2AC2VEXOMDrone

QUICK START GUIDE SenseFly EXOM This guide will help you understand the basics of using the SenseFly eXom drone. For more information, refer to the user guide. Charging the battery 1. Select the adapter corresponding to your country and connect it to the power supply 2. Connect the charger to the power supply 3. Plug the battery to the charger 4. When all the LED are black, the battery is fully charged Installing the battery 1. Insert the battery into the appropriate compartment Connecting to eMotion 1. Download the latest SenseFly software from : http://my.sensefly.com 2. Install eMotionX and the device drivers 3. Plug your Ground modem on a USB port 4. Press the power button 5. Launch eMotionX 6. When your drone has been successfully detected by the Ground modem, its serial number will appear in the FTDI port pulldown menu 7. In the Connect dialog, click the DRONE button to select it, then click OK 8. Plan a mission and start it GENERAL INFORMATION SenseFly Ltd products are subject to Civil Aviation regulations. Regulations may vary depending on the country where you intend to operate your product. ANY USE OF SENSEFLY LTD PRODUCTS IN BREACH OF THE LAW OF THE COUNTRY WHERE YOU OPERATE THE PRODUCT IS UNDER YOUR SOLE RESPONSIBILITY. INFORM YOURSELF BEFORE USING THE PRODUCT. SOME COUNTRIES MAY HAVE LAWS THAT LIMIT THE USE OF UNMANNED AIRCRAFT TO ‘LINE-OF-SIGHT’ OPERATIONS AND/OR PROHIBIT THE USE OF UNMANNED AIRCRAFT AT ALL OR IN SPECIFIC AREAS. FCC and IC Compliance statement This device complies with part 15 of the FCC Rules and Industry Canada License exempt RSS standard(s). Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide a reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and uses in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures. 1. Reorient or relocate the receiving antenna 2. Increase the separation between the equipment and the receiver 3. Connect the equipment into a an outlet on a circuit different from that to which the receiver is connected 4. Consult the dealer or an experienced radio/TV technician for help This Class B digital apparatus complies with Canadian ICES-003. This equipment complies with FCC’s radiation exposure limits set forth for an uncontrolled environment under the following conditions: 1. This equipment should be installed and operated such that a minimum separation distance of 20cm is maintained between the radiator (antenna) and user’s/nearby person’s body at all times. 2. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This radio transmitter (Ground modem transmitter: CONTAINS IC ID: 9301A-103678DT60M) has been approved by Industry Canada to operate with the antenna types listed below with the maximum permissible gain indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device. Antenna type Max Gain (2.4GHz et 5GHz) Dual band dipole 3dBi Disposal of this product at the end of its life At the end of this product’s life, please do not dispose of this product in your general household waste. Instead, in order to prevent possible harm to the environment or human health from uncontrolled waste disposal, please dispose of this product separately in accordance with your local laws and regulation. For more information on the separate collection systems for waste electrical and electronic equipment that are available for consumers, near your home, free of charge, please contact your local municipal authority. You can also contact senseFly Ltd or the reseller from which you purchased your drone who may provide recycling services or be part of a recycling scheme. GUIDE DE DEMARRAGE RAPIDE SenseFly EXOM Ce guide vous aidera à comprendre les bases du drone eXom de SenseFly. Pour plus d’informations, consultez le guide utilisateur. Charger la batterie 1. Sélectionnez l’adaptateur correspondant à votre pays et connectez-le à votre alimentation 2. Connectez le chargeur à l’alimentation 3. Branchez la batterie au chargeur 4. Quand toutes les LED de la batterie sont éteintes, celle-ci est complètement chargée Installer la batterie Insérez la batterie dans le compartiment approprié Connecter le drone à eMotionX 1. Téléchargez la dernière version du logiciel sur : http://my.sensefly.com 2. Installez eMotionX et les pilotes des périphériques 3. Branchez votre ground modem à un port USB 4. Pressez le bouton d’allumage du drone 5. Lancez eMotionX 6. Quand votre drone a été détecté par le ground modem, son numéro de série apparaitra dans le menu déroulant 7. Dans la fenêtre Connect, cliquez sur le bouton DRONE puis sur OK 8. Planifiez une mission et démarrez là INFORMATIONS GENERALES Les produits de senseFly Ltd sont sujets aux règlements de l’aviation civile. Ces règlements peuvent varier selon le pays où vous avez l’intention d’utiliser votre produit. TOUTE UTILISATION DES PRODUITS SENSEFLY LTD EN VIOLATION AVEC LES LOIS DU PAYS DANS LE…

