2ABXQ-B83033G Feature Phone

Functions Description 1 Dial key 8 USB 2 End key 9 Headset Jack 3 Menu 10Back Camera 4 Mail 11Speaker 5 Home 12Return Key 6 Receiver 13Navigation Key 7 Antenna Keys functions description II Make the most of your B8303 while being productive and entertaining. Use this quick guide to take advantage of all the great features available to you. Don't forget to register your new B8303. Productivity, efficient and entertainment all in one. Making phone calls When you want a call, press the phone keypad to input the area code and phone number. Press Menu key to save. Press Dial key to dial the number. If the number is stored with a name, it appears on the display when you dial the number. You can also make a call through call logs, phonebook and messages. Managing contacts Your contact list With my B8303I want to... III To view the contacts on your phone, select Phonebook in the menu. Press corresponding alphanumeric keys to search for a number by name. Enter the first letter of the name that you want to find. Select contact’s name, press Menu key to open the option menu. Add a contact Press Middle key to move the cursor to Add new contact, first, confirm the storage media in: To SIM1,To SIM2, To phone. If preferred storage is phone, then input Name, Number, Caller picture, Caller ringtone. ※Note：If add new entry to SIM card, there only need input name and number.※ SMS and MMS messaging Inbox Through the menu you can read received SMS and MMS messages of SIM1 and SIM2. There is “1” or “2” icon displayed on the right side of every messages, it means this message is received by SIM1 or SIM2. To the message list, select one and open it, press Menu key to view, replay, forward, IV delete and other options. Write text and multimedia messages 3. Select Write message,write the content, press Menu key to insert number, name, subject and other attach. 4. Press Menu key to select Send to and select the number, press Menu key to select Send to send the message. Call center Call history In this menu, you can view all the calls, or the call you missed, dialed and received. There is “1” or “2” icon displayed on the left side of every call logs, it means this call is dialed or received by SIM1 or SIM2. Select the call log, press SIM1 or SIM2 to dial the number with SIM1 or SIM2. Call settings Set SIM1 call settings, SIM2 call settings and Advance settings. Phone Guard V Call Blacklist Input the number you want to shield, then you will not get calls from this number. SMS Blacklist Input the number you want to shield, then you will not get a message from this number. Reject by SMS If the function is turned on, you can press Options while there is incoming call and select Reject by SMS, then messages will send to the number when you reject their calls. File manager To save more information, the phone support memory card. The card can be installed at any time. The menu can manage the files on the phone. Multimedia Camera Enter the menu, the display shows the preview image. Shortcut key operation: VI Press Middle key to take a photo. Press Left/Right navigation key to adjust the focal distance. Press Menu key to choose to adjust EV, change image size, change image quality, change white balance, change LED highlight, change delay timer, change cont shot, change camera. Sound Recorder Through the menu, you can record sound by yourself. Press Options to start recording. During recording, press Return key to stop, select whether to save. The file is saved as *.amr file. Midea player Through the menu, you can play music or ring tone file. Press Middle key to access myplaylists. During playing the music, press Left or Right navigation key to next music file; long press Left or Right navigation key to fast forward or Rewind; press Up and Down navigation key to adjust volume; press Middle key to pause/play the playing file. FM radio VII Please plug the headset before open the FM radio. After opened,the phone will show the channel frequency that the phone searched automatically. You can press Left/right navigation keys to change the channel frequency. Press up/down navigation keys to adjust volume. Press Middle key to pause/play the FM. And press Right soft key to exit. Bluetooth Through the setting enter into connectivity , press Middle key, select “Bluetooth”. Turn on/off: set the function on or off. Visibility: Select On or Off. If disable the feature, the phone will not be used as a BT device. My device: show my BT device list. If the list is empty, press OK key to search the new device. Select one device, press Left soft key to pair, if the device has passcode, input the passcode and press OK. Search audio device: Before search Bluetooth device, power on Bluetooth function. After searching new device, connect the new device in pairs according to the display information. When VIII successfully connected, the devices can communicate. My name: edit the device name. Advanced: set Bluetooth parameter. Browser STK STK features are provided by your service provider. If your SIM card supports STK feature, you will see the STK menu. Different STK has different STK main menu. Please contact your service provider if the STK does not work. Internet services Wireless Application Protocol, a kind of browse Internet webpage mode. You can browse the internet , and grasp any information through your mobile. You need to apply the service to your network service provider before using the service. FCC RF Exposure Information and Statement The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device types: B8303( FCC ID: 2ABXQ-B8303) has also been tested against this SAR limit. The highest SAR value reported under this standard during product certification for use at the ear is 1.405W /kg and when properly worn on the body is 1.192W /kg. This device was tested for typical body-worn operations with the back of the handset kept 1.5cm from the body. To maintain compliance with FCC RF exposure requirements, use accessories t…

