2ABU6-MBS01Pallet Beacon

BriefIntroduction MBS01withnRF52serieschipandsupportingBLE5.0protocolisalow-consumptionbeaconfor trailertracking;itiseasilyinstalledonthetrailerorforkliftsduetoitsspecialdesign;Besides, basedontheindoorpositioningtechnology,theproductcanhelpindustriesincludingfactory manufacturingandwarehousemanagementtoachievedigitalandvisualmanagementonassets. KeyFeatures BLE5.0&nRF52Series 40MonthsofServiceLife AccidentalShutdownPrevention Ik08Shockproof IP65Waterproof&Dustproof 100mBroadcastingDistance MarketApplications SmartWarehouseManagement SmartIndustrialManufacturing DeviceSpecifications BasicParameters ItemValueRemarks MaterialABSNull ColorBlack/GreyOptional Protection IP65、IK08 Null Dimensions（L*W*H） 116.1*25.2*9.2mmNull NetWeight19gBatteryincluded Battery 1pcCRseriesbatterypack （ 2pcsunitsincluded ） 440mAhtotalcapacity BatteryLifetime40Monthsbydefault ChipModelnRF52seriesNull BluetoothStandardBLE5.0Null BluetoothProtocol iBeacon&Eddystone Null ConfigurationAppBeaconSET+Null SensorsNoNull NFCNoNull LEDNoNull OTANoNull Operating Temperature -20~60°C Null DefaultBroadcastingParameters(BeaconPlusFirmware) TypeItemDefaultSettings iBeacon (On) UUID(16bytes)E2C56DB5-DFFB-48D2-B060-D0F5A71 096E0 Major(2bytes)0 Minor(2bytes)0 Measuredpower-59dBm(0xC5) Txpower0dBm Interval(ms)2000ms UID (Off) InstanceIDRandom NamespaceIDRandom Measuredpower-24dBm(0xE8) Txpower0dBm Interval(ms)2000ms URL (Off) URLhttp://www.minew.com/ Measuredpower-24dBm(0xE8) Txpower0dBm Interval(ms)2000ms TLM (Off) ElectricitymVBydefault PDUpacketsBydefault Boot-timeBydefault Measuredpower-24dBm(0xE8) Txpower0dBm Interval(ms)4000ms INFO (On) DeviceNameMBS01 ElectricityBydefault MACAddressFactorysetting Measuredpower-24dBm(0xE8) Txpower-8dBm Interval(ms)4000ms Sensor (Off) SensordataNo Password minew123Bydefault ConnectableYesItisconfigurationmode Compatibility SystemsSupportVersionSupport iOS10.0andabove iPhone6/6Plus/6S/6SPlus,iPhone7/7Plus, iPhone8/8Plus,iPhonex/xr/xs/xsmax, iPhone11/11pro/11promax, iPadmini/mini2/4/Air/Pro,etc. Android4.3andabove SAMSUNG,MIUI,HUAWEI,ONEPLUS,VIVO, OPPO,etc. ProductAppearance Installations Methods:Double-sideadhesivetape&Screwinstallation Details: Double-sideadhesivenotes: RecommendedInstallationEnvironment:ThematerialsurfaceshouldbeAluminum, galvanizedsteel,enamelsteel,stainlesssteel,ceramic,glass/epoxyresin,acrylic,PBT,ABS, PC,hardPVC,etc. TemperatureRange:10~75 °C BestTemperature:21~38°C,useinalow-temperature Requirements:Nodustonthematerialsurfaceandcleanitbeforeinstallation.Before pasting,increasingtheviscositywithahairdryer,orstickingitoverhalf-hoursata reasonabletemperatureandthenpressingfor2secondsandrepeatforbetterstability. Screwinstallationnotes: RecommendedInstallationEnvironment:Screwsinstallationshouldbeconsideredonthe woodenpallet,ironshelf,etc. TemperatureRange:-20~60°C DetailSteps: FirstStep:drillscrewholesonthesurfaceofahardsurfacetobeinstalled. Second:putthegreenexpansionplugintothescrewholesonthehardsurfacetobe installed. TheLast:putthescrewsintothegreenexpansionplug,andinstalltheproductinthe directionofscrewholes. Notes:thediameterofscrewsholeis6mm;theinstallationaboveisonlyasareference;users shouldinstalltheproductaccordingtotheactualsituation. Cautions Theproductisdesignedwithnobuttonandswitchedonwhenshippingforavoidingthe falsetrigger,anditalsocannotbeswitchedoffbyconfigurationappuntilthebatteryis exhausted. Inahumidenvironment,theproductneedstobeinstalledaccordingtoitswaterproofgrade, andshouldavoidsoakingforalong-time. BLEbeaconsshouldbeinstalledawayfromobstaclesandcorners. Itisnotrecommendedusersturnonallbroadcastingframesforalongservicelife. Itwouldbedamagedbyusingoverthenormaloperatingtemperature. Pleaseavoidthedirectsunshinesothatdamagestheshellandaffectstheshockproofgrade. TheMinewgroupwillnotberesponsibleforthedamageorinjurybyillegallydissembling themainbody. ProductPackage Certifications FCC warning: Any Changes or modifications not expressly approved by the party responsible for compliance co uld void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note:This equipmenthas beentestedand foundto complywiththe limitsfor a ClassB digitalde vice,pursuantto part 15 of the FCC Rules.Theselimitsare designedto providereasonableprotec tion againstharmfulinterferencein a residentialinstallation.This equipmentgeneratesusesand can radiateradiofrequencyenergyand,if not installedand usedin accordancewiththe instructi ons, may causeharmfulinterferenceto radiocommunications.However,thereis no guaranteeth at interferencewill not occurin a particularinstallation.If this equipmentdoescauseharmfulint erferenceto radioor televisionreception,whichcan be determinedby turningthe equipmentoff and on, the user is encouragedto try to correctthe interferenceby one or moreof the following measures: -Reorientor relocatethe receivingantenna. -Increasethe separationbetweenthe equipmentand receiver. -Connectthe equipmentinto an outleton a circuitdifferentfromthat to whichthe receiveris con nected. -Consultthe dealeror an experiencedradio/TVtechnicianfor help. This equipmentcomplieswithFCC radiationexposurelimitsset forthfor an uncontrolledenviron ment.This equipmentshouldbe installedand operatedwithminimumdistance20cmbetweent he radiator& yourbody. ItemsInnerBox (Batteryexcluded)OuterBox (Batteryexcluded) PackagePicture Quantity36 Pcs/box360 Pcs/box Net Weight684 g/box6.84 kg/box GrossWeight762 g/box8.1 kg/box Dimensions30.5 x 11 x 7. 2 cm32 x 23 .5 x 40 cm QualityAssurance ThefactoryhasalreadyobtainedthecertificationofISO9001QualitySystem.Eachproducthas beenstrictlytested(testingincludetransmissionpower,sensitivity,powerconsumption,stability, aging,etc.). WarrantyPeriod:12monthsfromthedateofshipping(Batteryandother…

