2AC9I-C1-PNL1Wireless Security and Smart Home Panel

ClareOne Wireless Security and Smart Home Panel Quick Start Guide Model CLR-C1-PNL1 1 1 Press the backplate gently back in place. Panel mounting Remove the backplate, exposing the battery. Attach the power supply. Verify that the battery is plugged in. Desk Wall Connect the panel stand, and then slide to the desired position. Remove the backplate, exposing the battery. Attach the power supply to the panel. Place the mounting bracket against the wall, and then use the in- cluded screws to attach the mount to the wall. Press the panel onto the mounting bracket, and then slide the panel downward. 2 Power Connect power supply with brack- et to the wall. Do not connect to a receptacle controlled by a switch. 3 Wizard Follow the displayed onscreen wizard. 4 Optional - Install Assist Use the Clare Controls Install Assist app to add smart home devices. 5 Enjoy! Rest secure with ClareOne and enjoy the benefits of a safe, smart, and happy home with Clare Contols. Tech Support- Clare Controls, LLC. General: 941.328.3991 Fax: 941.870.9646 www.clarecontrols.com Integrator/Dealer Support: 941.404.1072 [email protected] Note: For additionanl power options, refer to the full manual DOC 1871. Desk Mounting Notes • The panel must be mounted at least 1ft from a table edge, a heat or water source, and any sources of interference. • Peel the clear film from the anti-skid rubber on the bottom of the panel mount. If this film is not removed, the panel may slide on a tabletop. To view the full manual DOC 1871, scan the QR code or access the link below. http://bit.ly/35RJzMd Before starting installation see standards on residential installation, refer to Installation of Residential Fire Warning Systems, CAN/ULC-S540. The system must be installed in accordance with Chapter 29 of the National Fire Alarm and Signaling Code, ANSI/NFPA 72. Homeowners should contact their dealer for assistance. ClareOne Wireless Security and Smart Home Panel Quick Start Guide Model CLR-C1-PNL1 2 Regulatory ETL listed to UL 1023, UL 985, UL 1610, ULC C1023, ULC S545, ULC S304 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment should be installed in accordance with Chapter 29 of the National Fire Alarm and Signaling Code, ANSI/NFPA 72, (National Fire Protection Association, Batterymarch Park, Quincy, MA 02269). This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. Warning: changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. Wiring Diagram (1) Power supply to connect to a non-switch controlled outlet. (2) (Optional) Ethernet cable to connect to router. (3) (Optional) Wires to connect an external siren. Use recognized energy limited cable for connection. Battery notes: • For battery replacement order CLR-C1-BATT • Maximum Battery Voltage: 4.35V DC • Maximum Battery Capacity: 5200mAh • Maximum Charging Current: 2600mA • Standard Charging Current: 1040mA • Battery Duration: 24 hours + 4 minutes of continued alarm after the 24 hour period Typical Installation Layout Note: The maximum distance over which a sensor and the panel can communicate may be reduced when the equipment is installed in a typical home. Placement of the sensor, building materials and construction, loca- tion of mirrors and other RF interfering/blocking devices can all reduce the overall range. DOC ID 1885 Rev 01.01

