WT1/WT2 Electronic Thermometer User’s Manual Guangdong Biolight Meditech Co., Ltd. 1 Product Information
Product Model: WT1/WT2
Product Name: Electronic Thermometer
Manufacturer Name: Guangdong Biolight Meditech Co.,Ltd.
After Service Contact Information: Address: No.2 Innovation First Road, Technical Innovation Coast, Hi-tech Zone, Zhuhai, P.R. China Fax: +86-756-3399919 Post code: 519085 Toll-free consultation hot line: +86-400-8818-233 Revision History This manual has a revision number. This revision number changes whenever the manual is updated due to software or technical specification change. Contents of this manual are subject to change without prior notice.
Document No.:
Revision number: V1.0
Release time: July, 2014 Copyright © 2014 Guangdong Biolight Meditech Co., Ltd. All rights reserved. Statement Manufacturer holds the copyright of this manual, and we are also entitled to deal with this manual as confidential files. This manual is only used for operation, maintenance and service of product, someone else can not publish the manual. This manual contains exclusive information protected by copyright laws and we reserve its copyright. Without written approval of manufacturer no parts of this manual shall be photocopied, Xeroxed or translated into other languages. The contents contained in this manual are subject to amendments without notification. 2 Manufacturer's Responsibility Only under the following circumstances will manufacturer be responsible for the safety, reliability and performance of the instrument:
All the installation, expansion, readjustment, renovation or repairs are conducted by the personnel certified by manufacturer.
The storage condition, operation condition and electrical status of the instrument conform to the product specification.
The instrument is used in accordance with the user’s manual. About this manual This manual contains the instructions necessary to operate the product safely and in accordance with its function and intended use. Observance of this manual is a prerequisite for proper product performance and correct operation. This manual is based on the maximum configuration and therefore some contents may not apply to your product. If you have any question, please contact us. This manual is an integral part of the product. It should always be kept close to the equipment so that it can be obtained conveniently when needed. Illustrations are for reference only. They may be not in conformity with your products. Signs in this manual： ：： ： Warning: Indicates a potential hazard or unsafe practice that, if not avoided, will result in death or serious injury. Caution: Indicates a potential hazard or unsafe practice that, if not avoided, could result in minor personal injury or product/property damage. Note: Provides application tips or other useful information to ensure that you get the most from your product.       I Contents 1. Intended Use ............................................................................................................................. 1 2. Application ................................................................................................................................ 1 3. Safety Information .................................................................................................................... 1 4. Appearance ............................................................................................................................... 3 5. Download And Install The Software ......................................................................................... 4 6. Battery Installation Steps .......................................................................................................... 4 7. Using Steps ............................................................................................................................... 5 8. Normal Body Temperature ........................................................................................................ 8 9. Maintenance and Cleaning ........................................................................................................ 9 10. Accessory and Specifications ................................................................................................ 9 11. Troubleshooting .................................................................................................................. 11 12. Equipment Symbols ............................................................................................................ 12 Appendix A Guidance and Manufacturer’s Declaration of EMC ................................................... 13 1 1. Intended Use The device is intended to be used for measuring and monitoring human temperature continuously via wireless signal transmission of the measuring result. 2. Application The device is reusable and intended for measuring human temperature for persons over two years old. It can be used in hospital and at home. 3. Safety Information Warning： ：： ：  Any form of modification to this device is forbidden;  Don’t used the device together with MRI or CT equipment;  Explosion danger: don’t use the device in flammable anesthetic gas;  Don’t squeeze the device. If the housing is broken, please stop using the device. Caution： ：： ：  Please check device regularly to make sure that it contacts skin tightly; otherwise the data may be inaccurate.  The device is for indoor use only;  Please pay attention to the operation temperature and humidity. Using the device in a condition that does not satisfy the requirement may lead measurement error;  The effective wireless transmission distance is 15m in a barrier-free environment. If more than this distance, the product might not work. Please use this product within effective wireless transmission distance;  Muscle and fat affect wireless transmission, so the transmission range would be weaken when adult or obese chil…
