2ABU6-DS116Electronic Shelf Label

Shenzhen Minew Technologies Co., Ltd.

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Dec 19, 2023
Application Purpose: Original Equipment
Date of Application: Dec 19, 2023
Equipment Note: Electronic Shelf Label
Frequency Range: 2402.00000000 - 2480.00000000
Company: Shenzhen Minew Technologies Co., Ltd.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

0°C-40°C -20°C-60°C 09:00-11:30 Marketing Brainstorming Roger 5+ Attendees UPCOMING 14:00-15:00 Interview X-man 15:30-16:30 product Perfoemance Dec 15 09:00-15:00 orientation ¡ ¡ Address：Building I, Gangzhilong Science Park, Qinglong Road, Longhua District, Shenzhen, 518109, China Phone：+86(755)2103 8160 Email: [email protected] Website： https://www.minewtag.com FCC Requirement changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residentialinstallation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interferencewill not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception,which can be determined by turn- ing the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ‒ Reorient or relocate the receiving antenna. ‒ Increase the separation between the equipment and receiver. ‒ Connect the equipment into an outlet on a circuit different from that towhich the receiver is connected. ‒ Consult the dealer or an experienced radio/TV technician for help. To maintain compliance with FCC’s RF Exposure guidelines, This equipment should be installed and operated with minimum distance between 20cm the radiator your body: Use only the supplied antenna.

Attestation Statements

Sh enzhen Minew Technologies Co., Ltd . The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Federa l Communications Commission Authori zation and Evaluation Division Equipment Authori zation Bra nch 7435 Oakland Mills Road Columbia, MD 21046 12 /13/23 U.S . Agent Designati on [Shenzhen Min ew Technolo gie s Co., Ltd.]acknowledges th eir consent fo r th e following conta ct located in th e Unite d Sta te s to act as th eir agent for service of process for th e equipment for which auth orizati on is sought (FCC ID :2ABU6-DS116): Name and company of U.S . agent: Sijie Zhang / THREE STONES MEDIA LLC Physical U.S . address of agent: 1200 Broadway St. APT 329, Los Angeles, CA90015 FRN of U.S . agent: 0033401761 Email address of U.S . agent: [email protected] o m [THREE STONES MEDIA LLC]acknowledges th eir obligati on to accept service of process on behalf of[Shenzhen Min ew Technolo gie s Co., Ltd.]. [Shenzhen Min ew Technolo gie s Co., Ltd.]with th e FRN[0023364128]accepts its obligati on to mainta in an agent fo r service of process in th e Unite d Sta te s fo r no less th an one year afte r either th e grante e has permanentl y te rminated all marketi ng and importa tion of th e applicable equipment with in th e U.S ., or th e conclusion of any Co mmission-relate d administr ati ve or judicial proceeding involving th e equipment, whichever is later. By signing th is fo rm, we confirm th e above and th at we are aware of th e applicati on requirements liste d under § 2.9 11(d)(7). Sincerely, Signature [Name] yanyan Zhang [Title] Quality Superv isor [Company] Shenzhen Minew Technologies Co., Ltd. Signature [Name of U.S. agent] Sijie Zhang [Title of U.S. agent] [Company of U.S. agent] THREE STONES MEDIA LLC 48_[model] US_Agent_2.911(d)(7)-U, V04

Attestation Statements

ShenzhenMinewTechnologiesCo.,Ltd. TheinformationprovidedinthisletterisbasedonthereferencedrulepartsofTitle47oftheCFRaswellasKDB986446D01. FederalCommunicationsCommission AuthorizationandEvaluationDivision EquipmentAuthorizationBranch 7435OaklandMillsRoad Columbia,MD21046 12/13/23 Towhomitmayconcern: We,[ShenzhenMinewTechnologiesCo.,Ltd.],herebycertifythattheequipmentforwhich authorizationissought(FCCID:2ABU6-DS116)isnot“covered”equipmentprohibitedfromreceiving anequipmentauthorizationpursuantto§2.903oftheFCCrules. Wealsocertifythat,asofthedateofthefilingoftheapplication,wearenotidentifiedontheCovered List(https://www.fcc.gov/supplychain/coveredlist)asanentityproducing“covered”equipment. Bysigningthisform,weconfirmtheaboveandthatweareawareoftheapplicationrequirements listedunder§2.911(b)and(d)(5)and(6). Sincerely, Signature [Name]yanyanZhang [Title]QualitySupervisor [Company]ShenzhenMinewTechnologiesCo.,Ltd. 6 2 _ [ m o d e l ] C o v e r e d E q u _ 2 . 9 1 1 ( d ) ( 5 ) ( i ) a n d ( i i ) - U , V 0 2

External Photos

ATTACHMENT PHOTOGRAPHS OF EUT Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6

ID Label/Location Info

部品料号 NO. 年.月.日版本变更记录签名未标公差 ±0.1 ±0.12 ±0.2 ±0.4 ±0.5 L≦4 4＜L≦16 16＜L≦63 63＜L≦250 250＞L 表面处理材质颜色 1 2 3 单位: mm 比例:1/1 结构年.月.日深圳云里物里科技股份有限公司 V005 Y-YB-CR-065 密级：绝密部品名称版本部品规格书生效日期美工硬件审核 NPI This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Model: DS116 FCC ID: 2ABU6-DS116 MAC: XXXXXXXXXXXX Made in China SHENZHEN MINEW TECHNOLOGIES CO LTD-R/N-

