2ABUV-MRC565-40-43Packet Data Radio Transceiver

OPERATION & MAINTENANCE OF THE MRC-565 PACKET DATA RADIO Rev. F July 23, 2014 Maiden Rock Communications PO Box 575 Seeley Lake, Montana USA Tel: (207) 715 8242 2014 by Maiden Rock Communications All rights reserved Page 2 MRC-565 Packet Data Radio Operations & Maintenance GENERAL WARRANTY Maiden Rock Communications (MRC) warrants that its products conform to the published specifications and are free from manufacturing and material defects for one year after shipment. Warranty-covered equipment that fails during the warranty period will be promptly repaired at MRC’s facility in Kent, Washington. International customers are required to pay shipping costs to the MRC facility, with Seattle as the point of U.S. entry. MRC will pay incoming U.S. duty fees. MRC will pay shipping costs to return the equipment to the customer, with the customer paying all return duty fees. This warranty is contingent upon proper use of the equipment and does not cover equipment that has been modified in any way without MRC’s approval or has been subjected to unusual physical or electrical stress, or on which the original identification marks have been removed or altered. Page 3 MRC-565 Packet Data Radio Operations & Maintenance EXPOSURE TO RF RADIATION The FCC guidelines limit the maximum permitted exposure to RF radiation for Occupational/ Controlled Exposure to 1 mw/sq. cm for frequency ranges of 30-300 MHz. This limit and the following equation for calculating field strength (obtained from OET Bulletin 65) is used to calculate the minimum separation between humans and the transmit antenna based on MPE S= P*G* DC/(4**R*R) P = Transmit power in milliwatts = 100,000 G = Antenna gain referenced to an isotropic radiator = 1.68 (2.2dbi) mobile quarter wave dipole mounted to fender/roof of automobile = 10.0 (10.0 dbi) fixed 5 element Yagi mounted to top of fixed antenna tower = 3.3 (5.2 dbi) fixed half wave dipole mounted to fixed antenna tower leg R = separation required cm DC = Maximum duty cycle of transmitter = 10 % S = Power density = 1 milliwatt/square cm This equation is accurate for the far field of an antenna, but will over-predict power density in the near field. Thus, the near field MPE distances calculated here are “worst case” or conservative. Antenna separation for mobile applications: The typical antenna used in mobile application has a maximum antenna gain of less than 2.2 dBi (¼ wave dipole or ½ wave dipole). To insure safe operation the antenna must be mounted such that the separation between the antenna and any human occupants of the vehicle exceeds .36 meters (14”). The best location for antenna mounting is the center of the vehicle roof. This will provide additional RF shielding between the antenna and the human occupants that reduces the RF exposure to levels well below that specified in FCC OET Bulletin 65. When working on the antenna and or co-ax cable always disable the transmitter by turning its power off. Antenna separation for fixed applications: For fixed applications, antenna gains and mounting techniques can vary depending on the application. For Yagi antennas whose gain does not exceed 10 dBi, that antenna must be mounted a minimum of .90 meters from any humans occupants. Lower gain antennas, such as side mount dipoles, exhibit lower gain (5.2 dBi) allow closer separations (.52 meters for 5.2 dBi antennas). This will provide RF shielding between the antenna and the human occupants that reduce the RF exposure to levels below that specified in FCC OET Bulletin 65. When working on the antenna and or co-ax cable always disable the transmitter by turning its power off. Page 4 MRC-565 Packet Data Radio Operations & Maintenance REVISION PAGE Document Title: Operation of the MRC-565 Packet Data Radio in a Meteor Burst Network Document Number: MAN-OPS-MRC-565 – Meteor Burst Revision # Date Revision Redline 04/20/2014 Redline Release Initial 05/10/2014 Initial Release A 05/25/2014 Release A TD B 7/23/14 Update format, references, TOCs (JW) C 6/21/2014 Update format, references, TOCs (JW) D 6/22/2014 Updated Theory of Ops TD E 7/17/2014 Update format, TOC (JW) F G H I Page 5 MRC-565 Packet Data Radio Operations & Maintenance MCC 545B MRC-565 DIFFERENCES There are several differences between the MCC 545B and the MRC-565. A summary of these differences is given below:  Number of circuit boards MRC-565 has 2 MCC 545 has 3  MRC-565 is a software defined radio with no adjustments on CMU board  Both units have similar power amp boards  No battery backed up RAM. No PWR FAIL RESTORE message  New LPM modes  Ethernet Port with TCP/IP  USB Host Port for Thumb drive Logging and Data Storage  USB Device Port for connecting to PC USB port. Requires Driver For the most part the MRC-565 operator commands are the same as the MCC 545B commands. However, there are a few differences as noted below: MCC 565 MRC 545 ASSIGN ASSIGN ASSIGN,RXn,CHAN,PROTOCOL NONE CHAN,TX,RX,MOD-VAL,CHAN FREQ,TX,RX,CHAN CHAN,N FREQ,N CHAN FREQ CAL NONE DSP NONE IP NONE IPCONFIG NONE FILE NONE FPGA FPGA LPM LP[M RECEIVERS NONE SCALE SCALE SP NONE SIG NONE RXTH RXTH TEST,TX TEST,TX TRACEERT TRACEPORT SDI12 NONE In the cases where there are similar commands for the MCC 545 and MRC-565, the commands are slightly different. Refer to APPENDIX C for details. Page 6 MRC-565 Packet Data Radio Operations & Maintenance TABLE OF CONTENTS Title Page EXPOSURE TO RF RADIATION ................................................................................................ 3 MCC 545B MRC-565 DIFFERENCES ......................................................................................... 5 1 INTRODUCTION ................................................................................................................ 14 2 NETWORKS ........................................................................................................................ 16 2.1 Meteor Burst Communications ............................................................…

