2AC33S4-GSMAlarm system

www.etiger.com S4 Combo Secual / S4 Combo Vid Secual GSM and Landline Alarm System Features - GSM/PSTN transmitter - Supports up to 30 remote controls, 50 wireless accessories and 50 RFID tags - Can store up to 5 phone numbers, 5 SMS numbers, and 2 CMS numbers (for systems connected to a Central Monitoring System) - Arm / disarm the system by SMS, phone call, or App (on iOS or Android) - Can be disarmed by RFID tag - Built-in siren (100dB) and call function from the panel - SMS alerts for power failure, power recovery and low battery - Audio surveillance of the site from distance - 2 x 800mAh lithium batteries included (8h battery life in standby mode) Specifications Product name S4 Combo Secual SKU S4-C Control panel power supply Input: AC 110-240V / 50-60 Hz Output: DC 12V / 1 A GSM working frequency 850 / 900 / 1800 / 1900 mHz Radio-frequency 315MHz (±75KHz) Standby current 110ma Alarm current 340mA Backup batteries Lithium Batteries: 3.7V / 800 mAh x 2 (BL-5B) Internal siren 100dB Housing material ABS plastic Operating conditions Temperature: -10°C~55°C Humidity: ≤ 80% (non-condensing) Control panel dimensions (L x W x H) 188 x 132 x 26 mm Box Content S4 Control Panel x1 Motion Detectors x2 Door / Window Contacts x2 Remote Controls x2 RFID Tags x2 PSTN Cable x1 PSTN Adaptor x1 AC Adaptors x1 Documentation x1 S4 Combo Vid Secual + IP Camera x 1 (with AC Adaptor and manual) 2 Quick Start-up Control Panel Layout (Front) Call RFID Tag Reader Arm Disarm Stay (Home Mode) LCD Display SOS LED Status Indicator (armed / disarmed) Control Panel Layout (Back) Monitoring MIC Speaker Power Supply Interface Tamper Switch Power Switch Telephone Interface Battery Compartment SIM card Slot Power On/Off Adapter interface Electronic lock VCC Z1 GND SP GND LOCK P1 Wired siren 500mA Wired sensors (24h zone) Output for wired sensors 4 Accessories Safety and Troubleshooting Quick start-up Control Panel Operations SMS Operations Connect your System The S4 Combo Secual features a dual GSM and PSTN transmitter. This means that the control panel of your alarm system will communicate with you either through a SIM card (GSM module) or through your telephone landline (PSTN module). a. Using the PSTN transmitter (telephone landline) Connect the smaller connector of the telephone cable (supplied with your system) to the landline interface in the battery compartment at the back of the panel. Connect the other end of the telephone cable to the signal output provided by your landline carrier or to the phone connector of your ADSL box. b. Using the GSM transmitter (SIM card) Open the battery compartment at the back of the control panel and insert a SIM card in the control panel. Important Before using the S4 Combo Secual in GSM mode, you need to purchase a SIM card that works on the GSM network with 850 / 900 / 1800 / 1900 MHz frequency. We recommend you to subscribe to a plan with unlimited texts and one hour of voice. For more information, please contact your local reseller. Important Make sure the SIM card does not require any PIN code. For more information, please contact your local reseller. Turning your System On 1. Plug the AC adaptor to an AC socket. 2. Plug the output connector of the AC adaptor into the adaptor interface in the battery compartment at the back of the control panel. 3. Turn the power switch to "ON" (in the battery compartment at the back of the control panel). 5 Mount the Control Panel Before mounting the control panel on the wall, make sure the reception of the GSM signal is sufficient. Fix the wall-mounting bracket on the wall with screws. Wedge the panel on the bracket, make sure they fit well. First Operations Select GSM / PSTN Mode Refer to the instructions page 12 to deactivate the mode you do not want to use. GSM mode only (SIM card required, sold separately): set "LINECUT ALARM" to "OFF" PSTN mode only (connection to your telephone landline required): set "GSM FAIL TIP" to "OFF" By default, both GSM and PSTN are activated. Store a phone number To interact with the control panel by SMS, by phone call and/or from the app, at least one phone number must be stored in the control panel. Please refer to the instructions on page 10 of this manual. Change the language By default the language of the S4 control panel is set to English. If you wish to change the system language, refer to the instructions on page 25 of this manual. "System language" refers to the language of the SMS you receive from the control panel, and the menu of the LCD display. Arm / Disarm the System The alarm system can be armed or disarmed on the control panel, by SMS, by App and by phone call. On the control panel: Refer to the instructions on page 9 of this manual. By RFID tag (disarm only): swipe the RFID tag in front of the RFID reader of the control panel. To start receiving SMS notifications when the system is disarmed by RFID tag, you must store an SMS number and rename the RFID tags as explained respectively on page 21 and page 22 of this manual (up to 4 RFID tags can be renamed). If you have stored several SMS numbers, only the first number stored will receive SMS notifications when your system is disarmed by RFID tag. By SMS (in GSM mode only): To arm the system: send “1” by SMS to the number of the SIM card in the control panel. To disarm the system: send “0” by SMS to the number of your system’s SIM card. By app (in GSM mode only): Click on “Arm” in the app. The app is available for download on the App Store and Google Play (more information on etiger.com). 6 Accessories Safety and Troubleshooting Quick start-up Control Panel Operations SMS Operations Register Wireless Accessories & RFID Tags 1. Type your admin code followed by “Enter” on the control panel to enter the setup menu. 2. Enter the Connection Mode by navigating through the menu: "ACCESSORIES" --> "WIRELESS SENSORS" , "RFID TAG" or "REMOTE" --> "ADD A NEW" When registering a detector, you will be asked to select the type of detector (Normal Sensor, Ho…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (current) 3.0 4.0 May-23-2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 4.0 _ Shanghai Etiger Digital Technology Co., Ltd._ 2014/9/14 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, ________ Shanghai Etiger Digital Technology Co., Ltd.__ __hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product： Alarm system Trade Name： eTIGER Model Name： S4-GSM Serial Model： MG1-PSTN/GSM,S4-PSTN/GSM,S4V-GSM, S4-C,S4-CV,S4-CL,S4-CL-P FCC ID： 2AC33S4-GSM Sincerely, Signature Name: Josie Qin Title: Manager Address: Room 2010, Juyuan building, No.1000 Qiujiang Road, Shanghai, China

