2ABU6-MS56PXDigital Broadcasting Device (iBeacon)

TEL: +86-755-8886 8480 FAX: +86-755-2982 5342 EMAIL: [email protected] URL: www.rfodm.com Page 2 Minew Technologies MS56 Min iBeacon Datasheet V1.0 D D e e s s c c r r i i p p t t i i o o n n The MiniBeacon MS56PX is developed and produced including hardware and firmware all by MINEW Technologies. It is built-in a battery holder and a coin battery, it can work as a standalone system. Moreover, MS56PX is based on CC2540/CC2541 BLE 4.0 module and built-in an advanced power management unit, the advanced power management unit helps MiniBeacon to save at least 20% battery energy than other beacons without this unit. A A b b o o u u t t M M i i n n i i B B e e a a c c o o n n - Built-in MiniBeacon firmware - Built-in a 1000mAh CR2477 battery - Bluetooth low energy technology compatible - Excellent link budget (up to 97dB) - Suitable for long distance applications - Accurate digital RSSI - High performance and low power 8051 core MCU - AES security coprocessor C C e e r r t t i i f f i i c c a a t t i i o o n n s s - iBeacon License - FCC Regulation (FCC Part 15) - CE Regulations (Included EN300328, EN301489, EN60950, EN62479) F F e e a a t t u u r r e e & & A A d d v v a a n n t t a a g g e e - Application for advertisement and proximity location - Supports both iOS 7.0+ and Android 4.3+ system - Built-in pairing password to prevent others changing the settings - MiniBeacon name, UUID, Major, Minor values and broadcasting interval can be changed by customer - Battery capacity intelligent detecting and notification feature - Supports soft reboot function, no longer required to take out the battery to reboot the device - MiniBeacon serial ID can be customized, it will help customer to easily distinguish which one is which - Placed a button on the board used to activate / shutdown beacon device - Supports the connectable and non-connectable broadcasting mode - Supports the OAD function - Publishes the free upgraded firmware regularly - Built-in JTAG port for other customized application firmware as a standalone system - The customer’s logo can be printed on the housing if required - Customized housing and firmware services will be welcomed Image 1 TEL: +86-755-8886 8480 FAX: +86-755-2982 5342 EMAIL: [email protected] URL: www.rfodm.com Page 3 Minew Technologies MS56 Min iBeacon Datasheet V1.0 R R a a p p i i d d l l y y t t o o B B u u i i l l d d a a H H o o u u s s i i n n g g f f o o r r y y o o u u r r B B e e a a c c o o n n MS56 consists of silicone rubber housing and iBC08 kernel. The iBC08 kernel is a small iBeacon unit with a matt-white plastic housing in fact, its size is 33 x 34 x 15mm. Based on the iBC08 kernel, it quite easy and rapidly to build a housing for your beacons in low cost. How easy and rapidly? 1) we would like to provide many different housing designs for you to choose; 2) we can help you to build a housing in 15 days, but the rights of casing belongs to you; Is it truly low cost? Sure. Please give us an email or phone call, further detailed quotation will be sent to you in 24 hrs. Image 2 Image 3 O O p p e e r r a a t t i i o o n n I I n n s s t t r r u u c c t t i i o o n n s s 1. Activate MiniBeacon as below method before using device 1.1 Press the BUTTON and keep holding 10 seconds, the Blue LED will light on 5 seconds and then off; it means that MiniBeacon was wakening up and starts to broadcasting. See image 4 and 5. 2. Shutdown MiniBeacon as below method 2.1 Press the BUTTON and keep holding 10 seconds, the Blue LED will flash 5 times and then off; it means that MiniBeacon was on sleeping mode and stop broadcasting. Image 4 Image 5 * Please be not ed the color difference was caused by the shooting. BUTTON Blue LED Federal Communications Commission (FCC) Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ●Reorient or relocate the receiving antenna. ●Increase the separation between the equipment and receiver. ●Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ●Consult the dealer or an experienced radio/TV technician for help. Warning: Changes or modifications made to this device not expressly approved by Shenzhen Minew Technologies Co., Ltd. may void the FCC authorization to operate this device. Note: The manufacturer is not responsible for any radio or tv interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment.

