2ABF8-NE101SAPersonal security device

User manual NE101EU Introduction The eNest is an advanced personal mobile emergency device that combines GSM, GPRS, GPS and WiFI technologies to offer the most comprehensive alert and location features. By just pressing an alarm button, the users can call for assistance and get the help they need efficiently. The eNEST is small, lightweight and practical, and has been designed for an everyday use. The device can be worn clipped on, in the pocket of your jacket, or simply in your hand bag, barely unnoticeable yet always accessible. The eNEST is a quad band device and will work on the GSM 850, 900, 1800 and 1900 networks. Precautions and Compliance Precautions Please read these safety instructions to ensure the correct use of your eNEST. 1. Turn your eNEST off during a flight. 2. Do not use your eNEST while driving. 3. Do not touch your eNEST or its power plug with a wet hand while charging. 4. Do not disassemble, repair, or access to the PCB board of your eNEST on your own. 5. Use only NESTWORK approved batteries and accessories. 6. Use only the standard charger cable and plug included with your eNEST. 7.Avoid exposing your eNEST to high temperatures or near a source of heating, such as fire, a stove, or microwave oven. Compliance This equipment is designed to comply with the local legislation in the country it is being sold. If you require any compliance documentation, please contact your local distributor. 1. Features Alarm Features Fixed Time Reporting at a tracking interval. The eNEST will automatically report its position to the NESTWORK platform every fixed cycle. Customer can create as many as four Safe Zones (Geo Fence) in the online platform and configure them to be a circular or rectangular area, or a path. Customer also configures these Safe Zones to be active at all times or during a specific time interval. The eNEST will automatically send an alarm when entering/leaving these active Safe Zones. Pressing emergency side buttons at the same time for 3 seconds will send an alarm signal and current location information to a pre-defined number and/or call center. The eNEST is equipped with a motion sensor, which immediately alerts pre-defined numbers and/or call center in case of an ‘inactivity’ situation, according to the parameters previously set in the online platform. The eNESTis also equipped with a fall detector, so it can be programmedto alert pre-defined numbers and/or call center in case of a ‘fall’ event. Notification Features The eNEST sends out an alert when device is switched on or off. The eNEST sends out an alert when the battery power is low. Speed Sensor sends out an alert when the eNEST device exceeds the Speed Limit previously set in the online platform. If separation between the eNEST and the bracelet occurs, when bracelet has been previously paired to the device, the eNEST will automatically send an alert alerting of this situation. These notifications can be enabled or disabled individually 2. Components AC Power Adaptor Micro-USB charging cable User Manual Rechargeable 700mAh battery (Li-ion) Belt Clip Do not use non genuine parts as it could damage the battery or cause an explosion. 3. Keypad Description Power ON/OFF: - Hold on this key until LED turns on for turning ON/OFF the device Side Buttons: - Press these two buttons simultaneously for 3 seconds for sending a SOS signal - Short pressing any of these buttons will turn screen on for status information Right Button: - Short press this button for answering an incoming call - Short press this button during an alarm countdown for cancelling the alarm process - Short press this button for pairing confirmation during a bracelet pairing sequence 4. Micro USB Interface Description Plug-in the AC power adapter to this interface for battery charging. Device can also be charged by connecting the USB cable to the computer. Plug-in the USB cable and connect it to the computer for Firmware updates and downloads. Due to the used enclosure material, the device shall only be connected to a USB Interface of version 2.0 or higher. The connection to so called power USB is prohibited. 5. Getting started 5.1 Installing the Micro SIM card Open the back cover of the eNEST and remove the battery. Insert the Micro SIM card as shown below, ensuring the gold- coloured contact area of the Micro SIM card is facing downward on the device. Close the SIM card holder and slide it to lock. Slide the battery back in and push it down to lock it into position. Carefully place the back cover back making sure the rubber is not stuck underneath. 4.2 Charging the battery Open the Micro USB cover on the bottom of the device. Connect the USB cable to the Micro USB interface as shown below. Connect the USB cable to a computer’s USB port charger or to an AC wall socket using the AC adapter. The battery level on theStatus Screen of the eNEST will confirm that the eNEST is charging. Please note that you can use the eNEST while it is charging. If the eNEST is not switched on when you are charging it, the battery charge level indicator will still be visible on the screen. When the battery charge level Indicator is full, the charging process is complete and the charger can be disconnected. Charging the battery usually takes between 3 and 5 hours depending on the state of the battery. The adapter shall be installed near the equipment and shall be easily accessible. This charger is for indoor use only. CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS 6. Screen icons Battery Level Low Battery GPRS Signal No GPRS Signal Bracelet Paired Bracelet Not Paired Bracelet Pairing Process SOS Alarm Countdown SOS Alarm Sent SOS Alarm Received SOS Alarm Cancelled FALL Alarm Countdown FALL Alarm Sent FALL Alarm Received FALL Alarm Cancelled INACTIVITY Alarm Countdown INACTIVITY Alarm Sent INACTIVITY Alarm Received INACTIVITY Alarm Cancelled Incoming Call Call in Process Missed Call 7. Operati…