SCS-F19: Confidentiality Request Letter Page 1 of 3 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 3 Rev 3.0 Shanghai Etiger Digital Technology Co., Ltd. 2014/9/14 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AC33S4-GSM We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description - BOM - - Tune up procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Signature Name: Josie Qin Title: Manager Address: Room 2010, Juyuan building, No.1000 Qiujiang Road, Shanghai, China SCS-F19: Confidentiality Request Letter Page 3 of 3 Rev 3.0

Shanghai Etiger Digital Technology Co., Ltd. Model Difference FCC ID: 2AC33S4-GSM Model : S4-GSM, MG1-PSTN/GSM,S4-PSTN/GSM,S4V-GSM, S4-C,S4-CV,S4-CL,S4-CL-P All the models are the same circuit and RF module, except the mode names. Regards, Client’s signature Signature Na me: Josie Qin Title: Manager Address: Room 2010, Juyuan building, No.1000 Qiujiang Road, Shanghai, China

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7

FCC ID LABELING AND LOCATION FCC ID Label Alarm system Model NO.: S4-GSM eTIGER Input Rating: DC 12V/ 500mA FCC ID: 2AC33S4-GSM Shanghai Etiger Digital Technology Co., Ltd. Made in China This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 GSM ANT Photo 5 Photo 6 Photo 7 Photo 8 315MHz ANT Photo 9 Photo 10

