VolantexRC products are NOT TOYS, to be used by ages 14 and over. Owners Manual Series Safety Precautions As the user of this product, you are solely responsible for operating in a manner that does not endanger yourself and others or result in damage to the product or the property of others. • Never attempt to swim after a stalled RC boat. • Never operate your RC boat while standing in the water. • Never operate your RC boat in the presence of swimmers. • NOTE: Because of the sharp running hardware included with this RC boat, we do not recommend a rubber blow up raft. • RC boat running hardware is very sharp. Be very careful when working on and around the metal parts. • While the motor is running pay close attention to the propeller. Do not come in contact with the propeller at any time the engine is running or serious injury will result. • Always keep a safe distance in all directions around your model to avoid collisions or injury. This model is controlled by a radio signal subject to interference from many sources outside your control. Interference can cause momentary loss of control. • Always avoid water exposure to all equipment not specifically designed and protected for this purpose. Moisture causes damage to unprotected electronics • Always keep all chemicals, small parts and anything electrical out of the reach of children. • Never place any portion of the model in your mouth as it could cause serious injury or even death. • Always keep all chemicals, small parts and anything electrical out of the reach of children. 1 WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product before operating. Failure to operate the product correctly can result in damage to the product, personal property and cause serious injury. This is a sophisticated hobby product and NOT a toy. It must be operated with caution and common sense and requires some basic mechanical ability. Failure to operate this Product in a safe and responsible manner could result in injury or damage to the product or other property. This product is not intended for use by children without direct adult supervision. Do not attempt disassembly, use with incompatible components or augment product in any way without the approval of VolantexRC, Co., Ltd.. This manual contains instructions for safety, operation and maintenance. It is essential to read and follow all the instructions and warnings in the manual, prior to assembly, setup or use, in order to operate correctly and avoid damage or serious injury. Boat Battery Pack(s) Installation 1. Roat the hatch on the hull cover in clockwise to unlock the hatch. 2. Open the hull cover. 3. Adhere loop tape (included) to the battery. 4. Secure the boat battery on the hook strip in the boat. 5. Secure the battery in the hull with the hook and loop strap as shown. Rudder Installation 1. Align the propeller with the drive dog on the flex shaft, then install the propeller using the included locknut. 2. Install the rudder horn to the rudder by two screw. 3. Install the rudder to the rudder holder and fix it by a bolt as show in the graphic. 4. Connect the cooling line to the fitting on the top of the rudder. 5. Ensure the trim tab panel is either perpendicular to or parallel to the bottom of the boat. If it’s needed to switch the angle of the panel, tie or release the screw which is touch the panel to switch the angle. 2 3 1 2 5 4 Unlock Lock 1 open 2 Antenna Tube Installation 1. Carefully feed the end of the receiver antenna through the grommet inside the hull. 2. Pull the antenna wire out of the grommet towards the outside of the boat, then slide the antenna through the antenna tube. 3. Insert the tube into the grommet, then fit the cap onto the tube. 4. Apply clear tape to the antenna, grommet and hull in the boat to keep the antenna from moving. 3 Getting Started 1. Power on the transmitter. 2. Connect the battery. 3. Test the transmitter’s control of the boat with the boat on the display stand. 4. After launching the boat in the water, start driving slowly. If the boat does not go straight, adjust the trimer on the transmitter to run it straight. Checking the Radio System CAUTION: Always keep all body parts, hair and dangling or loose items away from a spinning propeller, as these could become entangled. NOTICE: Always power on the transmitter before powering on the ESC. Always power off the ESC before powering off the transmitter. Never transport the boat with the battery connected to the ESC. 1. Turn the transmitter throttle and rudder trim to the middle position. 2. Power on the transmitter. 3. Connect a fully charged battery to the ESC. 5. Ensure the rudder moves in the proper direction when the controller is moved left or right. 6. Pull the throttle to full, then return the throttle to neutral, ensuring the propeller turns counterclockwise. The ESC auto-sensing voltage cutoff will engage when the ESC detects a low battery charge. Release the throttle and recharge the battery when necessary. Testing Your Boat in the Water 1. Carefully place the boat in the water. 2. Operate the boat at slow speeds near the shoreline. Avoid objects in the water at all times. 3. Once you are comfortable operating the boat at slow speeds, it is safe to operate the boat farther from the shore. Tip: If you are using too much steering trim on your transmitter to make the boat drive straight, return the trim to neutral and mechanically center the rudder. To do this, loosen the ball link from the rudder horn, then turn the ball link on the linkage threads until the rudder is properly centered. 4. Bring the boat back to shore when you notice the boat starting to lose speed. 4 5. Power off the ESC and disconnect the battery packs. 6. Allow the motor, ESC and battery packs to cool before charging the batteries or operating the boat again. NOTICE: DO NOT TURN OFF THE TRANSMITTER FIRST OR THE RECEIVER MAY PICK UP STRAY SIGNALS AND RUN OUT OF CONTROL. Boating Tips Avoid boatin…
