BSM Wireless SFM7000 SFM7000 Backend WORK INSTRUCTION Revision: AA 09/16/14 Page 1 Of 12 1.0 Authorization 2.0 Procedure Revision History Revision Date Detail of Change Changed by AA Sept 16 2014 Initial Release Isaac Kuruvilla FCC ID : 2AC9T-DORIN16MB This device complies with Part 15 of the FCC Rules -exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. This product contains a radio transmitter with 802.11b/g/n technology which has been tested and found to be compliant with the applicable regulations governing a radio transmitter in the 2.400 GHz to 2.4835 GHz frequency range. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. Engineering Engineering Manager Manufacturing Manager Quality Manager 75 International Blvd., Suite 100, Toronto, ON M9W 6L9 Tel (416) 675-1201|Toll (866) 768-4771|Fax (416) 679-8992 www.bsmwireless.com BSM Wireless SFM7000 SFM7000 Backend WORK INSTRUCTION Revision: AA 09/16/14 Page 2 Of 12 The Dorin ASYDORINWLAN RF Module complies with Part 15 of the FCC rules and regulations. Compliance with the labeling requirements, FCC notices and antenna usage guidelines is required. To fulfill FCC Certification, We must comply with the following regulations: 1.The system integrator must ensure that the text on the external label provided with this device is placed on the outside of the final product 2.Dorin ASYDORINWLAN RF Module may only be used with antennas that have been tested and approved for use with this module [refer to the antenna specification]. Modifications not expressly approved by BSM Wireless could void the user's authority to operate the equipment. IMPORTANT: We must test final product to comply with unintentional radiators (FCC section 15.107 & 15.109) before declaring compliance of their final product to Part 15 of the FCC Rules. IMPORTANT: The RF Module has been certified for remote and base radio application only. RF Exposure WARNING: To satisfy FCC RF exposure requirements for mobile transmitting devices, a separation distance of 20 cm or more should be maintained between the antenna of this device and persons during device operation. to ensure compliance, operations at closer than this distance are not recommended. the antenna used for this transmitter must not be co -located in conjunction with any other antenna or transmitter. BSM Wireless SFM7000 SFM7000 Backend WORK INSTRUCTION Revision: AA 09/16/14 Page 3 Of 12 THIS DOCUMENT IS PROVIDED “AS IS” WITH NO WARRANTIES WHATSOEVER, INCLUDING ANY WARRANTY OF MERCHANTABILITY, NON-INFRINGEMENT, FITNESS FOR ANY PARTICULAR PURPOSE, OR ANY WARRANTY OTHERWISE ARISING OUT OF ANY PROPOSAL, SPECIFICATION OR SAMPLE. BSM WIRELESS DISCLAIMS ALL LIABILITY, INCLUDING LIABILITY FOR INFRINGEMENT OF ANY PROPRIETARY RIGHTS, RELATING TO USE OF INFORMATION IN THIS DOCUMENT. NO LICENSE, EXPRESSED OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED HEREIN. *THIRD-PARTY BRANDS, NAMES, AND TRADEMARKS ARE THE PROPERTY OF THEIR RESPECTIVE OWNERS. BSM Wireless SFM7000 SFM7000 Backend WORK INSTRUCTION Revision: AA 09/16/14 Page 4 Of 12 3.0 PURPOSE 3.1 This document provides specific instructions on the assembly for the SFM7000. 4.0 SCOPE 4.1 Shall cover the Dorin module assembly on to the SFM7000 board. FCC ID 2AC9T-DORIN16MB 5.0 RECORDS 5.1 Addition(s) to this work instruction must be approved by authorization in section one. 6.0 ASSOCIATED DOCUMENTS 6.1 N/A at this time. 7.0 DEFINITIONS 7.1 N/A: Not Applicable. 7.2 TBD: To Be Determined. 8.0 RESPONSIBILITY Name Responsibilities Management Shall ensure operator(s) read and understand procedure(s) and to ensure operator(s) are following set procedure(s). Supervisor Ensure work instructions are followed Process Engineering Shall maintain set procedure(s). Any change(s) to set procedures shall be communicated to appropriate team member(s) by process engineering Operator Shall adhere to this procedure(s) Maintenance Shall understand set procedure(s) 9.0 SAFETY REQUIREMENTS 9.1 Only trained personnel to perform this operation. BSM Wireless SFM7000 SFM7000 Backend WORK INSTRUCTION Revision: AA 09/16/14 Page 5 Of 12 10.0 INSTRUCTIONS No. Trailer Detector Board A Pick the following parts for assembly: 1. PCBA SFM7000 (qty 1pc) 2. PCIe Wifi PCBA Dorin Module ASYDORINWLAN (qty 1pc) 3. Sliver screws (qty 2 pcs) 4. Smaller sliver screws (qty 2pcs) 5. Battery (qty 1pc) 6. UFL Cable (qty 1pc) 7. Antenna Cable (qty 1pc) 8. Washer (1pc) 9. Black screws (qty 8pcs) 10. Aluminum Chassis (qty 1pc) 11. Front cover plate (qty 1pc) 12. Back cover plate (qty 1pc) 13. Wifi Antenna (1pc) 1. 2. BSM Wireless SFM7000 SFM7000 Backend WORK INSTRUCTION Revision: AA 09/16/14 Page 6 Of 12 3. 4. 5. 6. 7. 8. 9.10. BSM Wireless SFM7000 SFM7000 Backend WORK INSTRUCTION Revision: AA …

Text truncated - open the document above for the full version.

