2ABUOHS-ZSDRF Remote Controller

HS-ZSD14-RF01 instruction book 1、Features .Complete UHF transmitter .Frequency range 433.920MHz .Data eates to 10kbps ASK .Output power to 10dBm .Low external part count .Low voltage operation (down to 1.8V) .Operate with crystals or ceramic resonators .Power down modes and wake-up functions to reduce power consumption 2、Product specifications: 1. Size: 85 * 40 * 7 mm, 2. Working voltage: DC 3V 3. The maximum working current: 20 mA 4. Remote control frequency: 433.920 M/remote control distance of 20 meters 5. Encoding: fixed yards 3、Product application: The HS - ZSD14 - RF01 applicable to control LED light bar. After light boxes, billboards, LED light source control, equipped with wireless remote control... And so on. 4、Electrical Characteristics Specifications apply for VDD =3.0V, TA=25°C, FreqREFOSC=13.650MHz,EN=VDD.Bold Values indicate-40 °C to 85°C unless otherwise noted.1kbps data rate 50% duty cycle.RL 50 ohm load (matched) 。 5、Function, mode and operating instructions 1, the remote control as shown in the figure below, key distribution and function; SPEED MODE ON/OFF 6、Connection diagram： 7、FCC Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1)this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation

Taizhou Heystar Electronic Technology Co., Ltd Authority to Act as an Agent We declare that the following representative (agent) Name Jack kang Position EMC Manager Company Name Shenzhen TCT Testing Technology Co., Ltd. Address 1F, Building 1, Yibaolai Industrial Park, Qiaotou Village, Fuyong Town, Baoan District, Shenzhen, China Tel / Fax +86-0755-27673339/+86-0755-27673332 E-Mail [email protected] to act on our behalf on all matters concerning the application and documents submitted to PHOENIX TEST-LAB for product certification below Product Name RF Remote Controller Model Name HS-ZSD14-RF01 Brand Name Yours sincerely, Signatory Feb. 18, 2014 Name Ying ping Chen Position Manager Company Name Taizhou Heystar Electronic Technology Co., Ltd Address Shuangqiao Village, Dayang Str.area, Linhai City, Zhejiang Province, China Tel / Fax 057685137979/057685137791 E-Mail [email protected] In case of FCC, we certify that we are not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance.

Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Request for Confidentiality Company name: Taizhou Heystar Electronic Technology Co., Ltd COMPANYLIMITED FCC ID: 2ABUOHS-ZSD FCC Part 15 Certification Gentlemen, Pursuant to 47 CFR 0.457(d)(1)(ii) and 0.459 we hereby requests permanent confidentiality of the following documents for the subject application: Exhibit Type Description ☒ Schematics All circuitry of devices and component values ☒ Block Diagrams Details of device showing the frequency of all oscillators ☒ Operational Description Description of the circuit functions Note: Exhibit types that are commonly held confidential are: (1) Schematics, (2) Block Diagrams, (3) Bill Of Materials, (4) Operational Descriptions. Any exhibit NOT granted confidentiality is viewable on the FCC website as soon as a grant is issued. These documents contain detailed system and equipment description and related information about the product which we considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, we consider that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Yours sincerely, Signatory Feb. 18, 2014 Name Ying ping Chen Position Manager Company Name Taizhou Heystar Electronic Technology Co., Ltd Address Shuangqiao Village, Dayang Str.area, Linhai City, Zhejiang Province, China Tel / Fax 057685137979/057685137791 E-Mail [email protected]

External photo

LABEL ARTWORK AND LOCATION Label size: W*L=15mm*33mm FCC ID Label Location

1 Internal photo 2

FCC ID TEST REPORT for RF Remote Controller Model: HS-ZSD14-RF01 FCC ID: 2ABUOHS-ZSD Prepared for: Taizhou Heystar Electronic Technology Co., Ltd Shuangqiao Village, Dayang Str.area, Linhai City, Zhejiang Province, China Prepared by: Shenzhen TCT Testing Technology Co.,Ltd 1F, Building 1, Yibaolai Industrial Park, Qiaotou Village, Fuyong Town, Baoan District, Shenzhen, Guangdong, China TEL: +86-0755-27363339 FAX: +86-0755-27673332 Report Number：TCT140211006F2-1 Date of Test： Feb. 05~Feb. 17, 2014 Date of Report： Feb. 17, 2014 The results detailed in this test report relate only to the specific sample(s) tested. It is the Application’s responsibility to ensure that all production units are manufactured with equivalent EMC characteristics. This report is not to be reproduced except in full, without written approval from TCT Testing Technology. FCC ID: 2ABUOHS-ZSD Report Number: TCT140211006F2-1 Page 2 of 24 Table of Contents 1.0 General Details....................................................................................................................................................... 4 1.1 Test Lab Details ............................................................................................................................................... 4 1.2 Applicant Details ............................................................................................................................................. 4 1.3 Description of EUT.......................................................................................................................................... 5 1.4 Statement: N.A. ............................................................................................................................................... 5 1.5 Test Engineer ................................................................................................................................................... 5 2.0 Test equipments and Associated Equipment used during the test..................................................................... 6 2.1 Test Equipments............................................................................................................................................... 6 2.2 AE used during the test .................................................................................................................................... 6 2.3. Block Diagram of EUT Configuration ........................................................................................................... 6 3.0 Technical Details.................................................................................................................................................... 7 3.1 Summary of test results ................................................................................................................................... 7 3.2 Test Standards .................................................................................................................................................. 7 4.0 EUT Modification.................................................................................................................................................. 7 5.0 Measurement Uncertainty（95% confidence levels, k=2)................................................................................. 7 6.0 Power Line Conducted Emission Test.................................................................................................................. 8 6.1 Schematics of the test ...................................................................................................................................... 8 6.2 Test Method and test Procedure ....................................................................................................................... 8 6.3 EUT Operating Condition................................................................................................................................ 8 6.4 Test Equipment ................................................................................................................................................ 8 6.5 Conducted Emission Limit .............................................................................................................................. 9 6.6 Test specification: ............................................................................................................................................ 9 6.7 Test result......................................................................................................................................................... 9 7.0 Manually Activated Transmitter........................................................................................................................ 12 7.1 Block diagram of Test setup .......................................................................................................................... 12 7.2 Limit .............................................................................................................................................................. 12 7.3 Test Equipment .............................................................................................................................................. 12 7.4 Test specification ........................................................................................................................................... 12 7.5 Test result....................................................................................................................................................... 12 8.0 Radiated Emission Test....................................................................................................................................... 14 8.1 Test Method and test Procedure:.................................................................................................................... 14 8.2 Block diagram of Test setu…
