2ABZ6BT005Bluetooth Activity Checker

How to wear it Bluetooth 4.0 Daily Steps Daily Travel time Daily Distance Daily Calories burnt Battery level shown on OLED Daily Sleep data 14 days data record for main unit Battery level shown the battery level in APP when synchronizing every time. Clock (built in RTC) with yy/mm/dd Clear sensor memories by APP. Device Daily RangeFeaturesKey and (OLED version) BTOO5 IM 正面 ( 210 x 297mm ) BTOO5 IM 背面 ( 210 x 297mm ) OPERATION MANUAL BT 4.0 Activity & Sleep Tracker - BT005 Step 0 – 350,000 steps Step Distance 0 – 500.0km or 0 – 500.0miles Travel Time 00:00 – 24:00 (hr:mm) Calories 0 – 50000 kcal Age 5-99 Weight 30 – 136kg (66lb – 300 lb) Height 100 cm – 200cm (39 inches – 79 inches) Stride length 30 cm – 150cm (12 inches – 59 inches) BT 4.0Step DistanceTravel time Avg. speed Press the key to clear all setting, and restore to default setting, The functions of the device are disabled until activating the device. Reset Reset Battery level Sleep data Calories Z Z Reset Clip it Bag it Wear the wrist band at night to track your sleep 1 key (Standalone version, OLED Version) -Press once to interchange the display mode. -Press and hold 2 second to enter sleep tracker mode. -In sleep tracker mode, press and hold 2 seconds to exit sleep tracker mode. OLED display : all display will be shown on the OLED, no LED. Display Step, Distance, Calories, Activity Time, Average Speed, Average Pace.Edit Target step, step distance, and calories. History mode can show Daily, Weekly, Monthly, Yearly and Total. History Chart can show Weekly, Monthly, Yearly. Daily summary mode Display Start sleep time, Stop sleep time, Time in bed, Asleep time, Disrupted, Efficiency. History modeHistory chart Display history --- Daily, Weekly and Monthly Graph history display --- Weekly, Monthly, Yearly. History mode Pedometer Z Z Z HomeTripSettingSleep TrackerHeart Rate 99999 Steps 88.8 Km < < Week of -- 01/04/2013 Step Distance 45000 kcal Calories Activity time 00:30:00 T otal Daily Weekly Monthly Y early < < Last update: 03/04/2013 03/04/2013 Wed Sleep tracker Z Z Z HomeTripSettingSleep TrackerHeart Rate 97% Ef ficiency Your Daily Summary 97% 7h 30m Asleep / Resting 7h 17m 22:00 03/04/2013 05:30 04/04/2013 Disrupted + Likely Awake 13m Z Z Z Start ti me Time in bed End time Z Z Ef ficiencyAsleep / RestingDisrupted 94%5h 21m 5h 36m 05/04/2013 15m Time in bed 98%6h 02m 6h 10m04/04/2013 8m Time in bed 97%7h 17m 7h 30m03/04/2013 13m Time in bed 95%5h 30m 5h 46m02/04/2013 16m Time in bed Daily Weekly Monthly Z Z Z HomeTripSettingSleep TrackerHeart Rate < < Week of -- 01/04/2013 Sleep tracker Z Z Z Asleep timeSleep Efficiency 10 8 6 4 2 01/0402/0403/0404/0405 /04 06/0407/04 100 80 60 40 20 00 %hr Weekly Monthly Z Z Z HomeTripSettingSleep TrackerHeart Rate < < Week of -- 01/04/2013 Sleep tracker Z Z Z Daily summary mode 9999 Steps Step 20000 < < Last update: 03/04/2013 03/04/2013 Wed 45% 8.8 Km Dist ance 16 75% 4000 00:30:00 kcal Calories 10000 45% Pedometer Z Z Z HomeTripSettingSleep TrackerHeart Rate Activity time km/hr History chart 5000 4000 3000 2000 1000 29/0330/0331/0301/0402/0403/0404/04 0 step 5000 4000 3000 2000 1000 0 kcal Weekly Monthly Y early Pedometer Z Z Z HomeTripSettingSleep TrackerHeart Rate < < Week of -- 01/04/2013 StepCalories Activity time 500 400 300 200 100 29/0330/0331/0301/0402/0403/0404/04 0 km 50 40 30 20 10 0 hr Weekly Monthly Y early Pedometer Z Z Z HomeTripSettingSleep TrackerHeart Rate < < Week of -- 01/04/2013 Distance Pedometer - To update the data, click on the APP to update the data. Sleep tracker - To update the data, click on the APP to update the data. Micro USB charging It is strongly advised to upload your data every 5~7 days, to maintain the completeness of monitoring. 16 AVG. Speed MyWay Fit To synchronize the data, it must to be connected between device and mobile Phone. 1.) In pedometer mode, press the key to Bluetooth connection mode, “Disconnect” will be shown. 2.) Press and hold key 2 seconds to enable Bluetooth connection. OLED display will be shown “Connecting” below: 3.) To check the mobile phone bluetooth status whether is on. (Settings Bluetooth select bluetooth on) 4.) Open the APP 5.) In Home mode, click Trip or Sleep tracker to enter corresponding pages. 6.) To update the data, click on the APP to update the data. 7.) Press button on the pedometer once to exit the Bluetooth mode, representing the device is working in the pedometer mode. Synchronizing the data Z Z Z Pocket it OLED Display Low battery indicator 1.) In order to save the power, OLED display will be only displayed on for 3 seconds. 2.) If the OLED is off, press key to wake the OLED on for 3 seconds. Note : The function of key should be valid when there is OLED display. Battery Charging 1.) When plug in the USB for charging, the OLED will be shown battery charging symbol until unplug the USB power. (Charging diagram like iphone charging direction.) Note : During charging, the function must work properly. -When there is low battery, it will display 1s low battey icon when press key from OLED wake up. Then, enter to previous corresponding stage. It is strongly advised to charge every 5~7 days, to maintain the completeness of monitoring. Forget Device Clear Memory Updating the customer setting After Bluetooth connection, the user can set the personal setting in profile page (Setting Profile) After setting the personal information, press Update icon to update the information to tracker. Clear the stored data inside App In profile page, press CLEAR PROFILE to clear the stored data inside APP. Unpaired internal memory Press Forget Device can be unpaired the paired activity & sleep tracker. The user can pair the new tracker again. Profile Settings GenderFemale Age Heightcm kgWeight cmStride Unit 30 160 60 80 CLEAR PROFILE Male MetricEnglish Name User CLEAR PROFILE Update Update Clear internal memory After Bluetooth connected is connected, press Clear Memory icon inside APP can clear all data store inside activity & sleep trac…