– 1 – Revised 12/4/13 Product Description The RAH Series utilizes a helical element to greatly reduce the physical length of the antenna housing. They are ideal for products requiring an ultra-compact, aesthetically pleasing antenna in a right angle form factor. Despite their tiny size, they are ruggedly constructed and able to withstand punishing environments just like our larger whips. The antennas attach via a Part 15 compliant RP-SMA connector. The 2.45GHz version is also available with a standard SMA connector. Features • Low cost • Ultra-compact • Right angle mount • Excellent performance • Omnidirectional pattern • Fully weatherized • Flexible main shaft • Rugged & damage-resistant • Part 15 compliant RP-SMA connector • Use with plastic* or metal enclosures * Requires proximity ground plane Electrical Specifications Center Frequency: 2.45GHz Recom. Freq. Range: 2.35-2.60GHz Wavelength: ¼-wave VSWR: ≤ 2.0 typical at center Peak Gain: 1.6dBi Impedance: 50-ohms Connector: RP-SMA Oper. Temp. Range: –40° to +90°C Electrical specifications and plots measured on 10.16 cm x 10.16 cm (4.00” x 4.00”) reference ground plane ANT-2.4-CW-RAH Data Sheet by Ordering Information ANT-2.4-CW-RAH-RPS (with RP-SMA connector) ANT-2.4-CW-RAH-SMA (with SMA connector) 7.4 mm (0.29") H8.0 mm (0.32") 18.6 mm (0.73") 7.0 mm (0.28") 17.1 mm (0.67") – 2 – by VSWR Graph What is VSWR? The Voltage Standing Wave Ratio (VSWR) is a measurement of how well an antenna is matched to a source impedance, typically 50-ohms. It is calculated by measuring the voltage wave that is headed toward the load versus the voltage wave that is reflected back from the load. A perfect match will have a VSWR of 1:1. The higher the first number, the worse the match, and the more inefficient the system. Since a perfect match cannot ever be obtained, some benchmark for performance needs to be set. In the case of antenna VSWR, this is usually 2:1. At this point, 88.9% of the energy sent to the antenna by the transmitter is radiated into free space and 11.1% is either reflected back into the source or lost as heat on the structure of the antenna. In the other direction, 88.9% of the energy recovered by the antenna is transferred into the receiver. As a side note, since the “:1” is always implied, many data sheets will remove it and just display the first number. How to Read a VSWR Graph VSWR is usually displayed graphically versus frequency. The lowest point on the graph is the antenna’s operational center frequency. In most cases, this will be different than the designed center frequency due to fabrication tolerances. The VSWR at that point denotes how close to 50-ohms the antenna gets. Linx specifies the recommended bandwidth as the range where the typical antenna VSWR is less than 2:1. Counterpoise Quarter-wave or monopole antennas require an associated ground plane counterpoise for proper operation. The size and location of the ground plane relative to the antenna will affect the overall performance of the antenna in the final design. When used in conjunction with a ground plane smaller than that used to tune the antenna, the center frequency typically will shift higher in frequency and the bandwidth will decrease. The proximity of other circuit elements and packaging near the antenna will also affect the final performance. For further discussion and guidance on the importance of the ground plane counterpoise, please refer to Linx Application Note AN-00501: Understanding Antenna Specifications and Operation. Data Sheet ANT-2.4-CW-RAH VSWRReflected Power 3:1 2:1 1:1 25% 11% 0% 2450MHz2550MHz2350MHz 1.357

Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 1 th day of October 2014 SUBJECT: FCC Application for 2AC9T-DORIN16MB To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Verification Authorization procedure to the Part 15B - Unintentional Radiator portion of this composite filing. Regards, Isaac Kuruvilla 75 International Blvd., Suite 100, Toronto, ON M9W 6L9 Tel (416) 675-1201|Toll (866) 768-4771|Fax (416) 679-8992 www.bsmwireless.com

