2ABD3MS-WR50CDInternet Radio

3 • DE Inhalt 1 Einführung ................................................. 3 1.1 Produktmerkmale ................................. 3 2 Sicherheitshinweise ................................. 4 3 Bedienelemente und Anschlüsse ........... 5 3.1 Internetradio ......................................... 5 3.2 Fernbedienung ..................................... 6 4 Inbetriebnahme ......................................... 7 4.1 Aufstellung ............................................ 7 4.2 Rackinstallation .................................... 7 4.3 Anschlüsse herstellen .......................... 7 4.4 Ein-/Ausschalten .................................. 7 4.5 Fernbedienung ..................................... 7 5 WLAN-Netzwerk einrichten ...................... 8 6 Bedienung ............................................... 10 6.1 Grundfunktionen ................................. 10 6.2 Hauptmenü ......................................... 10 6.3 Meine Favoriten .................................. 11 6.4 Internetradio ....................................... 14 6.5 Musik abspielen (Medienserver) ........ 15 6.6 Speicher (SD-Karte) ........................... 15 6.7 DAB-Radio.......................................... 16 6.8 FM-Radio ............................................ 17 6.9 Bluetooth ............................................ 18 6.10 CD-Player ........................................ 18 6.11 Wecker ............................................. 18 6.12 Sleep-Timer (Schlummerautomatik) 19 7 Systemeinstellungen .............................. 20 8 Problembehebung .................................. 22 9 Reinigung und Wartung ......................... 23 10 Umweltschutz.......................................... 23 11 Technische Daten ................................... 24 D00133624, Version 1.1, Stand 16/02/2022 Produkt-Updates, Dokumentationen, Software und Support erhalten Sie unter www.omnitronic.de. Die neueste Version der Bedienungsanleitung finden Sie im Downloadbereich des Produkts. © 2022 OMNITRONIC. Alle Rechte vorbehalten. Dieses Dokument darf ohne schriftliche Genehmigung des Copyrightinhabers weder ganz noch teilweise reproduziert werden. Der Inhalt dieses Dokuments kann ohne vorherige Ankündigung modifiziert werden, wenn Änderungen in Methodik, Design oder Herstellung dies erforderlich machen. Alle in diesem Dokument erwähnten Marken gehören den jeweiligen Eigentümern. 1 Einführung Willkommen bei Omnitronic! Mit dem TUNA-NET-CD hören Sie Radio von tausenden Internetsendern weltweit in bester Qualität. Außerdem ist der rauschfreie Empfang von DAB+ und von herkömmlichen FM-Sendern möglich. Verbinden Sie den TUNA dazu einfach über WLAN mit dem Internet. Der TUNA lässt sich einfach über das große Jogdial oder die mitgelieferte Fernbedienung steuern. Über verschiedene Equalizereinstellungen passen Sie den Sound genau Ihren Vorstellungen und Ihren Lautsprechern an. An den digitalen und analogen Ausgängen können Sie einen externen Verstärker oder Aktivboxen anschließen; auch ein Kopfhörer- ausgang steht zur Verfügung. Sollte das Radioprogramm Ihnen einmal nicht zusagen, können einfach Musik von CDs, Speicherkarten, Bluetooth-Quellen und Medien- servern im lokalen Netzwerk wiedergeben. Diese Bedienungsanleitung zeigt Ihnen, wie Sie das Internetradio in Betrieb nehmen und nutzen. Damit Sie sich und andere keinen Gefahren aussetzen, beachten Sie bitte unbedingt alle Sicherheits- hinweise in dieser Anleitung und alle auf dem Gerät angebrachten Sicherheitshinweise. Diese Bedienungsanleitung gilt für die Artikel- nummer: 11045014. Bitte bewahren Sie dieses Dokument für weiteren Gebrauch auf und geben Sie es ggf. an nachfolgende Besitzer weiter. 1.1 Produktmerkmale • Zugriff auf tausende Radiostationen weltweit • Sendersuche nach Genre, Sendername, Standort • Netzwerkverbindung über WLAN • Bluetooth-Funktion zur kabellosen Musikübertragung von Ihren Musikgeräten • Empfang von FM-Radio und rauschfreiem DAB+ • Unterstützt UPnP und DLNA für Media-Streaming von im Netzwerk freigegebenen Dateien • Audio- und MP3-CD • Steckplatz für microSD-Speicherkarten • 2,4‘‘ großes, beleuchtetes TFT-Farbdisplay • Einfache Bedienung über Jogdial • Verschiedene Equalizereinstellungen • Sommer-/Winterzeit-Umschaltung • Sleep-Timer und Wecker-Funktion • Digitale und analoge Ausgänge für externe Verstärker oder Aktivlautsprecher • Kopfhörerausgang • Lieferung inklusive IR-Fernbedienung, Stabantenne und Wurfantenne • Robustes Stahlgehäuse mit Aluminium-Frontplatte • 482-mm-Rackeinbau (1 HE), Montagewinkel abnehmbar 4 • DE 2 Sicherheitshinweise • Bitte lesen Sie vor der Verwendung des Produkts diese Anleitung. Sie enthält wichtige Hinweise für den korrekten Betrieb. Bewahren Sie diese Anleitung für weiteren Gebrauch auf. • Das Gerät dient zur Wiedergabe von Internet-, DAB- und FM-Radiosendern. Außerdem kann Musik von CDs, Speicherkarten, Bluetooth-Quellen und Medienservern im lokalen Netzwerk wiedergegeben werden. • Verwenden Sie das Produkt ausschließlich gemäß den hier gegebenen Vorgaben, damit es nicht versehentlich zu Verletzungen oder Schäden kommt. • Bei Sach- oder Personenschäden, die durch unsachgemäße Handhabung oder Nichtbeachten dieser Bedienungsanleitung verursacht werden, übernehmen wir keine Haftung und es erlischt jeder Gewährleistungsanspruch. • Aus Sicherheitsgründen ist das eigenmächtige Umbauen oder Verändern des Produkts ist nicht gestattet und hat den Verfall der Gewährleistung zur Folge. • Um die Gefahr eines elektrischen Schlages zu vermeiden, niemals irgendeinen Teil des Produkts öffnen. Nur an eine vorschriftsmäßige Steckdose anschließen, die der Produktspezifikation entspricht. Verlegen Sie das Anschlusskabel so, dass es nicht zur Stolperfalle wird. • Dieses Gerät enthält eine Laserdiode der Klasse 1. Um einen sicheren Betrieb zu gewährleisten, dürfen weder Abdeckungen entfernt werden, noch darf versucht werden, sich Zugang zum Geräteinneren zu verschaffen. • Das Produkt ist für den trockenen Inn…

