2ABPO16042015Hi-Fi Music Centre

1 CREATRON Wall Mountable Bluetooth Music System with CD 2 USER MANUAL MIC192U Selecting fine audio equipment such as the unit you've just purchased is only the start of your musical enjoyment. Now it's time to consider how you can maximize the fun and excitement your equipment offers. This manufacturer and the Electronic Industries Association's Consumer Electronics Group want you to get the most out of your equipment by playing it at a safe level. One that lets the sound come through loud and clear without annoying blaring or distortion and, most importantly, without affecting your sensitive hearing. Sound can be deceiving. Over time your hearing "comfort level" adapts to higher volumes of sound. So what sounds "normal" can actually be loud and harmful to your hearing. Guard against this by setting your equipment at a safe level BEFORE your hearing adapts. To establish a safe level: • Start your volume control at a low setting. • Slowly increase the sound until you can hear it comfortably and clearly, and PLEASE READ THIS USER MANUAL COMPLETELY BEFORE OPERATING THIS UNIT AND RETAIN THIS BOOKLET FOR FUTURE REFERENCE. 3 without distortion. Once you have established a comfortable sound level: • Set the dial and leave it there. Taking a minute to do this now will help to prevent hearing damage or loss in the future. After all, we want you listening for a lifetime. We Want You Listening For a Lifetime Used wisely, your new sound equipment will provide a lifetime of fun and enjoyment. Since hearing damage from loud noise is often undetectable until it is too late, this manufacturer and the Electronic Industries Association's Consumer Electronics Group recommend you avoid prolonged exposure to excessive noise. Customer's Record: The serial number of this product is found on its back cover. You should note the serial number of this unit in the space provided as a permanent record of your purchase to aid in identification in the event of theft of loss. Model Number: MIC192U Serial Number: ________________ IMPORTANT SAFETY INSTRUCTIONS When used in the directed manner, this unit has been designed and manufactured to ensure your personal safety. However, improper use can result in potential electrical shock or fire hazards. Please read all safety and operating instructions carefully before installation and use, and keep these instructions handy for future reference. Take special note of all warnings listed in these instructions and on the unit. 1. Read these instructions – All the safety and operating instructions should be read before the appliance is operated. 2. Keep these instructions – The safety and operating instructions should be kept for future reference. 3. Heed all warnings – All warnings on the appliance and in the operating instructions should be adhered to. 4 4. Follow all instructions – All operation and use instructions should be followed. 5. Do not use this apparatus near water – The appliance should not be used near water; for example, near a bath tub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool. 6. Clean only with dry cloth – The appliance should be cleaned only as recommended by the manufacturer. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. The appliance should be situated so that its location or position does not interfere with its proper ventilation. For example, the appliance should not be situated on a bed, sofa, rug, or similar surface that may block the ventilation openings; or placed in a built-in installation, such as a bookcase or cabinet that may impede the flow of air through the ventilation openings. 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9. AC adaptor is used as disconnect device and it should remain readily operable during intended use. In order to disconnect the apparatus from the mains completely, the AC adaptor should be disconnected form the mains socket outlet completely. 10. Only use attachments / accessories specified by the manufacturer. 11. Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. 12. Unplug this apparatus during lightning storms or when unused for long periods of time. 13. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. 14. This appliance shall not be exposed to dripping or splashing water and that no object filled with liquids such as vases shall be placed on the apparatus. 15. Power Sources – The appliance should be connected to a power supply only of the type described in the operating instructions or as marked on the appliance. Do not overload wall outlet. 16. Battery shall not be exposed to excessive heat such as sunshine, fire or the like 17. Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. 18. Do not attempt to dismantle, open or repair this product yourself. If a fault occurs, seek advice from your local qualified service technician or contact the distributor via the telephone number at the back of this instruction manual. 19. Caution marking and nameplate are located on back of product. 20. The device is not intended to be operated within 20 cm from the user IMPORTANT NOTE Avoid installing the unit in locations described below: • Places exposed to direct sunlight or close to heat radiating appliances such as electric heaters. 5 • Places subject to constant vibration. • Dusty, humid or moist places. • Sources of electrical noise such as flu…

Text truncated - open the document above for the full version.

Creation Electronics Ltd. Unit 7, 10/F., Corporation Square, 8 Lam Lok Street, Kowloon Bay, Kowloon, Hong Kong. Tel : (852) 2690 3100 2246 9736 Fax : (852) 2246 9762 Email: [email protected] Long Term Confidentiality Request Letter Date : 19 May 2015 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (Hi-Fi Music Centre/ MIC192U # FCC ID: 2ABPO16042015#) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the (circuit schematic/ parts list / block diagram/ Circuit Description ) required to be submitted with this application be permanently withheld from public review. SPECIFY REASON FOR REQUEST (i.e. the above documents are company proprietary information that could never get into the possession of your competition). Please contact me if there is any information you may need. Sincerely, Print name：Dino Wong Title: Director Signature:

Creation Electronics Ltd. Unit 7, 10/F., Corporation Square, 8 Lam Lok Street, Kowloon Bay, Kowloon, Hong Kong. Tel : (852) 2690 3100 2246 9736 Fax : (852) 2246 9762 Email: [email protected] Agent Authorization Letter Date : 19 May 2015 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize STC(Dongguan) Company Limited to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Print name：Dino Wong Title: Director Signature:

Updated on 2005/02/07 by Kally Chan To : STC (DongGuan) COMPANY LIMITED DECLARATION OF IDENTITY Hereby we: (Name of Applicant) Basic Model Number: MIC192U Basic Brand Name: CREATRON Basic Product Name: Hi-Fi Musice Centre Basic Test Report Application Number: DM119503 / DM119504 Declare the Circuit, PCB Layout, Electrical Parts and Outlook of the following product(s) are identical to the basic model: New / Additional Model Number(s): JBS-350 New / Additional Brand Name(s): Jensen Remarks: Signature with Company Chop : Printed Name : Dino Wong DATE:20 June 2015 The difference only on Brand name and model no。 Except the following(s) :

1 External Photo FCC ID: 2ABPO16042015 Front View of The Product Rear View of The Product 2 Top View of The Product Bottom View of The Product 3 Left View of The Product Right View of The Product 4 Global View of The Product Global View of The Product

Label Location

Model: MIC192U Power Requirement : AC-DC Adaptor 12V 1500mA CLASS 1 LASER PRODUCT Frequency : FM 87.5 – 108 MHz FCC ID : 2ABPO16042015 MIC192U Rating Plate Date : 19 May 15 WALL MOUNTABLE BLUETOOTH MUSIC SYSTEM WITH CD Made in China THIS PRODUCT COMPLIES WITH DHHS RULES 21 CFR, SUBCHAPTER J, PART1040 AT THE DATE OF MANUFACTURE. This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 60 mm 30 mm CREATRON

1 Internal Photo FCC ID: 2ABPO16042015 Inside View of The Product Inner Circuit Top View 2 Inner Circuit Bottom View Inner Circuit Top View 3 Inner Circuit Bottom View Inner Circuit Top View 4 Inner Circuit Bottom View Inner Circuit Top View 5 Inner Circuit Bottom View Inner Circuit Top View 6 Inner Circuit Bottom View Inner Circuit Top View 7 Inner Circuit Bottom View

Specifications Information on the equipment Device name Brand Model No. CMD2022C Manufacturer IC：卓荣集成电路科技有限公司； Equipment type Transmitter Receiver Transceiver Frequency of operation 2402MHz-2480MHz Type of modulation 1M 2M 3M Channel spacing 1MHz Channel number 79 个 Peak output power +4dBm Mode of operation Simplex Duplex Antenna gain 0dBi Antenna type A quarter wavelength folding type antenna Antenna connector IC built-in Operating voltage 3.3V-5V