ClareOne Wireless Security and Smart Home Panel User Manual Model CLR-C1-PNL1 Last modified: 03/02/20 DOC ID - 1871 • Rev 02.01 Copyright © 05MAR20 Clare Controls, LLC. All rights reserved. This document may not be copied in whole or in part or otherwise reproduced without prior written consent from Clare Controls, LLC., except where specifically permitted under US and international copyright law. Trademarks and patents The ClareOne name and logo are trademarks of Clare Controls, LLC. Other trade names used in this document may be trademarks or registered trademarks of the manufacturers or vendors of the respective products. Manufacturer Clare Controls, LLC. 7519 Pennsylvania Ave., Suite 104, Sarasota, FL 34243, USA FCC compliance FCC ID: 2AC9I-C1-PNL1 Contains FCC IDs: XMR201609EC21V and 2AATL-8223A-SR This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. Warning: changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This transmitter must no be co- located or operating in conjunction with any other antenna or transmitter. This equipment should be installed and operated with minimum distance 20 cm between the radiator and your body. EU compliance EU directives 1999/5/EC (R&TTE directive): Hereby, Clare Controls, Llc. declares that this device is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. 2004/108/EC (EMC directive): Hereby, Clare Controls, Llc. Declares that this device is in compliance with the essential requirements and other relevant provisions of Directive 2004/108/EC. 2006/95/EC (Low Voltage directive): Hereby, Clare Controls, Llc. Declares that this device is in compliance with the essential requirements and other relevant provisions of Directive 2006/95/EC. 2002/96/EC (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points. For more information see: www.recyclethis.info. 2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted municipal waste in the European Union. See the product documentation for specific battery information. The battery is marked with this symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your supplier or to a designated collection point. For more information see: www.recyclethis.info. Contact information For contact information, see www.clarecontrols.com. ClareOne i Content Important information...iii Limitation of liability...iii Introduction...1 Package contents...1 Specifications...2 Installing the panel...4 ClareOne setup wizard...15 ClareOne Panel menus...18 ClareOne menu bar...18 ClareOne status bar...19 ClareOne quick settings menu...20 Security...22 Security user management...22 Operating security...22 Favorites...28 Activity...31 Settings...32 Display...32 User Settings...33 Installer Settings...34 About...34 User and Installer Settings...35 User Management...36 WiFi...42 Time Zone...43 Security & Arming...44 Sensor Management...46 Restart...52 System Test...52 Check for Updates...56 Panel Reset...58 Demo Mode...59 ii ClareOne Emergency...61 Basic operation...65 Panel states...65 Panel LED...65 Maintenance...66 Contact...67 Evacuation plan...68 Glossary...71 Appendices...72 Quick reference...73 Trouble conditions...76 Panel zone list tracking...77 Sensor installations and specifications...79 ClareOne iii Important information Limitation of liability To the maximum extent permitted by applicable law, in no event will Clare Controls, LLC. be liable for any lost profits or business opportunities, loss of use, business interruption, loss of data, or any other indirect, special, incidental, or consequential damages under any theory of liability, whether based in contract, tort, negligence, product liability, or otherwise. Because some jurisdictions do not allow the exclusion or limitation of liability for consequential or incidental damages the preceding limitation may not apply to you. In any event the total liability of Clare Controls, LLC. shall not exceed the purchase price of the product. The foregoing limitation will apply to the maximum extent permitted by applicable law, regardless of whether Clare Controls, LLC. has been advised of the possibility of such damages and reg…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 6 External Photos for SZEM1911020336CR FCC ID: 2AC9I-C1-PNL1 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 6 1 EUT Constructional Details SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 6 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 4 of 6 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 5 of 6 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 6 of 6

���.� �� ��.� �-R=� Clare Controls Model: CLR-C�-PNL� Residential Burglar and Fire Alarm System Battery Manufacturer: Guangdong Pow-Tech New Power Co., Ltd Battery Model: PT������-PCM���� ETL Listed to UL ����, UL ���, UL ����, ULC C����, ULC S���, & ULC S��� INSTALLATION ONLY BY A TRAINED INSTALLER For Installation information including Mounting and Wiring Diagrams refer to DOC-���� and DOC-����. This equipment should be installed in accordance with Chapter �� of the National Fire Alarm and Signaling Code, ANSI/NFPA ��, (National Fire Protection Association, Batterymarch Park, Quincy, MA �����). Test the system at least once per week. This system is to be checked by a qualified technician at least every � years. This device complies with part �� of the FCC Rules. Operation is subject to the following two conditions: (�) This device may not cause harmful interference, and (�) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: �AC�I-C�-PNL� Contains FCC IDs: XMR������EC��V & �AATL-����A-SR Label Location

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 11 Internal Photos for SZEM1911020336CR FCC ID: 2AC9I-C1-PNL1 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 11 1 EUT Constructional Details LTE Antenna 1 LTE Antenna 2 Wifi Antenna Z Wave Antenna 433MHz Antenna SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 11 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 4 of 11 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 5 of 11 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 6 of 11 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 7 of 11 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 8 of 11 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 9 of 11 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 10 of 11 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 11 of 11

