612804000239 入门指南 Aston 2023.11.9 Welcome Welcome to the OnePlus family! We're thrilled you’ve chosen OnePlus. This guide will help you get the most out of your new device. Read through this quick guide carefully to ensure safe and proper use of your device. Get Support Please visit the oneplus.com/privacy-and-legal page to find more information on our warranty and return policy. You can also reach out to OnePlus Customer Support by visiting oneplus.com/support. Regulatory Steps to search Regulatory : Go to Settings - About device - Regulatory SAR Values The SAR values below are the highest values reported for this device: FCC/ISED Highest SAR: Head: 1.19 W/kg(1g), Body: 1.19 W/kg(1g), Hotspot 1.19 W/kg(1g) Learn More For more information, please download the complete guide on https://service.oneplus.com/global/user-manual. This manual is for reference only, the actual product shall prevail. The information is subject to change without notice. Model: CPH2611 Bienvenue Bienvenue dans la famille OnePlus ! Nous sommes enchantés de votre choix de OnePlus. Ce guide vous permet de tirer le meilleur parti de votre nouvel appareil. Lisez attentivement ce guide de démarrage rapide pour une utilisation sûre et correcte de votre appareil. Obtenir une assistance Rendez-vous sur la page oneplus.com/privacy-and-legal pour plus d'informations sur nos politiques de garantie et de retours. Vous pouvez également contacter le service clients OnePlus en visitant oneplus.com/support. Réglementation Pour faire des recherches dans la réglementation : Allez dans Paramètres - À propos de l'appareil - Réglementation Valeurs DAS Les valeurs de DAS indiquées ci-dessous sont les valeurs les plus hautes constatées pour cet appareil: FCC/ISED Highest SAR: Tête : 119 W/kg(1g), Corps : 1.19 W/kg(1g), Point chaud: 1.19 W/kg(1g) En savoir plus Pour obtenir plus d'informations, veuillez télécharger le guide complet sur https://service.oneplus.com/global/user-manual. Ce manuel est à titre indicatif uniquement, le produit fait foi. Les informations sont susceptibles d'être modifiées sans préavis. Modèle : CPH2611 Quick Guide Must Know EN: Front Camera FR: Caméra avant 1 3 EN: In-display fingerprint sensor FR: Capteur d'empreinte digitale intégré 5 EN: Volume FR: Volume EN: Nano SIM Slot FR: Emplacement carte nano SIM 9 EN: Alert Slider FR: Alert Slider 7 EN: Earpiece Speaker FR: Haut-parleur supérieur 2 EN: Speaker FR: Haut-parleur 4 6 EN: Power Sleep/Wake FR: Mise en veille/sortie de veille EN: USB Type-C port FR: Port USB type C 8 ENFR Version 12.1 © 2023 OnePlus All Rights Reserved This manual is published by OnePlus. OnePlus may correct any misprints, errors, and inaccuracies in the manual or improve its apps and/or devices at any time it deems necessary without any notice. Such changes will be applied in the later versions of this manual. All images in this manual are for 1 2 3 489 7 5 6

