1 Door / Window Alarm POCSAG Transmitter Model No. WD2 Operation Manual 2 The WD2 Door/window alarm transmitter is designed to directly page security persons with t he magnet switch activation either from the open to close or close to open status. There are no wire connections necessary. And the installation is easy and simple for all kinds of operations. If the door or window is opened, it will activate the call alarm and send a message out to the set paging receiver. More of the various paging features can be set easily by the PC programming process. It is easy to program and set up with the desired pager frequency, capcode, data rate, repeat t ime etc functions. Notice : The changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. IMPORTANT NOTE: To comply with the FCC RF exposure compliance requirements, no change to the antenna or the device is permitted. Any change to the antenna or the device could result in the device exceeding the RF exposure requirements and void user's authority to operate the device. 3 Main Features •Fast response • Direct to pagers •Easy installation •Easy operation •No wires installation •No power cord •Antenna inside • Long distance •Long battery life •Frequency synthesized •New EU frequency correspond •Place on the door or window •2 Magnet switches inside • Programming via micro USB by PC •Auto send battery low alarm message 4 A. How to change WD2 battery 1). Open the WD2 battery cover 2). Then changes with the new CR2032 battery +Positive side UP 5 Wireless Devices Inc. Taiwan www.wirelessdevices.com.tw July.2013

Wireless Devices Inc. (Taiwan) 8 FL., No. 56, LE-QUN 3rd Road, Taipei 104, Taiwan. Tel (8862) 85020001 Fax. (8862) 85023576 Date: July.9.2014 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 c.c. UL Verification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize ELECTRONICS TESTING CENTER, TAIWAN, and hereafter referred to as ETC, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by ELECTRONICS TESTING CENTER, TAIWAN, on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing ETC as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Robert Yang / General Manager Wireless Devices Inc. Taiwan. 8th FL., No. 56, LE-QUN 3rd Road, Taipei 104, Taiwan. REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us. 3. Authorized signature must be in agreement with grantee code contact in FCC database.

Wireless Devices Inc. (Taiwan) 8 FL., No. 56, LE-QUN 3rd Road, Ta ipei 104, Taiwan. Tel (8862) 85020001 Fax. (8862) 85023576 F ederal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: 2ABL6WD2 T o Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Bl ock Diagram Theory of Operation A bove mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards Robert Yang / General Manager Wireless Devices Inc. Taiwan. 8th FL., No. 56, LE-QUN 3rd Road, Taipei 104, Taiwan.

ETC Report No.:14-07-RBF-027-01 Sheet 1 of 4 Sheets FCC ID:2ABL6WD2 Rev. No 1.0 CONSTRUCTED PHOTOS of EUT 1. 2. ETC Report No.:14-07-RBF-027-01 Sheet 2 of 4 Sheets FCC ID:2ABL6WD2 Rev. No 1.0 CONSTRUCTED PHOTOS of EUT 3. 4.

30*20 mm FCC ID: 2ABL6WD2 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

ETC Report No.:14-07-RBF-027-01 Sheet 3 of 4 Sheets FCC ID:2ABL6WD2 Rev. No 1.0 CONSTRUCTED PHOTOS of EUT 5. 6. ETC Report No.:14-07-RBF-027-01 Sheet 4 of 4 Sheets FCC ID:2ABL6WD2 Rev. No 1.0 CONSTRUCTED PHOTOS of EUT 7. 8.

