2ABU6-B8Digital Broadcasting Device

B8 Social Distancing Wristband User Guide Copyrights Reserved by Minew | minew.com Page 1 B8 Social Distancing Wristband User Guide V1.0 Contents 1. Product Layout2 2. Introduction2 3. Features Introduction2 5. Parameters3 6. Separate Main Body and Strap3 7. Charging4 8. Firmware Support4 9. Indicator Description4 10. Caution4 B8 Social Distancing Wristband User Guide Copyrights Reserved by Minew | minew.com Page 2 1.Product Layout ①Strap ②Main body ③Touch button ④Wristband charge port ⑤Indicator light 2.Introduction B8 Wristband is a wearable tag with a vibration motor and a 3-axis accelerometer sensor. It advertises data in a Minew-defined format. Featuring 2-meter safe social distancing alarm and USB direct charging, the tag supports data interaction with MWristband APP. 3.Features Introduction Proximity Alerts When tag wearer A is within 2-meter of wearer B, it is an alarm distance. The wristbands of both wearer A and B will vibrate, and red lights flash. Store Contact Information Enable data storage function of B8 wristband through Demo APP. When tag A detects tag B within 2-meter, tag A will automatically store the ID and contact dates of tag B, and vice versa. If more tags come within a 2-meter range, tag A will automatically store the contact information of all other tags. 4.Turn On/Off Turn On: Press the Touch Button until the blue indicator light flash, meaning the device is activated. Turn Off: The tag can not be turned off via the Touch Button. Users can turn it off via APP. B8 Social Distancing Wristband User Guide Copyrights Reserved by Minew | minew.com Page 3 5.Parameters 6.Separate Main Body and Strap Separate the main body and strap at the Touch Button side. Note: Do not pull the strap directly while trying to separate the main body and strap, try to force the strap out from the left or right side. ItemValue ModelB8 Working Temperature-20°C-60°C Length26cm Charging Time2H Input VoltageDC 5V Built-in SensorACC MaterialMain body: ABS+PC; Strap: TPU Waterproof RateIP67 Weight24.5g ColorDefault Black, other colors can be customized Data Storage20,000 contact records Packing ListWristband, User Guide B8 Social Distancing Wristband User Guide Copyrights Reserved by Minew | minew.com Page 4 7.Charging Insert the charge port of the tag into a charger with USB interface or a computer USB interface to charge. Notes: The charge port is on the same side as the Touch Button. Before charging, dry the charge ports of both the tag and charger. 8. Firmware Support MWristband APP and SDK are provided for developers. Firmware upgrade over the air is supported. 9.Indicator Description 10.Caution Charge the device for around 2 hours before use. Do not hit the main body seriously. Keep away from strong magnetic fields. OperationIndicator Light ChargingGreen Light On Alarm Distance(within 2-meter of another tag)Red Light Flashes, Vibration Alert Low BatteryBlue Light Flashes FCC Requirement changes or modifications not expressly approved by the party responsible for compliance could void the user ’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: – Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. – Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. – Consult the dealer or an experienced radio/TV technician for help.

