2ABR4-STEALTHMultiMode Stealth Series

Stealth Series 2 Veridt Reader Terminal Installation Guide Compliance Statements FCC 15.105 FCC (US) (a) For a Class A digital device or peripheral, the instructions furnished the user shall include the following or similar statement, placed in a prominent location in the text of the manual: Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Industry Canada ICES-003 Compliance CAN ICES-3 (A)/NMB-3(A) FCC 15.19 FCC (US): This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause unde- sired operation. IC (Canada): This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this devicemust accept any interference, including interference that may cause undesired operation of the device. Cet appareil est conforme aux normes Industry Canada exemptes de licence RSS standard(s). Son fonctionnement est soumis aux deux conditions suivantes : (1) cet appareil ne doit pas provoquer d'interférences et (2) cet appareil doit accepter toute interférence, y compris les interférences susceptibles de provoquer un fonctionnement indésirable FCC 15.21 IMPORTANT! Changes or modifications not expressly approved by Veridt, Inc could void the user’s authority to operate the equipment. IC (Canada): IMPORTANT! Changes or modifications not expressly approved by Veridt, Inc could void the user’s authority to operate the equipment. IMPORTANT ! Les changements ou modifications non approuvés expressément par Veridt, Inc pourrait annuler l'autorité de l'uti- lisateur à faire fonctionner l'équipement. CE STANDARDS Testing for compliance to CE requirements was performed by an independent laboratory. The unit under test was found compliant to class B limits of part 15 of the FCC Rules. 3 Veridt Reader Terminal Installation Guide for MultiMode Stealth™ Reader Terminals Reader P/N Contactless Contact Key Pad Biometric H” x W” x D” 900W2030 X X X X 7.0 X 3.0 X 1.6 900W2036 X X X 5.5 X 3.0 X 1.6 900W2037 X X 5.5 X 3.0 X 1.6 900W2026 X X 5.5X 3.0 X 1.6 900W2027 X 5.5X 3.0 X 1.6 Veridt Fixed Reader Terminal Hardware Configurations This document provides installation information for the Veridt reader hardware platforms described below 900W2026 900W2030 900W2027 900W2036 Note 2: The mounting plate fits into a re- cessed area in the rear of the reader, so that the reader mounts flush to the wall and the mounting plate is completely con- cealed. The depth measurement includes that additional dimensional requirement of approximately 0.35 inches. 900W2037 4 Veridt Reader Terminal Installation Guide Reader Communications Options All Veridt reader platforms are based on a common architecture and therefore installation instructions apply to all read- ers. This common architecture allows for multiple communications interface options as well as options for interfacing to third party software for High Assurance security solutions and Mode Control (setting the operational mode in multi- format readers; e.g., card + PIN, card + Bio, etc.). The reader is equipped with two communications interfaces: 1) Wiegand which can be configured up to 512 bits and 2) Serial RS-485 which can also be converted to Ethernet. The Wiegand output is typically pre-configured for the chosen application, but is also field configurable using the MultiMode SDK. Serial/Ethernet communications are typically preconfigured for the chosen application. The feature set and application determines the combination of hardware and software required. Reader Communi- cations Interface Hardware Interface Access Control Panel Communica- tions Interface Hardware Interface Software Wiegand None Wiegand RS-485 Half duplex None RS-485 Half duplex Veridt EWACs pivCLASS PACS Service Admin RS-485 Half duplex Veridt EWACs Veridt Mode Control RS-485 Full duplex HID PAM pivCLASS PACS Service Admin Veridt EWAC Communications Interface HID PAM 5 Veridt Reader Terminal Installation Guide Reader Mode Selections for Communication Option Selected Wiegand Wiegand RS-485 Wiegand RS-485/Vlinx pivCLASS RS-485 EWACs pivCLASS RS-485 EWACs Mode Control RS-485 HID PAM 1 Card Only Card Only (no PKI) CHUID (TWIC) CHUID (TWIC) Card Only (no PKI) CHUID(PIV) 2 Card + PIN (no PKI) CAK(TWIC) CAK(TWIC) Card + PIN (no PKI) CAK(PIV) 3 Card + PIN + BIO (no PKI) CHUID + BIO (TWIC) CHUID + BIO (TWIC) Card + PIN + BIO (no PKI) PKI+ PIN (PIV) 4 CAK + BIO (TWIC) CHUID + CAK + BIO (TWIC) PKI+ PIN + BIO (PIV) 5 CHUID (PIV) 6 CHUID + PKI (PIV) 7 CHUID + PKI + BIO (PIV) 8 CAK (PIV) 9 CHUID + CAK (PIV) 10 Card Only (no PKI) 11 Card + PIN (no PKI) 12 Card + PIN + PACS PIN (no PKI) 13 Card + PIN +BIO (no PKI) Typical Mode of operation for Hardware / Software Combinations Optionally available Legacy Prox Feature is configured with readers when P/N 920FW0PR is specified. MultiMode Stealth™ reader configured for legacy Prox 125KHz operation: includes sub-license, firmware and additional hardware for 125KHz operation. Specify Legacy Card. Specify reader P/N. Cannot be used with HID PAM configured readers. 6 Veridt Reader Terminal Installation Guide Credential Options Veridt Readers are programed to operate in a multi…