Version 12.2 © 2023 OnePlus All Rights Reserved This user manual provides the product safety information. Before using the phone, please read the Safety Guide carefully. Statement 'The Safety Guide' contains information regarding safety, operation and instructions and the security information below and keep it for backup. For more information about the phone, you can: the corresponding information. E.g. Instructions/User Guide. Safety & security information Read all information before using the device to ensure safe and proper use. • to Excessively high or low temperatures may damage the mobile phone or • • • The adapter, as the disconnect device from the mains, shall be installed near the device and easily accessible. • • The back cover can't be removed. • Do not replace, disassemble, modify, mechanically crush or cut the • of heat or in a low air pressure location, which may lead to an explosion or • • immediately and contact the OnePlus Service Center. • in blasting areas/near blasting caps and comply with all signs and instructions. • but it will eventually wear out. • • To prevent possible hearing damage, do not listen at high volume levels for long periods. • the user's ears and cause auditory disorders (temporary or permanent deafness, buzzing in the ears, tinnitus or hyperacusis). It is therefore strongly recommended not to use medium volume. • Precautions for using the device: Observe all safety instructions for any places, especially in hospital / health Do not use your device and adhere to all safety warnings/regulations EN regarding mobile device usage while driving. Persons with electronic implants (pacemakers, insulin pumps, neurostimulators, etc.) are recommended to place the mobile telephone 15 cm away from the implant or on the opposite side of the implant. Recommendations for use: 1. No danger relating to the use of a mobile telephone has been observed and this is purely a preventive measure. telephone: A. In good reception conditions: when the signal indicator displays a full signal on the signal reception bar. C. Giving priority to the use of data, SMS and MMS messages rather than calls. 3. Pregnant women should keep the mobile phone away from their abdomen and teenagers should keep the mobile phone away from their lower abdomen. 4. It is recommended to make reasonable use of the mobile phone by their durations or by limiting the night use of the device. • charger it is intended for use as a desktop device and should not be when using in the wireless charging mode please place the device at a minimum distance of 20cm from your body. • Do not leave your phone and its accessories within the reach of small others, or may accidentally damage the phone. • • upgrading. • these cases. • • FCC Regulatory Conformance FCC Statement following two conditions: that may cause undesired operation. NOTE: NOTE: limits are designed to provide reasonable protection against harmful to communications. OnePlus Device Warranty Information OnePlus devices purchased on oneplus.com or authorized sales channels come with a limited warranty. The duration of this warranty is dependent on the original country or region of purchase and is only redeemable within the the hardware components of the product as originally supplied and does not packaged or sold together with the product. The limited warranty only covers functional defects of product caused by workmanship or build materials. EEA models warranty is applicable only in EEA. If the device is bought from EEA The limited warranty does not cover 1. Defects or damage resulting from accidents, neglect, misuse, or abnormal use; abnormal conditions or improper storage; exposure to liquid, moisture, 2.Scratches, dents and cosmetic damage, unless caused by OnePlus. 3. Defects or damage resulting from excessive force or use of metallic objects on the touch screen. 4. Devices that have the serial number or the IMEI number removed, defaced, damaged, altered or made illegible. 5. Ordinary wear and tear. 6. Defects or damage resulting from the use of the product in conjunction or connection with accessories, products, or ancillary/peripheral equipment not furnished or approved by OnePlus. 7. Any physical feature defects or damage resulting from improper testing, operation, maintenance, installation, service, or adjustment not furnished or approved by OnePlus. 8. Defects or damage resulting from external causes such as collision with 9. Defects or damage resulting from cellular signal reception or transmission, or 10. Free warranty replacements and repairs are only valid in the country or region This manual is published by OnePlus. OnePlus may correct any misprints, errors, and inaccuracies in the manual or improve its apps and/or devices at any time it deems necessary without any notice. Such changes will be applied in the later versions of this manual. All images in this manual are for Le présent manuel d'utilisation fournit des informations sur la sécurité du sécurité. Déclaration Les Guide de sécurité contiennent des informations relatives à la sécurité, Guide de l'utilisateur. Informations de sécurité et de sûreté utilisation sûre et appropriée. • Ce téléphone mobile peut fonctionner à une température ambiante peuvent endommager le téléphone mobile ou réduire la durée de vie de la • • • installé près de l'appareil et doit rester facilement accessible. • • Le couvercle arrière n'est pas amovible. • • l'intérieur de sources de chaleur, ni dans un endroit où la pression de l'air • Pour éviter d'endommager les composants ou les circuits internes de • OnePlus. • • • FR • élevé sur de longues périodes. • temporaire ou permanente, bourdonnement dans les oreilles, • les écoles, les garages professionnels et à bord d'un avion. de sécurité concernant l'utilisation des appareils mobiles au volant. 1. Aucun danger lié à l'utilisation d'un téléphone mobile n'a été constaté et 3. Les femmes enceintes doivent tenir le téléphone mobile éloigné de leur abdomen et les a…

Text truncated - open the document above for the full version.