Text truncated - open the document above for the full version.

Sh enzhen Minew Technologies Co., Ltd . The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Federa l Communications Commission Authori zation and Evaluation Division Equipment Authori zation Bra nch 7435 Oakland Mills Road Columbia, MD 21046 7/ 12/23 U.S . Agent Designati on [Shenzhen Min ew Technolo gie s Co., Ltd.]acknowledges th eir consent fo r th e following conta ct located in th e Unite d Sta te s to act as th eir agent for service of process for th e equipment for which auth orizati on is sought (FCC ID :2ABU6-MBS01): Name and company of U.S . agent: Sijie Zhang / THREE STONES MEDIA LLC Physical U.S . address of agent: 1200 Broadway St. APT 329, Los Angeles, CA90015 FRN of U.S . agent: 0033401761 Email address of U.S . agent: [email protected] o m [THREE STONES MEDIA LLC]acknowledges th eir obligati on to accept service of process on behalf of[Shenzhen Min ew Technolo gie s Co., Ltd.]. [Shenzhen Min ew Technolo gie s Co., Ltd.]with th e FRN[0023364128]accepts its obligati on to mainta in an agent fo r service of process in th e Unite d Sta te s fo r no less th an one year afte r either th e grante e has permanentl y te rminated all marketi ng and importa tion of th e applicable equipment with in th e U.S ., or th e conclusion of any Co mmission-relate d administr ati ve or judicial proceeding involving th e equipment, whichever is later. By signing th is fo rm, we confirm th e above and th at we are aware of th e applicati on requirements liste d under § 2.9 11(d)(7). Sincerely, Signature [Name] yanyan Zhang [Title] Quality Superv isor [Company] Shenzhen Minew Technologies Co., Ltd. Signature [Name of U.S. agent] Sijie Zhang [Title of U.S. agent] [Company of U.S. agent] THREE STONES MEDIA LLC 48_[model] US_Agent_2.911(d)(7)-U, V04

