2ABGH-RC400LXOrbic Speed X (LTE/WCDMA/WIFI)

Getting Started： Thank you for choosing Orbic Speed X 4G LTE mobile hotspot device. Note: This User Guide provides the basic operations of the Orbic Speed X. General Appearance 1. Menu button 2. Signal status icon 3. Network mode icon 4. Wi-Fi signal icon 5.Unread message icon 6. Battery icon 7.Power button 8. USB Type C port 9. Battery cover 10. Cutout to remove back cover Display Layout and Icons Quick Start Guide 1 2 3 456 Description 1. Signal status icon 2. Network mode icon 3. Send/receive data activity arrows 4. Wi-Fi signal and number of access users 5. The number of unread message maximum is 100 6. Battery capacity icon, if battery capacity is lower than 20%, this icon is red. SIM Card and Battery Your Orbic Speed X comes preinstalled with a 4G LTE SIM card. Notes: • The SIM card MUST remain in your Orbic Speed X when in use. Once the SIM card has been inserted into the Orbic Speed X, do not remove! • DO NOT remove SIM card when the device is powered on since this may damage the card and the device. • Do not bend or scratch your SIM card. Avoid exposing your SIM card to static electricity, water or dirt. Removing the 4G LTE SIM Card 1. Power off the Orbic Speed X. Remove the battery cover and take out the battery. 2. Gently remove the SIM card from the SIM card slot Setting up Wi-Fi connection 1. Press and hold the “power” button for 3 seconds until the welcome logo is displayed on the Screen, and Wi-Fi is on. 2. Use your terminal devices to search the wireless network connection with the Wi-Fi’s SSID of “4G-WIFI-2.4G-xxxx ”or “4G-WIFI-5G-xxxx ” and click “Connect”. If the security mechanism is applied, you need to enter the correct PASSWORD. Note: xxxx is the last 4 digits of device MAC. The default password is the latst 8 digits of IMEI. You can also find the default SSID and Password in the WIFI Info page of Orbic Speed X screen. How to change the SSID & Password 1. L og in to http://192.168.1.1 enter the management page. 2. Select Settings> Wireless> WLAN Settings, then you will see “Wi-Fi Name(SSID) ” and “Password”, Make sure you delete the old name and password and enter the new name and password as you require. 3. Select “Apply” button, wait for the screen to display prompting “Success”, and then log out. 4. Wait for the computer or laptop screen to display the Wi-Fi icon. This means the wireless network connection has been successful. Inserting and Charging the Battery 1. Use the thumb catch at the bottom of your Orbic Speed X to open the battery cover and align the battery contacts with the terminals in the battery compartment as shown. Push the battery down until it clicks into place. (Figure 1 and 2) 2. Place the battery cover over the battery compartment and press it downward until it clicks into place. (Figure 3) 3. Your Orbic Speed X comes with charger. To charge: Plug one end of the charger into an electrical outlet and the other end into the Orbic Speed X Type-C Port. (Figure 4) Figure 3 Figure 1 Figure 2 Figure 4 Logging into the Device Management Website 1. Make sure your device is connected to the Orbic Speed X via Wi-Fi. 2. Open the browser, and enter http : //192.168.1.1 in the address bar. 3. Enter username and password, and click “Login”. The administrator has the right to check and modify configuration permission. Note: The default username is admin, the default password is 12$XXX(XXX is the last three digits of IMEI) Restore Factory Settings If you are uncertain of which Wi-Fi settings you have configured or changed, there are two ways you can restore the factory defaults. Option 1: Log into Device Management Website to restore to factory default settings. Option 2: Press and hold “Reset” button in the battery compartment for 5 seconds. See figure 5. Note: Reset button will delete all the device’s user-defined Wi-Fi settings and restore Admin setting and Wi-Fi Setting to factory default. Troubleshooting: If you are having trouble with Orbic Speed X, here are a few things you can do to get it to function properly. 1. If the Orbic Speed X is not responsive, reboot it by press the “Power” button for about 8 seconds 2. Restore factory settings Q&A Q: What do I do if I see the SSID but failed to connect? A: 1. Check the password you entered is the right one. Q: What to do if there is no service? A: The possible reason is listed as below: 1. Unstable local signal. 2. Hardware problem. You can try the following solutions: 1. If you are inside a building or near a structure that may be blocking the signal, change the position or location of the device. For example, try moving the device close to a window. 2. Check the hardware or use another device and retry. Q: What to do if I forget the Wi-Fi Key? A: 1. You can find the Wi-Fi Key in the Wi-Fi Info page on the SCREEN. 2. You can also reset the device to factory defaults by press the reset button for 5 seconds. Q: Data connection failed. A: You have no network coverage. Try moving location until you get good reception. Q: The modem cannot connect to the internet when overseas A: you can check if the data roaming function is enabled in the Device Setting page on the SCREEN. Make sure you have international roaming enabled on your plan. You can contact your service provider before you go overseas to enable roaming. To the Owner • Some electronic devices, such as the electronic system of vehicles, are susceptible to electromagnetic interference sent by your device if inadequately shielded. Please consult the manufacturer of your device before using if necessary. • Operating your device may interfere with medical devices like hearing aids and pacemakers. Please always keep them more than 20 centimeters away from such medical devices when they are turned on. Turn your device off if necessary. Consult a physician or the manufacturer of the medical device before using your device. • Be aware of the usage limitation when using your device at places such as oil warehouses or chemical factories, where there are explosive…