Text truncated - open the document above for the full version.

Uniphone Communication Co., Ltd SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 Uniphone Communication Co., Ltd SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 2014-03-06 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Uniphone Communication Co., Ltd hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product： 3G Feature Phone Trade Name： Bitel Model Name： B8303 Serial Model： N/A FCC ID: 2ABXQ-B8303 We affirm that between SIEMIC and _ Uniphone Communication Co., Ltd , any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Signature Date:2014-03-06 Name: Qin JianXin Title: Manager Address: B3-801,Kexing science Park,Hi-Tech Park Mid-Zone , Nanshan , Shenzhen,China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Uniphone Communication Co., Ltd 2014-03-06 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ABXQ-B8303 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description - BOM - Tune up procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Signature Date:2014-03-06 Name: Qin JianXin Title: Manager Address: B3-801,Kexing science Park,Hi-Tech Park Mid-Zone , Nanshan , Shenzhen,China

Uniphone Communication Co., Ltd Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 2014-02-27 SUBJECT: FCC Application for ( FCCID: 2ABXQ-B8303) To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite device. We understand that devices subject to the DoC procedure are required to be tested to show compliance with the FCC technical regulations by a recognized accredited testing laboratory. The testing laboratory must be accredited by a Commission approved accreditation body or designated under the terms of a government-to-government Mutual Recognition Agreement (MRA). A listing of those accredited testing laboratories that have been recognized by the Commission is published on the FCC Webpage: https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm Select the "accredited" option to search for FCC recognized accredited test firms. Test facilities located in countries, where the U.S. does not have an operational Telcom MRA are not recognized by the FCC to test for the DoC procedure. Regards, Signatory Signature Date:2014-03-06 Name: Qin JianXin Title: Manager Address: B3-801,Kexing science Park,Hi-Tech Park Mid-Zone , Nanshan , Shenzhen,China

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7

FCC ID LABELING AND LOCATION FCC ID Label 3G Feature Phone Model NO.: B8303 Bitel Input Rating: DC 5V/ 1000mA FCC ID: 2ABXQ-B8303 Uniphone Communication Co., Ltd Made in China This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 GSM&WCDMA ANTENNA Photo 3 Photo 4 BT ANTENNA Photo 5 Photo 6 Photo 7 Photo 8 Photo 9 Photo 10 Photo 11