Text truncated - open the document above for the full version.

9/17/2014 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Subject: Request for Permanent Confidentiality To whom it may concern: In accordance with 47CFR Section 0.457 and Section 0.459 pertaining to confidential material, we hereby request to hold permanently confidential all information contained within the below identified exhibits/document categories submitted pursuant to radio equipment certification requirements for FCC ID: 2ABUV-MRC565-40-43 1. Block Diagram 2. Operational Description 3. Schematics 4. Parts List / Tune-Up Procedure The above material contains trade secrets and proprietary information as specified by 47CFR 0.457(d) and technical data, which would customarily be guarded from competitors. The public disclosure of this information might be harmful to our company and provide unjustified benefits to our competitors. Sincerely, Tom Donich President Maiden Rock Communications, LLC

FCC ID: 2ABUV-MRC565-40-43 CMU PCB Top CMU PCB Bottom RFPA PCB Top RFPA PCB Bottom

FCC ID: 2ABUV-MRC565-40-43 66 mm

2ABUV-MRC565-40-43 Internal with main shields 2ABUV-MRC565-40-43 without main shields CMU PCB Top CMU PCB Bottom MRC565-430-43 RFPA PCB Top with minor shield MRC565-40-43 RFPA PCB Top without minor shield RFPA PCB Bottom

MRC565 PACKET DATA RADIO TRANSCEIVER EXPOSURE TO RF RADIATION The FCC guidelines limit the maximum permitted exposure to RF radiation for Occupational/ Controlled Exposure to 1 mw/sq. cm for frequency ranges of 30-300 MHz. This limit and the following equation for calculating field strength (obtained from OET Bulletin 65) is used to calculate the minimum separation between humans and the transmit antenna based on MPE: S= P*G* DC/(4**R*R) => R=(P*G*DC/(4*π*S))^0.5 as rearranged to solve for separation distance, R P = Transmit power in milliwatts = 100,000 G = Antenna gain referenced to an isotropic radiator = 1.68 (2.2 dBi) mobile quarter wave dipole mounted to fender/roof of automobile = 10.0 (10.0 dBi) fixed 5 element Yagi mounted to top of fixed antenna tower = 3.3 (5.2 dBi) fixed half wave dipole mounted to fixed antenna tower leg R = separation required cm DC = Maximum duty cycle of transmitter = 10 % S = Power density = 1 milliwatt/square cm This equation is accurate for the far field of an antenna, but will over-predict power density in the near field. Thus, the near field MPE distances calculated here are “worst case” or conservative. Antenna separation for mobile applications: The typical antenna used in mobile application has a maximum antenna gain of less than 2.2 dBi (¼ wave dipole or ½ wave dipole). To insure safe operation the antenna must be mounted such that the separation between the antenna and any human occupants of the vehicle exceeds .36 meters (14”). The best location for antenna mounting is the center of the vehicle roof. This will provide additional RF shielding between the antenna and the human occupants that reduces the RF exposure to levels well below that specified in FCC OET Bulletin 65. When working on the antenna and or co-ax cable always disable the transmitter by turning its power off. Antenna separation for fixed applications: For fixed applications, antenna gains and mounting techniques can vary depending on the application. For Yagi antennas whose gain does not exceed 10 dBi, that antenna must be mounted a minimum of .90 meters from any humans occupants. Lower gain antennas, such as side mount dipoles, exhibit lower gain (5.2 dBi) allow closer separations (.52 meters for 5.2 dBi antennas). This will provide RF shielding between the antenna and the human occupants that reduce the RF exposure to levels below that specified in FCC OET Bulletin 65. When working on the antenna and or co-ax cable always disable the transmitter by turning its power off.

