2AB9RRCN1008ZigBee

User Manual for RCN1008 The remote control used RF4CE protocol to send RF signals (buttons and rotary wheel) for device controlling. The remote can be used after pairing with a dedicated device which was in stalled with a receiver dongle. RCN1008 was used as a dongle which need to be installed in customer’s device. It offers several different interfaces, like UART, SPI and I2C to communicate with customer’s device according predefined protocol. 1: product fig ure (RCN1008) 3: Technic al specific ations RF operating frequency: 2425MHz, 2450MHz, 2475MHz Reference frequency: 2.400GHz Channel spacing: 25MHz Modulation method: Offset-Quadrature Phase Shift Keying Communication rate: 250Kbps Output power: 1DBm Communication mechanism: applied Zigbee frequency hopping mechanism, passively frequency hopping. Average operating current：<25mA Static operating current: key press waking up <30uA Operating voltage：2.5V-3.4V Max remitt ing current: 20mA Max rate：250Kbit/s Receiving sensitivity： -85dbm Receiving current：<20mA Sleep current：<20uA Max receiving distance：>15M Normal operating receiving distance： 10M 4: Warning - Do not disassemble, repair, modify or replace the remote control Unit or any of its components. - Please comply with the national and international flight safety regulations when using device during your flight trip. - When storing rechargeable batteries for collection, keep in a vented, non-metal container. Operating for this product is between 40°F ~103°F (5°C ~40°C). Storage for this pro duct is between -4F°~ 185°F(-20°C~85°C). - Do NOT dispose of the battery in public trash; it is unlawful under state and federal environmental laws and regulations. - Please dispose of the battery at local battery recycling center. - This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation；

Building 2405,Qingjianhu Scienc巳＆Technology Park, N0.58 Weixin Road,Suzhou Industrial Park Suzhou Jiangsu China Te七十86-512-69567584 Fax:+86-512-6856 7598 Authoritv to Act as A1!ent Date: 2014-05-12 American Certification Body, Inc. 6731 Whittier A venue Suite Cl 10 McLean, VA 2210 I τo Whom It May Concern: Audixτechnologv (WuJian的Co. .Ltd. is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). 认Tecertify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug A七useAct of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b ), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Expiration Date: 12 months By: 。 b 、叶 7 nk ar y 明 n 川归因 [ ·I ahi XQ Title: R&D Director On behalf of: Suzhou BesCon Electronics Co叫Ltd. (Company Name) Telephone：十86-18934597686 1 -Must be sign巳dby applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provid巳d.Lette1s should be plac巳don appropriate Jett巳rhead. 022311...6

Building 2405,Qingjianhu Scicnc巳＆Technology Park, N0.58 W巳ixinRoad,Suzhou Industrial Park ,Suzhou Jiangsu China Tel:+86-5 l 2-69567584 Fax:+86”512-6856 7598 Reαuest for Confidentialitv Date: 2014-05-12 Subject: Confidentiality Request for: 2AB9RRCN1008 Pursuant to FCC 47 CRF 0.457( d) and 0.459 and IC RSP-100, Section I 0, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested 口ShortTerm因Permanent 囚ShortTerm 囚ShortTerm 口ShortTenn 口ShortTenn 口ShortTenn 口ShortTenn 囚ShortTenn 口Permanent*2 囚Permanent 囚Perma阳lt 口Perma阳it 囚Permanent 因ShortTenn口Permanent* *Note: (Insert Exolanation as~旦旦旦旦｝ Exhibit Block Diagrams External Photos Internal Photos Operation Description/Theory of Operation Parts List & Placement/SOM Tune-Up Procedure Schematics Test Setup Photos User’s Manual Suzhou BesCon Electronics Co叫Ltd.has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available t。”competition”wouldnegate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of i豆豆＿daysfrom the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: The applicant understands that until such time that IC distinguishes between Short Term and Permanent Confidentiality, either type of marked exhibit above will simply be marked Confidential when submitted to IC. Sincerely, \ ！飞ι叩 一一一一＿Xiaoen Yang By: (P约ntname) 2 -The asterisked it巳ms(*)require further justification before p巳口nanentconfidentiality will be allowed. Thes巳alsocurrently require review by the FCC under their Permit-But-Ask policy before the grant is issued and can delay completion of an application. Further justification should be added to the note above. One such example for a potted device would be:“The EUT is FULLY po位巳dusing a non-removable epoxy based mat巳rial.Removal of potting material causes iη巳parable damage to internal circuitry. See photographs exhibits that outlin巳th巳devicebefore and aft巳rpo枕ing." 3 -Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead. 022311 - 6