Text truncated - open the document above for the full version.

Ocean Digital Technology Ltd. Agent Authorization Company: Ocean Digital Technology Ltd. Address: Flat B, 12/F., Yeung Yiu Chung (No.8) Ind. Bldg., 20 Wang Hoi Road,Kowloon Bay, Hong Kong. Product Name: Internet Radio Model Number(s): MA-50CDE, MA-50CD, WR-50CD, WR-50CDE, MA-50,WR-50 Product Description: We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2022.03.30 Name: Karen Ho Title: Manager Company: Ocean Digital Technology Ltd.

Ocean Digital Technology Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2022.03.30 Subject; Request for Confidentiality FCC ID: 2ABD3MS-WR50CD To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Karen Ho Title: Manager

Model difference letter 2022.03.30 Dear MiCOM Reviewer, This is a new Application from Ocean Digital Technology Ltd. Model No.: MA-50CDE, MA-50CD, WR-50CD, WR-50CDE, MA-50,WR-50. Only the model MA-50CDE was tested, since the electrical circuit design, layout, components used and internal wiring were identical for the above models, with difference being model name. Thank you for your cooperation! Yours sincerely, Signatory: Name: Karen Ho Position: Manager Company Name: Ocean Digital Technology Ltd. Address: Flat B, 12/F., Yeung Yiu Chung (No.8) Ind. Bldg., 20 Wang Hoi Road,Kowloon Bay, Hong Kong. Tel / Fax E-Mail: 85224201464 [email protected] Ocean Digital Technology Ltd.

