2AB9USANICHECK1Wall-mounted hand sanitizer monitor

Sanicheck Setup Instructions For FCC Testing The two test units were shipped with the power cable disconnected. This cable must be reconnected BEFORE any testing is performed. 1.Remove the right plastic cover by sliding it downward as shown in the next two photos. 2. The power cable consists of a red and black wire with a keyed connected on the end. Insert this connector into the appropriate header as shown in the next two photos. 3.Put the plastic cover back in place and slide it up to secure it into position. 4.To test the NFC (near field communication) functions of the Sanicheck, turn on the provided Nexus Tablet by pressing and holding the power button on the top right side. 5.Tap the “Sanicheck App” icon as shown in the next picture. 6. Make sure the “Download” tab is selected as in the next photo. 7. Hold the back of the table up against the front of the Sanicheck unit as in the next photo. The Sanicheck unit will beep. The Tablet UI will zoom out slightly and a message will be displayed “Touch To Beam”. DO NOT TOUCH THE SCEEN at this time. Wait approximately 5 seconds, and the data will automatically transfer. 8. Pull the tablet away from the Sanicheck unit and wait for the beep to indicate disconnection. Data download is now complete. 9. To change the configuration of the Sanicheck unit, switch the App to the “Upload Tab” as in the next photo. If the previous steps worked properly, the current Sanicheck configuration will be displayed as in the next photo. 10. Change any of the desired values. Hold the tablet back up to the Sanicheck and wait for the beep followed by UI zoom. The message will once again appear “Touch to Beam”. This time, TOUCH THE SCREEN to beam the new configuration to the Sanicheck as in the next photo. 11. Remove the tablet from the Sanicheck and wait for the disconnect beep. The new configuration is now uploaded.

Page 1 of 1 FCC ID: 2AB9U-SANICHECK1 IC ID: CT Project:P1420005 From: Shawn McMillen Date: 5/3/14 Please include a statement of compliance to the 15.203 requirements for a part 15C device. Note: these devices are categorically excluded from routine RF exposure evaluation. CT – The 15.203 requirement has been included in the Test Report Response by: Submitted by: Date:

PHONE FAX WEB 218 Wyassup Road, North Stonington, CT 06359 860.822.3721 [email protected] HDH Technologies, LLC Proposed label to be attached to back of the SaniCheck unit: Label location on back of SaniCheck unit: FCC ID: 2AB9U-SANICHECK1 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

p1420005_FCC_Part 1.1310_Rev 1.0 Page 1 of 4 Test Report Prepared for: HDH Technologies Model: Sanicheck NFC Description: Sanicheck NFC Hand Sanitizing Monitor FCC ID: 2AB9U-SANICHECK1 To FCC Part 1.1310 Date of Issue: April 29, 2014 On the behalf of the applicant: HDH Technologies 218 Wyassup Road North Stonington, CT 06359 Attention of: George Panciera, CEO Ph: (860) 822-3721 E-Mail: [email protected] Prepared By Compliance Testing, LLC 1724 S. Nevada Way Mesa, AZ 85204 (480) 926-3100 phone / (480) 926-3598 fax www.compliancetesting.com Project No: p1420005 Alex Macon Project Test Engineer This report may not be reproduced, except in full, without written permission from Compliance Testing All results contained herein relate only to the sample tested p1420005_FCC_Part 1.1310_Rev 1.0 Page 2 of 4 Test Report Revision History Revision Date Revised By Reason for Revision 1.0 April 29, 2014 Alex Macon Original Document p1420005_FCC_Part 1.1310_Rev 1.0 Page 3 of 4 ILAC / A2LA Compliance Testing, LLC, has been accredited in accordance with the recognized International Standard ISO/IEC 17025:2005. This accreditation demonstrates technical competence for a defined scope and the operation of a laboratory quality management system (refer joint ISO-ILAC-IAF Communiqué dated January 2009) The tests results contained within this test report all fall within our scope of accreditation, unless below Please refer to http://www.compliancetesting.com/labscope.html for current scope of accreditation. Testing Certificate Number: 2152.01 FCC Site Reg. #349717 IC Site Reg. #2044A-2 Non-accredited tests contained in this report: N/A p1420005_FCC_Part 1.1310_Rev 1.0 Page 4 of 4 Description The EUT is a wall mounted device which incorporates NFC to upload and download data. This is a fixed device used in Uncontrolled Exposure environment. Limits - Uncontrolled Exposure 47 CFR 1.1310 Table 1, (B) 0.3-1.234 MHz: Limit [mW/cm²] = 100 1.34-30 MHz: Limit [mW/cm²] = (180/f²) 30-300 MHz: Limit [mW/cm²] = 0.2 300-1500 MHz: Limit [mW/cm²] = f/1500 1500-100,000 MHz Limit [mW/cm²] = 1.0 Test Frequencies, MHz 13.56 Power, Conducted, mW (P) 2.51 Antenna Gain Isotropic 0dBi Antenna Gain Numeric (G) 1.0 Antenna Type NFC Distance (R) 20 cm Power Density Calculations Formula = S = PG / 4πR² Power Density (S) = 0.000499 Limit = 0.978933354 The Power Density is below the Limit. END OF TEST REPORT