Text truncated - open the document above for the full version.

Project No.: 1401C184 Page 2 of 11 Neutron Engineering Inc. Project No.: 1401C184 Page 3 of 11 Neutron Engineering Inc. Project No.: 1401C184 Page 4 of 11 Neutron Engineering Inc.

ODEHOORFDWLRQ

Project No.: 1401C184 Page 5 of 11 Neutron Engineering Inc. Project No.: 1401C184 Page 6 of 11 Neutron Engineering Inc. Project No.: 1401C184 Page 7 of 11 Neutron Engineering Inc. Project No.: 1401C184 Page 8 of 11 Neutron Engineering Inc. Project No.: 1401C184 Page 9 of 11 Neutron Engineering Inc. Project No.: 1401C184 Page 10 of 11 Neutron Engineering Inc. Project No.: 1401C184 Page 11 of 11 Neutron Engineering Inc.

Neutron Engineering Inc. FCC RF EXPOSURE REPORT FCC ID: 2ABZ6BT005 Project No. : 1401C184 Equipment : Bluetooth Activity Checker Model : BT005 Applicant : R.E.A.C ELECTRONIC CO., LTD Address : 7/F., O.T.B. Building, 259-265 Des Voeux Road Central, Hong Kong China 999077 According: : FCC Guidelines for Human Exposure IEEE C95.1 Neutron Engineering Inc. No.3, Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. MPE CALCULATION METHOD: Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Table for Field Antenna: Ant. Manufacturer Model Name Antenna TypeConnector Gain (dBi) 1 N/A N/A Printed Antenna N/A -1.01 GENERAL CONCULUSION: Maximum measured transmitter power: Output Power (dBm) Output Power (mW) Limit (mW) 2.16 1.6 10 According to FCC KDB447498 V05, Appendix A, SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm The maximum measured output peak power of this EUT is 1.6 mW, less than 10mW at 5mm distance. Conclusion: No SAR evaluation required since transmitter power is below FCC threshold