Text truncated - open the document above for the full version.

Date: Jan 14 , 2014 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 Re: THE NEST NETWORK S.L. FCC ID: 2ABF8-NE101SA FCC Part 15C/22/24 Certification Confidentiality Request Gentlemen: This letter is to comply with 47 CFR 0.457 and 0.459 pertaining to confidentiality material. THE NEST NETWORK S.L. requests that the following documents regarding this submission for FCC ID: 2ABF8-NE101SA be kept confidential: Exhibit Type File Name Block Diagram Block Diagram.pdf Schematics Schematics.pdf Operational Description Operation Description.pdf Tune-up Tune-up.pdf Part list BOM.pdf Those documents contain detailed system and equipment description and related information about the product which 2ABF8-NE101SA considers to be confidential proprietary, a custom design and, otherwise, not releasable to the general public. Since this design is a basis form which future technological products will evolve, 2ABF8-NE101SA considers this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Ivy.Zhu General manager

External Photos 1. EUT full view with accessories 2. EUT front view 3. EUT rear view 4. EUT left side view 5. EUT right side view 6. EUT top view 7. EUT bottom view

Label: 30*15mm Label Location

Internal Photos 1. EUT uncover view 2. Mainboard front view with shielding 3. Mainboard rear view 4. Mainboard front view without shielding 5. GSM chip view 6. CPU chip view 7. 2.4G Chip view 8. WiFi chip view 9. GPS chip view 10. GSM antenna view 11. WIFI antenna view 12. GPS antenna view 13. 2.4G antenna view