OnePlus Technology (Shenzhen) Co., Ltd. 022423-17 rev 6 Certification Application Attestation Statements Date: November 27, 2023 FCC ID: 2ABZ2-AA560 American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 To Whom It May Concern: Statement for 47 CFR section 2.911(d)(5)(i) OnePlus Technology (Shenzhen) Co., Ltd. certifies that as of the date of the application the equipment for which authorization is sought is not “covered” equipment 1 prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, including affiliates or subsidiaries of the named companies, the applicant must include an explanation on why the equipment is not “covered” equipment. Additional Explanation: <N/A> Statement for 47 CFR section 2.911(d)(5)(ii) OnePlus Technology (Shenzhen) Co., Ltd. (“the applicant”) certifies that, as of the date of the filing of this application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Thank you, By: __________________ Ariel Cheng (Signature 2 ) (Print name) Title: Compliance Manager Company: OnePlus Technology (Shenzhen) Co., Ltd. Telephone: 0755-61898696 1 - The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist . 2 - Letters must be placed on appropriate letterhead.

U.S. Agent Designation for Service of Process TO: Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 ATTENTION: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name: ONEPLUS USA CORP. FRN: 0033456914 Contact Name: Bing(Robin) Liu Physical U.S. address:Riverside Commons, 5000 Riverside Drive, Building 5, Suite 300, Irving, Texas 75039 Email: [email protected] This letter is to confirm that we ONEPLUS USA CORP. have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. U.S. Agent Signature: Date: September 18, 2023 Signed by (Printed Name/Title): Bing(Robin) Liu/CEO The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission- related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: OnePlus Technology (Shenzhen) Co., Ltd. Grantee Code: 2ABZ2 FRN: 0023432420 Contact Name: Ariel Cheng Address: 18C02, 18C03, 18C04, and 18C05, Shum Yip Terra Building, Binhe Avenue North, Futian District, Shenzhen, Guangdong, P.R. China. Email:[email protected] Applicant Signature: Date: September 18, 2023 Signed by (Printed Name/Title):Ariel Cheng/ Manager