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1401C184 Page 1 of 57 FCC Radio Test Report FCC ID: 2ABZ6BT005 This report concerns (check one): Original Grant Class II Change Issued Date : Feb. 28, 2014 Project No. : 1401C184 Equipment : Bluetooth Activity Checker Model Name : BT005 Applicant : R.E.A.C ELECTRONIC CO., LTD Address : 7/F., O.T.B. Building, 259-265 Des Voeux Road Central, Hong Kong. Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Jan. 27, 2014 Date of Test: Jan. 27, 2014~ Feb. 27, 2014 Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory: (Steven Lu) Neutron Engineering Inc. No.3,Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL: 0769-8318-3000 FAX: 0769-8319-6000 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1401C184 Page 2 of 57 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C, or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FCCP-1-1401C184 Page 3 of 57 Table of Contents Page 1 . CERTIFICATION 6 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 3 . GENERAL INFORMATION 9 3.1 GENERAL DESCRIPTION OF EUT 9 3.2 DESCRIPTION OF TEST MODES 11 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 12 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 13 3.5 DESCRIPTION OF SUPPORT UNITS 14 4 . EMC EMISSION TEST 15 4.1 CONDUCTED EMISSION MEASUREMENT 15 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 15 4.1.2 TEST PROCEDURE 15 4.1.3 DEVIATION FROM TEST STANDARD 15 4.1.4 TEST SETUP 16 4.1.5 EUT OPERATING CONDITIONS 16 4.1.6 EUT TEST CONDITIONS 16 4.1.7 TEST RESULTS 16 4.2 RADIATED EMISSION MEASUREMENT 19 4.2.1 RADIATED EMISSION LIMITS 19 4.2.2 TEST PROCEDURE 20 4.2.3 DEVIATION FROM TEST STANDARD 20 4.2.4 TEST SETUP 21 4.2.5 EUT OPERATING CONDITIONS 22 4.2.6 EUT TEST CONDITIONS 22 4.2.7 TEST RESULTS-BETWEEN 30MHZ AND 1000MHZ 24 4.2.8 TEST RESULTS (ABOVE 1000 MHZ) 31 5 . BANDWIDTH TEST 39 5.1 APPLIED PROCEDURES / LIMIT 39 5.1.1 TEST PROCEDURE 39 5.1.2 DEVIATION FROM STANDARD 39 5.1.3 TEST SETUP 39 5.1.4 EUT OPERATION CONDITIONS 39 5.1.5 EUT TEST CONDITIONS 39 5.1.6 TEST RESULTS 40 6 . MAXIMUM OUTPUT POWER TEST 42 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1401C184 Page 4 of 57 Table of Contents Page 6.1 APPLIED PROCEDURES / LIMIT 42 6.1.1 TEST PROCEDURE 42 6.1.2 DEVIATION FROM STANDARD 42 6.1.3 TEST SETUP 42 6.1.4 EUT OPERATION CONDITIONS 42 6.1.5 EUT TEST CONDITIONS 42 6.1.6 TEST RESULTS 43 7 . ANTENNA CONDUCTED SPURIOUS EMISSION 44 7.1 APPLIED PROCEDURES / LIMIT 44 7.1.1 TEST PROCEDURE 44 7.1.2 DEVIATION FROM STANDARD 44 7.1.3 TEST SETUP 44 7.1.4 EUT OPERATION CONDITIONS 44 7.1.5 EUT OPERATION CONDITIONS 44 7.1.6 TEST RESULTS 44 8 . POWER SPECTRAL DENSITY TEST 49 8.1 APPLIED PROCEDURES / LIMIT 49 8.1.1 TEST PROCEDURE 49 8.1.2 DEVIATION FROM STANDARD 49 8.1.3 TEST SETUP 49 8.1.4 EUT OPERATION CONDITIONS 49 8.1.5 EUT TEST CONDITIONS 49 8.1.6 TEST RESULTS 50 9 . MEASUREMENT INSTRUMENTS LIST 52 10 . EUT TEST PHOTO 54 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1401C184 Page 5 of 57 REPORT ISSUED HISTORY Issued No. Description Issued Date NEI-FCCP-1-1401C184 Original Issue. Feb. 28, 2014 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1401C184 Page 6 of 57 1. CERTIFICATION Equipment : Bluetooth Activity Checker Brand Name : ELAH Model Name : BT005 Applicant : R.E.A.C ELECTRONIC CO., LTD Manufacture : REAC INDUSTRIAL CO., LTD Address : ZHONGFANG GONG YE QU, SHATOU GUAN LI QU, CHANGAN TOWN, DONGGUAN CITY, GUANGDONG, CHINA Factory : REAC INDUSTRIAL CO., LTD Address : ZHONGFANG GONG YE QU, SHATOU GUAN LI QU, CHANGAN TOWN, DONGGUAN CITY, GUANGDONG, CHINA Date of Test : Jan. 27, 2014~ Feb. 27, 2014 Test Item : ENGINEERING SAMPLE Standard(s) : FCC Part15, Subpart C(15.247) / ANSI C63.4-2009 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCP-1-1401C184) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). Neutron Engineering Inc. Report No.: NEI-FCCP-1-1401C184 Page 7 of 57 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): Applied Standard(s): FCC Part15 (15.247) , Subpart C Standard(s) Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(d) Antenna conducted Spurious Emission PASS 15.247(a)(2) 6dB Ba…

Text truncated - open the document above for the full version.

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1401C184 Page 54 of 57 10. EUT TEST PHOTO Conducted Measurement Photos Neutron Engineering Inc. Report No.: NEI-FCCP-1-1401C184 Page 55 of 57 Radiated Measurement Photos 9K~30MHz Neutron Engineering Inc. Report No.: NEI-FCCP-1-1401C184 Page 56 of 57 Radiated Measurement Photos 30~1000MHz Neutron Engineering Inc. Report No.: NEI-FCCP-1-1401C184 Page 57 of 57 Radiated Measurement Photos Above 1000MHz
