2ABRK86869937000001Car Camera and Warning System

DR-1 GPS DRIVING RECORDER Operation Manual www.TMG-FACETS.com Facets Product Design & Development Ltd. Taiwan Microwave Group www.TMG-FACETS.com TMG, the TMG logo, and other TMG marks are owned by TMG and may be registered. All other trademarks are the property of their respective owners. Table of Content Introduction Thank you for purchasing DR-1 GPS DRIVING RECORDER, one of the most innovative and sophisti- cated road safety monitoring systems available today. Please be sure to read this manual to familiarize yourself with the features and operation of this product. Enjoy the trip with TMG and drive safely. ! Caution Motorists are expected to exercise all due caution while using this product, and to obey all applicable traffic laws. To prevent theft, always conceal this product before you leave the vehicle. Installation ......................................................... Profile ................................................................ Specifications ..................................................... Features .............................................................. Operation ............................................................ Firmware Update ................................................ Report to Us ........................................................ Trouble Shooting ................................................. Warranty .............................................................. 3 7 9 11 13 15 17 18 19 4 Installation 1. Wipe windshield with cleaner. 2. Remove sticker cover and press the hook against windshield. 3. Hang DR-1 on the bracket. Try to insert the hook all the way to the end. Adjust angle and fasten the screw. 4. Organize wire as shown below. DC12~24V 5. Plug in cigeratte lighter plug. It can accomodate a 12~24V power source. Tuck in Trim of A Pillar Hide behind Sun Shield Wrap around Mirror Neck Hide under Carpet 6 Installation- Wireless Radar Detector(Optional) RED + BLACK - Only DR-1 with built-in RF receiver works for wireless radar detector. Please make sure to acquire correct model. 1. Install it with screws, cable ties or double-sided tape be- tween grille or under the bumper. 2. Make sure there is no metal parts blocking the front of radar detector. 3. Connect black wire to “-” and red wire to “+” on the battery. 4. Organize cable by cable ties. 5. Radar detector works better for some types of radars when it is installed vertically. Please consult the local dealer for best solution in your region. ! Warning Even though it is easy to install the unit, we still recommand you to find a professional to help if you don’t feel comfortable doing it by yourself. Profile MICRO High Resolution GPS Tracking with Speed Camera Warning Event Recording With professional optical lens, high quality night view is promised. Surroundings are well covered by 110° of viewing angle. Click event recording button to save video without being overwritten. G-sensor records 3D【X、Y、Z axis】 G-force simul- taneously, and starts event recording when G-force exceeds threshold limit. Permanent files are limited to 10. Old files will still be replaced by new ones once the number exceeds 10. 8 Main Features GPS warns you POI based speed cameras. Replay in- tegrates real time tracking on Google Map. Radar de- tector is optional for mobile radar detection. BACK/EXIT 10 Specifications of Video Camera 1. Lens: F/2.8 2. Image sensor: 1.3M CMOS 3. View angle: 110° 4. Built-in lithium battery 5. 2.5”TFT LCD display 6. Compression format: M-JPEG(AVI) 7. Resolution: 1280*720@30fps 8. Media: Micro SD, Class6~10, up to 32G. 9. Loop, seamless recording. 10. Event recording button 11. 3 axes G-sensor 12. Language: 11 language supported 13. GPS: Latest GPS module 14. Google Map Integrated replay 15. Speed camera warning 16. Free database update 17. User programmable warning spots 18. Working temperature: -20~+75°C 19. Input: DC12~24V 20. Dimension: 70*65*22mm 21. Weight: 97g 22. Material: PC/ABS 23. Product origin: Taiwan Specifications of Radar Detector(Optional) Input: DC 12V X band: 10.525 GHz ± 50 MHz K band: 24.150 GHz ± 100 MHz New K band: 24.125 GHz ± 100 MHz Ka band: 33.4 ~ 36.0 GHz (Coverage can be adjusted in some regions.) LASER: 904nm Operation Temperature - 25 oC ~ + 85 oC This device complies with part 15 of FCC rules: Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 9 Radar/ Laser Detection(Optional) Emergency Vehicle Warnings(Optional) DR-1’s optional radar detector reacts to SWS (Safety Alert® Traffic Warning System). DR-1’s optional radar detector detects X, K, New K, Super Wide Ka bands and laser. Please refer to the Specifications for more information. It also detect pulses shorter than what’s generated by an Instant-on/Pulsed Radar. STS (Signal Tracking System, Optional) Radar signals with increasing intensity will be tracked by DR-1’s optional radar detector, and the alert will not be inter- rupted by temporary interference to hold user’s awareness of a true threat. Built-in Speed Limit Map DR-1 “knows” the speed limit of the road your are currently driving on by a built-in speed limit map. DR-1 activates its optional radar detector only when you exceed speed limit under Adaptive Threshold Mode. Fixed Pole Speed/ Red Light Camera Alerts Other POI based Warnings A voice alert is activated while you are approaching a camera spot whose coordination data is stored in the database. To minimize driver distraction, DR-1 only reacts to cameras targeting the traffic flow you are in. The display will start to count down the distance to the spot, and a speeding alert will be activated if current speed is beyond the local speed limit in the case of approaching a speed camera spot. Speeding alert will change from “You are speeding.” to “Please slow down!” if a radar signal is detected in a c…

