2ABPH-TX300V2TX300-V2 FM transmitter

TX V2 FM Broadcast Transmitter User Manual v1.1 No part of this manual may be reproduced in any form without prior written permission from BW Broadcast. The information and specifications contained in this document are subject to change at any time without notice. Copyright 2013 BW Broadcast www.bwbroadcast.com TX V2 FM Broadcast Transmitter Contents 2 Contents Contents .................................................................................................................................................................. 2 Introduction ............................................................................................................................................................. 3 Warranty ................................................................................................................................................................. 4 Safety ...................................................................................................................................................................... 6 Front and Rear Panels ............................................................................................................................................ 7 Display .................................................................................................................................................................... 8 Basic Setup ........................................................................................................................................................... 10 Examples of Use ................................................................................................................................................... 11 FSK Keyer (Translators) ....................................................................................................................................... 16 Audio Processing .................................................................................................................................................. 16 Remote Control ..................................................................................................................................................... 16 In Field Software Upgrade .................................................................................................................................... 19 Alarms and Triggers .............................................................................................................................................. 19 Logging ................................................................................................................................................................. 21 Menu Map ............................................................................................................................................................. 23 Full Parameter List ................................................................................................................................................ 25 Specifications ........................................................................................................................................................ 27 TX V2 FM Broadcast Transmitter Introduction 3 Introduction The BW Broadcast V2 is the latest development in a high specification range of FM transmitters over 15 years in the making. Its broadband “notune” design allows 87.5  108MHz operation without requiring tuning or calibration. The inclusion of fourband DSPX audio processing means stations without a dedicated processor sound great, right out of the box. Those who already have external processing benefit from BW Broadcast’s unique dualloop virtual VFO exciter and field proven ultralow distortion modulator integrated into a great performing, highly stable FM transmission system. Features such as slidein power supplies, and unique solderfree GoldClamp transistors (not present on all models) make infield maintenance simple. A high resolution OLED screen displays RF, audio and system parameters. The control wheel and three front panel buttons allow easy navigation of the menus. Help tips for every parameter make setup simple without having to refer to the technical manual Every V2 Transmitter features a LAN connection for Ethernet local or remote control. The LAN connection also supports SNMP, telnet, and email alerts via either SMTP or BW Broadcast’s mail server. Where a LAN connection is not available, the RS232 connection can be used. Intelligent alarms and email alerts ensure busy engineers can manage their stations with minimal intervention. A real time clock and comprehensive logging is available for those who like to see more detailed status. Also present are 4 rear panel optoisolated triggers that allow external equipment to control the transmitter. It is advised that this manual is read to learn all of the advanced features of the V2 Transmitter. TX V2 FM Broadcast Transmitter Warranty 4 Warranty BW Broadcast warrants the mechanical and electronic components of this product to be free of defects in material and workmanship for a period of two (2) years from the original date of purchase, in accordance with the warranty regulations described below. If the product shows any defects within the specified warranty period that are not due to normal wear and tear and/or improper handling by the user, BW Broadcast shall, at its sole discretion, either repair or replace the product. If the unit has a manufacturers fault within twenty eight (28) days then BW Broadcast will pay the freight at their discretion. If the warranty claim proves to be justified, the product will be returned to the user freight prepaid. Warranty claims other than those indicated above are expressly excluded. Return authorisation number To obtain warranty service, the buyer (or his authorized dealer) must call BW Broadcast during normal business hours BEFORE returning the…

Text truncated - open the document above for the full version.

08,hJanuary 2014 TRaCGlobalLtd. 100FrobisherBusinessPark Malvern Worcestershire WR141BX UK ToWhomIt MayConcern: V L)i_ubraadcast BWBroadcastLimited Unit27, IOCentre CroydonRoad. Croydon CRO4WQ.UK Tel: +442082530290 Fax:+442082530291 [email protected] www.bwbroadcast.com Wecertifythatwearenotsubjecttodenialoffederalbenefits,thatincludesFCCbenefits, pursuanttoSection5301oftheAnti-DrugAbuseACTof1988,U.S.C.862.Further,no party,asdefinedin 47 CFR1.2002(b),totheapplication,issubjecttodenialoffederal benefits,thatincludesFCCbenefits. Thankyou foryourattentiontothismatter. Yoursfaithfully BWBroadcastLtd ScottInez