Text truncated - open the document above for the full version.

eXom external photos: Top view Bottom view Front view Side view

MODEL: SENSEFLY EXOM FCC ID: 2AC2VEXOM IC: 12288A-EXOM 12.5V --- 20A Use only with sensey battery MODEL: SENSEFLY EXOM FCC ID: 2AC2VEXOM IC: 12288A-EXOM 12.5V --- 20A Use only with sensey battery

eXom internal photos 1 Motor : MOT Top MOT Bottom 2 Frame : BLDC Top BLDC Radio control RF part detail BLDC Bottom Radio Control antenna 3 Body : Body top view with 3pcs Ultrasonic Body Bottom view with 4 th Ultrasonic Body bottom view Detail : Mag2 Body detail : Button Body detail : rear Body detail : Rear Ultrasonic Body detail : Left Ultrasonic Body detail : Right Ultrasonic Mag2 Top Mag2 Bottom Button Top Button Bottom Neratec Top Neratec Bottom Wifi (Neratec DT60) Antenna Bottom Wifi (Neratec DT60) Antenna Top GPS Antenna Top GPS Antenna Bottom MainBoard Top MainBoard Bottom with shield MainBoard Bottom without shield with module MainBoard Bottom without shield without module Ultrasonic Top Ultrasonic Bottom 4 Payload Payload overview Top Payload overview Bottom PYLD1 Top PYLD1 Bottom MAG1 Top MAG1 Bottom PYLD2 Top PYLD2 Bottom 5 Battery Drone rear without battery Drone rear with Battery Battery without casing BATT Top Batt Bottom

Internal Photos DT60M Project: 5122.06 DT60M Date: April 09, 2015 Author: Patric Cathomas Approved: April 09, 2015/Michael Aeschbacher Confidentiality: public Figure 1: Internal Photo Top-Layer DT60M Figure 2: Photo Bottom-Layer DT60M