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM191102033603 Page: 1 of 30 Keny Xu EMC Laboratory Manager TEST REPORT Application No.: SZEM1911020336CR Applicant: Clare Controls Address of Applicant: 7519 Pennsylvania Av Suite 104, Sarasota, Florida, 34243, United States Manufacturer: Clare Controls Address of Manufacturer: 7519 Pennsylvania Av Suite 104, Sarasota, Florida, 34243, United States Factory: SYBER SENSE IOT COMPANY LIMITED Address of Factory: 3/F, Building A, Hanhaida High-tech Park, Datian Yang C District, Shiwei Community, Matian Street, Guangming New District, Shenzhen, China. Equipment Under Test (EUT): EUT Name: Wireless Security and Smart Home Panel Model No.: CLR-C1-PNL1 Trade mark: ClareOne FCC ID: 2AC9I-C1-PNL1 Standard(s) : 47 CFR Part 15, Subpart C 15.249 Date of Receipt: 2019-11-19 Date of Test: 2019-11-19 to 2019-11-26 Date of Issue: 2019-11-27 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM191102033603 Page: 2 of 30 Revision Record Version Chapter Date Modifier Remark 01 2019-11-27 Original Authorized for issue by: Harry Wu /Project Engineer Eric Fu /Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM191102033603 Page: 3 of 30 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.249 N/A 47 CFR Part 15, Subpart C 15.203 Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.249 ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass 20dB Bandwidth 47 CFR Part 15, Subpart C 15.249 ANSI C63.10 (2013) Section 6.9 47 CFR Part 15, Subpart C 15.215 Pass Field Strength of the Fundamental Signal (15.249(a)) 47 CFR Part 15, Subpart C 15.249 ANSI C63.10 (2013) Section 6.5&6.6 47 CFR Part 15, Subpart C 15.249(a) Pass Restricted Band Around Fundamental Frequency 47 CFR Part 15, Subpart C 15.249 ANSI C63.10 (2013) Section 6.4&6.5&6.6 47 CFR Part 15, Subpart C 15.205 & 15.249(d) & 15.209 Pass Radiated Emissions 47 CFR Part 15, Subpart C 15.249 ANSI C63.10 (2013) Section 6.4&6.5&6.6 47 CFR Part 15, Subpart C 15.209 & 15.249 (a),(d) Pass SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM191102033603 Page: 4 of 30 3 Contents Page 1 COVER PAGE ............................................................................................................................................ 1 2 TEST SUMMARY ....................................................................................................................................... 3 3 CONTENTS ................................................................................................................................................ 4 4 GENERAL INFORMATION ........................................................................................................................ 5 4.1 DETAILS OF E.U.T. ............................................................................................................................... 5 4.2 DESCRIPTION OF SUPPORT UNITS ......................................................................................................... 5 4.3 MEASUREMENT UNCERTAINTY .............................................................................................................. 5 4.4 TEST LOCATION .................................................................................................................................... 6 4.5 TEST FACILITY ...................................................................................................................................... 6 4.6 DEVIATION FROM STANDARDS ............................................................................................................... 6 4.7 ABNORMALITIES FROM STANDARD CONDITIONS ..................................................................................... 6 5 EQUIPMENT LIST ...................................................................................................................................... 7 6 RADIO SPECTRUM TECHNICAL REQUIREMENT ............................................................................... 10 6.1 ANTENNA REQUIREMENT .................................................................................................................... 10 6.1.1 Test Requirement: ....................................................................................................................... 10 6.1.2 Conclusion ................................................................................................................................... 10 7 RADIO SPECTRUM MATTER TEST RESULTS ..................................................................................... 11 7.1 CONDUCTED EMISSIONS AT AC POWER LINE (150KHZ-30MHZ) ........................................................... 11 7.1.1 E.U.T. Operation .......................................................................................................................... 11 7.1.2 Measurement Procedure and Data............................................................................................. 11 7.2 20DB BANDWIDTH .............................................................................................................................. 14 7.2.1 E.U.T. Operation .......................................................................................................................... 14 7.2.2 Test Setup Diagram ..................................................................................................................... 14 7.2.3 Measurement Procedure and Data............................................................................................. 14 7.3 FIELD STRENGTH OF THE FUNDAMENTAL SI…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 3 Setup Photos for SZEM1911020336CR FCC ID: 2AC9I-C1-PNL1 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 3 1 Photographs 1.1 Conducted Emissions at AC Power Line (150kHz-30MHz) Test Setup 1.2 Radiated Emissions Test Setup SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 3