FCC RADIO TEST REPORT FCC ID: 2ABXQ-B8303 Product： 3G Feature Phone Trade Name： Bitel Model Name： B8303 Serial Model： N/A Report No.： NTEK-2014NT0124047F1 Prepared for Uniphone Communication Co., Ltd B3-801,Kexing science Park,Hi-Tech Park Mid-Zone , Nanshan , Shenzhen,China Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community,Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 75 Report No.: NTEK-2014NT0124047F1 TEST RESULT CERTIFICATION Applicant’s name ............. Uniphone Communication Co., Ltd Address ............................. B3-801,Kexing science Park,Hi-Tech Park Mid-Zone , Nanshan , Shenzhen,China Manufacture's Name ........ Uniphone Communication Co., Ltd Address ............................. B3-801,Kexing science Park,Hi-Tech Park Mid-Zone , Nanshan , Shenzhen,China Product description Product name ......................3G Feature Phone Model and/or type reference .......................... B8303 Serial Model： N/A Standards ......................... FCC Part15.247 Test procedure .....................ANSI C63.4-2009 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test ........................................ Date (s) of performance of tests ......... 24 Jan. 2014 ~20 Feb. 2014 Date of Issue ....................................... 20 Feb. 2014 Test Result ........................................... Pass Testing Engineer : (Polo Cha) Technical Manager : (Brown Lu) Authorized Signatory : (Bovey Yang) Page 3 of 75 Report No.: NTEK-2014NT0124047F1 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 9 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.5 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 17 3.2.1 RADIATED EMISSION LIMITS 17 3.2.2 TEST PROCEDURE 18 3.2.3 DEVIATION FROM TEST STANDARD 18 3.2.4 TEST SETUP 19 3.2.5 EUT OPERATING CONDITIONS 20 3.2.6 TEST RESULTS (BELOW 30 MHZ) 21 3.2.7 TEST RESULTS (BETWEEN 30M – 1000 MHZ) 22 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 23 4 . NUMBER OF HOPPING CHANNEL 33 4.1 APPLIED PROCEDURES / LIMIT 33 4.1.1 TEST PROCEDURE 33 4.1.2 DEVIATION FROM STANDARD 33 4.1.3 TEST SETUP 33 4.1.4 EUT OPERATION CONDITIONS 33 4.1.5 TEST RESULTS 34 5 . AVERAGE TIME OF OCCUPANCY 35 5.1 APPLIED PROCEDURES / LIMIT 35 Page 4 of 75 Report No.: NTEK-2014NT0124047F1 Table of Contents Page 5.1.1 TEST PROCEDURE 35 5.1.2 DEVIATION FROM STANDARD 35 5.1.3 TEST SETUP 36 5.1.4 EUT OPERATION CONDITIONS 36 5.1.5 TEST RESULTS 37 6 . HOPPING CHANNEL SEPARATION MEASUREMENT 43 6.1 APPLIED PROCEDURES / LIMIT 43 6.1.1 TEST PROCEDURE 43 6.1.2 DEVIATION FROM STANDARD 43 6.1.3 TEST SETUP 43 6.1.4 EUT OPERATION CONDITIONS 43 6.1.5 TEST RESULTS 44 7 . BANDWIDTH TEST 50 7.1 APPLIED PROCEDURES / LIMIT 50 7.1.1 TEST PROCEDURE 50 7.1.2 DEVIATION FROM STANDARD 50 7.1.3 TEST SETUP 50 7.1.4 EUT OPERATION CONDITIONS 50 7.1.5 TEST RESULTS 51 8 . PEAK OUTPUT POWER TEST 57 8.1 APPLIED PROCEDURES / LIMIT 57 8.1.1 TEST PROCEDURE 57 8.1.2 DEVIATION FROM STANDARD 57 8.1.3 TEST SETUP 57 8.1.4 EUT OPERATION CONDITIONS 57 8.1.5 TEST RESULTS 58 9 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 64 9.1 DEVIATION FROM STANDARD 64 9.2 TEST SETUP 64 9.3 EUT OPERATION CONDITIONS 64 9.4 TEST RESULTS 65 10 . ANTENNA REQUIREMENT 73 10.1 STANDARD REQUIREMENT 73 10.2 EUT ANTENNA 73 11 . EUT TEST PHOTO 74 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 75 Report No.: NTEK-2014NT0124047F1 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(a)(1) Hopping Channel Separation PASS 15.247(b)(1) Peak Output Power PASS 15.247(c) Radiated Spurious Emission PASS 15.247(a)(iii) Number of Hopping Frequency PASS 15.247(a)(iii) Dwell Time PASS 15.247(a)(1) Bandwidth PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 75 Report No.: NTEK-2014NT0124047F1 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 75 Report No.: NTEK-2014NT0124047F1 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment 3G Feature Phone Trade Name Bitel Model Name B8303 Serial Model N/A Model Difference N/A Product Description The EUT is a 3G Feature Phone Operation Frequency: 2402~2480 MHz Modulation T…

Text truncated - open the document above for the full version.

Page 74 of 75 Report No.: NTEK-2014NT0124047F1 11. EUT TEST PHOTO Radiated Measurement Photos Page 75 of 75 Report No.: NTEK-2014NT0124047F1 CONDUCTED EMISSION Photo