Text truncated - open the document above for the full version.

Reliance Communications LLC Date: 2020/06/29 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 Re: Reliance Communications LLC FCC ID:2ABGH-RC400LX Confidentiality Request Gentlemen: This letter is to comply with 47 CFR 0.457 and 0.459 pertaining to confidentiality material. Reliance Communications LLC requests that the following documents regarding this submission for FCC ID: 2ABGH-RC400LX be kept confidential: Exhibit Type Block Diagram Schematics Operational Description Part list tune-up information File Name Block Diagram.pdf Schematic.pdf Operational description.pdf BOM.pdf tune-up information.pdf Those documents contain detailed system and equipment description and related information about the product which Reliance Communications LLC considers to be confidential proprietary, a custom design and, otherwise, not releasable to the general public. Since this design is a basis form which future technological products will evolve, Reliance Communications LLC considers this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Yours Sincerely, Contact name:Saqib Ghouri Title:Director, Product Management Tel:631-240-8394 Email:[email protected] Company name :Reliance Communications LLC

Reliance Communications LLC Date: 2020/06/29 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: The Reliance Communications LLC the undersigned, hereby authorizes Mrs. Wendy Zhan from Shenzhen Morlab Communications Technology Co., Ltd., to act on the behalf of the Reliance Communications LLC solely in matters relating to the application for an FCC equipment authorization for FCC ID:2ABGH-RC400LX including the signing of documents in connection with this Application. Necessary acts carried out Shenzhen Morlab Communications Technology Co., Ltd. on our behalf of the Reliance Communications LLC in connection with the Application shall have the same effect as acts of the Reliance Communications LLC also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Thank you for your attention to this matter. Yours Sincerely, Signatory: Contact name:Saqib Ghouri Title:Director, Product Management Tel:631-240-8394 Email:[email protected] Company name :Reliance Communications LLC

Declaration To whom it may concern: We have declared below featured for FCC equipment authorization, Device FCC ID: 2ABGH-RC400LX Don't operate on Channels 12 and 13. US 2.4G channel 12-13 and Country code selection are disabled through proprietary software and are not user changeable Should you have any questions, please feel free to contact me. Date:2020/6/29 Signature: Contact Name: Saqib Ghouri Title: Director, Product Management Company name: Reliance Communications LLC

