2ABXP-GPSGPS CAR ALARM

Learning remote control(2pcs can be learn at one time),the steps as follow: 1. Under disarm status, open car door and step on foot brake, turn ACC from OFF to ON for 3 times, finally stop at ON position. LED indicator light uninterruptedly which indicating the system has enter into learning status. Or open car door and step on foot brake, turn on the ACC, press emergency button for 3 times,the system will enter into learning status. 2. Press any button within 10 seconds, siren chirp once indicating the first button has been learned successfully. 3. Repeat step 2 to learn the 2 nd remote(siren chirp twice indicating the 2 nd remote has been learned successfully); After the 2 nd remote be learned successfully, the siren will chirp twice indicating the system is going to exit the state of learning mode. 4. During learning process, turn the car key to OFF position, or no action to remote control within 10 seconds, the system will exit the state of learning mode automatically. At this moment the siren will chirp twice too. When disarm, open the door, turn ACC to ON . Function model Setting/ way to change Siren sound 1 time Siren sound 2 tiems 1、Lock Press one time able ※disable 2、Unlock press one time disable able 3、Trunk release Press 2 seconds disable disable 4、door open delay, doom light delay. press +2second ※5seconds 30seconds with “※” marks are the factory settings FCC ID: 2ABXP-GPS This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment。

KLEMA FLORIDA INTERNATIONAL L.L.C. Date: 01.03.2014 Authority to Act as an Agent We declare that the following representative (agent) Name Mark Zhu Position Manager Company Name Shenzhen Certification Technology Service Co., Ltd. Address 2F, Building B, East Area of Nanchang Second Industrial Zone, Gushu 2 nd Road, Bao’an District, Shenzhen 518126, P.R. China Tel / Fax 0755-86375541/0755-26736857 Email [email protected] to act on our behalf on all matters concerning the application and documents submitted to PHOENIX TEST-LAB for product certification below Product Name GPS CAR ALARM Model Name GPS Car Alarm . Yours sincerely, Signatory Name LUIS SIMON MARTINEZ Position PRESIDENT Company Name KLEMA FLORIDA INTERNATIONAL L.L.C. Address 4960 NW, 165th Street, Unit 9B, Miami, FL 33014, U.S.A. Tel 1-305-626.9009 Fax 1-305-626.4714 Email [email protected] In case of FCC, we certify that we are not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance.

KLEMA FLORIDA INTERNATIONAL L.L.C. Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Request for Confidentiality Company name: KLEMA FLORIDA INTERNATIONAL L.L.C. FCC ID : 2ABXP-GPS FCC Part 15 Certification Gentlemen, Pursuant to 47 CFR 0.457(d)(1)(ii) and 0.459 we hereby requests permanent confidentiality of the following documents for the subject application: Exhibit Type Description ☒ Schematics All circuitry of devices and component values ☒ Block Diagrams Details of device showing the frequency of all oscillators ☒ Operational Description Description of the circuit functions Note: Exhibit types that are commonly held confidential are: (1) Schematics, (2) Block Diagrams, (3) Bill Of Materials, (4) Operational Descriptions. Any exhibit NOT granted confidentiality is viewable on the FCC website as soon as a grant is issued. These documents contain detailed system and equipment description and related information about the product which we considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, we consider that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Yours sincerely, Signatory Name LUIS SIMON MARTINEZ Position PRESIDENT Company Name KLEMA FLORIDA INTERNATIONAL L.L.C. Address 4960 NW, 165th Street, Unit 9B, Miami, FL 33014, U.S.A. Tel 1-305-626.9009 Fax 1-305-626.4714 Email [email protected]

30mm 16mm Company: KLEMA FLORIDA INTERNATIONAL L.L.C. Name: GPS CAR ALARM Model Number: GPS Car Alarm FCC ID: 2ABXP-GPS