Text truncated - open the document above for the full version.

External Photos of 900W2026 Stealth External Photos of 900W2027 Stealth Lite External Photos of 900W2037 Stealth Dual Lite External Photos of 900W2030 Stealth Bio External Photos of 900W2036 Stealth Dual

FCC ID: 2ABR4-STEALTH I C: 117 2 7A - ST E A LT H MODEL: 900W2030 SERIAL NO: C40R140001 Veridt, Inc. FCC ID: 2ABR4-STEALTH I C: 117 2 7A - ST E A LT H MODEL: 900W2036 SERIAL NO: C40B140001 Veridt, Inc. FCC ID: 2ABR4-STEALTH I C: 117 2 7A - ST E A LT H MODEL: 900W2037 SERIAL NO: C00B140001 Veridt, Inc. FCC ID: 2ABR4-STEALTH I C: 117 2 7A - ST E A LT H MODEL: 900W2026 SERIAL NO: C403140001 Veridt, Inc. FCC ID: 2ABR4-STEALTH I C: 117 2 7A - ST E A LT H MODEL: 900W2027 SERIAL NO: C003140001 Veridt, Inc.

Securing Identity: Credential Reader Solutions Veridt, Inc. | 7182 US Highway 14 | Suite 401 | Middleton | Wisconsin 53562 Phone: 608-833-1840 | Fax: 608-833-1806 | www.veridt.com Large Housing – 900W2030 FCC Label location 900W2036 FCC Label location Securing Identity: Credential Reader Solutions Veridt, Inc. | 7182 US Highway 14 | Suite 401 | Middleton | Wisconsin 53562 Phone: 608-833-1840 | Fax: 608-833-1806 | www.veridt.com 900W2037 FCC Label location 900W2026 FCC Label location Securing Identity: Credential Reader Solutions Veridt, Inc. | 7182 US Highway 14 | Suite 401 | Middleton | Wisconsin 53562 Phone: 608-833-1840 | Fax: 608-833-1806 | www.veridt.com 900W2027 FCC Label location

Internal Photos of 900W2026 Stealth Main PCB LED Buzzer PCB Internal Photos of 900W2027 Stealth Lite Main PCB LED Buzzer PCB Internal Photos of 900W2037 Stealth Dual Lite Main PCB LED Buzzer PCB Internal Photos of 900W2030 Stealth Bio Main PCB LED Buzzer PCB Internal Photos of 900W2036 Stealth Dual Main PCB LED Buzzer PCB