Report No.: SZ13090062S01A Shenzhen Morlab Communications Technology Co., Ltd Phone: +86 (0) 755 36698555 Web site: http://www.morlab.cn/ Fax: +86 (0) 755 36698525 Email: [email protected] Page 2 of 93 DIRECTORY 1. TESTING LABORATORY .................................................................................................................... 4 1.1 IDENTIFICATION OF THE RESPONSIBLE TESTING LOCATION ................................................................... 4 1.2 ACCREDITATION CERTIFICATE .............................................................................................................. 4 1.3 LIST OF TEST EQUIPMENTS .................................................................................................................. 4 2. TECHNICAL INFORMATION .............................................................................................................. 5 2.1 IDENTIFICATION OF APPLICANT ............................................................................................................. 5 2.2 IDENTIFICATION OF MANUFACTURER ..................................................................................................... 5 2.3 EQUIPMENT UNDER TEST (EUT) .......................................................................................................... 5 2.3.1 PHOTOGRAPHS OF THE EUT ............................................................................................................. 5 2.3.2 IDENTIFICATION OF ALL USED EUT ..................................................................................................... 6 2.4 APPLIED REFERENCE DOCUMENTS ...................................................................................................... 6 2.5 DEVICE CATEGORY AND SAR LIMITS .................................................................................................... 6 2.6 TEST ENVIRONMENT/CONDITIONS ........................................................................................................ 7 3. SPECIFIC ABSORPTION RATE (SAR) .............................................................................................. 8 3.1 INTRODUCTION .................................................................................................................................... 8 3.2 SAR DEFINITION .................................................................................................................................. 8 4. SAR MEASUREMENT SETUP ........................................................................................................... 9 4.1 THE MEASUREMENT SYSTEM ............................................................................................................... 9 4.2 PROBE ................................................................................................................................................ 9 4.3 PROBE CALIBRATION PROCESS ......................................................................................................... 11 4.3.1 DOSIMETRIC ASSESSMENT PROCEDURE .......................................................................................... 11 4.3.2 FREE SPACE ASSESSMENT PROCEDURE .......................................................................................... 11 4.3.3 TEMPERATURE ASSESSMENT PROCEDURE ....................................................................................... 11 4.4 PHANTOM .......................................................................................................................................... 12 4.5 DEVICE HOLDER ................................................................................................................................ 12 5. TISSUE SIMULATING LIQUIDS ........................................................................................................ 13 6. UNCERTAINTY ASSESSMENT ........................................................................................................ 15 Report No.: SZ13090062S01A Shenzhen Morlab Communications Technology Co., Ltd Phone: +86 (0) 755 36698555 Web site: http://www.morlab.cn/ Fax: +86 (0) 755 36698525 Email: [email protected] Page 3 of 93 6.1 UNCERTAINTY EVALUATION FOR EUT SAR TEST ..................................................................... 15 6.2 UNCERTAINTY FOR SYSTEM PERFORMANCE CHECK ............................................................. 16 7. SAR MEASUREMENT EVALUATION ............................................................................................... 18 7.1 SYSTEM SETUP .................................................................................................................................. 18 7.2 VALIDATION RESULTS ........................................................................................................................ 19 8. OPERATIONAL CONDITIONS DURING TEST ................................................................................ 20 8.1 BODY-WORN CONFIGURATIONS .......................................................................................................... 20 8.2 MEASUREMENT PROCEDURE .............................................................................................................. 20 8.3 DESCRIPTION OF INTERPOLATION/EXTRAPOLATION SCHEME ................................................................ 20 9. MEASUREMENT OF CONDUCTED PEAK OUTPUT POWER ........................................................ 22 10. TEST RESULTS LIST ...................................................................................................................... 24 11. MULTIPLE TRANSMITTERS EVALUATION ................................................................................... 26 ANNEX A GRAPH TEST RESULTS ..................................................................................................... 28 Change History Issue Date Reason for change 1.0 Feb. 27, 2014 First edition Report No.: SZ13090062S01A Shenzhen Morl…

Text truncated - open the document above for the full version.

FCC ID: 2ABF8-NE101SA 1. Screen upward 2. Back upward 5mm 5mm FCC ID: 2ABF8-NE101SA 3. Screen upward 4. Back upward FCC ID: 2ABF8-NE101SA 5. Edge A 6. Edge A 5mm FCC ID: 2ABF8-NE101SA Liquid Level Photo Body Liquid Liquid depth: 15.5cm