Siège Social : Emitech - 3, rue des Coudriers - Z.A. de l’Observatoire - 78180 MONTIGNY LE BX - France Siret : 344 545 645 00022 - Tél. : 33 (0)1 30 57 55 55 - Fax : 33 (0)1 30 43 74 48 - E-mail : [email protected] - URL : www.emitech.fr S.A. au capital de 1 560 000 € - R.C.S. VERSAILLES 344 545 645 - APE 7112B RR051-15-102324-7-A Ed. 0 Certification Radio test report According to the standard: CFR 47 FCC PART 15 Equipment under test: DRONE EXOM FCC ID: 2AC2VEXOM Company: SENSEFLY DISTRIBUTION: Mr GILLE (Company: SENSEFLY) Number of pages: 54 with 9 appendixes Technical Verification and Ed. Date Modified Written by Quality Approval pages Name Visa Name Visa 0 21/08/2015 Creation S. LOUIS M. DUMESNIL Duplication of this test report is only permitted for an integral photographic facsimile. It includes the number of pages referenced here above. This document is the result of testing a specimen or a sample of the product submitted. It does not imply an assessment of the conformity of the whole manufactured products of the tested sample. RR051-15-102324-7-A Ed. 0 Page 2 out of 54 DESIGNATION OF PRODUCT: DRONE EXOM Serial number (S/N): AD04 EX-99-12880 Reference / model (P/N): SENSEFLY EXOM Software version: — MANUFACTURER: SENSEFLY COMPANY SUBMITTING THE PRODUCT: Company: SENSEFLY Address: Route de Genève 38 1033 Cheseaux-Lausanne SWITZERLAND Responsible: Mr GILLE DATES OF TEST: Between 11-JUNE-2015 to 21-AUG-2015 TESTING LOCATION: EMITECH ANGERS laboratory at JUIGNE SUR LOIRE (49) FRANCE 21 rue de la Fuye 49610 Juigne sur Loire France FCC 2.948 Listed Site Registration Number: 90469 FCC Accredited under US-EU MRA Designation Number: FR0009 Test Firm Registration Number: 873677 TESTED BY: S. LOUIS and T. LEDRESSEUR RR051-15-102324-7-A Ed. 0 Page 3 out of 54 CONTENTS TITLE PAGE 1. INTRODUCTION ________________________________________________________________ 4 2. PRODUCT DESCRIPTION ________________________________________________________ 4 3. NORMATIVE REFERENCE ________________________________________________________ 5 4. TEST METHODOLOGY ___________________________________________________________ 5 5. TEST EQUIPMENT CALIBRATION DATES ____________________________________________ 6 6. TESTS AND CONCLUSIONS ______________________________________________________ 7 7. RADIATED EMISSION LIMITS ____________________________________________________ 11 8. ADDITIONAL PROVISIONS TO THE GENERAL RADIATED EMISSION LIMITATIONS ___________ 13 9. MAXIMUM PEAK OUTPUT POWER ________________________________________________ 15 10. INTENTIONAL RADIATOR ______________________________________________________ 17 APPENDIX 1: Photos of the equipment under test APPENDIX 2: Test set up APPENDIX 3: Test equipment list APPENDIX 4: 6 dB bandwidth APPENDIX 5: 20 dB bandwidth APPENDIX 6: Band edge APPENDIX 7: Channel spacing APPENDIX 8: Time of occupancy on any frequency APPENDIX 9: Number of hopping channels RR051-15-102324-7-A Ed. 0 Page 4 out of 54 1. INTRODUCTION This document presents the result of RADIO test carried out on the following equipment: DRONE EXOM in accordance with normative reference. The device under test integrates a multifrequency transceiver (FHSS 2.4GHz). The host device of certified modules shall be properly labeled to identify the modules within. 2. PRODUCT DESCRIPTION Class: B Utilization: Drone Antenna type and gain: Internal wiring antenna 1dBi Operating frequency range: from 2403 MHz to 2478 MHz Frequency tested: 2403 MHz (low channel), 2439 MHz (central channel), 2479MHz (high channel) Number of channels: 15 Channel spacing: 2 MHz Modulation: FHSS Power source: Battery LiPo, 11.1Vdc Power level, frequency range and channels characteristics are not user adjustable. The details pictures of the product and the circuit boards are joined with this file. RR051-15-102324-7-A Ed. 0 Page 5 out of 54 3. NORMATIVE REFERENCE The standards and testing methods related throughout this report are those listed below. They are applied on the whole test report even though the extensions (version, date and amendment) are not repeated. CFR 47 FCC Part 15 (2014) Radio Frequency Devices ANSI C63.4 2009 Methods of measurement of Radio-Noise Emissions from low-voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz. ANSI C63.10 2009 Testing Unlicensed Wireless Devices. 558074 D01 DTS v03r02 Guidance for Performing Compliance on Digital Transmission Systems Operating under §15.247 Public Notice DA 00-705 Filing and Measurement Guideline for Frequency Hopping Spread Spectrum Systems. 4. TEST METHODOLOGY Radio performance tests procedures given in CFR 47 part 15: Subpart A –General Paragraph 19: labelling requirements Paragraph 21: information to user Subpart B –Unintentional Radiators Paragraph 105: information to the user Paragraph 107: Conducted limits Paragraph 109: Radiated emission limits Paragraph 111: Antenna power conduction limits for receivers Subpart C – Intentional Radiators Paragraph 203: Antenna requirement Paragraph 205: Restricted bands of operation Paragraph 207: Conducted limits Paragraph 209: Radiated emission limits; general requirements Paragraph 212: Modular transmitter Paragraph 215: Additional provisions to the general radiated emission limitations Paragraph 247: Operation within the bands 902-928 MHZ, 2400-2483.5 MHz and 5725-5850 MHz RR051-15-102324-7-A Ed. 0 Page 6 out of 54 5. TEST EQUIPMENT CALIBRATION DATES Equipment Model Type Last verification Next verification Validity 0000 BAT-EMC Software / / / 1406 EMCO 6502 Loop antenna 27/01/2015 27/01/2017 27/03/2017 1922 Microwave DB C020180F- 4B1 Low-noise amplifier 20/08/2014 20/08/2015 20/10/2015 1939 IMC WR42 Antenna 20/04/2012 20/04/2016 20/06/2016 1940 IMC WR42 Antenna 20/04/2012 20/04/2016 20/06/2016 3036 ALC Microwave ALN02- 0102 Low-noise amplifier 14/05/2014 14/05/2015 14/07/2015 4087 Filtek LP03/1000-7GH Low Pass Filter 24/02/2014 24/02/2016 24/04/2016 4088 R&S FSP40 Spectrum Analyzer 22/08/2013 22/08/2015 22/10/2015 …

Text truncated - open the document above for the full version.