ShenzhenMinewTechnologiesCo.,Ltd. TheinformationprovidedinthisletterisbasedonthereferencedrulepartsofTitle47oftheCFRaswellasKDB986446D01. FederalCommunicationsCommission AuthorizationandEvaluationDivision EquipmentAuthorizationBranch 7435OaklandMillsRoad Columbia,MD21046 7/12/23 Towhomitmayconcern: We,[ShenzhenMinewTechnologiesCo.,Ltd.],herebycertifythattheequipmentforwhich authorizationissought(FCCID:2ABU6-MBS01)isnot“covered”equipmentprohibitedfromreceiving anequipmentauthorizationpursuantto§2.903oftheFCCrules. Wealsocertifythat,asofthedateofthefilingoftheapplication,wearenotidentifiedontheCovered List(https://www.fcc.gov/supplychain/coveredlist)asanentityproducing“covered”equipment. Bysigningthisform,weconfirmtheaboveandthatweareawareoftheapplicationrequirements listedunder§2.911(b)and(d)(5)and(6). Sincerely, Signature [Name]yanyanZhang [Title]QualitySupervisor [Company]ShenzhenMinewTechnologiesCo.,Ltd. 6 2 _ [ m o d e l ] C o v e r e d E q u _ 2 . 9 1 1 ( d ) ( 5 ) ( i ) a n d ( i i ) - U , V 0 2

ATTACHMENT PHOTOGRAPHS OF EUT Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6

Pallet Beacon ModelMBS01 FCC ID: 2ABU6-MBS01 Pallet Beacon ModelMBS01 FCC ID: 2ABU6-MBS01

Photo 7 Photo 8 ANT Photo 9

Report No.: S23062501905001 Version.1.3 Page 1 of 60 RADIO TEST REPORT FCC ID: 2ABU6-MBS01 Product: Pallet Beacon Trade Mark: MINEW Model No.: MBS01 Family Model: N/A Report No.: S23062501905001 Issue Date: Jul 03, 2023 Prepared for Shenzhen Minew Technologies Co., Ltd. 3rd Floor, I Building, Gangzhilong Science Park, Qinglong Road, Longhua District, Shenzhen City, China Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen 518126 P.R. China Tel. 400-800-6106, 0755-2320 0050, 0755-2320 0090 Website: http://www.ntek.org.cn Report No.: S23062501905001 Version.1.3 Page 2 of 60 TABLE OF CONTENTS 1 TEST RESULT CERTIFICATION ...................................................................................................................... 4 2 SUMMARY OF TEST RESULTS ......................................................................................................................... 5 3 FACILITIES AND ACCREDITATIONS ............................................................................................................. 6 3.1 FACILITIES..................................................................................................................................................... 6 3.2 LABORATORY ACCREDITATIONS AND LISTINGS ................................................................................. 6 3.3 MEASUREMENT UNCERTAINTY ............................................................................................................... 6 4 GENERAL DESCRIPTION OF EUT .................................................................................................................. 7 5 DESCRIPTION OF TEST MODES ..................................................................................................................... 9 6 SETUP OF EQUIPMENT UNDER TEST ......................................................................................................... 10 6.1 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM ..................................................................... 10 6.2 SUPPORT EQUIPMENT............................................................................................................................... 11 6.3 EQUIPMENTS LIST FOR ALL TEST ITEMS .............................................................................................. 12 7 TEST REQUIREMENTS .................................................................................................................................... 14 7.1 CONDUCTED EMISSIONS TEST ............................................................................................................... 14 7.1.1 Applicable Standard .................................................................................................................................. 14 7.1.2 Conformance Limit ................................................................................................................................... 14 7.1.3 Measuring Instruments............................................................................................................................. 14 7.1.4 Test Configuration .................................................................................................................................... 14 7.1.5 Test Procedure ........................................................................................................................................... 14 7.1.6 Test Results ................................................................................................................................................ 15 7.2 RADIATED SPURIOUS EMISSION ............................................................................................................ 16 7.2.1 Applicable Standard .................................................................................................................................. 16 7.2.2 Conformance Limit ................................................................................................................................... 16 7.2.3 Measuring Instruments............................................................................................................................. 17 7.2.4 Test Configuration .................................................................................................................................... 17 7.2.5 Test Procedure ........................................................................................................................................... 18 7.2.6 Test Results ................................................................................................................................................ 19 7.3 6DB BANDWIDTH ....................................................................................................................................... 25 7.3.1 Applicable Standard .................................................................................................................................. 25 7.3.2 Conformance Limit ................................................................................................................................... 25 7.3.3 Measuring Instruments............................................................................................................................. 25 7.3.4 Test Setup .................................................................................................................................................. 25 7.3.5 Test Procedure ........................................................................................................................................... 25 7.3.6 Test Results ................................................................................................................................................ 25 7.4 DUTY CYCLE ............................................................…