Internal Photos

Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 NFC receiver ANT Photo 7 Photo 8 BT ANT Photo 9 Photo 10 Photo 11

RF Exposure Info

FCC ID: 2ABU6-DS116 RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b) Limits for Maximum Permissible Exposure (MPE) MPE Calculation Method E (V/m) ＝ d GP**30 Power Density: Pd (W/m²) ＝ 377 2 E E ＝ Electric field (V/m) P ＝ Average RF output power (W) G ＝ EUT Antenna numeric gain (numeric) d ＝ Separation distance between radiator and human body (m) The formula can be changed to Pd ＝ 2 *377 **30 D GP From the EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. Measurement Result Operation Frequency: BLE: 2402-2480MHz Power density limited: 1mW/ cm 2 Antenna Type: PCB Antenna Antenna gain: 3.7 dBi, R=20cm conducted power Evaluation result Power density Limits (dBm)(mW)(dBi)Numeric 2402 3.33±14 2.5123.72.340.00121 2440 3.433±14 2.5123.72.340.00121 2480 3.533±14 2.5123.72.340.00121 2402 3.313±14 2.5123.72.340.00121 2440 3.453±14 2.5123.72.340.00121 2480 3.533±14 2.5123.72.340.00121 (mW/cm2 )(mW/cm2) Antenna Gain BLE(1M) Max tune-up power Channel Freq. (MHz) modulation Tune-up power (dBm) (dBm) BLE(2M) Conclusion: For the max result : 0.0012≤ 1.0 for Max Power Density, compliance RF exposure.. Signature: Date: 12/14/2023 NAME AND TITLE (Please print or type): Alex Li/Manager COMPANY (Please print or type): Shenzhen NTEK Testing Technology Co., Ltd./ 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen P.R. China.

Test Report

Report No.: S23112201728001 Version.1.3 Page 1 of 54 RADIO TEST REPORT FCC ID: 2ABU6-DS116 Product: Electronic Shelf Label Trade Mark: Model No.: DS116 Family Model: DS116R, DS116Y, DS116Q Report No.: S23112201728001 Issue Date: Dec 07. 2023 Prepared for Shenzhen Minew Technologies Co., Ltd. 3rd Floor, I Building, Gangzhilong Science Park, Qinglong Road, Longhua District, Shenzhen City, China Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community,Xixiang Street Bao’an District, Shenzhen 518126 P.R. China Tel:400-800-6106,0755-2320 0050 / 2320 0090 Website: http://www.ntek.org.cn Report No.: S23112201728001 Version.1.3 Page 2 of 54 TABLE OF CONTENTS 1 TEST RESULT CERTIFICATION ...................................................................................................................... 3 2 SUMMARY OF TEST RESULTS ......................................................................................................................... 4 3 FACILITIES AND ACCREDITATIONS ............................................................................................................. 5 3.1 FACILITIES..................................................................................................................................................... 5 3.2 LABORATORY ACCREDITATIONS AND LISTINGS ................................................................................. 5 3.3 MEASUREMENT UNCERTAINTY ............................................................................................................... 5 4 GENERAL DESCRIPTION OF EUT .................................................................................................................. 6 5 DESCRIPTION OF TEST MODES ..................................................................................................................... 8 6 SETUP OF EQUIPMENT UNDER TEST ........................................................................................................... 9 6.1 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM ....................................................................... 9 6.2 SUPPORT EQUIPMENT ............................................................................................................................... 10 6.3 EQUIPMENTS LIST FOR ALL TEST ITEMS .............................................................................................. 11 7 TEST REQUIREMENTS .................................................................................................................................... 13 7.1 CONDUCTED EMISSIONS TEST ............................................................................................................... 13 7.2 RADIATED SPURIOUS EMISSION ............................................................................................................ 15 7.3 6DB BANDWIDTH ....................................................................................................................................... 24 7.4 DUTY CYCLE ............................................................................................................................................... 25 7.5 PEAK OUTPUT POWER .............................................................................................................................. 27 7.6 POWER SPECTRAL DENSITY ................................................................................................................... 28 7.7 CONDUCTED BAND EDGE MEASUREMENT......................................................................................... 30 7.8 SPURIOUS RF CONDUCTED EMISSIONS ................................................................................................ 31 7.9 ANTENNA APPLICATION .......................................................................................................................... 32 8 TEST RESULTS ................................................................................................................................................... 33 8.1 1M .................................................................................................................................................................. 33 8.2 2M .................................................................................................................................................................. 44 Report No.: S23112201728001 Version.1.3 Page 3 of 54 1 TEST RESULT CERTIFICATION Applicant’s name .................... : Shenzhen Minew Technologies Co., Ltd. Address .................................. : 3rd Floor, I Building, Gangzhilong Science Park, Qinglong Road, Longhua District, Shenzhen City, China Manufacturer's Name ............. : Shenzhen Minew Technologies Co., Ltd. Address .................................. : Building 3, Instrument World Industrial Park, No. 306, Guanlan Guiyue Road, Longhua District, Shenzhen Product description Product name ......................... : Electronic Shelf Label Model and/or type reference : DS116 Family Model .......................... : DS116R, DS116Y, DS116Q Test Sample Number .............. : S231122017028 Date (s) of performance of tests ............. : Nov 22. 2023 ~ Dec 07. 2023 Measurement Procedure Used: APPLICABLE STANDARDS APPLICABLE STANDARD/ TEST PROCEDURE TEST RESULT FCC 47 CFR Part 2, Subpart J FCC 47 CFR Part 15, Subpart C KDB 174176 D01 Line Conducted FAQ v01r01 ANSI C63.10-2013 KDB 558074 D01 15.247 Meas Guidance v05r02 Complied This device described above has been tested by Shenzhen NTEK Testing Technology Co., Ltd., and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of Shenzhen NTEK Testing Technology Co., Ltd., this document may be altered or revised by Shenzhen NTEK Testing Technolo…

