2ABZATU-W1402ATablet PC

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 Xie He Kong Company Limited Room502,5/F,Tungsun Commercial Centre,194-200 Lockhart Rd,Wanchai,HK 2015-3-17 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, XIE HE KONG COMPANY LIMITED hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): FCC ID: 2ABZATU-W1402A Model: TU-W1402A Product name: Tablet PC Sincerely, signature : name / title: Yuan Ping / Manager address: Room502,5/F,Tungsun Commercial Centre,194-200 Lockhart Rd,Wanchai,HK

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Xie He Kong Company Limited Room502,5/F,Tungsun Commercial Centre,194-200 Lockhart Rd,Wanchai,HK 2015-3-17 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ABZATU-W1402A We hereby request confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, signature : name / title: Yuan Ping / Manager address: Room502,5/F,Tungsun Commercial Centre,194-200 Lockhart Rd,Wanchai,HK

Xie He Kong Company Limited Room502,5/F,Tungsun Commercial Centre,194-200 Lockhart Rd,Wanchai,HK FCC ID: 2ABZATU-W1402A To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite device. We understand that devices subject to the DoC procedure are required to be tested to show compliance with the FCC technical regulations by a recognized accredited testing laboratory. The testing laboratory must be accredited by a Commission approved accreditation body or designated under the terms of a government-to-government Mutual Recognition Agreement (MRA). A listing of those accredited testing laboratories that have been recognized by the Commission is published on the FCC Test facilities located in countries, where the U.S. does not have an operational Telcom MRA are not recognized by the FCC to test for the DoC procedure. Sincerely, signature : name / title: Yuan Ping / Manager address: Room502,5/F,Tungsun Commercial Centre,194-200 Lockhart Rd,Wanchai,HK

Label location

Antenna Location

FCC ID: 2ABZATU-W1402A Test Result of RF Exposure Evaluation According to the KDB-447498 D01 V05, FCC 47CFR§2.1093 the following RF exposure evaluation shall to demonstrate RF exposure compliance. [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance,mm)] * [√f(GHz)] 1.1. Test Result of RF Exposure Evaluation Target power W/ tolerance (dBm) Max tune up power tolerance (dBm) Separation distance mm RF exposure 802.11b 8 ±1.0 9.0 5.00 2.47 802.11g 7 ±1.0 8.0 5.00 1.96 802.11n(HT20) 7 ±1.0 8.0 5.00 1.96 802.11n(HT40) 7 ±1.0 8.0 5.00 1.96 The Max RF exposure is 2.47. Threshold at which no SAR required is≤ 3.0 for 1-g SAR, Separation distance is 5mm. Conclusion: So no SAR is required.

FCC ID:2ABZATU-W1402A Keyway Testing Technology Co., Ltd. Report No. 15KWE032368F Page 1 of 43 FCC TEST REPORT for Xie He Kong Company Limited Tablet PC Model Number: TU-W1402A FCC ID: 2ABZATU-W1402A Prepared for : Xie He Kong Company Limited Address : Room502,5/F,Tungsun Commercial Centre,194-200 Lockhart Rd,Wanchai,HK Prepared by : Keyway Testing Technology Co., Ltd. Address : Building 1, Baishun Industrial Zone, Zhangmutou Town, Dongguan, Guangdong, China Tel: 86-769-8718 2258 Fax: 86-769-8718 1058 Report No. : 15KWE032368F Date of Test : Mar. 11~16, 2015 Date of Report : Mar. 17, 2015 FCC ID:2ABZATU-W1402A Keyway Testing Technology Co., Ltd. Report No. 15KWE032368F Page 2 of 43 TABLE OF CONTENTS Test Report Declaration Page 1. TEST SUMMARY .......................................................................................................................... 4 2. GENERAL PRODUCT INFORMATION ......................................................................................... 5 2.1. Product Function .................................................................................................................... 5 2.2. Description of Device (EUT) .................................................................................................. 5 2.3. Independent Operation Modes .............................................................................................. 5 2.5. TEST SITES .......................................................................................................................... 6 2.6. List of Test and Measurement Instruments ............................................................................ 7 3. TEST SET-UP AND OPERATION MODES .................................................................................. 8 3.1. Principle of Configuration Selection ....................................................................................... 8 3.2. Block Diagram of Test Set-up ................................................................................................ 8 3.3. Test Operation Mode and Test Software ............................................................................... 8 3.4. Special Accessories and Auxiliary Equipment ....................................................................... 8 3.5. Countermeasures to Achieve EMC Compliance .................................................................... 8 4. EMISSION TEST RESULTS ......................................................................................................... 9 4.1. Conducted Emission at the Mains Terminals Test ................................................................. 9 4.2. Radiated Emission Test ....................................................................................................... 12 5. BAND EDGE COMPLIANCE TEST ............................................................................................. 28 5.1. Limits .................................................................................................................................... 28 5.2. Test setup ............................................................................................................................ 28 6. 6DB OCCUPY BANDWIDTH ....................................................................................................... 30 6.1. Limits .................................................................................................................................... 30 7. OUTPUT POWER TEST ............................................................................................................. 33 7.1. Limits .................................................................................................................................... 33 7.2. Test setup ............................................................................................................................ 33 7.3. Test result ............................................................................................................................ 33 8. POWER SPECTRAL DENSITY TEST ........................................................................................ 34 8.1. Limits .................................................................................................................................... 34 8.2. Test setup ............................................................................................................................ 34 8.3. Test result ............................................................................................................................ 34 9. ANTENNA REQUIREMENTS ...................................................................................................... 39 9.1. Limits .................................................................................................................................... 39 9.2. Result ................................................................................................................................... 39 10. PHOTOGRAPHS OF TEST SET-UP ....................................................................................... 40 11. PHOTOGRAPHS OF THE EUT ............................................................................................... 42 FCC ID:2ABZATU-W1402A Keyway Testing Technology Co., Ltd. Report No. 15KWE032368F Page 3 of 43 Keyway Testing Technology Co., Ltd. Applicant: Address: Xie He Kong Company Limited Room502,5/F,Tungsun Commercial Centre,194-200 Lockhart Rd,Wanchai,HK Manufacturer: Address: Xie He Kong Company Limited Room502,5/F,Tungsun Commercial Centre,194-200 Lockhart Rd,Wanchai,HK E.U.T: Tablet PC Model Number: TU-W1402A Trade Name: ------ Serial No.: ------ Date of Receipt: Mar. 11, 2015 Date of Test: Mar. 11~16, 2015 Test Specification: FCC Part 15, Subpart C Section 15.247: 2014 ANSI C63.4:2009 KDB558074 D01 DTS Meas Guidance v03r02 Test Result: The equipment under test was found to be compl…