Text truncated - open the document above for the full version.

version01 ShenzhenMinewTechnologiesCo.,Ltd. DeclarationconcerningAntennaSpecification Itisherebydeclaredthattheproduct ModelNo.:MBS01 FCCID:2ABU6-MBS01 fulfillstherequirementinFCCtestrelatingtotheantennatype. ThedevicespecifiedaboveconfirmstotheFCCrecommendationsforPCBAntennaantennatype(s) describedbelow: ModelNo.ofantenna:ANT-BBNCNC20008 Typeofantenna: PCBAntenna Gainoftheantenna:3.39dBi Frequencyrange:2400-2480MHz Themountingoftheantennaisfixedtotheradiomoduleandnootherantennashouldbeused. Companyname:ShenzhenMinewTechnologiesCo.,Ltd. Address:3rdFloor,IBuilding,GangzhilongSciencePark,QinglongRoad,LonghuaDistrict, ShenzhenCity,China City:ShenzhenCity ZIP/Postalcode: Country: China Name:yanyanZhangDate: 12/07/2023 Signature:

深圳云里物里科技股份有限公司 产品天线测试报告（TheAntennaTestReport） Y-YB-CR-115V001密级：绝密/confidentiality 第1页共6页 AntennaCoding：ANT-BBNCNC20008 AntennaType：PCBonboardAntenna ModeloftheDUT ： MBS01 AntennaManufacturer：ShenzhenMinewTechnologiesCo.,Ltd. 1、TechnicalSpecification ElectricalSpecifications FrequencyRange（MHz） 2400-2480 InputImpedance（Ω） 50 ReturnLoss（dB）＜-10 VSWR ＜ 2 PeakGain （ dBi ） 3.39 PolarizationTypeLinearpolarization MechanicalSpecifications AntennaSize(mm)16.5*5.99 RadiatorCuprum 2、Theshapeandsizeoftheantenna 深圳云里物里科技股份有限公司 产品天线测试报告（TheAntennaTestReport） Y-YB-CR-115V001密级：绝密/confidentiality 第2页共6页 3、Theresultofthetest 3.1TestEnvironment 深圳云里物里科技股份有限公司 产品天线测试报告（TheAntennaTestReport） Y-YB-CR-115V001密级：绝密/confidentiality 第3页共6页 3.2GainandEfficiency 深圳云里物里科技股份有限公司 产品天线测试报告（TheAntennaTestReport） Y-YB-CR-115V001密级：绝密/confidentiality 第4页共6页 3.33D PolarPlot 2402MHz 2440MHz 深圳云里物里科技股份有限公司 产品天线测试报告（TheAntennaTestReport） Y-YB-CR-115V001密级：绝密/confidentiality 第5页共6页 2480MHz 3.42DRadiationPattern （1）E1，XZPlane，phi=0 深圳云里物里科技股份有限公司 产品天线测试报告（TheAntennaTestReport） Y-YB-CR-115V001密级：绝密/confidentiality 第6页共6页 （2）E2，YZPlane，phi=90° （3）H，XYplane，theta=90°

Radiated Measurement Photos