This report contains a total of 34 pages and may be reproduced in full only. Partial reproduction may only be done with the written consent of CKC Laboratories, Inc. Maiden Rock Communications ADDENDUM TO TEST REPORT 95510-4 Packet Data Radio Model: MRC565-40-43 Tested To The Following Standards: FCC Part 90I Report No.: 95510-4A Date of issue: July 18, 2014 This test report bears the accreditation symbol indicating that the testing performed herein meets the test and reporting requirements of ISO/IEC 17025 under the applicable scope of EMC testing for CKC Laboratories, Inc. We strive to create long-term, trust based relationships by providing sound, adaptive, customer first testing services. We embrace each of our customers’ unique EMC challenges, not as an interruption to set processes, but rather as the reason we are in business. Page 2 of 34 Report No.: 95510-4A TABLE OF CONTENTS Administrative Information .......................................................................................................................... 3 Test Report Information ............................................................................................................................................ 3 Revision History ......................................................................................................................................................... 3 Report Authorization ................................................................................................................................................. 3 Test Facility Information ............................................................................................................................................ 4 Software Versions ...................................................................................................................................................... 4 Site Registration & Accreditation Information .......................................................................................................... 4 Summary of Results ................................................................................................................................................... 5 Conditions During Testing.......................................................................................................................................... 5 Equipment Under Test ............................................................................................................................................... 6 Peripheral Devices ..................................................................................................................................................... 6 FCC Part(s) 2 / 90I ......................................................................................................................................... 7 2.1046 / 90.205 RF Power Output ............................................................................................................................. 7 2.1047 Modulation Characteristics .......................................................................................................................... 13 2.1049 / 90.209 Occupied Bandwidth ..................................................................................................................... 14 2.1051 / 90.210(c) Spurious Emissions at Antenna Terminals ................................................................................ 19 2.1053 / 90.210(c) Field Strength of Spurious Radiation ......................................................................................... 27 2.1055 / 90.213 Frequency Stability ........................................................................................................................ 31 Supplemental Information .......................................................................................................................... 33 Measurement Uncertainty ...................................................................................................................................... 33 Emissions Test Details .............................................................................................................................................. 33 Page 3 of 34 Report No.: 95510-4A ADMINISTRATIVE INFORMATION Test Report Information REPORT PREPARED FOR: REPORT PREPARED BY: Maiden Rock Communications 586 Double Arrow Road Seeley Lake, MT 59868 Morgan Tramontin CKC Laboratories, Inc. 5046 Sierra Pines Drive Mariposa, CA 95338 REPRESENTATIVE: Fred Cleveland Project Number: 95510 Customer Reference Number: CKC 04152014 DATE OF EQUIPMENT RECEIPT: April 14, 2014 DATE(S) OF TESTING: April 14 - 16, 2014 Revision History Original: Testing of Packet Data Radio Model: MRC565-40-43 to FCC Part 90I. Addendum A: To correct the test conditions for section 2.1046 / 90.205 RF Power Output and to correct the test equipment and test conditions for section 2.1053 / 90.210(c) Field Strength of Spurious Radiation. Report Authorization The test data contained in this report documents the observed testing parameters pertaining to and are relevant for only the sample equipment tested in the agreed upon operational mode(s) and configuration(s) as identified herein. Compliance assessment remains the client’s responsibility. This report may not be used to claim product endorsement by A2LA or any government agencies. This test report has been authorized for release under quality control from CKC Laboratories, Inc. Steve Behm Director of Quality Assurance & Engineering Services CKC Laboratories, Inc. Page 4 of 34 Report No.: 95510-4A Test Facility Information Our laboratories are configured to effectively test a wide variety of product types. CKC utilizes first class test equipment, anechoic chambers, data acquisition and information services to create accurate, repeatable and affordable test results. TEST LOCATION(S): CKC Laboratories, Inc. 22116 23…

Text truncated - open the document above for the full version.