Federal Communications CommissionDA 23-914 Before the Federal Communications Commission Washington, D.C. 20554 In the Matter of Amendment of the Commission’s Rules Governing Standards for Hearing Aid-Compatible Handsets ) ) ) ) WT Docket No. 20-3 ORDER Adopted: September 29, 2023Released: September 29, 2023 By the Chief, Wireless Telecommunications Bureau: I.INTRODUCTION 1.Today we grant a limited waiver of section 20.19(b)(1) and (b)(3) of the Commission’s wireless hearing aid compatibility rules with respect to the volume control technical standard that handset manufacturers use in part to certify handsets as hearing aid-compatible under the 2019 ANSI Standard. 1 Our action is prompted by a request filed by the Alliance for Telecommunications Industry Solutions (ATIS) seeking waiver of certain aspects of these rules. 2 Under the terms of the time-limited waiver we grant today, a handset may be certified as hearing aid-compatible under the 2019 ANSI Standard if it meets the volume control testing requirements described in this Order as well as all other aspects of the 2019 ANSI Standard. 2.Consistent with ATIS’s September 12, 2023, ex parte letter (ATIS Ex Parte Letter) and as a condition of this waiver, we require a handset to pass the conversational gain test at the 2 Newton (N) force level on all available narrowband and wideband codecs and air interface combinations. 3 With respect to the 8N force level test, we agree with the ATIS Ex Parte Letter that this test should be performed, and we waive the requirement that a handset achieve at least an 18 dB conversational gain. 4 This waiver is conditioned on manufacturers performing the 8N force level test using the same testing parameters that we are requiring for the 2N force level test and to place on the handset’s package label the resulting conversational gain (even if it is below 18 dB) in a manner consistent with our existing hearing aid compatibility labeling rules. 3.With respect to the related receive distortion and noise performance (distortion/noise) and receive acoustic frequency response performance (frequency response) tests, we agree with the ATIS Ex Parte Letter that handsets must pass testing using at least one narrowband and one wideband codec of the 1 The 2019 ANSI Standard refers to the technical document entitled Accredited Standards Committee C63®– Electromagnetic Compatibility, American National Standard Methods of Measurement of Compatibility Between Wireless Communications Devices and Hearing Aids, ANSI C63.19-2019 (approved Aug. 19, 2019) (2019 ANSI Standard). 2 Petition of ATIS on Behalf of the Covered Entities of the Hearing Aid Compatibility Task Force for Limited, Interim Waiver, WT Docket Nos. 15-285 and 20-3 (filed Dec. 16, 2022) (ATIS Waiver Petition). ATIS filed its waiver petition on behalf of all manufacturers and service providers subject to section 20.19(b)(1) and (b)(3) of the Commission’s wireless hearing aid compatibility rules. Id. at 1, 4. 3 Letter from Thomas Goode, General Counsel, ATIS, to Marlene H. Dortch, Secretary, FCC, WT Docket Nos. 15- 285 and 20-3, at 2 (filed Sept. 12, 2023) (ATIS Ex Parte Letter); see also ATIS Waiver Petition at 4, 12-13. Below we explain the conversational gain test. See infra para. 9. 4 ATIS Ex Parte Letter at 2. Originally, ATIS had proposed to waive the entire 8N force level test. ATIS Waiver Petition at 10-11, 13. Federal Communications CommissionDA 23-914 2 manufacturer’s choosing. 5 We also accept ATIS’s suggestion that at least one narrowband and one wideband codec must pass testing for distortion/noise and frequency response and tests will be limited to one bit rate and only with those air interfaces associated with the chosen codecs and that the other codecs used for conversational gain at the 2N and 8N force levels are not required to undergo the distortion/noise and frequency response tests. 6 Further, as detailed below, we accept ATIS’s suggested method to set the volume control setting for testing these other codecs for conversational gain. 7 4.By taking these steps, we ensure that when the exclusive use transition period ends on December 5, 2023, new handset models can be certified as hearing aid-compatible using the 2019 ANSI Standard as modified by the conditions established in this Order. 8 Our actions allow consumers with hearing loss who use hearing aids or cochlear implants to benefit from wider availability of handsets offering improved hearing aid compatibility under the 2019 ANSI Standard’s radio frequency (RF) interference and inductive coupling requirements. In addition, our approach gives consumers assurance that a handset’s amplifier/speaker combination will provide improved volume control functionality over narrowband and wideband modes of voice communications, and that consumers have the information that they need to make informed purchasing decisions. Our actions today will move us closer to the Commission’s goal of reaching 100% hearing aid compatibility for wireless handsets, while also creating a path forward for testing to ensure that handsets have volume control capabilities. 9 5.This waiver is effective immediately upon release of this Order so that manufacturers may afford the benefits of this relief to consumers with hearing loss as soon as feasible. In reliance upon ATIS’s representations that efforts are underway to expeditiously develop a new volume control standard through the TIA standards setting process, we limit this waiver to a two-year period. 10 During this waiver period, we will evaluate the effectiveness of the waiver standard in meeting the needs of consumers with hearing loss and take action where appropriate. We expect that a two-year time limitation for the waiver will encourage all interested parties to work together to rapidly develop an improved volume control standard that we can incorporate into our rules in the future. To ensure this outcome, we condition this waiver in part on ATIS filing a status lett…

Text truncated - open the document above for the full version.

OnePlus Technology (Shenzhen) Co., Ltd. To Whom lt May Concern, We are certifying the HAC Compliance of FCC ID: 2ABZ2-AA560 under the ANSI C63.19-2019, and the Volume Control performance is assessed under the condition of the limited-term waiver DA23-914. We attest that, the package label is compliance with 47 CFR 20.19f)(1) and states the actual conversational gain obtained under the waiver for the passing codecs demonstrated in section2.a. and 2.b. of KDB 285076 D05 HAC Wavier and for the lowest conversational gain achieved for each 2N and 8N. APPROVED BY: Projects Manager: Ariel Cheng Signature: Company name: OnePlus Technology (Shenzhen) Co., Ltd. Date: 2023/12/07

OnePlus Technology (Shenzhen) Co., Ltd. 18C02, 18C03, 18C04 and 18C05, Shum Yip Terra, Building, Binhe Avenue North, Futian District, Shenzhen , China Tel: 0755-61898696 ; Fax: 0769-86076938 041521-14 Authority to Act as Agent Date: November 10, 2023 American Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: CTTL-Telecommunication Technology Labs, CAICT_ is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. We also declare that the information provided to the FCC is true and correct to the best of our knowledge (47 CFR 2.911(d)) and we have been informed of the grantee responsibilities (47 CFR 2.909) with regard to certified equipment. Thank you, Agency Agreement Expiration Date: July 10,2024 By: Ariel Cheng (Signature 1 ) (Print name) Title: Compliance Manager On behalf of: OnePlus Technology (Shenzhen) Co., Ltd. (Company Name) Telephone: 0755-61898696 1 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