8"'January2014 buubroadcasL BWBroadcastLimited Unit27. IOCentre CroydonRoad. Croydon CRO4WQ.UK Tel:+442082530290 Fax:+442082530291 [email protected] www.bwbroadcast.com RequestforConfidentiality InAccordancewithFCCRule0.459 TRaCGLOBALLTD. 100FrobisherBusinessPark Malvern WorcestershireWR141BX UK RE:CertificationApplication FCCID:2ABPH-TX300V2 ToWhomIt MayConcern: Please be advisedthatthe followinginformationis to be heldconfidentialonbehalfof BW BroadcastLtd. •Schematics •BlockDiagram •TechnicalDescription •BOM The application contains technical information whichBWBroadcast Ltd deems to betrade secretsandpropriety.If madepublic, theinformationmight be used to thedisadvantageof theapplicantinthemarketplace. Thankyouforyourattentiontothismatter. Yoursfaithfully BWBroadcastLtd ScottInez

TX300V2 Photographic documentation Author: Owner: Valid from: Pavel Valousek Pavel Valousek 15.01.2014 Page 1 of 6 Printed: 16/01/2014 1 External photographs 1.1 Top 1.2 Bottom TX300V2 Photographic documentation Page 2 of 6 Printed: 16/01/2014 1.3 Left 1.4 Right 1.5 Front 1.6 Back TX300V2 Photographic documentation Page 3 of 6 Printed: 16/01/2014 2 Internal photographs 2.1 Overview 2.2 All in one board TX300V2 Photographic documentation Page 4 of 6 Printed: 16/01/2014 2.3 Power amplifier board 2.4 Front panel controller TX300V2 Photographic documentation Page 5 of 6 Printed: 16/01/2014 2.5 TX300 Busbar 2.6 TX300 Power supply interface TX300V2 Photographic documentation Page 6 of 6 Printed: 16/01/2014 2.7 Power supply

TX300V2 Labelling details Author: Owner: Valid from: Pavel Valousek Pavel Valousek 15.01.2014 Page 1 of 2 Printed: 21/01/2014 1 FCC label 1.1 Artwork 1.2 Position and fixing The label will be located on the rear panel of the transmitter unit in left top corner as shown in the picture below. There are two options how the label will be affixed to the unit. For standard production the label will be a part of non removable rear panel silk screen. For labelling the existing units a permanent sticker will be used. TX300V2 Labelling details Page 2 of 2 Printed: 21/01/2014 2 Other labels There is a warning statement with VEEE symbol on the rear panel located between the main fan outlet and power supply slot.

TX300V2 Photographic documentation Author: Owner: Valid from: Pavel Valousek Pavel Valousek 15.01.2014 Page 1 of 6 Printed: 16/01/2014 1 External photographs 1.1 Top 1.2 Bottom TX300V2 Photographic documentation Page 2 of 6 Printed: 16/01/2014 1.3 Left 1.4 Right 1.5 Front 1.6 Back TX300V2 Photographic documentation Page 3 of 6 Printed: 16/01/2014 2 Internal photographs 2.1 Overview 2.2 All in one board TX300V2 Photographic documentation Page 4 of 6 Printed: 16/01/2014 2.3 Power amplifier board 2.4 Front panel controller TX300V2 Photographic documentation Page 5 of 6 Printed: 16/01/2014 2.5 TX300 Busbar 2.6 TX300 Power supply interface TX300V2 Photographic documentation Page 6 of 6 Printed: 16/01/2014 2.7 Power supply