p1420005_FCC_Part 15.225_Rev 1.0 Page 1 of 11 Test Report Prepared for: HDH Technologies Model: Sanicheck NFC Description: Sanicheck NFC Hand Sanitizing Monitor FCC ID: 2AB9U-SANICHECK1 To FCC Part 15.225 Date of Issue: April 29, 2014 On the behalf of the applicant: HDH Technologies 218 Wyassup Road North Stonington, CT 06359 Attention of: George Panciera, Hardware Engineer Ph: (860) 822-3721 E-Mail: [email protected] Prepared by Compliance Testing, LLC 1724 S. Nevada Way Mesa, AZ 85204 (480) 926-3100 phone / (480) 926-3598 fax www.compliancetesting.com Project No: p1420005 Alex Macon Project Test Engineer This report may not be reproduced, except in full, without written permission from Compliance Testing All results contained herein relate only to the sample tested p1420005_FCC_Part 15.225_Rev 1.0 Page 2 of 11 Test Report Revision History Revision Date Revised By Reason for Revision 1.0 4/29/14 Alex Macon Original Document p1420005_FCC_Part 15.225_Rev 1.0 Page 3 of 11 Table of Contents Description Page Standard Test Conditions Engineering Practices ........................................................................................... 6 Test Results Summary .................................................................................................................................... 7 Field Strength .................................................................................................................................................. 8 Frequency Stability ......................................................................................................................................... 9 Radiated Emissions ...................................................................................................................................... 10 p1420005_FCC_Part 15.225_Rev 1.0 Page 4 of 11 ILAC / A2LA Compliance Testing, LLC, has been accredited in accordance with the recognized International Standard ISO/IEC 17025:2005. This accreditation demonstrates technical competence for a defined scope and the operation of a laboratory quality management system (refer joint ISO-ILAC-IAF Communiqué dated January 2009) The tests results contained within this test report all fall within our scope of accreditation, unless noted in the table below. Please refer to http://www.compliancetesting.com/labscope.html for current scope of accreditation. Testing Certificate Number: 2152.01 FCC Site Reg. #349717 IC Site Reg. #2044A-2 Non-accredited tests contained in this report: N/A p1420005_FCC_Part 15.225_Rev 1.0 Page 5 of 11 The applicant has been cautioned as to the following: 15.21 Information to User The user’s manual or instruction manual for an intentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 15.27(a) Special Accessories Equipment marketed to a consumer must be capable of complying with the necessary regulations in the configuration in which the equipment is marketed. Where special accessories, such as shielded cables and/or special connectors are required to enable an unintentional or intentional radiator to comply with the emission limits in this part, the equipment must be marketed with, i.e. shipped and sold with, those special accessories. However, in lieu of shipping or packaging the special accessories with the unintentional or intentional radiator the responsible part may employ other methods of ensuring that the special accessories are provided to the consumer, without an additional charge. Information detailing any alternative method used to supply the special accessories for a grant of equipment authorization or retained in the verification records, as appropriate. The party responsible for the equipment, as detailed in § 2.909 of this chapter, shall ensure that these special accessories are provided with the equipment. The instruction manual for such devices shall include appropriate instructions on the first page of text concerned with the installation of the device that these special accessories must be used with the device. It is the responsibility of the user to use the needed special accessories supplied with the equipment. p1420005_FCC_Part 15.225_Rev 1.0 Page 6 of 11 Standard Test Conditions Engineering Practices Except as noted herein, the following conditions and procedures were observed during the testing. In accordance with ANSI C63.10-2009 and unless otherwise indicated in the specific measurement results, the ambient temperature of the actual EUT was maintained within the range of 10° to 40°C (50° to 104°F) unless the particular equipment requirements specify testing over a different temperature range. Also, unless otherwise indicated the humidity levels were in the range of 10% to 90% relative humidity. Measurement results, unless otherwise noted, are worst-case measurements. Environmental Conditions Temperature (°C) Humidity (%) Pressure (mbar) 23.7 – 24.5 16.8 – 25.1 964.5 – 972.6 EUT Description Model: Sanicheck NFC Description: NFC Hand Sanitizing Monitor The EUT is a wall mounted device used to monitor an entrance way and ensure sanitation procedure is followed. It uses NFC in order to download and upload data. EUT Operation during Tests The EUT’s NFC was activated using the manufacturer supplied tablet. For frequency stability, a continuous signal device was supplied for testing. Accessories: Qty Description Mfg Model S/N 1 Tablet Asus Nexus N/A Cables: Qty Description Length (M) Shielding Y/N Shielded Hood Y/N Termination 1 Ribbon cable <3m N N N/A p1420005_FCC_Part 15.225_Rev 1.0 Page 7 of 11 Test Results Summary Specification Test Name Pass, Fail, N/A Comments 15.225(a) Fundamental Field Strength Pass 15.225(b)(c) Out of Band Spurious Emissions Pass 15.225(e) Frequency Stability Pass 15.209, 15.225(d) Radiated Emissions Pass 15.207 Conducted Powerline Emissions N/A EUT is a battery powered device. p1420…

Text truncated - open the document above for the full version.

Test Setup Photos FCC ID: 2AB9U-SANICHECK1 RF Conducted #1 RF Radiated #1 RF Radiated #2