Text truncated - open the document above for the full version.

App-Tronics LLC Date：January 6, 2014 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Dear Sir or Madam, We, App-Tronics LLC hereby authorize Compliance Certification Services Inc / Rex.Liao . to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. This authorization expires on 2014/12/24 Your Sincerely, Name: Mark A. Tierno Title: President, Founder App-Tronics LLC TEL: (888)587-4111 toll free (440)364-0920 cell E-Mail: [email protected]

App-Tronics LLC Date：January 21, 2014 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Confidentiality Request FCC ID: 2ABRK86869937000001 Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, App-Tronics LLC hereby requests permanent confidential treatment of information accompanying this application as outlined below: Common exhibits for which confidentiality is requested are: Schematics Block Diagrams Theory of Operation The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Your Sincerely, Name: Mark A. Tierno Title: President, Founder App-Tronics LLC TEL: (888)587-4111 toll free (440)364-0920 cell E-Mail: [email protected]

Report No.T130923D06 Page 1 of 16 External Photo(GPS Driving Recorder) Report No.T130923D06 Page 2 of 16 Report No.T130923D06 Page 3 of 16 Report No.T130923D06 Page 4 of 16 External Photo(Cigarette Lighter plug) Report No.T130923D06 Page 5 of 16 Report No.T130923D06 Page 6 of 16 Report No.T130923D06 Page 7 of 16 External Photo(Radar Detector) Report No.T130923D06 Page 8 of 16 Report No.T130923D06 Page 9 of 16 External Photo(Control Box) Report No.T130923D06 Page 10 of 16 Report No.T130923D06 Page 11 of 16 External Photo(Laser Transponder) Report No.T130923D06 Page 12 of 16 Report No.T130923D06 Page 13 of 16 External Photo(Laser Transponder) Report No.T130923D06 Page 14 of 16 Report No.T130923D06 Page 15 of 16 External Photo(Remote Controller) Report No.T130923D06 Page 16 of 16

App-Tronics Stealth Interceptor This device complies with Part 15 of FCC Rules. Operation is subject to following two conditions; (1) this device may not cause harmful interference and (2) this device must accept any inetrference received, including interference that may cause undesired operation. FCC ID: 2ABRK86869937000001 Serial No.: Made in Taiwan

External Photo(Control Box) Label Location

Report No.T130923D06 Page 1 of 4 Internal Photo Report No.T130923D06 Page 2 of 4 Report No.T130923D06 Page 3 of 4 Report No.T130923D06 Page 4 of 4