Report No.SZ13090062W01 Shenzhen Morlab Communications Technology Co., Ltd. Phone: +86 (0) 755 36698555 Web site: http://www.morlab.cn/ Fax: +86 (0) 755 36698525 Email: [email protected] Page 2 of 48 TABLE OF CONTENTS GENERAL INFORMATION ............................................................................................................................. 3 1.1 EUT DESCRIPTION .................................................................................................................................... 3 1.2 TEST STANDARDS AND RESULTS .............................................................................................................. 4 1.3 FACILITIES AND ACCREDITATIONS ............................................................................................................. 5 2. 47 CFR PART 2, PART 22H REQUIREMENTS ..................................................................................... 6 2.1 CONDUCTED RF OUTPUT POWER ............................................................................................................. 6 2.2 PEAK TO AVERAGE RAT I O ........................................................................................................................ 14 2.3 99% OCCUPIED BANDWIDTH ................................................................................................................... 17 2.4 FREQUENCY STABILITY ............................................................................................................................ 24 2.5 CONDUCTED OUT OF BAND EMISSIONS ................................................................................................... 26 2.6 BAND EDGE ............................................................................................................................................. 33 2.7 TRANSMITTER RADIATED POWER (EIRP/ERP) ....................................................................................... 36 2.8 RADIATED OUT OF BAND EMISSIONS ....................................................................................................... 41 Change History Issue Date Reason for change 1.0 2013-11-19 First edition Report No.SZ13090062W01 Shenzhen Morlab Communications Technology Co., Ltd. Phone: +86 (0) 755 36698555 Web site: http://www.morlab.cn/ Fax: +86 (0) 755 36698525 Email: [email protected] Page 3 of 48 GENERAL INFORMATION 1.1 EUT Description EUT Type ............................. : eNest Serial No. ............................. : (n.a, marked #1 by test site) Hardware Version ................ : V4.0 Software Version .................. : Applicant .............................. : Manufacturer ........................ : V1.5.2 The Nest Network S.L. Plaza Republica Argentina 3 Madrid Spain The Nest Network S.L. Plaza Republica Argentina 3 Madrid Spain Frequency Range ................ : GSM 850MHz: Tx: 824.20 - 848.80MHz (at intervals of 200kHz); Rx: 869.20 - 893.80MHz (at intervals of 200kHz) GSM 1900MHz: Tx: 1850.20 - 1909.80MHz (at intervals of 200kHz); Rx: 1930.20 - 1989.80MHz (at intervals of 200kHz) Modulation Type ................... : GSM,GPRS Mode with GMSK Modulation Multislot Class ...................... : GPRS: Multislot Class12 Antenna Type ....................... : PIFA Antenna Emission Designators .......... : GSM 850:247KGXW,GSM 1900:250KGXW Note 1: The transmitter (Tx) frequency arrangement of the Cellular 850MHz band used by the EUT can be represented with the formula F(n)=824.2+0.2*(n-128), 128<=n<=251; the lowest, middle, highest channel numbers (ARFCHs) used and tested in this report are separately 128 (824.2MHz), 190 (836.6MHz) and 251 (848.8MHz). Note 2: The transmitter (Tx) frequency arrangement of the PCS 1900MHz band used by the EUT can be represented with the formula F(n)=1850.2+0.2*(n-512), 512<=n<=810; the lowest, middle and highest channel numbers (ARFCHs) used and tested in this report are separately 512 (1850.2MHz), 661 (1880.0MHz) and 810 (1909.8MHz). Note 3: For a more detailed description, please refer to Specification or User’s Manual supplied by the applicant and/or manufacturer. Report No.SZ13090062W01 Shenzhen Morlab Communications Technology Co., Ltd. Phone: +86 (0) 755 36698555 Web site: http://www.morlab.cn/ Fax: +86 (0) 755 36698525 Email: [email protected] Page 4 of 48 1.2 Test Standards and Results The objective of the report is to perform testing according to 47 CFR Part 2, Part 22 and Part 24 the EUT FCC ID Certification: No. Identity Document Title 1 47 CFR Part 2 (10-1-12 Edition) Frequency Allocations and Radio Treaty Matters; General Rules and Regulations 2 47 CFR Part 22 (10-1-12 Edition) Public Mobile Services 3 47 CFR Part 24 (10-1-12 Edition) Personal Communications Services Test detailed items/section required by FCC rules and results are as below: No. Section Description Result 1 2.1046 Conducted RF Output Power PASS 2. 24.232(d) Peak to average radio PASS 2 2.1049,22.917 24.238 99% Occupied Bandwidth PASS 3 2.1055,22.355 24.235 Frequency Stability PASS 4 2.1051,2.1057 22.917,24.238 Conducted Out of Band Emissions PASS 5 2.1051,2.1057 22.917,24.238 Band Edge PASS 6 22.913,24.232 Transmitter Radiated Power (EIPR/ERP) PASS 7 2.1053,2.1057 22.917,24.238 Radiated Out of Band Emissions PASS NOTE：Measurement method according to TIA/EIA 603.D-2010 Report No.SZ13090062W01 Shenzhen Morlab Communications Technology Co., Ltd. Phone: +86 (0) 755 36698555 Web site: http://www.morlab.cn/ Fax: +86 (0) 755 36698525 Email: [email protected] Page 5 of 48 1.3 Facilities and Accreditations 1.3.1 Facilities Shenzhen Morlab Communications Technology Co., Ltd. Morlab Laboratory is a testing organization accredited by China National Accreditation Service for Conformity Assessment (CNAS) according to ISO/IEC 17025. The accreditation certificate number is L3572. All measurement facilities used to collect the measurement data are located at FL.1, Building A, FeiYang Science Park, No.8 LongChang Road,Block 67, BaoAn District, Shen…

Text truncated - open the document above for the full version.

Test Setup Photos 1. Conducted Spurious Emission 2. Radiated Spurious Emission