FCC ID:2ABU6-B8 TestModelNo.:B8 FCC ID:2ABU6-B8 FCC ID:2ABU6-B8 FCC ID:2ABU6-B8

FCC ID:2ABU6-B8 TestModelNo.:B8 FCC ID:2ABU6-B8 FCC ID:2ABU6-B8 FCC ID:2ABU6-B8

Shenzhen Huaxia Testing Technology Co., Ltd 1F., Block A of Tongsheng Technology Building,Huahui Road, Dalang Street, Longhua District, Shenzhen, China Telephone: +86-755-26648640 Fax:+86-755-26648637 Website:www.cqa-cert.com Report Template Version: V04 Repor tTemplate Revision Date: 2018-07-06 RF Exposure Evaluation Report The test report is effective only with both signature and specialized stamp, The result(s) shown in this report refer only to the sample(s) tested. Without written approval of CQA, this report can’t be reproduced except in full. Report No.:CQASZ20200700754E-02 Applicant: Shenzhen Minew Technologies Co., Ltd Address of Applicant:3rd Floor, I Bulding, Gangzhilong Science Park, Qinglong Road, LonghuaDistrict, Shenzhen City, China Equipment Under Test (EUT): EUT Name: Digital Broadcasting Device Model No.:B8 Brand Name:MINEW FCC ID:2 ABU6-B8 Standards: 47 CFR Part 1.1307 47 CFR Part 2.1093 KDB447498D01 General RF Exposure Guidance v06 Date of Receipt:2020-07-27 Date of Test:2020-07-27 to 2020-08-05 Date of Issue:2020-08-06 Test Result:PASS* *In the configuration tested, the EUT complied with the standards specified above Tested By： (TinyYou) Reviewed By: ( Sheek Luo ) Approved By: ( Jack Ai ) Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20200700754E-02 Page: 2 of 6 1Version Revision History Of Report ReportNo.Version Description Issue Date CQASZ20200700754E-02Rev.01 Initial report 2020-08-06 Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20200700754E-02 Page: 3 of 6 2 Contents Page 1 VERSION......................................................................................................................................................................2 2CONTENTS..................................................................................................................................................................3 3 GENERAL INFORMATION........................................................................................................................................4 3.1 C LIENTINFORMATION................................................................................................................................................4 3.2 G ENERALDESCRIPTION OFEUT................................................................................................................................4 4 SAR EVALUATION.....................................................................................................................................................5 4.1 RF E XPOSURECOMPLIANCEREQUIREMENT..............................................................................................................5 4.1.1 Standard Requirement..................................................................................................................................5 4.1.2 Limits................................................................................................................................................................5 4.1.3 EUT RF Exposure..........................................................................................................................................6 Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20200700754E-02 Page: 4 of 6 3 General Information 3.1 Client Information Applicant: Shenzhen Minew Technolo gies Co., Ltd Address of Applicant: 3rd Floor, I Bulding, Gangzhilong Science Park, Qinglong Road, LonghuaDistrict, Shenzhen City, China Manufacturer: Shenzhen Minew Technolo gies Co., Ltd Address of Manufacturer: 3rd Floor, I Bulding, Gangzhilong Science Park, Qinglong Road, Lon ghuaDistrict, Shenzhen City,China Factory: Shenzhen Minew Technologies Co., Ltd Address of Factory: Floor 2-4, Building 3, Instrument World Industrial Park, No. 306, Guanlan Guiyue Road, Longhua District, Shenzhen 3.2 General Description of EUT Product Name: Digital Broadcasting Device Model No.: B8 Trade Mark:MINEW Hardware Version: V1.X Software Version: V1.X Operation Frequency:2402MHz~2480MHz Bluetooth Version:V5.0 Modulation Type:GFSK Transfer Rate:1Mbps Number of Channel:40 Product Type:MobilePortableFix Location Test Software of EUT:nRFgo Studio (manufacturer declare) Antenna Type: PCB antenna Antenna Gain: 0.88 dBi EUT Power Supply: lithium battery:DC3.7V 100mAh Charge by DC5V . Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20200700754E-02 Page: 5 of 6 4 SAR Evaluation 4.1 RF Exposure Compliance Requirement 4.1.1 Standard Requirement According to KDB447498D01 General RF Exposure Guidance v06 4.3.1. Standalone SAR test exclusion considerations Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Exclusion Threshold condition, listed below, is satisfied. 4.1.2 Limits The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)]≤3.0 for 1-g SAR and≤7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation 17 The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is≤50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20200700754E-02 Page: 6 of 6 4.1.3EUT RF Exposure 1) For BLE Measurement Data GFSK mode Test channelPeak Output Power (dBm) Tune up tolerance (dBm) Maximum tune-up Power (dBm)(mW) Lowest(2402MHz)3.553.0±14.02.512 Middle (2440MHz)3.392.5±…

Text truncated - open the document above for the full version.

