUTOR: ............................................................................................................................................ 19 QUICK START - OPERATING THE PET TUTOR: ............................................................................................................. 19 CARE AND CLEANING: ............................................................................................................................................................... 20 THE PET TUTOR CONTROL CENTER PROGRAM FOR COMPUTERS: ...................................................................... 22 CONNECTING THE PET TUTOR TO THE CONTROL CENTER: ............................................................................................................... 22 Timers: ................................................................................................................................................................................................................. 22 TOD (Time Of Day) Triggers: ................................................................................................................................................................ 23 Internet: .............................................................................................................................................................................................................. 24 Logger: ................................................................................................................................................................................................................ 25 Diagnostic Screen: ....................................................................................................................................................................................... 25 TRAINING TIPS ............................................................................................................................................................................ 25 FREQUENTLY ASKED QUESTIONS: ....................................................................................................................................... 26 SPECIFICATIONS: ........................................................................................................................................................................ 28 IMPORTANT HEALTH INFORMATION AND SAFETY PRECAUTIONS ......................................................................... 28 SAFETY PRECAUTIONS FOR AC ADAPTER ................................................................................................................................................. 29 Servicing of Double- Insulated Products ........................................................................................................…

Text truncated - open the document above for the full version.

FEEDER external - front FEEDER external – side

Smart Animal Feeder PN: SAT-0002 SN: XXXXXXX www.pettutor.biz Patent Pending A s s e m b l e d i n t h e U . S . A . Date of Mfg: mm/yyyy FCC ID: 2AB7I-FEEDER01 IC: x XXXXXX This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful Interference, and (2) this device must accept any interference received, including interference that may cause undesired

Feeder internal board -front Feeder internal board –back

TEST REPORT Report Number: 101518599MIN-002 Project Number: G101518599 Testing performed on the SAT-0002 FCC ID: 2AB7I-FEEDER01 Industry Canada ID: 11848A-FEEDER01 to 47 CFR Part 15. 249:2013 RSS- 210, Issue 8, 2010 RSS-Gen, Issue 3, 2010 47 CFR, Part 15:2013, §15.107 and §15.109, Class / ICES-003, Issue 5:2012 For Smart Animal Training Systems, LLC Test Performed by: Test Authorized by: Intertek Testing Services NA, Inc. 7250 Hudson Blvd., Suite 100 Oakdale, MN 55128 USA Smart Animal Training Systems, LLC 133 W. Market Street Indianapolis, IN 46204 USA Prepared by: Date: March 17, 2014 Simon Khazon Reviewed by: Date: March 17, 2014 Richard Blonigen This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. EMC Report No: 101518599MIN-002 FCC ID: 2AB7I-FEEDER01 IC ID: 11848A-FEEDER01 Page 2 of 30 TABLE OF CONTENTS 1.0 GENERAL DESCRIPTION .......................................................................................................... 3 1.1 Product Description; Test Facility ...................................................................................... 4 1.3 Environmental conditions .................................................................................................. 5 1.4 Measurement uncertainty .................................................................................................. 6 1.5 Field Strength Calculation ................................................................................................. 6 2.0 TEST SUMMARY .......................................................................................................................... 7 3.0 TEST CONDITIONS AND RESULTS ........................................................................................ 8 3.1 Field strength of fundamental ............................................................................................ 8 3.2 Field strength of harmonics and spurious emissions ...................................................... 10 3.3 Bandwidth of Emissions .................................................................................................. 17 3.4 Transmitter power line conducted emissions .................................................................. 20 3.5 Receiver/digital device radiated emissions ..................................................................... 23 3.6 Digital device conducted emissions ................................................................................ 27 4.0 TEST EQUIPMENT..................................................................................................................... 30 EMC Report No: 101518599MIN-002 FCC ID: 2AB7I-FEEDER01 IC ID: 11848A-FEEDER01 Page 3 of 30 1.0 GENERAL DESCRIPTION Model: SAT-0002 with Switching Power Adapter FranMar, model ZZU1001-100050-2A Type of EUT: Feeder (Smart Animal Trainer) Serial Number: B0023 FCC ID: 2AB7I-FEEDER01 Industry Canada ID: 11848A- FEEDER01 Related Submittal(s) Grants: None Company: Smart Animal Training Systems, LLC Customer: Mr. Wes Anderson Address: 133 W. Market Street Indianapolis, IN 46204 USA Phone: 317-721-4001 E-mail: [email protected] Test Standards: 47 CFR, Part 15:2013, §15.249 RSS–210, Issue 8, 20010 RSS-Gen, Issue 3, 2010 47 CFR, Part 15:2013, §15.107 and §15.109, Class ICES-003, Issue 5:2012 Other Type of radio: Stand -alone Module Hybrid Date Sample Submitted: February 28, 2014 Test Work Started: March 7, 2014 Test Work Completed: March 14, 2014 Test Sample Conditions: Damaged Poor (Usable) Good EMC Report No: 101518599MIN-002 FCC ID: 2AB7I-FEEDER01 IC ID: 11848A-FEEDER01 Page 4 of 30 1.1 Product Description; Test Facility Product Description: Dog Feeder Transceiver Operating Frequency 2405 MHz Modulation: QPSK Emission Designator: 2M81GXW Antenna(s) Info: Integral Antenna Antenna Installation: User Professional Factory Transmitter Power Configuration: Internal battery External power source 100-240VAC 230VAC 400VAC VDC Other: 0.5 Amp. 47-63Hz Special Test Arrangement: None Test Facility Accreditation: A2LA (Certificate No. 1427.01) Test Methodology: Measurements performed according to the procedures in ANSI C63.10- 2009 EMC Report No: 101518599MIN-002 FCC ID: 2AB7I-FEEDER01 IC ID: 11848A-FEEDER01 Page 5 of 30 1.2 EUT Configuration The equipment under test was operated during the measurement under the following conditions: - Standby - Continuous - Continuous un-modulated - Test program (customer specific) - Operating modes of the EUT: No. Description 1 In Continuous mode EUT was transmit every 1 second. Cables: No. Type Length Designation Note 1 Unshielded, 2 wires 1.2 m AC/DC Adapter Support equipment/Services: No. Item Description None 1.3 Environmental conditions During the measurement the environmental conditions were within the listed ranges: Normal Temperature: 15-35 ° C Humidity: 30-60 % Atmospheric pressure: 86-106 kPa EMC Report No: 101518599MIN-002 FCC ID: 2AB7I-FEEDER01 IC ID: 11848A-FEEDER01 Page 6 of 30 1.4 Measurement uncertainty The expanded uncertainty (k = 2) for radiated emissions from 30 to 1000 MHz has been determined to be: ±4 dB at 10m and ±5.4 dB at 3m The expanded uncert…
