Manual I: Make sure fully charge the battery when you start to use the goods (see photos): II: The products can be controlled by the wireless remote in high frequency(433MHZ).The remote is easily operated in 20meters when it is point to the battery box. How to use the remote controller：Match Code The remote controller can control each product separately, also, it can control all of these products if you need. Please check the following steps if you would like to recode it. A) Turn on the battery, the product will glow red light. B) Keep pressing the button Code until the indicator light is twinkling. C) point to the battery box and press any button on the remote controller, the indicator light will turn off, then it finish recoding. D) Repeat these steps if you would like this remote control the other products you want. III: Temperature Range The operation temperature range for fiber optical products is -10~50 . At high temperatures the fiber optical fabrics might be °C melting and deforming, while the embrittlement, breakage and the optical attenuation could be serious at low temperatures. IV: Environment 1. Avoid using fiber optical products in dust, high humidity and smeary environment. The attenuation of the optics and the discoloration of fiber optical surface will be increased if the products surface is smeary and dusty. 2.Ventilated, moistureproof and waterproof measures must be taken while in transportation and storage, as in this kind of environment will damage the fabric. 3. Avoid exposing to the UV radiation directly and using fiber optical products under the high energy ray situation. 4. Avoid putting products together with plasticizer or polymer materials with plasticizer. The plasticizer might transfer to the product surface, which led to the serious decrease of the optics. The products should be protected from the influence from organic chemicals, including propiophenone, ethyl acetate, diluent, petrol and so on. V: Usage & Washing 1. Never fold the fiber optical fabric perpendicularly to the fiber optics, otherwise this may permanently damage or break its optics.Never pull, distort and fold into dead angles, otherwise the products will be deformed and breakdown. 2. Prevent the cladding of fiber optics from scratching and destroying, otherwise luminescence performance attenuate. 3. Prevent products bearing the external forces for long term. 4. Do handle with care to avoid breaking the fiber optics while using, because there are many processing points on the surface. 5. Don’t put the products into the water,because there is circuit inside.Products can be wiped with soft wet towel if there are stains.Wiped by using neutral detergent if necessarily, then simply place it on a clothes hanger and keep it in shade to dry. Checked the photos enclosed: 6. Charge the battery timely when the light is getting dim. 7. Quality Guarantee:We are aimed to offering high quality products and perfect after-sale services.One year warranty for our electronic component, except for damaged by human factors. Dirty Product Step1: Spray cleaning fluid Step 2: Scrub with a wet towel Step 3: With step 2 till clean FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter.

SZ Fashion Luminous Clothing Co.,Ltd Model Difference FCC ID: 2ABGTYQ-42 Model : YQ-01,YQ-02,YQ-04,YQ-06,YQ-07, YQ-08,YQ-09,YQ-24,YQ-25,YQ-26, YQ-27,YQ-39,YQ-41,YQ-30,YQ-12, YQ-40,YQ-43-YQ-50,YQ-57, YQ-42 All the models are the same circuit and RF module, except the mode names and color. Regards, Client’s signature Signature Name: Mo Li Title: Manager Tel: 0755-89397759

775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 SZ Fashion Luminous Clothing Co.,Ltd SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 2013/11/30 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, SZ Fashion Luminous Clothing Co.,Ltd __hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product： luminous clothes with remote controller Trade Name： N/A Serial Model： YQ-42 Model Name： YQ-01,YQ-02,YQ-04,YQ-06,YQ-07, YQ-08,YQ-09,YQ-24,YQ-25,YQ-26, YQ-27,YQ-39,YQ-41,YQ-30,YQ-12, YQ-40,YQ-43-YQ-50,YQ-57, FCC ID： 2ABGTYQ-42 We affirm that between SIEMIC and ___ SZ Fashion Luminous Clothing Co.,Ltd ___ , any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature Signature Name: Mo Li Title: Manager Tel: 0755-89397759

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 SZ Fashion Luminous Clothing Co.,Ltd 2013-11-30 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ABGTYQ-42 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Sincerely, Client’s signature Signature Name: Mo Li Title: Manager Tel: 0755-89397759

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6

APPENDIX A - PRODUCT LABELING Proposed FCC ID Label Format Label size: 60mm*40mm 55mm 30mm Company: SZ Fashion Luminous Clothing Co.,Ltd Name: Luminous clothing Model Number: YQ-42 FCC ID: 2ABGTYQ-42 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