Text truncated - open the document above for the full version.

Test Report

version01 ShenzhenMinewTechnologiesCo.,Ltd. DeclarationconcerningAntennaSpecification Itisherebydeclaredthattheproduct ModelNo.:DS116,DS116R,DS116Y,DS116Q FCCID:2ABU6-DS116 fulfillstherequirementinFCCtestrelatingtotheantennatype. ThedevicespecifiedaboveconfirmstotheFCCrecommendationsforPCBAntennaantennatype(s) describedbelow: ModelNo.ofantenna:ANT-BBNCNC23015 Typeofantenna: PCBAntenna Gainoftheantenna:3.7dBi Frequencyrange:2400-2480MHz Themountingoftheantennaisfixedtotheradiomoduleandnootherantennashouldbeused. Companyname: ShenzhenMinewTechnologiesCo.,Ltd. Address:3rdFloor,IBuilding,GangzhilongSciencePark,QinglongRoad,Longhua District,ShenzhenCity,China City:ShenzhenCity ZIP/Postalcode: Country:China Name:yanyanZhangDate:13/12/2023 Signature:

Test Report

深圳云里物里科技股份有限公司产品天线测试报告（TheAntennaTestReport） Y-YB-CR-089V003密级：绝密/confidentiality 第1页共6页天线型号（AntennaVersion）：ANT-BBNCNC23015 产品型号（ ModeloftheDUT ）： DS116 PCB 编号及版本（ PCBnumberandversion ） :ES002EX_V1.0 责任硬件工程师（ HardwareEngineer ）：窦淼全测试日期（ TestData ）： 2023.11.21 1 、技术指标 (TechnicalSpecification) 电性能指标 ElectricalSpecifications 频率范围 FrequencyRange （ MHz ） 2400-2480 频带宽度 Bandwidth(-10dB) （ MHz ） 300MHZ 输入阻抗InputImpedance（Ω） 50 回波损耗ReturnLoss（dB）＜-13 电压驻波比VSWR＜1.5 增益 Gain(@2.44GHz) （ dBi ） 3.27 峰值增益（ PeakGain ）（ dBi ） 3.7 极化形式PolarizationType 线极化 Linearpolarization 雷电保护 LightningProtection 直流接地（DCgrounding）功率容量PowerCapacity（mW） 1000 机械指标MechanicalSpecifications 天线尺寸 AntennaSize(mm) 20mm*4.5mm 辐射体 Radiator 铜 Cuprum 连接器型号 ConnectType 无工作温度WorkingTemperature（°C） -20~50 存储温度StorageTemperature（°C） -40~65 2 、天线外形和尺寸（ theshapeandsizeoftheantenna ）深圳云里物里科技股份有限公司产品天线测试报告（TheAntennaTestReport） Y-YB-CR-089V003密级：绝密/confidentiality 第2页共6页 3、测试结果（ Theresultofthetest ）深圳云里物里科技股份有限公司产品天线测试报告（TheAntennaTestReport） Y-YB-CR-089V003密级：绝密/confidentiality 第3页共6页 3.1增益和效率 (GainandEfficiency) 深圳云里物里科技股份有限公司产品天线测试报告（TheAntennaTestReport） Y-YB-CR-089V003密级：绝密/confidentiality 第4页共6页深圳云里物里科技股份有限公司产品天线测试报告（TheAntennaTestReport） Y-YB-CR-089V003密级：绝密/confidentiality 第5页共6页 3.2辐射方向图(R adiationPattern) 3D 方向图 2402MHz2440MHz2480MHz （1）E1，XZ面，phi=0°;（E1，XZplane，phi=0°）（2）E2，YZ面，phi=90°;（E2，YZ面，phi=90°）深圳云里物里科技股份有限公司产品天线测试报告（TheAntennaTestReport） Y-YB-CR-089V003密级：绝密/confidentiality 第6页共6页（ 3 ） H ， XY 面， theta=90 ° ; （ H ， XYplane ， theta=90 °）

Test Setup Photos

Radiated Measurement Photos