FCC ID: 2AB9RRCN1008 Page 1 of 1 Audix Technology (Wujiang )Co., Ltd. EMC Dept. Report No.: ACWE-F1405005 Figure 1 General Appearance(Front View) Figure 2 General Appearance(Back View)

                  36 mm 18.5 mm CVC-WR   This is the OPN (Ordable Product Number) Every label has this number. (CVC-WR) our logo with arcs Revision Number start with A. This letter will be updated if a change is implemented in production.

FCC ID: 2AB9RRCN1008 Page 1 of 2 Audix Technology (Wujiang )Co., Ltd. EMC Dept. Report No.: ACWE-F1405005 Figure 1 Component Side Figure 2 Solder Side Ant. Ant. FCC ID: 2AB9RRCN1008 Page 2 of 2 Audix Technology (Wujiang )Co., Ltd. EMC Dept. Report No.: ACWE-F1405005 Figure 3 Crystal Oscillator

FCC ID: 2AB9RRCN1008 Page 1 of 7 Audix Technology (Wujiang )Co., Ltd. EMC Dept. Report No.: ACWE-F1405014 APPLICATION FOR CERTIFICATION On Behalf of SuZhou BesCon Electronics Co., Ltd. RF4CE Dongle Model No. : RCN1008 Brand : Optelec FCC ID : 2AB9RRCN1008 Prepared for SuZhou BesCon Electronics Co., Ltd. Building 2405, Qingjianhu Science & Technology Park, No.58 Weixin Road, Suzhou Industrial Park Prepared by Audix Technology (Wujiang) Co., Ltd. EMC Dept. No. 1289 Jiangxing East Road, the Part of Wujiang Economic Development Zone Jiangsu China 215200 Tel : +86-512-63403993 Fax :+86-512-63403339 Report Number ACWE-F1405014 Date of Test Apr.17, 2014 Date of Report May 13, 2014 FCC ID: 2AB9RRCN1008 Page 2 of 7 Audix Technology (Wujiang )Co., Ltd. EMC Dept. Report No.: ACWE-F1405014 TABLE OF CONTENTS Description Page TEST REPORT CERTIFICATION ....................................................................................................... 4 1. GENERAL INFORMATION ....................................................................................................... 4 1.1. Description of Device (EUT) .................................................................................................................. 4 1.2. Tested Supporting System Details .......................................................................................................... 5 1.3. Description of Test Facility .................................................................................................................... 5 1.4. Measurement Uncertainty ....................................................................................................................... 5 2. SUMMARY OF STADARDS AND RESULTS .......................................................................... 6 2.1. Applicable Standard ................................................................................................................................ 6 2.2. Specification Limits ................................................................................................................................ 6 2.3. MPE Calculator Method ......................................................................................................................... 6 2.4. Calculated Result .................................................................................................................................... 7 FCC ID: 2AB9RRCN1008 Page 4 of 7 Audix Technology (Wujiang )Co., Ltd. EMC Dept. Report No.: ACWE-F1405014 1. GENERAL INFORMATION 1.1. Description of Device (EUT) Description : RF4CE Dongle Model No. : RCN1008 Serial No. : 695900081 FCC ID : 2AB9RRCN1008 Brand : Optelec Applicant : SuZhou BesCon Electronics Co., Ltd. Building 2405, Qingjianhu Science & Technology Park, No.58 Weixin Road, Suzhou Industrial Park Manufacturer : Optelec Limited Breslau 4 2993 LT Barendrecht The Netherlands Radio Technology : IEEE 802.15.4 (ZigBee®) Antenna Gain : -1.8dBi Fundamental Range : 2400 MHz -2480MHz Tested Frequency : 2425MHz (CH15) 2450MHz (CH20) 2475MHz (CH25) Working Frequency : 2.4 GHz Modulation type : O-QPSK Date of Receipt of Sample : Apr.17, 2014 Date of Test : Apr.17, 2014 FCC ID: 2AB9RRCN1008 Page 5 of 7 Audix Technology (Wujiang )Co., Ltd. EMC Dept. Report No.: ACWE-F1405014 1.2. Tested Supporting System Details 1.2.1. PC Manufacturer DELL Model Number PP26L Serial Number JX193A01 Power Cord Unshielded, Detachable, 1.5 m AC Adapter M/N: LA65NS1-00 Brand: DELL Input: AC 100-240V, 50-60Hz, 1.5A Output: DC 19.5V,3.34A DC Cord: Unshielded, Undetachable, 2.0m, 1 ferrite core. 1.3. Description of Test Facility Name of Firm Audix Technology (Wujiang) Co., Ltd. EMC Dept. Site Location No. 1289 Jiangxing East Road, the Eastern Part of Wujiang Economic Development Zone Jiangsu China 215200 Test Facilities RF Fully Chamber NVLAP Lab Code 200786-0 (NVLAP is a NATA accredited body under Mutual Recognition Agreement) Valid until on Sep.30, 2014 1.4. Measurement Uncertainty Test Item Uncertainty Maximum Peak Output Power ± 0.30dB Remark: Uncertainty = ku c (y) FCC ID: 2AB9RRCN1008 Page 6 of 7 Audix Technology (Wujiang )Co., Ltd. EMC Dept. Report No.: ACWE-F1405014 2. SUMMARY OF STADARDS AND RESULTS 2.1. Applicable Standard FCC OET Bulletin 65:1997 2.2. Specification Limits Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) Averaging Time |E| 2 , |H| 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f2)* 30 30-300 27.5 0.073 0.2 30 300-1500 -- -- f/150 30 1500-100,000 -- -- 1.0 30 f = frequency in MHz *Plane-wave equivalent power density NOTE: General population/uncontrolled exposures apply in situations in which the general public may be exposed, or in which persons that are exposed as a consequence of their employment may not be fully aware of the potential for exposure or can not exercise control over their exposure. The limit value 1.0mW/cm 2 is available for this EUT. 2.3. MPE Calculator Method S = PG/(4R 2 R = [PG/(4 where: S = power density (in appropriate units, e.g. mW/ cm 2 ) P = power input to the antenna (in appropriate units, e.g., mW) (the measured power value see Report: F12124 Section 6.6) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) FCC ID: 2AB9RRCN1008 Page 7 of 7 Audix Technology (Wujiang )Co., Ltd. EMC Dept. Report No.: ACWE-F1405014 2.4. Calculated Result Radio Frequency Radiation Exposure Evaluation Frequency Output Power to Antenna Antenna Gain Power Density Limit (MHz) (mW) (dBi) (Numeric) (mW/cm 2 )(mW/cm 2 ) 2425 1.51 2.21.68 0.000505 1. 2450 1.43 2.2 1.68 0.000478 1. 2475 1.35 2.21.68 0.000451 1. Frequency Output Power to Antenna Antenna Gain Limit Distance (MHz) (mW) (dBi) (Numeric) (mW/cm 2 ) (cm) 2425 1.51 2.261.68 1.0 0.521 2450 1.43…

Text truncated - open the document above for the full version.

FCC ID: 2AB9RRCN1008 Page 1 of 46 Audix Technology (Wujiang )Co., Ltd. EMC Dept. Report No.: ACWE-F1405005 APPLICATION FOR CERTIFICATION On Behalf of SuZhou BesCon Electronics Co., Ltd. RF4CE Dongle Model No. : RCN1008 Serial No. : 695900081 FCC ID : 2AB9RRCN1008 Prepared for SuZhou BesCon Electronics Co., Ltd. Building 2405, Qingjianhu Science & Technology Park, No.58 Weixin Road, Suzhou Industrial Park Prepared by Audix Technology (Wujiang) Co., Ltd. EMC Dept. No. 1289 Jiangxing East Road, the Part of Wujiang Economic Development Zone Jiangsu China 215200 Tel : +86-512-63403993 Fax :+86-512-63403339 Report Number ： ACWE-F1405005 Date of Test ： Apr.17~23, 2014 Date of Report ： May 13, 2014 FCC ID: 2AB9RRCN1008 Page 2 of 46 Audix Technology (Wujiang )Co., Ltd. EMC Dept. Report No.: ACWE-F1405005 TABLE OF CONTENTS Description Page TEST REPORT CERTIFICATION ....................................................................................................... 3 1. SUMMARY OF MEASUREMENTS AND RESULTS ............................................................. 4 2. GENERAL INFORMATION ....................................................................................................... 5 2.1. Description of Device (EUT) .................................................................................................................. 5 2.2. Tested Supporting System Details .......................................................................................................... 6 2.3. Description of Test Facility .................................................................................................................... 6 2.4. Measurement Uncertainty ....................................................................................................................... 6 3. RADIATED EMISSION MEASUREMENT .............................................................................. 8 3.1. Test Equipment ....................................................................................................................................... 8 3.2. Block Diagram of Test Setup .................................................................................................................. 8 3.3. Radiated Emission Limits ..................................................................................................................... 10 3.4. Test Procedure ...................................................................................................................................... 10 3.5. Assessment In All Three Orthogonal Planes ........................................................................................ 11 3.6. Measurement Results ............................................................................................................................ 11 3.7. Restricted Bands Measurement Results (For Below 1GHz) ................................................................. 13 3.8. Restricted Bands Measurement Results (For Above 1GHz) ................................................................ 17 3.9. Spurious Emission Measurement Results in Band Edge Emission (FCC Part 15, 15.205) .................. 21 4. 6 DB BANDWIDTH MEASUREMENT ................................................................................... 25 4.1. Test Equipment ..................................................................................................................................... 25 4.2. Block Diagram of Test Setup ................................................................................................................ 25 4.3. Specification Limits (§15.247(a)(2)) .................................................................................................... 25 4.4. Test Procedure ...................................................................................................................................... 25 4.5. Test Results ........................................................................................................................................... 25 5. MAXIMUM PEAK OUTPUT POWER MEASUREMENT ................................................... 28 5.1. Test Equipment ..................................................................................................................................... 28 5.2. Block Diagram of Test Setup ................................................................................................................ 28 5.3. Specification Limits (§15.247(b)(3)) .................................................................................................... 28 5.4. Test Procedure ...................................................................................................................................... 28 5.5. Test Results ........................................................................................................................................... 29 6. BAND EDGES MEASUREMENT ............................................................................................ 30 6.1. Test Equipment ..................................................................................................................................... 30 6.2. Block Diagram of Test Setup ................................................................................................................ 30 6.3. Specification Limits (§15.247(d)) ......................................................................................................... 30 6.4. Test Procedure ...................................................................................................................................... 30 6.5. Test Results ........................................................................................................................................... 30 7. POWER SPECTRAL DENSITY MEASUREMENT .............................................................. 32 7.1. Test Equipment ................................…

Text truncated - open the document above for the full version.

FCC ID: 2AB9RRCN1008 Page 1 of 2 Audix Technology (Wujiang) Co., Ltd. EMC Dept. Report No.: ACWE-F1405005 1. PHOTOGRAPHS OF MEASUREMENT 1.1. Radiated Disturbance Measurement Below 1GHz Above 1GHz FCC ID: 2AB9RRCN1008 Page 2 of 2 Audix Technology (Wujiang) Co., Ltd. EMC Dept. Report No.: ACWE-F1405005 1.2. Measurement for section 4/5/6/7/8