Reliance Communications LLC UNII Declaration Letter We have declared below featured for FCC equipment authorization, device FCC ID: 2ABGH-RC400LX (1) DFS Device -- Master, Client with Radar detection capability , Client without radar detection capability, N/A (2) Active / Passive Scanning , adhoc mode access point capability Frequency Band (MHz) Active Scanning (the device can transmit a probe (beacon)) passive scanning (where the device is can listen only with no probes) Ad Hoc Mode capability Access point capability 2412 – 2462 MHz Yes, No Yes, No Yes, No Yes, No 2422 – 2452 MHz Yes, No Yes, No Yes, No Yes, No 5745 – 5825 MHz Yes, No Yes, No Yes, No Yes, No 5755 – 5795 MHz Yes, No Yes, No Yes, No Yes, No 5180 – 5240 MHz Yes, No Yes, No Yes, No Yes, No 5190 – 5230 MHz Yes, No Yes, No Yes, No Yes, No 5260 – 5320 MHz Yes, No Yes, No Yes, No Yes, No 5270 – 5310 MHz Yes, No Yes, No Yes, No Yes, No 5500 – 5700 MHz Yes, No Yes, No Yes, No Yes, No 5510 – 5670 MHz Yes, No Yes, No Yes, No Yes, No (3) Country code selection ability - Yes , No If no, pls explain how was implemented : Country is selected as US by default and user can not change the country code. (4) Meet 15.202 requirement - Yes , No , pls check below : A master device is defined as a device operating in a mode in which it has the capability to transmit without receiving an enabling signal. In this mode it is able to select a channel and initiate a network by sending enabling signals to other devices A client device is defined as a device operating in a mode in which the transmissions of the device are under control of the master. A device in client mode is not able to initiate a network. (5) For client devices that have software configuration control to operate in different modes (active scanning in some and passive scanning in others) in different bands (devices with multiple equipment classes or those that operate on non-DFS frequencies) or modular devices which configure the modes of operations through software, the application must provide software and operations description on how the software and / or hardware is implemented to ensure that proper operations modes can not be modified by end user or an installer. Apply , No Apply , (If apply , pls help to provide explanation on how it was implement (By hardware or software , and how software was controlled) The device configuration can not be modified by user as program is not exposed to user by any means. Hardware does not allow USB connection for user which is must to change the configuration. If you have any questions, please feel free to contact me at the address shown below. Yours sincerely, Signatory Printed Name: Saqib Ghouri Position: Director, Product Management Company: Reliance Communications LLC

FCC ID:2ABGH-RC400LX IC:20994-RC400LX External Photos 1. EUT front view 2. EUT rear view 3. EUT left side view 4. EUT right side view 5. EUT top view 6. EUT bottom view 7. Accessories

1.Label 2.Labellocation Labelispermanentlyattachedtothedevice

FCC ID:2ABGH-RC400LX IC:20994-RC400LX Internal Photos 1. EUT uncover view 2. Antenna view Main Antenna AUX Antenna WIFI Antenna

REPORT No.：SZ20060021S01 TEST REPORT APPLICANT : Reliance Communications LLC PRODUCT NAME : Orbic Speed X MODEL NAME : RC400LX BRAND NAME : Orbic, Kajeet FCC ID : 2ABGH-RC400LX STANDARD(S) : FCC 47CFR Part 2(2.1093) RECEIPT DATE : 2020-04-16 TEST DATE : 2020-04-22 to 2020-07-14 ISSUE DATE : 2020-07-14 Edited by : Liang Yumei (Rapporteur) Approved by: Peng Huarui (Supervisor) NOTE: This document is issued by MORLAB, the test report shall not be reproduced except in full without prior written permission of the company. The test results apply only to the particular sample(s) tested and to the specific tests carried out which is available on request for validation and information confirmed at our website. MORLAB SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Te l : 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 1 of 97 REPORT No.：SZ20060021S01 DIRECTORY 1. SAR Results Summary ········································································································ 5 2. Technical Information ········································································································· 6 2.1. Applicant and Manufacturer Information ······································································ 6 2.2. Equipment Under Test (EUT) Description ····································································· 6 2.3. Environment of Test Site/Conditions ············································································· 8 3. Specific Absorption Rate (SAR) ························································································ 9 3.1. Introduction ······················································································································· 9 3.2. SAR Definition ··················································································································· 9 4. RF Exposure Limits ··········································································································· 10 5. Applied Reference Documents ························································································ 11 6. SAR Measurement System ······························································································· 12 6.1. E-Field Probe ··················································································································· 13 6.2. Data Acquisition Electronics (DAE) ············································································· 14 6.3. Robot ································································································································ 14 6.4. Measurement Server ······································································································ 14 6.5. Light Beam Unit ·············································································································· 15 6.6. Phantom ··························································································································· 15 6.7. Device Holder ·················································································································· 16 6.8. Data Storage and Evaluation ························································································ 17 6.9. Test Equipment List ······································································································· 20 7. Tissue Simulating Liquids ································································································ 22 8. SAR System Verification ··································································································· 24 8.1. Purpose of System Performance check ······································································ 24 8.2. System Setup ·················································································································· 24 MORLAB SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Te l : 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 2 of 97 REPORT No.：SZ20060021S01 8.3. Validation Results ··········································································································· 25 9. EUT Testing Position ········································································································· 27 9.1. Hotspot Mode Exposure Position Conditions ···························································· 27 10. Measurement Procedures ······························································································ 28 10.1. Spatial Peak SAR Evaluation ······················································································ 28 10.2. Power Reference Measurement ·················································································· 29 10.3. Area Scan Procedures ································································································· 29 10.4. Zoom Scan Procedures ······························································································· 30 10.5. SAR Averaged Methods ······························································································· 30 10.6. Power Drift Monitoring ································································································· 30 11. SAR Test Procedure ········································································································ 31 11.1. General scan Requirements ························································································ 31 11.2. Test procedu…

Text truncated - open the document above for the full version.