EMC Report for Veridt, Inc. on the MultiMode Stealth Series File: 101412796MPK-003 Page 1 of 43 TEST REPORT Report Number: 101412796MPK-003 Project Number: G101412796 November 27, 2013 Testing performed on the MultiMode Stealth Series Model Numbers: 900W2030, 900W2036, 900W2037, 900W2026 and 900W2027 FCC ID: 2ABR4-STEALTH IC: 11727A-STEALTH to FCC Part 15 Subpart C (15.225) Industry Canada RSS-210 Issue 8 FCC Part 15, Subpart B Industry Canada ICES-003 For Veridt, Inc. Test Performed by: Test Authorized by: Intertek 1365 Adams Court Menlo Park, CA 94025 USA Veridt, Inc. 7182 US Highway 14, Suite 401 Middleton, WI 53562 USA Prepared by: Date: November 27, 2013 Anderson Soungpanya Reviewed by: Date: November 27, 2013 Krishna Vemuri This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to copy or distribute this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. This report must not be used to claim product endorsement by A2LA, NIST nor any other agency of the U.S. Government. EMC Report for Veridt, Inc. on the MultiMode Stealth Series File: 101412796MPK-003 Page 2 of 43 Report No. 101412796MPK-003 Equipment Under Test: MultiMode Stealth Series Trade Name: Veridt, Inc. Model Numbers: 900W2030, 900W2036, 900W2037, 900W2026 and 900W2027 Serial Numbers: G40R130005 G40B130004 G00B130002 G403130001 G003130002 FCC ID: 2ABR4-STEALTH IC: 11727A-STEALTH Applicant: Veridt, Inc. Contact: Martin Janiak Address: 7182 US Highway 14, Suite 401 Middleton, WI 53562 Country USA Tel. Number: (608) 833-1840 Email [email protected] Applicable Regulation: FCC Part 15 Subpart C (15.225) Industry Canada RSS-210 Issue 8 FCC Part 15, Subpart B Industry Canada ICES-003 Test Site Location: ITS – Site 1 1365 Adams Drive Menlo Park, CA 94025 Date of Test: November 15 to 27, 2013 We attest to the accuracy of this report: Anderson Soungpanya Project Engineer Krishna K Vemuri EMC Senior Staff Engineer EMC Report for Veridt, Inc. on the MultiMode Stealth Series File: 101412796MPK-003 Page 3 of 43 TABLE OF CONTENTS 1.0 Summary of Tests .......................................................................................................................... 4 2.0 General Description ....................................................................................................................... 5 2.1 Product Description ............................................................................................................. 5 2.2 Related Submittal(s) Grants ................................................................................................ 6 2.3 Test Methodology ............................................................................................................... 6 2.4 Test Facility ......................................................................................................................... 6 3.0 System Test Configuration ............................................................................................................ 7 3.1 Support Equipment and description .................................................................................... 7 3.2 Block Diagram of Test Setup .............................................................................................. 8 3.3 Justification ......................................................................................................................... 9 3.4 Software Exercise Program ............................................................................................... 10 3.5 Mode of operation during test ........................................................................................... 10 3.6 Modifications required for Compliance ............................................................................ 10 3.7 Additions, deviations and exclusions from standards ........................................................ 10 4.0 Measurement Results ................................................................................................................... 11 4.1 Field Strength of Fundamental and Radiated Emissions Outside the band ....................... 11 4.2 Frequency Tolerance ......................................................................................................... 18 4.3 Occupied Bandwidth ......................................................................................................... 20 4.4 AC Line Conducted Emission ........................................................................................... 25 4.5 Radiated Emissions on Digital Parts and Receiver ............................................................ 34 5.0 List of test equipment .................................................................................................................. 42 6.0 Document History ........................................................................................................................ 43 EMC Report for Veridt, Inc. on the MultiMode Stealth Series File: 101412796MPK-003 Page 4 of 43 1.0 Summary of Tests TEST REFERENCE FCC 15.225 REFERENCE RSS-210 RESULTS Field Strength of Fundamental 15.225(a) A2.6 Complies Radiated Emissions Outside the band 15.225(b), 15.225(c), 15.225(d), 15.209 A2.6 Complies …

Text truncated - open the document above for the full version.

Radiated Emission test below 30 MHz Radiated Emission test above 30 MHz AC line conducted emission test