Model No.: MA-50CDE FRONT VIEW OF SAMPLE BACK VIEW OF SAMPLE Model No.: MA-50CDE LEFT VIEW OF SAMPLE RIGHT VIEW OF SAMPLE Model No.: MA-50CDE TOP VIEW OF SAMPLE BOTTOM VIEW OF SAMPLE Model No.: MA-50CDE OVERALL OF SAMPLE OVERALL OF Label BT/WIFI Antenna Model No.: MA-50CDE Antenna close-up Model No.: MA-50CDE

Label Location

Model: WR-50CD FCC ID: 2ABD3MS-WR50CD Made in China Tested To Comply With FCC Standards FOR HOME OR OFFICE USE NO USER SERVICEABLE PARTS INSIDE WARRANTY VOID IF OPENED 75mm 25mm 2022/03/09 MA-50CD

Model No.: MA-50CDE Page 1 of 3 INTERNAL PHOTO OF SAMPLE INT ERNAL PHOTO OF SAMPLE PCB Model No.: MA-50CDE Page 2 of 3 INTERNAL PHOTO OF SAMPLE PCB INT ERNAL PHOTO OF SAMPLE PCB Model No.: MA-50CDE Page 3 of 3 INTERNAL PHOTO OF SAMPLE PCB INT ERNAL PHOTO OF SAMPLE

Shenzhen Most Technology Service Co., Ltd. No.5, 2nd Langshan Road, North District, Hi-tech Industrial Park, Nanshan, Shenzhen, Guangdong, China. RF Exposure Evaluation Report Report Reference No. ..................... : FCC ID.. .......................................... : MTWG22010046-H 2ABD3MS-WR50CD Compiled by ( position+printed name+signature) .. : File administrators Alisa Luo Supervised by ( position+printed name+signature) .. : Test Engineer Sunny Deng Approved by ( position+printed name+signature) .. : Manager Yvette Zhou Date of issue ..................................... : March 22,2022 Representative Laboratory Name .: Shenzhen Most Technology Service Co., Ltd. Address ............................................ : No.5, 2nd Langshan Road, North District, Hi-tech Industrial Park, Nanshan, Shenzhen, Guangdong, China. Applicant’s name ............................ : Ocean Digital Technology Ltd. Address ............................................ : Flat B, 12/F., Yeung Yiu Chung (No.8) Ind. Bldg., 20 Wang Hoi Road,Kowloon Bay, Hong Kong. Test specification/ Standard ..........: 47 CFR Part 1.1307 47 CFR Part 1.1310 KDB447498D01 General RF Exposure Guidance v06 TRF Originator .................................. : Shenzhen Most Technology Service Co., Ltd. Shenzhen Most Technology Service Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Most Technology Service Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Most Technology Service Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Internet Radio Trade Mark ....................................... : N/A Manufacturer .................................... : Ocean Digital Technology Ltd. Model/Type reference....................... : MA-50CDE Listed Models .................................. : MA-50CD, WR-50CD, WR-50CDE, MA-50,WR-50 Modulation Type ............................... : GFSK, π/4DQPSK, 8DPSK, CCK/DSSS/ OFDM Operation Frequency ........................ : From 2402MHz to 2480MHz Hardware Version .............................. V1.1 Software Version ............................... APP:20220215.1229 Rating ............................................... : DC 9V by Adapter Result................................................ : PASS Report No.: MTWG22010046-H Page 2 of 7 T E S T R E P O R T Equipment under Test : Internet Radio Model /Type : MA-50CDE Listed Models : MA-50CD, WR-50CD, WR-50CDE, MA-50,WR-50 Remark Only with different model names. Applicant : Ocean Digital Technology Ltd. Address : Flat B, 12/F., Yeung Yiu Chung (No.8) Ind. Bldg., 20 Wang Hoi Road,Kowloon Bay, Hong Kong. Manufacturer : Ocean Digital Technology Ltd. Address : Flat B, 12/F., Yeung Yiu Chung (No.8) Ind. Bldg., 20 Wang Hoi Road,Kowloon Bay, Hong Kong. Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: MTWG22010046-H Page 3 of 7 1. Revision History Revision Issue Date Revisions Revised By 00 2022-03-22 Initial Issue Alisa Luo Report No.: MTWG22010046-H Page 4 of 7 2. SAR Evaluation 2.1 RF Exposure Compliance Requirement 2.1.1 Standard Requirement According to KDB447498D01 General RF Exposure Guidance v06 4.3.1. Standalone SAR test exclusion considerations Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Exclusion Threshold condition, listed below, is satisfied. 2.1.2 Limits According to FCC Part1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in part1.1307(b) F= Frequency in MHz Friis Formula Friis transmission formula: Pd = (Pout*G)/(4* Pi * R 2) Where Pd = power density in mW/cm2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Report No.: MTWG22010046-H Page 5 of 7 2.1.3 EUT RF Exposure Antenna Gain: 0dBi Antenna Gain: The maximum Gain measured in fully anechoic chamber is 2.4 in linear scale. Output Power Into Antenna & RF Exposure Evaluation Distance: EDR GFSK Test channel Peak Output Power (dBm) Tune up tolerance (dBm) Maximum tune-up Power (dBm) Lowest(2402 MHz) 1.23 1.23±1 2.23 Middle(2441MHz) 2.13 2.13±1 3.13 Highest(2480MHz) 3.11 3.11±1 4.11 π/4DQPSK Test channel Peak Output Power (dBm) Tune up tolerance (dBm) Maximum tune-up Power (dBm) Lowest(2402 MHz) 2.15 2.15±1 3.15 Middle(2441MHz) 2.02 2.02±1 3.02 Highest(2480MHz) 3.12 3.12±1 4.12 8DPSK Test channel Peak Output Power (dBm) Tune up tolerance (dBm) Maximum tune-up Power (dBm) Lowest(2402 MHz) 1.22 1.22±1 2.22 Middle(2441MHz) 2.02 2.02±1 3.02 Highest(2480MHz) 1.55 1.55±1 2.55 Report No.: MTWG22010046-H Page 6 of 7 WIFI 2.4G 802.11b Test channel Peak Output Power (dBm) Tune up tolerance (dBm) Maximum tune-up Power (dBm) Lowest(2412MHz) 13.23 13.23±1 14.23 Middle(2437MHz) 11.23 11.23±1 12.23 Highest(2462MHz) 10.56 10.56±1 11.56 802.11g Test channel Peak Output Power (dBm) Tune up tolerance (dBm) Maximum tune-up Power (dBm) Lowest(2412MHz) 13.55 13.55±1 14.55 Middle(2437MHz) 12.42 12.42±1 13.42 Highest(2462MHz) 11.52 11.52±1 12.52 802.11n(H20) Test channel Peak Output Power (dBm) Tune up tolerance (dBm) Maximum tune-up Power…