FCC ID2ABRK86869937000001 Report No.T130923D06-RP1 Page 1 / 25 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. FCC 47 CFR PART 15 SUBPART C AND ANSI C63.4:2009 TEST REPORT For Car Camera and Warning System Model : 2300is Trade Name : App-Tronics Issued for App-Tronics LLC 1605 Commodore Cove, Painesville, Ohio 44077, U.S.A. Issued by Compliance Certification Services Inc. Hsinchu Lab. NO. 989-1 Wen Shan Rd., Shang Shan Village, Qionglin Shiang Hsinchu County 30741, Taiwan, R.O.C TEL: +886-3-5921698 FAX: +886-3-5921108 http://www.ccsrf.com E-Mail : [email protected] Issued Date: December 20, 2013 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF or any government agencies. The test results of this report relate only to the tested sample identified in this report. FCC ID2ABRK86869937000001 Report No.T130923D06-RP1 Page 2 / 25 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. Revision History Rev. Issue Date Revisions Effect Page Revised By 00 12/20/2013 Initial Issue All Page 25 Gloria Chang FCC ID2ABRK86869937000001 Report No.T130923D06-RP1 Page 3 / 25 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. TABLE OF CONTENTS TITLE PAGE NO. 1. TEST REPORT CERTIFICATION ................................................................................ 4 2. EUT DESCRIPTION ..................................................................................................... 5 3. DESCRIPTION OF TEST MODES ............................................................................... 6 4. TEST METHODOLOGY ............................................................................................... 6 5. FACILITIES AND ACCREDITATION ........................................................................... 7 5.1 FACILITIES ............................................................................................................ 7 5.2 ACCREDITATIONS................................................................................................ 7 5.3 MEASUREMENT UNCERTAINTY ......................................................................... 8 6. SETUP OF EQUIPMENT UNDER TEST...................................................................... 9 7. FCC PART 15.231 REQUIREMENTS.......................................................................... 10 7.1 20dB BANDWIDTH ................................................................................................ 10-11 7.2 LIMIT OF TRANSMISSION TIME .......................................................................... 12-13 7.3 DUTY CYCLE CORRECTION FACTOR................................................................ 14-16 7.4 RADIATED EMISSION........................................................................................... 17-22 7.5 CONDUCTED EMISSION ...................................................................................... 23-25 FCC ID2ABRK86869937000001 Report No.T130923D06-RP1 Page 4 / 25 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. 1. TEST REPORT CERTIFICATION Applicant App-Tronics LLC Address 1605 Commodore Cove, Painesville, Ohio 44077, U.S.A. Equipment Under Test Car Camera and Warning System Model 2300is Trade Name App-Tronics Tested Date September 23 ~ December 20, 2013 APPLICABLE STANDARD Standard Test Result FCC Part 15 Subpart C AND ANSI C63.4:2009 PASS WE HEREBY CERTIFY THAT: The above equipment has been tested by Compliance Certification Services Inc., and found compliance with the requirements set forth in the technical standards mentioned above. The results of testing in this report apply only to the product/system, which was tested. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Approved by: Reviewed by: Sb. Lu Gundam Lin Sr. Engineer Sr. Engineer FCC ID2ABRK86869937000001 Report No.T130923D06-RP1 Page 5 / 25 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. 2. EUT DESCRIPTION Product Name Car Camera and Warning System Model Number 2300is Identify Number T130923D06 Received Date September 23, 2013 Frequency Range 433.92 MHz Transmit Power 81.86 dBμV/m Type of Modulation ASK Antenna Type Chip Antenna, Antenna Gain 0 dBi Power Rating 12Vdc (From Car Battery) Test Voltage 12Vdc DC Power Cord Type Non-shielded cable 0.5m × 1 (For car charger) I/O Port Power Port × 1, PS2 Port × 2 (Link sensor) Signal Cable Shielded PS2 cable 0.1m × 2 (Non-detachable) Remark : 1. The sample selected for test was engineering sample that approximated to production product and was provided by manufacturer. 2. For more details, please refer to the User’s manual of the EUT. 3. This submittal(s) (test report) is intended for FCC ID: 2ABRK86869937000001 filing to comply with Section 15.207, 15.209 and 15.231 of the FCC Part 15, Subpart C Rules. FCC ID2ABRK86869937000001 Report No.T130923D06-RP1 Page 6 / 25 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. 3. DESCRIPTION OF TEST MODES Radiated Emission (Below 1 GHz) Test: 1. The following test modes were scanned during the preliminary test: No. Pre-Test Mode 1 TX Mode 2. After the preliminary scan, the following test mode was found to produce the highest emission level. Final Test Mode Radiated Emission TX Mode Emission Conducted Emission N/A Remark : The…

Text truncated - open the document above for the full version.

FCC ID2ABRK86869937000001 Report No.T130923D06-RP1 Page 1 / 1 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. APPENDIX SETUP PHOTOS RADIATED EMISSION SETUP