Label Location

ANTENNA

Shenzhen Certification Technology Service Co., Ltd 2F, Building B, East Area of Nanchang Second Industrial Zone, Gushu 2nd Road, Bao'an District, Shenzhen 518126, P.R. China. FCC ID: 2ABXP-GPS Page 1 of 29 TEST REPORT FCC ID: 2ABXP-GPS Applicant : KLEMA FLORIDA INTERNATIONAL L.L.C. Address : 4960 NW, 165th Street, Unit 9B, Miami, FL 33014, U.S.A. Equipment under Test (EUT): Name : GPS CAR ALARM Model : GPS Car Alarm，Proximity Immobilizer，Car Dealer Top Alarm， Diamante Top Alarm，Elegant Top Alarm，Elite Top Alarm， Upgrade Top Alarm，Central Locking System，Parking Sensor， Keyless entry System Standards : FCC PART 15, SUBPART C : 2012 (Section 15.231) Report No. : CST-TCB131230007 Date of Test : February 14-20, 2014 Date of Issue : February 20, 2014 Test Result : PASS * z In the configuration tested, the EUT complied with the standards specified above z Authorized Signature (Mark Zhu) General Manager The manufacture should ensure that all the products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of Shenzhen Certification Technology Service Co., Ltd. Or test done by Shenzhen Certification Technology Service Co., Ltd. Approvals in connection with, distribution or use of the product described in this report must be approved by Shenzhen Certification Technology Service Co., Ltd. Approvals in writing. Report No.: CST-TCB131230007 FCC ID: 2ABXP-GPS Page 2 of 29 TABLE OF CONTENT Description Page 1 General Information ---------------------------------------------------------------------------------- 3 1.1 Description of Device (EUT)---------------------------------------------------------------------3 1.2 Description of Test Facility -----------------------------------------------------------------------3 2 EMC Equipment List --------------------------------------------------------------------------------- 4 3 Test Procedure----------------------------------------------------------------------------------------- 5 4 Summary of Measurement ------------------------------------------------------------------------- 6 4.1 Summary of test result ----------------------------------------------------------------------------6 4.2 Block Diagram -------------------------------------------------------------------------------------6 4.3 Assistant equipment used for test ----------------------------------------------------------------6 4.4 Test Conditions -------------------------------------------------------------------------------------7 4.5 Measurement Uncertainty (95% confidence levels, k=2)-------------------------------------7 5 Radiation Emission----------------------------------------------------------------------------------- 8 5.1 Radiation Emission Limits(15.209&231)-------------------------------------------------------8 5.2 Test Setup -------------------------------------------------------------------------------------------8 5.3 Test Procedure------------------------------------------------------------------------------------ 10 5.4 Test Equipment Setting For emission test. --------------------------------------------------- 11 5.5 Test Condition------------------------------------------------------------------------------------ 11 5.6 Test Result ---------------------------------------------------------------------------------------- 11 6 POWER LINE CONDUCTED EMISSION ------------------------------------------------------- 16 6.1 Conducted Emission Limits(15.209) ---------------------------------------------------------- 16 6.2 Test Setup ----------------------------------------------------------------------------------------- 16 6.3 Test Procedure------------------------------------------------------------------------------------ 17 6.4 Test Results --------------------------------------------------------------------------------------- 17 7 Occupied bandwidth -------------------------------------------------------------------------------- 18 7.1 Test limit ------------------------------------------------------------------------------------------ 18 7.2 Method of measurement ------------------------------------------------------------------------ 18 7.3 Test Setup ----------------------------------------------------------------------------------------- 18 7.4 Test Results --------------------------------------------------------------------------------------- 18 8 Transmission time ----------------------------------------------------------------------------------- 20 8.1 Test limit ------------------------------------------------------------------------------------------ 20 8.2 Method of measurement ------------------------------------------------------------------------ 20 8.3 Test Setup ----------------------------------------------------------------------------------------- 20 8.4 Test Results --------------------------------------------------------------------------------------- 20 9 Band Edge Check------------------------------------------------------------------------------------ 22 9.1 Test limit ------------------------------------------------------------------------------------------ 22 9.2 Test Procedure------------------------------------------------------------------------------------ 22 9.3 Test Setup ----------------------------------------------------------------------------------------- 22 9.4 Test Result ---------------------------------------------------------------------------------------- 22 10 Antenna Requirement ------------------------------------------------------------------------------ 23 10.1 Standard Requirement --------------------------------------------------------------------------- 23 10.2 Antenna Connected Construction-------------------------------------------------------------- 23 10.3 Result -----------------------------------------…

Text truncated - open the document above for the full version.

Radiated Emission Test Setup in Chamber