Text truncated - open the document above for the full version.

Shenzhen Most Technology Service Co., Ltd. No.5, 2nd Langshan Road, North District, Hi-tech Industrial Park, Nanshan, Shenzhen, Guangdong, China. TEST REPORT FCC Rules Part 15.247 Report Reference No. .....................: FCC ID.. .......................................... : MTWG22010046-R1 2ABD3MS-WR50CD Compiled by ( position+printed name+signature) .. : File administrators Alisa Luo Supervised by ( position+printed name+signature) .. : Test Engineer Sunny Deng Approved by ( position+printed name+signature) .. : Manager Yvette Zhou Date of issue ..................................... : March 22,2022 Representative Laboratory Name .: Shenzhen Most Technology Service Co., Ltd. Address ............................................ : No.5, 2nd Langshan Road, North District, Hi-tech Industrial Park, Nanshan, Shenzhen, Guangdong, China. Applicant’s name ............................ : Ocean Digital Technology Ltd. Address ............................................ : Flat B, 12/F., Yeung Yiu Chung (No.8) Ind. Bldg., 20 Wang Hoi Road,Kowloon Bay, Hong Kong. Test specification/ Standard ..........: FCC Rules Part 15.247 TRF Originator .................................. : Shenzhen Most Technology Service Co., Ltd. Shenzhen Most Technology Service Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Most Technology Service Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Most Technology Service Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Internet Radio Trade Mark ....................................... : N/A Manufacturer .................................... : Ocean Digital Technology Ltd. Model/Type reference....................... : MA-50CDE Listed Models .................................. : MA-50CD, WR-50CD, WR-50CDE, MA-50,WR-50 Modulation Type ............................... : GFSK, π/4DQPSK, 8DPSK Operation Frequency ........................ : From 2402MHz to 2480MHz Hardware Version .............................. V1.1 Software Version ............................... APP:20220215.1229 Rating ............................................... : DC 9V by Adapter Result................................................ : PASS Report No.: MTWG22010046-R1 Page 2 of 42 T E S T R E P O R T Equipment under Test : Internet Radio Model /Type : MA-50CDE Listed Models : MA-50CD, WR-50CD, WR-50CDE, MA-50,WR-50 Remark Only with different model names. Applicant : Ocean Digital Technology Ltd. Address : Flat B, 12/F., Yeung Yiu Chung (No.8) Ind. Bldg., 20 Wang Hoi Road,Kowloon Bay, Hong Kong. Manufacturer : Ocean Digital Technology Ltd. Address : Flat B, 12/F., Yeung Yiu Chung (No.8) Ind. Bldg., 20 Wang Hoi Road,Kowloon Bay, Hong Kong. Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: MTWG22010046-R1 Page 3 of 42 Contents 1 REVISION HISTORY ................................................................ 4 2 TEST STANDARDS .................................................................. 5 3 SUMMARY ............................................................................. 6 3.1 General Remarks 6 3.2 Product Description 6 3.3 Equipment Under Test 6 3.4 Short description of the Equipment under Test (EUT) 6 3.5 EUT operation mode 7 3.6 Block Diagram of Test Setup 7 3.7 Test Item (Equipment Under Test) Description* 7 3.8 Auxiliary Equipment (AE) Description 7 3.9 Antenna Information* 7 3.10 Related Submittal(s) / Grant (s) 8 3.11 Modifications 8 4 TEST ENVIRONMENT ............................................................... 9 4.1 Address of the test laboratory 9 4.2 Environmental conditions 9 4.3 Summary of measurement results 10 4.4 Statement of the measurement uncertainty 10 4.5 Equipments Used during the Test 11 5 TEST CONDITIONS AND RESULTS ............................................ 12 5.1 AC Power Conducted Emission 12 5.2 Radiated Emission 15 5.3 Maximum Peak Output Power 21 5.4 20dB Bandwidth 22 5.5 Frequency Separation 25 5.6 Number of hopping frequency 28 5.7 Time of Occupancy (Dwell Time) 30 5.8 Spurious RF Conducted Emission 33 5.9 Pseudorandom Frequency Hopping Sequence 39 5.10 Antenna Requirement 40 6 TEST SETUP PHOTOS OF THE EUT .......................................... 41 7 PHOTOS OF THE EUT ............................................................. 42 Report No.: MTWG22010046-R1 Page 4 of 42 1 Revision History Revision Issue Date Revisions Revised By 00 2022-03-21 Initial Issue Alisa Luo Report No.: MTWG22010046-R1 Page 5 of 42 2 TEST STANDARDS The tests were performed according to following standards: FCC Rules Part 15.247 : Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2013 : American National Standard for Testing Unlicensed Wireless Devices Report No.: MTWG22010046-R1 Page 6 of 42 3 SUMMARY 3.1 General Remarks Date of receipt of test sample : 2022.03.10 Testing commenced on : 2022.03.11 Testing concluded on : 2022.03.22 3.2 Product Description Product Name: Internet Radio Model/Type reference: MA-50CDE Power Supply： DC 9V by Adapter Testing sample ID： MT22030111 Bluetooth : Supported Type: Bluetooth BR/EDR Modulation: GFSK, π/4DQPSK, 8DPSK Operation frequency: 2402MHz~2480MHz Channel number: 79 Channel separation: 1MHz Antenna type: External antenna Antenna gain: 0dBi 3.3 Equipment Under Test Power supply system utilised Power supply voltage : ○ 230V / 50 Hz ● 120V / 60Hz ○ 12 V DC ○ 24 V DC ○ Other (specified in blank below) DC 9V by Adapter 3.4 Short description of the Equipment under Test (EUT) This is a Internet Radio D…

Text truncated - open the document above for the full version.

Model No.: MA-50CDE RE TEST SETUP RE TEST SETUP Model No.: MA-50CDE CE TEST SETUP