STC Test Report STC (Dongguan) Company Limited 68 Fumin Nan Road, Dalang, Dongguan, China. (Zip Code : 523 770) Tel : (86 769) 8111 9888 Fax : (86 769) 8111 6222 E-mail : [email protected] Homepage : www.dgstc.org This report shall not be reproduced unless with prior written approval from STC (Dongguan) Company Limited. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage. Date: 2015-05-26 Page 1 of 88 No.: DM119503 Applicant: Creation Electronics Ltd. Unit 7, 10/F, Corporation Square, 8 Lam Lok Street, Kowloon Bay, Hong Kong Manufacturer: Creation Electronics Ltd. Unit 7, 10/F, Corporation Square, 8 Lam Lok Street, Kowloon Bay, Hong Kong Description of Sample(s): Product: Hi-Fi Music Centre Brand Name: Creatron Model Number: MIC192U FCC ID: 2ABPO16042015 Date Sample(s) Received: 2015-05-15 Date Tested: 2015-05-20 to 2015-05-25 Investigation Requested: Perform ElectroMagnetic Interference measurement in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15: 2014 and ANSI C63.4: 2009 for FCC Certification. Conclusion(s): The submitted product COMPLIED with the requirements of Federal Communications Commission [FCC] Rules and Regulations Part 15. The tests were performed in accordance with the standards described above and on Section 2.2 in this Test Report. Remark(s): For additional model(s) details, please page 3. LONG Yun Jian, Along Authorized Signatory ElectroMagnetic Compatibility Department For and on behalf of STC (Dongguan) Company Limited STC Test Report STC (Dongguan) Company Limited 68 Fumin Nan Road, Dalang, Dongguan, China. (Zip Code : 523 770) Tel : (86 769) 8111 9888 Fax : (86 769) 8111 6222 E-mail : [email protected] Homepage : www.dgstc.org This report shall not be reproduced unless with prior written approval from STC (Dongguan) Company Limited. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage. Date: 2015-05-26 Page 2 of 88 No.: DM119503 CONTENT: Cover Page 1 of 88 Content Page 2 of 88 1.0 General Details 1.1 Test Laboratory Page 3 of 88 1.2 Equipment Under Test [EUT] Page 3 of 88 Description of EUT operation 1.3 Date of Order Page 3 of 88 1.4 Submitted Sample Page 3 of 88 1.5 Test Duration Page 3 of 88 1.6 Country of Origin Page 3 of 88 1.7 RF Module Details Page 4 of 88 1.8 Antenna Details Page 4 of 88 2.0 Technical Details 2.1 Investigations Requested Page 5 of 88 2.2 Test Standards and Results Summary Page 5 of 88 2.3 Table for Test Modes Page 6 of 88 3.0 Test Results 3.1 Emission Page 7 – 82 of 88 Appendix A List of Measurement Equipment Page 83 of 88 Appendix B Photographs Page 84-88 of 88 STC Test Report STC (Dongguan) Company Limited 68 Fumin Nan Road, Dalang, Dongguan, China. (Zip Code : 523 770) Tel : (86 769) 8111 9888 Fax : (86 769) 8111 6222 E-mail : [email protected] Homepage : www.dgstc.org This report shall not be reproduced unless with prior written approval from STC (Dongguan) Company Limited. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage. Date: 2015-05-26 Page 3 of 88 No.: DM119503 1.0 General Details 1.1 Test Laboratory STC (Dongguan) Company Limited EMC Laboratory 68 Fumin Nan Road, Dalang, Dongguan, Guangdong, China Telephone: (86 769) 81119888 Fax: (86 769) 81116222 1.2 Equipment Under Test [EUT] Description of Sample(s) Product: Hi-Fi Music Centre Manufacturer: Creation Electronics Ltd. Brand Name: Creatron Additional Brand Name: Jensen Model Number: MIC192U Addditional Model Number: JBS-350 Rating: Input: 100-240Va.c. 50/60Hz 0.5A; Output: 12Vd.c. 1.5A. The AC/DC adaptor was provided by the applicant with following details: Brand name: Stos; Model no.: QX18W120150FU 1.2.1 Description of EUT Operation The Equipment Under Test (EUT) is a Hi-Fi Music Centre. The r.f. signal was modulated by IC and type of modulation was frequency hopping spread spectrum Modulation. 1.3 Date of Order 2015-05-15 1.4 Submitted Sample(s): 1 Sample 1.5 Test Duration 2015-05-20 to 2015-05-25 1.6 Country of Origin China STC Test Report STC (Dongguan) Company Limited 68 Fumin Nan Road, Dalang, Dongguan, China. (Zip Code : 523 770) Tel : (86 769) 8111 9888 Fax : (86 769) 8111 6222 E-mail : [email protected] Homepage : www.dgstc.org This report shall not be reproduced unless with prior written approval from STC (Dongguan) Company Limited. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage. Date: 2015-05-26 Page 4 of 88 No.: DM119503 1.7 RF Module Details Module Model Number: CMD2022C Module FCC ID: Module Transmission Type: Bluetooth 2.1+EDR Modulation: FHSS (GFSK / π/4-DQPSK / 8DPSK) Data Rates: 1MBps: GFSK 2 MBps: π/4-DQPSK 3 MBps: 8DPSK Frequency Range: 2400-2483.5MHz Carrier Frequencies: 2402MHz – 2480MHz Module Specification (specification provided by manufacturer) 1.8 Antenna Details Antenna Type: Meander line antenna Antenna Gain: 0dBi STC Test Report STC (Dongguan) Company Limited 68 Fumin Nan Road, Dalang, Dongguan, China. (Zip Code : 523 770) Tel : (86 769) 8111 9888 Fax : (86 769) 8111 6222 E-mail : [email protected] Homepage : www.dgstc.org This report shall not be reproduced unless with prior written approval from STC (Dongguan) Company Limited. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage. Date: 2015-05-26 Page 5 of 88 No.: DM119503 2.0 Technical Details 2.1 Investigations Requested Perform Electromagnetic Interference measurements in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15: 2014 Regulations. FCC Pubic Notice DA 00-705 and ANSI C63.4: 2009 for FCC Certification. 2.2 Test Standards and Results Summary Tables EMISSION Results Summary Test Condition Test Requirement Test Method Class / Test Result Severity Pass Fail N/A Maximum Peak Conducted Output Power FCC 47CFR 15.247(b)(1) FCC Pubic Notice DA 00-705 N/A Radiated Spurious Emissions FCC 47CFR 15.209 ANSI C63.4:2009N/A AC Mains Conducted Emissions FCC 47CFR 15.207 ANSI C63.4:2009N/A Number …

Text truncated - open the document above for the full version.

1 Test Photo FCC ID: 2ABPO16042015 Measurement of Radiated Emission Test Set Up Measurement of Radiated Emission Test Set Up 2 Measurement of Radiated Emission Test Set Up Measurement of Conducted Emission Test Set Up
