2ABHJ-ADNP2014ADnP FM Transmitter, Technology for any car radio

Model # ADnP2014 FCC ID: 2ABHJ-ADNP2014 Model # ADNnP2014 FCC ID: 2ABHJ-ADNP2014 Model # ADnP2014 FCC ID: 2ABHJ-ADNP2104 ALPHA DESIGN AND PRODUCTS, INC. is introducing its Transcend Edition of High Performance FM Transmitter Device Your reliable solution for all your audio needs User’s Manual High-Quality FM Transmitter Device for Any Music and Media Streaming Devices INTRODUCTION Congratulation and THANK you for choosing ADnP’s high performance FM transmitter device as your HD sound quality audio solution and music needs within your automobile. Alpha Design and Products’ H.D. sound quality FM transmitter device is designed to empower music lovers to connect any of their media streaming devices to the car radio system and enjoy listening to their favorite tunes without the hassle of interference, crosstalk, or noise stemming from other FM radio channels and external sources. SETUP INSTRUCTION ADnP’s high performance FM transmitter device is designed to operate at 100.1 MHZ radio FM band. It does not have an On / Off switch. The module will turn on and starts audio signal transmission when its USB power cable is connected to power via a USB car charger as shown in figure 1. The recommended steps to properly operate this module are listed below: 1. Connect the USB power cable via a USB car charger to the cigarette lighter power source. 2 3. Set the FM radio channel to 100.1 MHZ. 4. Start enjoying your favorite music. . Connect you music / Mp3 player to the 3.5 mm audio cable SETUP INSTRUCTION (Continued) Figure 1. SUPERIOR QUALITY, HIGH PERFORMANCE, & RELIABLE BUILT IN USA AUDIO SETUP Connect the 3.5 mm audio cable to the analog I/O port of your media streaming device. To get the best audio performance and preventing audio dynamic range distortion, set the volume of your music player to approximately 80% of its maximum range. See figure 2. From this starting point, you can increase or decrease the volume appropriately. Figure 2. POWER CONNECTION SETUP This high performance FM transmitter module requires a DC voltage source ranging from 5V to 12V. We highly recommend users NOT to exceed the above input voltage to avoid permanent damage to their product. FCC STATEMENT This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device generates, uses, and radiates radio frequency energy and if not used in accordance with the instructions expressly approved by the manufacturer and the party responsible for compliance, the product’s warranty and User’s authority to operate the product is voided. Alpha Design and Products, Inc. model # ADnP2014 FCC ID: 2ABHJ-ADNP2014 LIMITED 1 YEAR WARRANTY Alpha Design and Products, Inc (ADnP) warrants the included hardware against defects in material and workmanship for one year from the date of original retail purchase. ADnP does not warrant against normal wear and tear, nor damage caused by accident or abuse. If a defect is discovered, ADnP will, at its option, repair or replace the product at no charge provided it is returned during the warranty period, with transportation prepaid, to the authorized dealer from whom you purchased the product. Proof of purchase will be required. This warranty does not apply if this product has been damaged by accident, abuse, misuse, misapplication, or tampered with in any way, shape, or form; if the product has been modified without written permission of ADnP; or if any ADnP serial number has been removed or defaced. THE WARRANTY AND REMEDIES SET FORTH ABOVE ARE EXCLUSIVE IN LIEU OF ALL OTHERS, WHETHER ORAL OR WRITTEN, EXPRESSED, OR IMPLIED. ADnP SPECIFICALLY DISCLAIMS ANY AND ALL IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION, WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. No ADnP dealer, agent, or employee is authorized to make any modification, extension or addition to this warranty. ADnP IS NOT RESPONSIBLE FOR SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGE RESULTING FROM ANY BREACH OF WARRANTY, OR ANY OTHER LEGAL THEORY, INCLUDING BUT NOT LIMITED TO, LOST PROFITS, DOWNTIME, GOODWILL, DAMAGE TO OR REPROGRAMMING, OR REPRODUCING ANY PROGRAM OR DATA STORED IN OR USED WITH ADnP PRODUCT. Figure 3.