Shenzhen Huaxia Testing Technology Co., Ltd 1F., Block A of Tongsheng Technology Building,Huahui Road, Dalang Street, Longhua District, Shenzhen, China Telephone: +86-755-26648640 Fax:+86-755-26648637 Website:www.cqa-cert.com Report Template Version: V04 Report Template Revision Date: 2018-07-06 TEST REPORT The test report is effective only with both signature and specialized stamp, The result(s) shown in this report refer only to the sample(s) tested. Without written approval of CQA, this report can’t be reproduced except in full. Report No.: CQASZ20200700754E-01 Applicant: Shenzhen Minew Technologies Co., Ltd Address of Applicant:3rd Floor, I Bulding, Gangzhilong Science Park, Qinglong Road, LonghuaDistrict, Shenzhen City, China Equipment Under Test (EUT): EUT Name:Digital Broadcasting Device Model No.:B8 Brand Name:MINEW FCC ID:2 ABU6-B8 Standards:47 CFR Part 15, Subpart C Date of Receipt:2020-07-27 Date of Test:2020-07-27 to 2020-08-05 Date of Issue:2020-08-06 Test Result:PASS* *In the configuration tested, the EUT complied with the standards specified above Tested By： (TinyYou) Reviewed By: ( Sheek Luo ) Approved By: ( Jack Ai ) Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20200700754E-01 Page: 2 of 44 1Version Revision History Of Report ReportNo.Version Description Issue Date CQASZ20200700754E-01Rev.01 Initial report 2020-08-06 Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20200700754E-01 Page: 3 of 44 2 Test Summary Test ItemTest RequirementTest methodResult Antenna Requirement 47 CFR Part 15, Subpart C Section 15.203/15.247 (c) ANSI C63.10 2013PASS AC Power Line Conducted Emission 47 CFR Part 15, Subpart C Section 15.207 ANSI C63.10 2013N/A Conducted Peak Output Power 47 CFR Part 15, Subpart C Section 15.247 (b)(3) ANSI C63.10 2013PASS 6dB Occupied Bandwidth 47 CFR Part 15, Subpart C Section 15.247 (a)(2) ANSI C63.10 2013PASS Power Spectral Density 47 CFR Part 15, Subpart C Section 15.247 (e) ANSI C63.10 2013PASS Band-edge for RF Conducted Emissions 47 CFR Part 15, Subpart C Section 15.247(d) ANSI C63.10 2013PASS RF Conducted Spurious Emissions 47 CFR Part 15, Subpart C Section 15.247(d) ANSI C63.10 2013PASS Radiated Spurious Emissions 47 CFR Part 15, Subpart C Section 15.205/15.209 ANSI C63.10 2013PASS Restricted bands around fundamental frequency (Radiated Emission) 47 CFR Part 15, Subpart C Section 15.205/15.209 ANSI C63.10 2013PASS N/A: When the EUT charging, BLE will not work , So Not Applicable Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20200700754E-01 Page: 4 of 44 3 Contents Page 1 VERSION....................................................................................................................................................................2 2 TEST SUMMARY......................................................................................................................................................3 3CONTENTS................................................................................................................................................................4 4 GENERAL INFORMATION.....................................................................................................................................5 4.1 C LIENTINFORMATION........................................................................................................................................... 5 4.2 G ENERALDESCRIPTION OFEUT...........................................................................................................................5 4.3 A DDITIONALINSTRUCTIONS..................................................................................................................................7 4.4 T ESTENVIRONMENT..............................................................................................................................................8 4.5 D ESCRIPTION OFSUPPORTUNITS..........................................................................................................................8 4.6 S TATEMENT OF THE MEASUREMENT UNCERTAINTY..............................................................................................9 4.7 T ESTLOCATION...................................................................................................................................................10 4.8 T ESTFACILITY.....................................................................................................................................................10 4.9 D EVIATION FROMSTANDARDS............................................................................................................................10 4.10 O THERINFORMATIONREQUESTED BY THECUSTOMER......................................................................................10 4.11 E QUIPMENTLIST................................................................................................................................................. 11 5 TEST RESULTS AND MEASUREMENT DATA............................................................................................... 12 5.1 A NTENNAREQUIREMENT.................................................................................................................................... 12 5.2 C ONDUCTEDPEAKOUTPUTPOWER....................................................................................................................13 5.3 6 DBOCCUPYBANDWIDTH..................................................................................................................................16 5.4 P OWERSPECTRALDENSITY................................................................................................................................19 5.5 B AND-EDGE FORRF CONDUCTEDEMISSIONS.................................................................................................... 22 5.6 S PURIOUSRF CONDUCTEDEMISSIONS.................................................................................…

Text truncated - open the document above for the full version.

FCC ID:2ABU6-B8 1 Photographs - EUT Test Setup 1.1 Radiated Spurious Emission 9KHz~30MHz: 30MHz~1GHz: FCC ID:2ABU6-B8 Above 1GHz:
