2ABHV-ANUDGERRemote control vibrating silicon bracelet

Wireless Intelligent vibration sensor YET-FR3 Basic functions: After pairing between the remote control and the sensor has triggered the remote control, the sensor can sense the radio signals emitted by remote control, so that the sensor vibrates, thereby alerting the owner. Learning: Press the button is pressed on the sensor and hold the sensor vibrating long after the first LED lights, release the button pressing LED off; pressing need to learn the remote control button and hold the vibration sensor LED blinks twice while 2, which means that the remote control and sensor paired. Repeat the above actions can learn more about the remote control, the sensor can learn up to 20 remote control. Clean code: Press the button is pressed on the sensor and hold the sensor vibration long after the first LED light, keeping the button pressed more than 5 seconds, LED goes out three times after vibration sensor, said sensor before learning all the remote control is removed a. Low reminder: When the sensor voltage is less than 3V, the sensor automatically every 20 seconds a short vibration, which means that the sensor's battery voltage is low, to remind users to charge. Charging using ordinary USB charging cable and connected to the sensor LED grow lights, you can charge one hour. Remote control to activate the sensor: When you need to make the sensor can send vibration warning signal when paired with only the need to trigger remote control can be. If the remote sensor receives the signal, will be shown to continuous vibration alert 3 seconds. To ensure that the temperature sensor can receive, remote control trigger time be sure to keep more than 3 seconds. Sensors can receive remote control commands distances greater than 15 meters, but the distance is too far, the sensor may be unable to receive remote control signals. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Company: Shenzhen Primus Technology CO., LTD Name: Remote control vibrating silicon bracelet Model Number: aNudger FCC ID: 2ABHV-ANUDGER

Shenzhen Primus Technology CO., LTD Date: 26.12.2013 Authority to Act as an Agent We declare that the following representative (agent) Name Mark Zhu Position Manager Company Name Shenzhen Certification Technology Service Co., Ltd. Address 2F, Building B, East Area of Nanchang Second Industrial Zone, Gushu 2 nd Road, Bao’an District, Shenzhen 518126, P.R. China Tel / Fax 0755-86375541/0755-26736857 Email [email protected] to act on our behalf on all matters concerning the application and documents submitted to PHOENIX TEST-LAB for product certification below Product Name Remote control vibrating silicon bracelet Model Name aNudger Brand Name N/A . Yours sincerely, Signatory Name Peter Yang Position Engineer Company Name Shenzhen Primus Technology CO., LTD Address Room 401, Taohuayuan hi-tech park, Bao’an district, Shenzhen, China Tel +86-755-89509951 Fax +86-755-28445133 Email [email protected] In case of FCC, we certify that we are not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance.

Shenzhen Primus Technology CO., LTD Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Request for Confidentiality Company name: Shenzhen Primus Technology CO., LTD FCC ID : 2ABHV-ANUDGER FCC Part 15 Certification Gentlemen, Pursuant to 47 CFR 0.457(d)(1)(ii) and 0.459 we hereby requests permanent confidentiality of the following documents for the subject application: Exhibit Type Description ☒ Schematics All circuitry of devices and component values ☒ Block Diagrams Details of device showing the frequency of all oscillators ☒ Operational Description Description of the circuit functions Note: Exhibit types that are commonly held confidential are: (1) Schematics, (2) Block Diagrams, (3) Bill Of Materials, (4) Operational Descriptions. Any exhibit NOT granted confidentiality is viewable on the FCC website as soon as a grant is issued. These documents contain detailed system and equipment description and related information about the product which we considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, we consider that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Yours sincerely, Signatory Name Peter Yang Position Engineer Company Name Shenzhen Primus Technology CO., LTD Address Room 401, Taohuayuan hi-tech park, Bao’an district, Shenzhen, China Tel +86-755-89509951 Fax +86-755-28445133 Email [email protected]

10mm 5mm FCC ID: 2ABHV-ANUDGER

Label Location

ANTENNA

Shenzhen Certification Technology Service Co., Ltd 2F, Building B, East Area of Nanchang Second Industrial Zone, Gushu 2nd Road, Bao'an District, Shenzhen 518126, P.R. China. FCC ID: 2ABHV-ANUDGER Page 1 of 29 TEST REPORT FCC ID: 2ABHV-ANUDGER Applicant : Shenzhen Primus Technology CO., LTD Address : Room 401, Taohuayuan hi-tech park, Bao’an district, Shenzhen, China Equipment under Test (EUT): Name : Remote control vibrating silicon bracelet Model : aNudger Standards : FCC PART 15, SUBPART C : 2012 (Section 15.231) Report No. : ST-TCB131204002 Date of Test : December 09-24, 2013 Date of Issue : December 25, 2013 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above Authorized Signature (Mark Zhu) General Manager The manufacture should ensure that all the products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of Shenzhen Certification Technology Service Co., Ltd. Or test done by Shenzhen Certification Technology Service Co., Ltd. Approvals in connection with, distribution or use of the product described in this report must be approved by Shenzhen Certification Technology Service Co., Ltd. Approvals in writing. Report No.: ST-TCB131204002 FCC ID: 2ABHV-ANUDGER Page 2 of 29 TABLE OF CONTENT Description Page 1 General Information------------------------------------------------------------------------------------3 1.1 Description of Device (EUT)---------------------------------------------------------------------3 1.2 Description of Test Facility-----------------------------------------------------------------------3 2 EMC Equipment List-----------------------------------------------------------------------------------4 3 Test Procedure------------------------------------------------------------------------------------------5 4 Summary of Measurement---------------------------------------------------------------------------6 4.1 Summary of test result-----------------------------------------------------------------------------6 4.2 Block Diagram--------------------------------------------------------------------------------------6 4.3 Assistant equipment used for test----------------------------------------------------------------6 4.4 Test Conditions-------------------------------------------------------------------------------------7 4.5 Measurement Uncertainty (95% confidence levels, k=2)-------------------------------------7 5 Radiation Emission------------------------------------------------------------------------------------8 5.1 Radiation Emission Limits(15.209&231)-------------------------------------------------------8 5.2 Test Setup--------------------------------------------------------------------------------------------8 5.3 Test Procedure-------------------------------------------------------------------------------------10 5.4 Test Equipment Setting For emission test.-----------------------------------------------------11 5.5 Test Condition-------------------------------------------------------------------------------------11 5.6 Test Result------------------------------------------------------------------------------------------11 6 POWER LINE CONDUCTED EMISSION-------------------------------------------------------16 6.1 Conducted Emission Limits(15.209)-----------------------------------------------------------16 6.2 Test Setup-------------------------------------------------------------------------------------------16 6.3 Test Procedure-------------------------------------------------------------------------------------17 6.4 Test Results-----------------------------------------------------------------------------------------17 7 Occupied bandwidth---------------------------------------------------------------------------------18 7.1 Test limit--------------------------------------------------------------------------------------------18 7.2 Method of measurement--------------------------------------------------------------------------18 7.3 Test Setup-------------------------------------------------------------------------------------------18 7.4 Test Results-----------------------------------------------------------------------------------------18 8 Transmission time------------------------------------------------------------------------------------20 8.1 Test limit--------------------------------------------------------------------------------------------20 8.2 Method of measurement--------------------------------------------------------------------------20 8.3 Test Setup-------------------------------------------------------------------------------------------20 8.4 Test Results-----------------------------------------------------------------------------------------20 9 Band Edge Check-------------------------------------------------------------------------------------22 9.1 Test limit--------------------------------------------------------------------------------------------22 9.2 Test Procedure-------------------------------------------------------------------------------------22 9.3 Test Setup-------------------------------------------------------------------------------------------22 9.4 Test Result------------------------------------------------------------------------------------------22 10 Antenna Requirement-------------------------------------------------------------------------------23 10.1 Standard Requirement----------------------------------------------------------------------------23 10.2 Antenna Connected Construction---------------------------------------------------------------23 10.3 Result------------------------------------------------------------------------------------------------23 11 Photographs of Test Setup----------------------------------------------------------…

Text truncated - open the document above for the full version.

Radiated Emission Test Setup in Chamber