ALPHA DESIGN AND PRODUGTS, INC. June 3,2014 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Subject Request for Permanent Confidentiality To whom it may concern: In accordance with 47CFR Section 0.457 and Section 0.459 pertaining to confidential material, we hereby request to hold permanently confider*ial att information contained within the below identified exhibits/do*u*rot categories submitted pursuant to radio equipment certification requirements for FCC ID: 2ABHJ-ADNP2014 1. Block Diagram 2. Antenna design and specification 3. Schematics 4. Parts List / Tune-Up Procedure / Bill Of Material (BOM) j. IC part numbers aid tdentification that can be taken or identifiedfrom internal photos. Thirefore, ICs must be either covered with tape of epoxy to prevent others from collecting part numbers and manufocturer ID 6. Engineering Operation of ADtP FM Transmitter The above material contains trade secrets and proprietary information as specified by 47CFR A.457(d) and technic al dxarwhich would customarily be guarded from competitors. The public disclosure of this information might be harrrful to our company and provide unjustified benefits to our competitors. President Alpha Design and Products, lnc 3572 Skyline Drive Hayward, CA94542 Abdul Wali

Model # ADNnP2014 FCC ID: 2ABHJ-ADNP2014

This report contains a total of 21 pages and may be reproduced in full only. Partial reproduction may only be done with the written consent of CKC Laboratories, Inc. Alpha Design and Products, Inc. ADDENDUM TO TEST REPORT 95441-8 FM Transmitter Device Model: ADnP_FMTX Tested To The Following Standards: FCC Part 15 Subpart C Section(s) 15.239 Report No.: 95441-8A Date of issue: June 6, 2014 This test report bears the accreditation symbol indicating that the testing performed herein meets the test and reporting requirements of ISO/IEC 17025 under the applicable scope of EMC testing for CKC Laboratories, Inc. We strive to create long-term, trust based relationships by providing sound, adaptive, customer first testing services. We embrace each of our customers’ unique EMC challenges, not as an interruption to set processes, but rather as the reason we are in business. Page 2 of 21 Report No.: 95441-8A TABLE OF CONTENTS Administrative Information .......................................................................................................................... 3 Test Report Information ............................................................................................................................................ 3 Revision History ......................................................................................................................................................... 3 Report Authorization ................................................................................................................................................. 3 Test Facility Information ............................................................................................................................................ 4 Software Versions ...................................................................................................................................................... 4 Site Registration & Accreditation Information .......................................................................................................... 4 Summary of Results ................................................................................................................................................... 5 Conditions During Testing.......................................................................................................................................... 5 Equipment Under Test ............................................................................................................................................... 7 Peripheral Devices ..................................................................................................................................................... 7 FCC Part 15 Subpart C ................................................................................................................................... 8 15.239(a) Occupied Bandwidth ................................................................................................................................. 8 15.239(b) RF Power Output ..................................................................................................................................... 10 15.239(c) Field Strength of Radiated Spurious Emissions and Band Edge ............................................................... 13 Supplemental Information .......................................................................................................................... 20 Measurement Uncertainty ...................................................................................................................................... 20 Emissions Test Details .............................................................................................................................................. 20 Page 3 of 21 Report No.: 95441-8A ADMINISTRATIVE INFORMATION Test Report Information REPORT PREPARED FOR: REPORT PREPARED BY: Alpha Design and Products, Inc. 3572 Skyline Drive Hayward, CA 94542 Morgan Tramontin CKC Laboratories, Inc. 5046 Sierra Pines Drive Mariposa, CA 95338 REPRESENTATIVE: Wali Rousta Project Number: 95441 DATE OF EQUIPMENT RECEIPT: May 14, 2014 DATE(S) OF TESTING: May 14-15, 2014 Revision History Original: Testing of the FM Transmitter Device, ADnP_FMTX to FCC Part 15 Subpart C Section 15.239. Addendum A: During the certification evaluation the following modifications were requested to be added to the report: the Band Edge data, the antenna setup photo, the Dual Universal USB Car Charger setup photo, and detailed information on the modifications were added to the Conditions During Testing table. Report Authorization The test data contained in this report documents the observed testing parameters pertaining to and are relevant for only the sample equipment tested in the agreed upon operational mode(s) and configuration(s) as identified herein. Compliance assessment remains the client’s responsibility. This report may not be used to claim product endorsement by A2LA or any government agencies. This test report has been authorized for release under quality control from CKC Laboratories, Inc. Steve Behm Director of Quality Assurance & Engineering Services CKC Laboratories, Inc. Page 4 of 21 Report No.: 95441-8A Test Facility Information Our laboratories are configured to effectively test a wide variety of product types. CKC utilizes first class test equipment, anechoic chambers, data acquisition and information services to create accurate, repeatable and affordable test results. TEST LOCATION(S): CKC Laboratories, Inc. 110 Olinda Place Brea, CA 92823 Software Versions CKC Laboratories Proprietary Software Version EMITest Emissions 5.00.14 Immunity 5.00.07 Site Registration & Accreditation Information Location CB # TAIWAN CANADA FCC JAPAN Brea A US0060 SL2-IN-E-1146R 3082D-1 90473 A-0147 Page 5 of 21 Report No.: 95441-8A SUMMARY OF RESULTS Standard / Specification: FCC Part 15 Subpart C Tes…