OnePlus Technology (Shenzhen) Co., Ltd. 18C02, 18C03, 18C04 and 18C05, Shum Yip Terra, Building, Binhe Avenue North, Futian District, Shenzhen , China Tel: 0755-61898696 ; Fax: 0769-86076938 041521-14 Request for Confidentiality Date: November 10, 2023 Subject: Confidentiality Request for: FCC ID: 2ABZ2-AA560 Pursuant to FCC 47 CFR 0.457(d) and 0.459 and IC RSP-100, Section 12.4, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit ☐ Short Term ☒ Permanent Block Diagrams ☒ Short Term External Photos ☒ Short Term ☐ Permanent * 1 Internal Photos ☐ Short Term ☒ Permanent Operation Description/Theory of Operation ☐ Short Term ☒ Permanent Parts List & Placement/BOM ☐ Short Term ☒ Permanent Tune-Up Procedure ☐ Short Term ☒ Permanent Schematics ☒ Short Term Test Setup Photos ☒ Short Term ☐ Permanent * 3 User’s Manual OnePlus Technology (Shenzhen) Co., Ltd. has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public before the requested period has expired. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: IC currently only distinguishes Permanent Confidentiality exhibits as shown above. Short Term confidentiality is not considered applicable to IC applications. Sincerely, By: Compliance Manager Ariel Cheng (Signature/Title 2 ) (Print name) 1 - The asterisked items (*) require further information to be provided to ACB before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 and the specific Document link for D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding specific information that must accompany these requests. 2 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

OnePlus Technology (Shenzhen) Co., Ltd. ADDRESS: 18C02, 18C03, 18C04, and 18C05, Shum Yip Terra Building, Binhe Avenue North, Futian District, Shenzhen, Guangdong, P.R. China Tel:+ 0755-61898696 Statement We, OnePlus Technology (Shenzhen) Co., Ltd., states that our device with FCC ID: 2ABZ2-AA560 is a multi-band mobile phone which supports GSM850/900/1800/1900, WCDMA Band 1/2/4/5/8, FDD LTE: B1/2/3/4/5/7/8/12/13/17/18/19/20/25/26/28/30/66/71 TDD LTE:38/39/40/41(HPUE) /48 Sub 6G SA: 1/2/3/5/7/8/20/25/28 /38/40/41(HPUE & UL MIMO) /66/71/77(HPUE & UL MIMO)/78(HPUE & UL MIMO) for cellular network. For connectivity functions, it is capable of 2.4GHz WiFi 11b/11g/11n-HT20/11n-HT40/11ax-HE20/40/11be-EHT20/40 5GHz WiFi 11a/11n-HT20/11n-HT40, 11ac-VHT20/11ac-VHT40/11ac-VHT80 (5.725 GHz –5.8 25 GHz/160/11ax-HE20/40/80/160/11be-EHT20/40/80/160 6G WIFI 11a-HT20/11ax-HE20/40/80/160/11be-EHT20/40/80/160/320 And Bluetooth 5.3 LE, along with NFC. However, LTE band 40 & NR N40 is not available in US market and Canada market, and will be disabled by software. Signature Contact Person: Ariel Cheng E-mail: [email protected]

OnePlus Technology (Shenzhen) Co., Ltd. Declaration of pre-install of OTT voice service We, [OnePlus Technology (Shenzhen) Co., Ltd.], as the manufacturer of FCC ID: 2ABZ2-AA560（Model: CPH2611）, declares that this model supports Wi-Fi Calling and only pre-installs Google MEET of OTT service with Android OS， and doesn’t support any other OTT services. We tested MEET using the software from Google according to KDB 285076 D02v04 Guidance for performing T-Coil tests for air interfaces supporting VOIP to support CMRS based telephone services. APPROVED BY: Projects Manager: Ariel Cheng Signature: Company name: OnePlus Technology (Shenzhen) Co., Ltd. Date: 2023/11/9