REPORT No.：SZ20060021S01 Annex C Plots of System Performance Check MORLAB SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Te l : 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Test Laboratory: Shenzhen Morlab Communications Technology Co., Ltd. Date: 2020.07.10 System Check_750MHz_Head Communication System: UID 0, CW (0); Frequency: 750 MHz;Duty Cycle: 1:1 Medium: HSL_750 Medium parameters used: f = 750 MHz; σ = 0. 93 1 S/m; ε r = 42.14; ρ = 1000 kg/m 3 Ambient Temperature：23.2 °C; Liquid Temperature：22.2 °C DASY5 Configuration: - Probe: ES3DV3 - SN3154; ConvF(6.34, 6.34, 6.34); Calibrated: 2019.07.16; - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn480; Calibrated: 2020.06.02 - Phantom: SAM 1; Type: QD000P40CC; Serial: TP:1471 - Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7331) CW750/Area Scan (81x81x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 2.38 W/kg CW750/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 51.10 V/m; Power Drift = -0.02 dB Peak SAR (extrapolated) = 3.21 W/kg SAR(1 g) = 2.12 W/kg; SAR(10 g) = 1.4 W/kg Maximum value of SAR (measured) = 2.37 W/kg 0 dB = 2.37 W/kg Test Laboratory: Shenzhen Morlab Communications Technology Co., Ltd. Date: 2020.07.01 System Check_835MHz_Head Communication System: UID 0, CW (0); Frequency: 835 MHz;Duty Cycle: 1:1 Medium: HSL_835 Medium parameters used: f = 835 MHz; σ = 0.942 S/m; ε r = 42.881; ρ = 1000 kg/m 3 Ambient Temperature：23.2 °C; Liquid Temperature：22.1 °C DASY5 Configuration: - Probe: EX3DV4 - SN3823; ConvF(9.3, 9.3, 9.3); Calibrated: 2020.01.03; - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn480; Calibrated: 2020.06.02 - Phantom: SAM 1; Type: QD000P40CC; Serial: TP:1471 - Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7331) CW835/Area Scan (81x81x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 2.58 W/kg CW835/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 54.69 V/m; Power Drift = -0.15 dB Peak SAR (extrapolated) = 3.56 W/kg SAR(1 g) = 2.42 W/kg; SAR(10 g) = 1.56 W/kg Maximum value of SAR (measured) = 2.61 W/kg 0 dB = 2.61 W/kg Test Laboratory: Shenzhen Morlab Communications Technology Co., Ltd. Date: 2020.07.09 System Check_1750MHz_Head Communication System: UID 0, CW (0); Frequency: 1750 MHz;Duty Cycle: 1:1 Medium: HSL_1750 Medium parameters used: f = 1750 MHz; σ = 1.448 S/m; ε r = 39.531; ρ = 1000 kg/m 3 Ambient Temperature：23.2 °C; Liquid Temperature：22.5 °C DASY5 Configuration: - Probe: EX3DV4 - SN3823; ConvF(7.99, 7.99, 7.99); Calibrated: 2020.01.03; - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn480; Calibrated: 2020.06.02 - Phantom: SAM 1; Type: QD000P40CC; Serial: TP:1471 - Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7331) CW1750/Area Scan (81x81x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 10.6 W/kg CW1750/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 86.92 V/m; Power Drift = -0.12 dB Peak SAR (extrapolated) = 17.3 W/kg SAR(1 g) = 9.56 W/kg; SAR(10 g) = 5.03 W/kg Maximum value of SAR (measured) = 10.8 W/kg 0 dB = 10.8 W/kg Test Laboratory: Shenzhen Morlab Communications Technology Co., Ltd. Date: 2020.07.08 System Check_1900MHz_Head Communication System: UID 0, CW (0); Frequency: 1900 MHz;Duty Cycle: 1:1 Medium: HSL_1900 Medium parameters used: f = 1900 MHz; σ = 1.389 S/m; ε r = 39.745; ρ = 1000 kg/m 3 Ambient Temperature：23.2 °C; Liquid Temperature：22.3 °C DASY5 Configuration: - Probe: EX3DV4 - SN3823; ConvF(7.74, 7.74, 7.74); Calibrated: 2020.01.03; - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn480; Calibrated: 2020.06.02 - Phantom: SAM 1; Type: QD000P40CC; Serial: TP:1471 - Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7331) CW 1900/Area Scan (81x81x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 11.3 W/kg CW 1900/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 92.63 V/m; Power Drift = 0.01 dB Peak SAR (extrapolated) = 18.4 W/kg SAR(1 g) = 9.97 W/kg; SAR(10 g) = 5.18 W/kg Maximum value of SAR (measured) = 11.2 W/kg 0 dB = 11.2 W/kg Test Laboratory: Shenzhen Morlab Communications Technology Co., Ltd. Date: 2020.07.12 System Check_2300MHz_Head Communication System: UID 0, CW (0); Frequency: 2300 MHz;Duty Cycle: 1:1 Medium: HSL_2300 Medium parameters used: f = 2300 MHz; σ = 1.64 S/m; ε r = 39.251; ρ = 1000 kg/m 3 Ambient Temperature：23.1 °C; Liquid Temperature：22.6 °C DASY5 Configuration: - Probe: EX3DV4 - SN3823; ConvF(7.56, 7.56, 7.56); Calibrated: 2020.01.03; - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn480; Calibrated: 2020.06.02 - Phantom: SAM 1; Type: QD000P40CD; Serial: TP:1471 - Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7331) CW2300/Area Scan (61x61x1): Interpolated grid: dx=1.200 mm, dy=1.200 mm Maximum value of SAR (interpolated) = 16.2 W/kg CW2300/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 72.31 V/m; Power Drift = 0.12 dB Peak SAR (extrapolated) = 16.3 W/kg SAR(1 g) = 11.94 W/kg; SAR(10 g) = 5.73 W/kg Maximum value of SAR (measured) = 16.3 W/kg 0 dB = 16.3 W/kg Test Laboratory: SAR Lab. of Shenzhen Morlab Communications Technology Co., Ltd. Date: 2020.04.22 System Check_2450MHz_Head Communication System: UID 0, CW (0); Frequency: 2450 MHz;Duty Cycle: 1:1 Medium: HSL_2450 Medium parameters used: f = 2450 MHz; σ = 1.87 S/m; ε r = 38.061; ρ = 1000 kg/m 3 Ambient Temperature：23.2 °C; Liquid Temperature：22.1 °C DASY5 Configuration: - Probe: EX3DV4 - SN…