FCC RADIO TEST REPORT FCC ID:2AC33S4-GSM Product： Alarm system Trade Name： eTIGER Model Name： S4-GSM Serial Model： MG1-PSTN/GSM,S4-PSTN/GSM,S4V-GSM, S4-C,S4-CV,S4-CL,S4-CL-P Report No.： NTEK-2014NT08121324F1 Prepared for Shanghai Etiger Digital Technology Co., Ltd. Room 2010, Juyuan building, No.1000 Qiujiang Road, Shanghai, China Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community,Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 28 Report No.: NTEK-2014NT08121324F1 ` TEST RESULT CERTIFICATION Applicant’s name................. : Shanghai Etiger Digital Technology Co., Ltd. Address ................................. : Room 2010, Juyuan building, No.1000 Qiujiang Road, Shanghai, China Manufacture's Name............ : Shanghai Etiger Digital Technology Co., Ltd. Address ................................. : Room 2010, Juyuan building, No.1000 Qiujiang Road, Shanghai, China Product description Product name ........................... : Alarm system Model and/or type reference : S4-GSM Serial Model： MG1-PSTN/GSM,S4-PSTN/GSM,S4V-GSM, S4-C,S4-CV,S4-CL,S4-CL-P Standards............................. : FCC Part15.231:01 Oct. 2013 Test procedure .............................. ANSI C63.4-2003 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test............................................: Date (s) of performance of tests .............: 07 Aug. 2014 ~28 Aug. 2014 Date of Issue...........................................: 28 Aug. 2014 Test Result...............................................: Pass Testing Engineer : (Kyle Xu) Technical Manager : (Brown Lu) Authorized Signatory : (Bill Yao) Page 3 of 28 Report No.: NTEK-2014NT08121324F1 ` Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 TEST FACILITY 5 1.2 MEASUREMENT UNCERTAINTY 5 2 . GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 DESCRIPTION OF TEST MODES 7 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 8 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 9 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 10 3 . ANTENNA REQUIREMENT 11 3.1 STANDARD REQUIREMENT 11 3.2 EUT ANTENNA 11 4 . EMC EMISSION TEST 12 4.1 CONDUCTED EMISSION MEASUREMENT 12 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 12 4.1.2 TEST PROCEDURE 13 4.1.3 DEVIATION FROM TEST STANDARD 13 4.1.4 TEST SETUP 13 4.2 RADIATED EMISSION MEASUREMENT 16 4.2.1 RADIATED EMISSION LIMITS 16 4.2.2 TEST PROCEDURE 17 4.2.3 DEVIATION FROM TEST STANDARD 17 4.2.4 TEST SETUP 18 4.2.5 TEST RESULTS (BELOW 30MHZ) 20 4.2.6 TEST RESULTS (BETWEEN 30 – 4000 MHZ) 21 4.2.7 DUTY CYCLE 22 5 . BANDWIDTH TEST 24 5.1 TEST PROCEDURE 24 5.2 DEVIATION FROM STANDARD 24 5.3 TEST SETUP 24 5.4 TEST RESULTS 25 6 . TRANSMITTER TIMEOUT 26 6.1 REQUIREMENTS 26 7 . EUT TEST PHOTO 27 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 4 of 28 Report No.: NTEK-2014NT08121324F1 ` 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15, Subpart C (15.231) Standard Section Test Item Judgment Remark 15.207 Conducted Emission Pass 15.203 Antenna Requirement Pass 15.231 Radiated Spurious Emission Pass 15.231 Occupied Bandwidth Pass 15.231 Transmitter Timeout Pass Page 5 of 28 Report No.: NTEK-2014NT08121324F1 ` 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 6 of 28 Report No.: NTEK-2014NT08121324F1 ` 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Alarm system Trade Name eTIGER Model Name S4-GSM Serial Model MG1-PSTN/GSM,S4-PSTN/GSM,S4V-GSM, S4-C,S4-CV,S4-CL,S4-CL-P Model Difference All the models are the same circuit and RF module, except the model names. Product Description The EUT is a Alarm system Operation Frequency: 315MHz Modulation Type: ASK Number Of Channel 1CH. Antenna Designation: Helical Antenna Antenna Gain(Peak) 0.5 dBi Output Power: 76.98 dBuV/m Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specification, please refer to the User's Manual. Channel List N/A Adapter Model：W&T-AD06D120050E INPUT:AC 100-240V~,50/60Hz Out put：DC12V , 0.5A Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. 2. Table for Filed Antenna Ant . Brand Model Name Antenna Type Connector Gain (dBi) NOTE 1 N/A N/A Helical AntennaN/A 0.5 Antenna Page 7 of 28 Report No.: NTEK-2014NT08121324F1 ` 2.2 DESCRIPTION OF TEST MODES To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mode or test configuration mode which possible have effect on EMI emission level. Each of these EUT operation mode(s) or test configuration mode(s) mentioned above was evaluated respectively. Pretest Mode Description Mode 1 TX Mo…

Text truncated - open the document above for the full version.

Page 27 of 28 Report No.: NTEK-2014NT08121324F1 ` 7. EUT TEST PHOTO Radiated Measurement Photos Page 28 of 28 Report No.: NTEK-2014NT08121324F1 ` Conducted Measurement Photos