Rev. No 1.0 FCC Part 15 EMI TEST REPORT of E.U.T. : Door/Window Alarm FCC ID : 2ABL6WD2 MODEL : WD2 Workin g Frequency : 433.92 MHz for APPLICANT : Wireless Devices Inc. ADDRESS : 8th FL., No. 56, LE-QUN 3rd Road, Taipei 104, Taiwan. Test Performed by ELECTRONICS TESTING CENTER, TAIWAN NO. 34. LIN 5, DINGFU VIL., LINKOU DIST., NEW TAIPEI CITY, TAIWAN, 24442, R.O.C. TEL : (02)26023052 Fax : (02)26010910 http://www.etc.org.tw ; e-mail: [email protected] Report Number : 14-07-RBF-027-01 ETC Report No.14-07-RBF-027-01 FCC ID:2ABL6WD2 Rev. No 1.0 TEST REPORT CERTIFICATION Applicant : Wireless Devices Inc. 8th FL., No. 56, LE-QUN 3rd Road, Taipei 105, Taiwan. Manufacturer : Wireless Devices Inc. 8th FL., No. 56, LE-QUN 3rd Road, Taipei 105, Taiwan. Description of EUT : a) Type of EUT : Door/Window Alarm b) Trade Name : ---- c) Model No. : WD2 d) FCC ID : 2ABL6WD2 e) Working Frequency : 433.92 MHz f) Power Supply : DC 3.0V Regulation Applied : FCC Rules and Regulations Part 15 Subpart C I HEREBY CERTIFY THAT; The data shown in this report were made in accordance with the procedures given in ANSI C63.4 (2003) and the energy emitted by the device was founded to be within the limits applicable. I assume full responsibility for accuracy and completeness of these data. Note : 1. The results of the testing report relate only to the items tested. 2. The testing report shall not be reproduced except in full, without the written approval of ETC. Summary of Tests Test Results Radiated Emission Pass Bandwidth of Emision Pass Conducted Emission N/A ETC Report No.14-07-RBF-027-01 FCC ID:2ABL6WD2 Rev. No 1.0 Issued Date : Aug. 05, 2014 Test Engineer : ( Tien-Lu Liao, Engineer ) Approve & Authorized Signer : S. S. Liou, Section Manager EMC Dept. II of ELECTRONICS TESTING CENTER, TAIWAN ETC Report No.14-07-RBF-027-01 FCC ID:2ABL6WD2 Rev. No 1.0 Table of Contents Page 1. GENERAL INFORMATION ............................................................................................................................... 1 1.1 PRODUCT DESCRIPTION........................................................................................................................................... 1 1.2 CHARACTERISTICS OF DEVICE:................................................................................................................................ 1 1.3 TEST METHODOLOGY.............................................................................................................................................. 1 1.4 TEST FACILITY........................................................................................................................................................ 1 2. DEFINITION AND LIMITS ................................................................................................................................ 2 2.1 DEFINITION............................................................................................................................................................. 2 2.2 RESTRICTED BANDS OF OPERATION........................................................................................................................ 2 2.3 LIMITATION............................................................................................................................................................. 2 2.4 LABELING REQUIREMENT........................................................................................................................................ 4 2.5 USER INFORMATION................................................................................................................................................ 4 3 SYSTEM TEST CONFIGURATION ................................................................................................................... 5 3.1 JUSTIFICATION........................................................................................................................................................ 5 3.2 DEVICES FOR TESTED SYSTEM................................................................................................................................5 4. RADIATED EMISSION MEASUREMENT ...................................................................................................... 6 4.1 APPLICABLE STANDARD.......................................................................................................................................... 6 4.2 MEASUREMENT PROCEDURE................................................................................................................................... 6 4.3 TEST DATA.............................................................................................................................................................. 8 4.4 FIELD STRENGTH CALCULATION........................................................................................................................... 13 4.5 ACTIVATE TIME.................................................................................................................................................... 13 4.6 CALCULATION OF DUTY FACTOR.......................................................................................................................... 13 4.7 RADIATED TEST EQUIPMENT................................................................................................................................. 17 4.8 MEASURING INSTRUMENT SETUP.......................................................................................................................... 17 4.9 RADIATED MEASUREMENT PHOTOS...................................................................................................................... 18 5. BANDWIDTH OF EMISSION........................................................................................................................... 19 5.1 APPLICABLE STANDARD PLOT GRAPHIC OF BANDWIDTH.........................................................…