Text truncated - open the document above for the full version.

REPORT No.：SZ20060021S01 Annex D Plots of Maximum SAR Test Results MORLAB SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Te l : 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Test Laboratory: Shenzhen Morlab Communications Technology Co., Ltd. Date: 2020.07.08 WCDMA Band II_RMC 12.2Kbps_Front Side_10mm_Ch9538 Communication System: UID 0, UMTS-FDD (0); Frequency: 1907.6 MHz;Duty Cycle: 1:1 Medium: HSL_1900 Medium parameters used: f = 1908 MHz; σ = 1.41 S/m; ε r = 39.631; ρ = 1000 kg/m 3 Ambient Temperature：23.2 °C; Liquid Temperature：22.3 °C DASY5 Configuration: - Probe: EX3DV4 - SN3823; ConvF(7.74, 7.74, 7.74); Calibrated: 2020.01.03; - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn480; Calibrated: 2020.06.02 - Phantom: SAM 1; Type: QD000P40CC; Serial: TP:1471 - Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7331) Ch9538/Area Scan (71x101x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 1.02 W/kg Ch9538/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 15.83 V/m; Power Drift = 0.12 dB Peak SAR (extrapolated) = 1.57 W/kg SAR(1 g) = 0.911 W/kg; SAR(10 g) = 0.486 W/kg Maximum value of SAR (measured) = 1.02 W/kg 0 dB = 1.02 W/kg Test Laboratory: Shenzhen Morlab Communications Technology Co., Ltd. Date: 2020.07.09 WCDMA Band IV_RMC 12.2Kbps_Back Side_10mm_Ch1513 Communication System: UID 0, UMTS-FDD (0); Frequency: 1752.6 MHz;Duty Cycle: 1:1 Medium: HSL_1750 Medium parameters used: f = 1753 MHz; σ = 1.454 S/m; ε r = 39.5; ρ = 1000 kg/m 3 Ambient Temperature：23.2 °C; Liquid Temperature：22.5 °C DASY5 Configuration: - Probe: EX3DV4 - SN3823; ConvF(7.99, 7.99, 7.99); Calibrated: 2020.01.03; - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn480; Calibrated: 2020.06.02 - Phantom: SAM 1; Type: QD000P40CC; Serial: TP:1471 - Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7331) Ch1513/Area Scan (71x101x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.961 W/kg Ch1513/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 13.88 V/m; Power Drift = 0.08 dB Peak SAR (extrapolated) = 1.15 W/kg SAR(1 g) = 0.868 W/kg; SAR(10 g) = 0.485 W/kg Maximum value of SAR (measured) = 0.970 W/kg 0 dB = 0.970 W/kg Test Laboratory: Shenzhen Morlab Communications Technology Co., Ltd. Date: 2020.07.01 WCDMA Band V_RMC 12.2Kbps_Back Side_10mm_Ch4132 Communication System: UID 0, UMTS-FDD (0); Frequency: 826.4 MHz;Duty Cycle: 1:1 Medium: HSL_835 Medium parameters used: f = 826.4 MHz; σ = 0.928 S/m; ε r = 42.777; ρ = 1000 kg/m 3 Ambient Temperature：23.2 °C; Liquid Temperature：22.1 °C DASY5 Configuration: - Probe: EX3DV4 - SN3823; ConvF(9.3, 9.3, 9.3); Calibrated: 2020.01.03; - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn480; Calibrated: 2020.06.02 - Phantom: SAM 1; Type: QD000P40CC; Serial: TP:1471 - Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7331) Ch4132/Area Scan (71x101x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.923 W/kg Ch4132/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 31.30 V/m; Power Drift = 0.01 dB Peak SAR (extrapolated) = 1.11 W/kg SAR(1 g) = 0.863 W/kg; SAR(10 g) = 0.633 W/kg Maximum value of SAR (measured) = 0.907 W/kg 0 dB = 0.907 W/kg Test Laboratory: Shenzhen Morlab Communications Technology Co., Ltd. Date: 2020.07.08 LTE Band 2_20MHz_QPSK_1RB_0Offset_Back Side_10mm_Ch18900 Communication System: UID 0, LTE (0); Frequency: 1880 MHz;Duty Cycle: 1:1 Medium: HSL_1900 Medium parameters used: f = 1880 MHz; σ = 1.361 S/m; ε r = 39.882; ρ = 1000 kg/m 3 Ambient Temperature：23.2 °C; Liquid Temperature：22. 3 °C DASY5 Configuration: - Probe: EX3DV4 - SN3823; ConvF(7.74, 7.74, 7.74); Calibrated: 2020.01.03; - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn480; Calibrated: 2020.06.02 - Phantom: SAM 1; Type: QD000P40CC; Serial: TP:1471 - Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7331) Ch18900/Area Scan (71x101x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.998 W/kg Ch18900/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 15.97 V/m; Power Drift = 0.02 dB Peak SAR (extrapolated) = 1.25 W/kg SAR(1 g) = 0.925 W/kg; SAR(10 g) = 0.571 W/kg Maximum value of SAR (measured) = 0.995 W/kg 0 dB = 0.995 W/kg Test Laboratory: Shenzhen Morlab Communications Technology Co., Ltd. Date: 2020.07.09 LTE Band 4_20MHz_QPSK_1RB_0Offset_Back Side_10mm_Ch20300 Communication System: UID 0, LTE (0); Frequency: 1745 MHz;Duty Cycle: 1:1 Medium: HSL_1750 Medium parameters used: f = 1745 MHz; σ = 1.438 S/m; ε r = 39.566; ρ = 1000 kg/m 3 Ambient Temperature：23.2 °C; Liquid Temperature：22.5 °C DASY5 Configuration: - Probe: EX3DV4 - SN3823; ConvF(7.99, 7.99, 7.99); Calibrated: 2020.01.03; - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn480; Calibrated: 2020.06.02 - Phantom: SAM 1; Type: QD000P40CC; Serial: TP:1471 - Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7331) Ch20300/Area Scan (71x101x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.793 W/kg Ch20300/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 13.71 V/m; Power Drift = 0.12 dB Peak SAR (extrapolated) = 1.09 W/kg SAR(1 g) = 0.762 W/kg; SAR(10 g) = 0.386 W/kg Maximum value of SAR (measured) = 0.79…

Text truncated - open the document above for the full version.