A RADIO TEST REPORT FOR BW BROADCAST Ltd ON TX 300 V2 FM BROADCAST TRANSMITTER DOCUMENT NO. TRA017223-W-US-01 Total number of pages: 51 TRaC Wireless Test Report : TRA-017223-W-US-01 Applicant : BW BROADCAST Ltd Apparatus : TX 300 V2 FM Broadcast Transmitter Specification(s) : CFR47 Part 73 subpart B & H 10-1-12 Edition : BETS-6 Issue 2 August 2005 Purpose of Test : Certification FCCID : 2ABPH-TX300V2 Authorised by : : Radio Product Manager Issue Date :28 th January 2014 Authorised Copy Number : PDF TRaC Global Test Report: TRA-017223-W-US-01 3 Contents Section 1: Introduction 4 1.1 General 4 1.2 Tests Requested By 5 1.3 Manufacturer 5 1.4 Apparatus Assessed 5 1.5 Test Result Summary 6 1.6 Notes Relating To The Assessment 7 1.7 Deviations from Test Standards 7 Section 2: Measurement Uncertainty 8 2.1 Radio Testing – General Uncertainty Schedule 8 Section 3: Modifications 10 3.1 Modifications Performed During Assessment 10 Appendix A: Formal Emission Test Results 11 A1 Transmitter Intentional Emission Conducted 12 A2 Modulation Characteristics - Audio Response – Part 2.1047 16 A3 Emission Mask Plots 2.1049 & 73.317 & BETS-6 18 A4 Conducted Spurious emissions- (Antenna Terminal) 25 A5 Frequency Stability 33 A6 Radiated Emissions 37 Appendix B: Additional Test and Sample Details 42 Appendix C: Additional Information 45 Appendix E: Photographs and Figures 46 TRaC Global Test Report: TRA-017223-W-US-01 4 Section 1: Introduction 1.1 General This report contains an assessment of an apparatus against Electromagnetic Compatibility Standards based upon tests carried out on samples submitted to the Laboratory. Test performed by: TRaC Global [ ] Unit E South Orbital Trading Park Hedon Road Hull, HU9 1NJ. United Kingdom. Telephone: +44 (0) 1482 801801 Fax: +44 (0) 1482 801806 TRaC Global [X] Unit 1 Pendle Place Skelmersdale West Lancashire, WN8 9PN United Kingdom Telephone: +44 (0) 1695 556666 Fax: +44 (0) 1695 577077 Email: [email protected] Web site: http://www.tracglobal.com Tests performed by: S Hodgkinson Report author: S Hodgkinson This report must not be reproduced except in full without prior written permission from TRaC Global. TRaC Global Test Report: TRA-017223-W-US-01 5 1.2 Tests Requested By This testing in this report was requested by : BW Broadcast Ltd Unit 27 IO Centre Croydon Road Croydon CR0 4WG 1.3 Manufacturer BW Broadcast Ltd Unit 27 IO Centre Croydon Road Croydon CR0 4WG 1.4 Apparatus Assessed The following apparatus was assessed between: 10 th - 23 rd December 2013 TX 300 V2 FM Broadcast Transmitter 87.5MHz – 108.0MHz TRaC Global Test Report: TRA-017223-W-US-01 6 1.5 Test Result Summary Full details of test results are contained within Appendix A. The following table summarises the results of the assessment. The statements relating to compliance with the standards below apply ONLY as qualified in the notes and deviations stated in sections 1.6 to 1.7 of this test report. Full details of test results are contained within Appendix A. The following table summarises the results of the assessment. Test Type Regulation Measurement standard Result RF Output Power Part 2.1046, part 73.267 BETS – 6 Section 6 ANSI/TIA 603 – D 2010 Complies Modulation Characteristics Part 2.1047 ANSI/TIA 603 – D 2010 Complies Emission Mask Part 2.1049, 73.317 BETS – 6 Section 6 Clause 6.3.3 ANSI/TIA 603 – D 2010 Complies Conducted Spurious Emissions (Antenna Terminal) Part 2.1053 BETS – 6 Section 6 Clause 6.3.3 ANSI/TIA 603 – D 2010 Complies Frequency Stability Part 73.1545 Part 2.1055 BETS – 6 Clause 6.2 ANSI/TIA 603 – D 2010 Complies Radiated spurious emissions (Cabinet radiation) Part 73.1053 ANSI/TIA 603 – D 2010 Complies Abbreviations used in the above table: CFR : Code of Federal Regulations ANSI : American National Standards Institution REFE : Radiated Electric Field Emissions PLCE : Power Line Conducted Emissions TRaC Global Test Report: TRA-017223-W-US-01 7 1.6 Notes Relating To The Assessment With regard to this assessment, the following points should be noted: The results contained in this report relate only to the items tested and were obtained in the period between the date of initial receipt of samples and the date of issue of the report. The apparatus was set up and exercised using the configurations, modes of operation and arrangements defined in this report only. Particular operating modes, apparatus monitoring methods and performance criteria required by the standards tested to have been performed except where identified in Section 1.7 of this test report (Deviations from Test Standards). For emissions testing, throughout this test report, “Pass” indicates that the results for the sample as tested were below the specified limit (refer also to Section 2, Measurement Uncertainty). Where relevant, the apparatus was only assessed using the monitoring methods and susceptibility criteria defined in this report. All testing with the exception of testing at the Open Area Test Site was performed under the following environmental conditions: Temperature : 17 to 23 °C Humidity : 45 to 75 % All dates used in this report are in the format dd/mm/yy. This assessment has been performed in accordance with the requirements of ISO/IEC 17025. 1.7 Deviations from Test Standards There were no deviations from the standards tested to. TRaC Global Test Report: TRA-017223-W-US-01 8 Section 2: Measurement Uncertainty 2.1 Radio Testing – General Uncertainty Schedule All statements of uncertainty are expanded standard uncertainty using a coverage factor of 1.96 to give a 95% confidence where no required test level exists. [1] Adjacent Channel Power Uncertainty in test result = 1.86dB [2] Carrier Power Uncertainty in test result (Power Meter) = 1.08dB Uncertainty in test result (Spectrum Analyser) = 2.48dB [3] Effective Radiated Power Uncertainty in test result = 4.71dB [4] Spurious Emissions Uncertainty in test result = 4.75dB [5] Maximum frequency error Uncertainty in test result (Power Meter) = 0.113ppm Uncertai…