Photo 7 Photo 8 ANT Photo 9

FCC RADIO TEST REPORT FCC ID: 2ABGTYQ-42 Product： luminous clothes with remote controller Trade Name： N/A Model Name： YQ-42 Serial Model： YQ-01,YQ-02,YQ-04,YQ-06,YQ-07, YQ-08,YQ-09,YQ-24,YQ-25,YQ-26, YQ-27,YQ-39,YQ-41,YQ-30,YQ-12, YQ-40,YQ-43-YQ-50,YQ-57 Report No.： BZT2013NT1108298F Prepared for SZ Fashion Luminous Clothing Co.,Ltd 8/F, Building A, Hong Sheng Yuan Industrial Zone, Bu Long road No.339, Ban Tian, Shenzhen, China Prepared by BZT Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China Page 2 of 25 Report No.: BZT2013NT1108298F ` TEST RESULT CERTIFICATION Applicant’s name ................. : SZ Fashion Luminous Clothing Co.,Ltd Address ................................. : 8/F, Building A, Hong Sheng Yuan Industrial Zone, Bu Long road No.339, Ban Tian, Shenzhen, China Manufacture's Name ............ : SZ Fashion Luminous Clothing Co.,Ltd Address ................................. : 8/F, Building A, Hong Sheng Yuan Industrial Zone, Bu Long road No.339, Ban Tian, Shenzhen, China Product description Product name ........................... : luminous clothes with remote controller Model and/or type reference : YQ-42 Serial Model： YQ-01,YQ-02,YQ-04,YQ-06,YQ-07, YQ-08,YQ-09,YQ-24,YQ-25,YQ-26, YQ-27,YQ-39,YQ-41,YQ-30,YQ-12, YQ-40,YQ-43-YQ-50,YQ-57 Rating(s) ................................ : DC 12V Standards ............................. : FCC Part15.231 Test procedure ..............................ANSI C63.4-2003 This device described above has been tested by BZT, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BZT, this document may be altered or revised by BZT, personal only, and shall be noted in the revision of the document. Date of Test ............................................ : Date (s) of performance of tests ............. : 20 Nov. 2013 ~30 Nov. 2013 Date of Issue ........................................... : 30 Nov. 2013 Test Result ............................................... : Pass Testing Engineer : (Apple Huang) Technical Manager : (Tom Zhang) Authorized Signatory : (Bovey Yang) Page 3 of 25 Report No.: BZT2013NT1108298F ` Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 TEST FACILITY 5 1.2 MEASUREMENT UNCERTAINTY 5 2 . GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 DESCRIPTION OF TEST MODES 7 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 8 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 9 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 10 3 . ANTENNA REQUIREMENT 11 3.1 STANDARD REQUIREMENT 11 3.2 EUT ANTENNA 11 3.3 CONDUCTED EMISSION MEASUREMENT 12 3.3.1 POWER LINE CONDUCTED EMISSION LIMITS 12 3.3.2 TEST PROCEDURE 13 3.3.3 DEVIATION FROM TEST STANDARD 13 3.3.4 TEST SETUP 13 3.2.5 TEST RESULT 14 3.4 RADIATED EMISSION MEASUREMENT 15 3.4.1 RADIATED EMISSION LIMITS 15 3.4.2 TEST PROCEDURE 16 3.4.3 DEVIATION FROM TEST STANDARD 16 3.4.4 TEST SETUP 16 3.4.5 TEST RESULTS (BLOW 30MHZ) 18 3.4.6 TEST RESULTS (BETWEEN 30 – 1000 MHZ) 19 4 . BANDWIDTH TEST 22 4.1 TEST PROCEDURE 22 4.2 DEVIATION FROM STANDARD 22 4.3 TEST SETUP 22 4.4 TEST RESULTS 23 5 . TRANSMITTER TIMEOUT 24 5.1 REQUIREMENTS 24 6 . EUT TEST PHOTO 25 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 4 of 25 Report No.: BZT2013NT1108298F ` 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15, Subpart C (15.231) Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A Note(1) 15.203 Antenna Requirement Pass 15.231 Radiated Spurious Emission Pass 15.231 Occupied Bandwidth Pass 15.231 Deactivation Time Pass NOTE: (1) ” N/A” denotes test is not applicable in this Test Report. Page 5 of 25 Report No.: BZT2013NT1108298F ` 1.1 TEST FACILITY BZT Testing Technology Co., Ltd. Add.:1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registered No.: 701733 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 6 of 25 Report No.: BZT2013NT1108298F ` 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment luminous clothes with remote controller Trade Name N/A Model Name YQ-42 Serial Model YQ-01,YQ-02,YQ-04,YQ-06,YQ-07,YQ-08,YQ-09, YQ-24,YQ-25,YQ-26,YQ-27,YQ-39,YQ-41,YQ-30, YQ-12,YQ-40,YQ-43-YQ-50,YQ-57 Model Difference Only model name is different. Product Description The EUT is a luminous clothes with remote controlle r Product Type Remote Control Operation Frequency: 433.92MHz Modulation Type: FSK Number Of Channel 1CH. Antenna Designation: PCB antenna Antenna Gain(Peak) 0.8dBi Output Power: 68.94 dBuV/m @3m(AV Max.) Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specification, please refer to the User's Manual. Channel List N/A Adapter N/A Battery DC 12V Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. 2. Table for Filed Antenna Ant . Brand Model Name Antenna Type Connector Gain (dBi) NOTE 1 N/A N/A PCB antenna NA 0.8 Antenna Page 7 of 25 Report No.: BZT2013NT1108298F ` 2.2 DESCRIPTION OF TEST MODES To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mode or test config…
