749161-101MadeinChina2014 FCCUserManual OperatingInstructions 15ctSmoothCBulbswithRemote What’sincluded CBulbLightStringwith transformer Remote Control Batteryfor Remote Transformer SafetyInstruction Sheet Operating Instruction Sheet QuickStartGuide What’snext ReadenclosedSafetyInstructionSheetbeforestarting. Removethelights,remotecontrolandbatteryfromthepackagingandfollowtheinstructionsbelow. RemoteControlBatteryInstallation 1.Removetheremotecontrolandbatteryfromtheplasticbag. 2.Openthebatterycoveronthebackoftheremotebyslidingthecovertowardsthebottomoftheremote. 3.Cleanthebatterycontactsandalsothoseofthedevicepriortobatteryinstallation. 4.Useonlythesametype23A,12VAlkalinebatteryforreplacement,useofotherbatteriesmaydamageremote. 5.Insertnegative(-)endofthebattery(seemarkingonbattery)intothespringsideofthebatteryholderandinsertpositive(+) endofthebatteryintotheotherside. 6.Closebatterycoverbyslidingbackintoplace. RemoteControlOperation Theremotehasthreebuttonsonthefrontsidetooperatethe15ctSmoothCBulbsremotecontrolledset: a.POWER––Thisisthelargerbuttonatthetop.PresstoturnthelightsOFF.Pressagaintoturnthelights ON. Note:Evenwhenthelightsareoff,thesetstillhaspowertoalllamps,todisconnectpower,youmustunplug theset. b.FUNCTION–Thisisasmallerbuttoninthemiddle.Presstochangethelightpatterntothenextfunctionmode. Inadditiontothelistbelow,thelightpatternsarealsolistedonthebacksideoftheremote.Afterreaching function7,thesetwillreturntoFunction1bypressingthefunctionbuttonagain.Forbestresults,pausefora fewsecondsbeforepushingthe“FUNCTION”buttonagainforthenextfunction. c.RESET–Thisisasmallerbuttonlocatedonthebottomoftheremote.Thisbuttonisusedifyouhavemultiple setsofthePhilips15ctSmoothCBulblightswithremotecontrol.Thisbuttonallowsyoutosynchronizeallyour setstothesamefunctionbypressingthebuttonaslongasalllightsetsareilluminated(setsdonothavetobe 749161-101MadeinChina2014 connectedtothesameoutlet,theyonlyneedtobewithinrangeoftheremote). TIP–Ifyouwanttoreturntheset(orsetsifyouhavemorethanone)backtoFunction1atanytime,justpushboththe “FUNCTION”and“RESET”buttonsatthesametimeforabout2secondsuntilthesetreturnstoFunction1.Thisresetsthe unitbacktoFunction1soyoucanstartoverandincaseyouarenotsurewhichfunctionyouareon. LightSetFunctions Thelightsetwhenusedinconjunctionwiththeremotecontrolhas7differentpreprogrammedfunctions.Tochangethefunctionsofthe lightset,youmustusetheremotecontrol,soitisimportanttokeepitinasafeplace. Theremotewillworkthroughmostwindowsandwalls,anddoesnotrequirealineofsightbetweentheremoteandlightstring,soyou cancomfortablyusetheremoteinsideyourhometochangeyourlightsifusedoutdoors. LightSetFunctions: 1.Chase–Fadebetweencolors5.Fadeandcolorchange 2.Growingcolorchange6.Fadebetweencolors 3.Singlefastcolorchange7.Flashbetweencolors 4.Chase-Fadecolorchange Thelightsetshaveamemoryofthelastfunctiontheywereusedin.Eachtimeyouturnthemoff(byusingtheremoteorby disconnectingpowertotheset)theywillturnoninthesamefunctiontheywereturnedoffat. NOTE–Ifproductisturnedoffwitharemote,andthenitisattemptedtoturnthemonbyplugginginorturningonawallswitch,the lightswillnotcomeonasitwillrememberthelastfunctionthatitwasturnedoffat,includingiftheremotewasusedtoturnthesetoff. Inthiscase,afterapplyingpowertotheset,turnthelightsonusingthepowerbuttonontheremote. UsingtheSet Pluglightstringintoa110V–125Vwallreceptacle,lightswillturnon.Presspowerbuttononremoteifthey donotturnonwhenfirstpluggedin. Fullyextendtheantennaandpushthebuttonmarked“Function”onremotetoadvancetonextfunction (afterlightsareturnedon). Incaseyouarenotsurewhichfunctionyouareon,youcanreturntheset(s)backtoFunction1(Chase- Fadebetweencolors)bypressingboththe“function”and“reset”buttonsatthesametimeforapproximately 2seconds. Note:theredLEDatthetopoftheremotewillilluminatewitheachpressofabuttonontheremote.Ifthe LEDdoesnotilluminate,installorreplacethebatteryintheremote. AdditionalNotesforUsingaSet: 1.Lightsmustbepluggedintoworkingoutletforthelightsetandremotecontroltofunction. 2.Theremotecontrolunitistheonlywaytochangethefunctionsettingofthisproduct. 3.WhenusingtheremotetoturnyoursetON,theremaybeaslightdelaybeforethelightfunctionstartsworking. 4.Tochangethelightfunction,itisrecommendedtowaitafewsecondsaftereachtimeyoupressthe“FUNCTION”buttonuntil youreachthedesiredfunction. 5.Ifthelightsdonotchangefunctionorthesetdoesnotturnonoroffwiththeremote,seethetroubleshootingsection. 6.Ifthereisapowerinterruption,includingifusedonaswitchedoutlet,onatimer,orpowerfailure,thesystem’smemorywill retainthelastlightfunctiondisplayed. 7.Theoperatingdistanceoftheremoteisupto90feet(27.4meters).Distancemayvaryduetootherradiotransmittersinthe area(cellphones,WiFisignals,wirelessphones,intercoms,babymonitor,etc.),microwaveovens,computers,materialsused intheconstructionofyourhome,trees,hills,bushesandotheritemsthatmayattenuatetheradiosignal. 8.Thebatteryintheremotewilldrainandbecomedepletedveryquicklyiftheremoteisplacedwhereone(orboth)ofthe buttonsontheremotearecontinuallypushed(suchasplacinganitemontopofthem,orstoringtheremoteupsidedown). SynchronizingMultipleSets 1.Plugallthelightstringsintoany110V–125Vwallreceptacle,lightswillturnon.Presspowerbuttononremoteiftheydonot turnonwhenfirstpluggedin.Lightsetsdonothavetobeconnectedendtoendortothesameoutlettobesynchronized,but mustbewithintherangeoftheremotecontrol(upto90feet(27.4meters)distancemayvary). 2.Pleasebesurenottooverloadanyoutletsorextensioncordswhenconnectingmultiplelightstrings. 3.Fullyextendtheantennaontheremote. 4.Pushthepowerbuttonifalllightsarenotalreadyon.Ifonlyoneorseverallightsareon,unplugthosethatareon,andwhile pluggedin,pushthepowerbuttontoturnontherestofthelights,thenreconnecttheotherlightssothatallwillbeon. 749161-101MadeinChina2014 5.Withallremotecontrolsetsturnedon,useanyremotecontrolandpresstheFUNCTIONandRESETbuttonatthesametime forabout2seconds,allsetsshouldreturntofunction1.Ifthisdidnotworkpleasetryitagain. 6.PresstheFUNCTIONbuttonuntilyouhaveselectedthedesiredlightfunctioneffect. 7.Forbestresults,allsetsshouldbeturnedo…