Shenzhen Minew Technologies Co., Ltd. 5 Floor, H Building, Gangzhilong Science Park, Qinglong Road, Longhua District, Shenzhen City, China TEL: +86-755-88868480 FAX: +86-755-29825342 DATE 09-03-2014 FCC ID: 2ABU6-MS56PX Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Shenzhen CTL Testing Technology Co., Ltd.(MR. Tracy Qi) at Floor 1-A, Baisha Technology Park, No. 3011, Shahexi Road, Nanshan, Shenzhen 518055 China to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Shenzhen Minew Technologies Co., Ltd. at 5 Floor, H Building, Gangzhilong Science Park, Qinglong Road, Longhua District, Shenzhen City, China. Dated this 09-03-2014 Agency agreement expiration date: 09-02-2015 By: Xiao Sheng Signature Printed Title: Engineer On behalf of : Shenzhen Minew Technologies Co., Ltd. Telephone: +86-755-88868480

Shenzhen Minew Technologies Co., Ltd. 5 Floor, H Building, Gangzhilong Science Park, Qinglong Road, Longhua District, Shenzhen City, China TEL: +86-755-88868480 FAX: +86-755-29825342 DATE 07-31-2014 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2ABU6-MS56PX Product Name: Digital Broadcasting Device (iBeacon) Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) • Schematics • Block diagram • Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 09-03-2014 By: Xiao Sheng Signature Printed Title: Engineer On behalf of : Shenzhen Minew Technologies Co., Ltd. Telephone: +86-755-88868480

FCC ID Label Information 1. Label location: 2. FCC ID Label: Model: MS56PX FCC ID: 2ABU6-MS56PX

Shenzhen CTL Testing Technology Co., Ltd. Tel: +86-755-89486194 Fax: +86-755-26636041 FCC PART 15 SUBPART C TEST REPORT FCC Part 15.249 Report Reference No......................: CTL1407291813-WF Compiled by ( position+printed name+signature)..: File administrators Jacky Chen Name of the organization performing the tests ( position+printed name+signature)..: Test Engineer Tracy Qi Approved by ( position+printed name+signature)..: Manager Tracy Qi Date of issue.....................................: Aug. 29, 2014 Test Firm..........................................: Shenzhen CTL Testing Technology Co., Ltd. Address.............................................: Floor 1-A, Baisha Technology Park, No. 3011, Shahexi Road, Nanshan, Shenzhen 518055 China. Applicant’s name............................: Shenzhen Minew Technologies Co., Ltd. Address.............................................: 5 Floor, H Building, Gangzhilong Science Park, Qinglong Road, Longhua District, Shenzhen City, China Test specification: Standard ...........................................: FCC Part 15.249: Operation within the bands 920-928 MHz, 2400- 2483.5 MHz, 5725-5850 MHz and 24.0 - 24.25 GHz. TRF Originator ..................................: Shenzhen CTL Testing Technology Co., Ltd. Master TRF.......................................: Dated 2011-01 Shenzhen CTL Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTL Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTL Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : Digital Broadcasting Device (iBeacon) Trade Mark.......................................: MINEW Models/Type reference.....................: MS56PX Modulation .......................................: GFSK Work Frequency...........................: 2402 MHz~2480 MHz Antenna Type..............................: internal FCC ID .............................................: 2ABU6-MS56PX Result................................................: Positive V1.0 Page 2 of 30 Report No.: CTL1407291813-WF T E S T R E P O R T Test Report No. : CTL1407291813-WF Aug. 29, 2014 ______________________________________________________________________________________________ Date of issue Equipment under Test : Digital Broadcasting Device (iBeacon) Model /Type : MS56PX Applicant : Shenzhen Minew Technologies Co., Ltd. Address : 5 Floor, H Building, Gangzhilong Science Park, Qinglong Road, Longhua District, Shenzhen City, China Manufacturer Shenzhen Minew Technologies Co., Ltd. Address 5 Floor, H Building, Gangzhilong Science Park, Qinglong Road, Longhua District, Shenzhen City, China Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. V1.0 Page 3 of 30 Report No.: CTL1407291813-WF Contents 1 . TEST STANDARDS.......................................................................4 2 . SUMMARY...................................................................................5 2.1. General Remarks .........................................................................................................................................5 2.2. Equipment Under Test ................................................................................................................................5 2.3. Short description of the Equipment under Test (EUT) ............................................................................5 2.4. EUT operation mode ...................................................................................................................................6 2.5. EUT configuration .......................................................................................................................................6 2.6. Related Submittal(s) / Grant (s)..................................................................................................................6 2.7. Modifications ...............................................................................................................................................6 3 . TEST ENVIRONMENT ....................................................................7 3.1. Address of the test laboratory ...................................................................................................................7 3.2. Test Facility ..................................................................................................................................................7 3.3. Environmental conditions ..........................................................................................................................7 3.4. Configuration of Tested System ................................................................................................................7 3.5. Statement of the measurement uncertainty .............................................................................................8 3.6. Equipments Used during the Test .............................................................................................................9 4 . TEST CONDITIONS AND RESULTS ..................................................9 4.1. Conducted Emissions Test ......................................................................................................................10 4.2. Radiated Emission Test ............................................................................................................................12 4.3. Band Edge Measurement..................................................................................…