Text truncated - open the document above for the full version.

Revision: 080314A TAIZHOU FENGDENG ELECTRONIC TECHNOLOGY CO.,LTD Request of Confidentiality March 31ˈ2014 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: 2ABG5-TZFDDZKJLV4FR To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. Best Regards Name Chen Pengcheng Title General Manager Tel.: 0576-88033908 / 18605761622 Fax: 0576-88033938 Mail: [email protected]

TAIZHOU FENGDENG ELECTRONIC TECHNOLOGY CO.,LTD Power of Attorney March 31ˈ2014 To whom it may concern: We, the undersigned, (TAIZHOU FENGDENG ELECTRONIC TECHNOLOGY CO.,LTD ) , hereby authorize Bureau Veritas ADT SHANGHAI to act on our behalf in all matters relating to all processes required in the FCC part 15 approval and any communication needed with the national authority. Any and all acts carried out by Bureau Veritas ADT SHAGNHAI on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please do not hesitate to contact us. Thank you! Sincerely yours, ------------------------------------------------------------------- Name Chen Pengcheng Title General Manager Tel.: 0576-88033908 / 18605761622 Fax: 0576-88033938 Mail: [email protected]

Operation theroy 1. Function: on and off, function, reset 2. Transmitter When you press the key, the remote control will transmit 433MHZ signal. The first button controls on and off of lights. The second button controls the functions of lights. The third button controls reset of lights. Receiver When the Receiver Module received the 433MHZ signal, it controls on and off or functions or reset of lights. And there is a button controlling the functions of lights in the receiving controller.