Ult G FCC Ultrate Accred NVLAP L SL Ko TP 3 O C Tel Fa x Website: Email: traTech roup of Labs C TCB & IC CB ech’s ditations: 0685 91038 1309 46390-2049 LAB CODE 20009 L2-IN-E-1119R orea KCC-RRA CA2049 TL363_B PTDP DA1300 000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 .: (905) 829-1570 x.: (905) 829-8050 www.ultratech-labs. c [email protected] h 93-0 com om Se p Ult 30 0 Oa L6 H Su De a As App ele Thi ap p Sec If y Yo u Dh Dha Aut ptember 29, 2 ratech Engi n 00 Bristol Circ kville, Ontario H 6G4 bject: ar Sir/Madam appointed ag proval (LMA) ctronic filing s s application plicant’s letter ction 15.212 r ou have any urs truly, harmajit Solanki armajit Solan thorized Agen 2014 neering Labs cle o Application FCC Part 1 5 (DTS) Opera Applicant: Product: Model No.: FCC ID: m: gent for BSM certification o site. is subject to r requesting fo rules. queries, plea ki nt s, Inc. for Limited M 5, Subpart C, ating in 2400 BSM Wir DORIN M ASYDOR 2AC9T-D Wireless Inc of the above p FCC certifica or LMA accor se do not hes Modular App Section 15.2 0 - 2483.5 MH reless Inc. Module RINWLAN DORIN16MB c, we submit t product. Kind ation for Limite rding to the m sitate to conta proval Certifi 247 - Digital Hz Band. the applicatio ly review all f ed Modular ap modular appro act us. ication (LMA Modulation S n for Limited files uploaded pproval, kindl oval requireme A) under Systems Modular d to your ly refer to ents in

Date: 1 th day of October 2014 To Whom It May Concern Subject: Authority to Act as an Agent Applicant: BSM Wireless Inc. FCC ID: 2AC9T-DORIN16MB Dear Sir/Madam, I hereby appoint UltraTech Engineering Labs Inc. (UltraTech) to act as my agent in preparation of this application for authorization of above equipment under F.C.C. Rules. The applicant hereby certify that neither the applicant nor any party to the application is subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a “party” for these purposes. I also certify that the information provided, properly describe the device or system for which authorization is required. Regards Isaac Kuruvilla 75 International Blvd., Suite 100, Toronto, ON M9W 6L9 Tel (416) 675-1201|Toll (866) 768-4771|Fax (416) 679-8992 www.bsmwireless.com

Date: 1 th day of October 2014 To Whom It May Concern Subject: Confidentiality Letter Applicant: BSM Wireless FCC ID: 2AC9T-DORIN16MB Dear Sir/Madam: The applicant would like to request the following documents submitted with this application for certification be withheld from public disclosure as per Section 0.457 & 0.459 of FCC Rules. 1. Operational Description 2. Block Diagram 3. Schematics 4. Parts List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Regards Isaac Kuruvilla 75 International Blvd., Suite 100, Toronto, ON M9W 6L9 Tel (416) 675-1201|Toll (866) 768-4771|Fax (416) 679-8992 www.bsmwireless.com

Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 1st October, 2014 Subject: Request for Limited Modular Approval for FCC ID: 2AC9T-DORIN16MB To Whom It May Concern: (1) Have its own RF shielding: This module transmitter does not have its own RF shielding. Instead, it gets installed within BSM wireless controlled end-product SFM7000W, which pr ovides the required RF shielding. (2) The module transmitter must have buffered modulation/data inputs: The data input to this module transmitter has buffered modulation/data inputs so as not to allow generating excessive data speed and abnormal modulation. (3) The module transmitter must have its own power supply regulation: BSM Wireless controlled end-product SFM7000W utilizes 12VDC, its internal power supply regulator automatically adjusts and provides 3.3VDC operating power to the m odule transmitter. (4) The module transmitter must comply with the antenna requirements of Section 15.203 and 15.204(c): Please refer to Antenna Data sheet, the equipment complies with the antenna requirement of section 15.203 and 15.204(c) (5) Tested in a stand-alone configuration: The module transmitter was tested in stand-alone test mode. (6) The module transmitter must be labeled with its own FCC ID, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module: The module transmitter itself contains FCC ID label; and as it will always be installed within BSM Wireless controlled end-product SFM7000W, the SFM7000W outer enclosure will have label which states: Contains FCC ID: 2AC9T-DORIN16MB 75 International Blvd., Suite 100, Toronto, ON M9W 6L9 Tel (416) 675-1201|Toll (866) 768-4771|Fax (416) 679-8992 www.bsmwireless.com (7) The module transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any s uch requirements: The installation of the Module Transmitter will be pe rformed at our authorized end-product SFM7000 manufacturing facilities and all necessary items of compliance ar e provided. (8) The module transmitter must comply with any applicable RF exposure requirements: The m odule transmitter complies with FCC radiation exposure requirement for mobile and fixed operation. Thank you for your consideration Sincerely Isaac Kuruvilla QA Engineer 75 International Blvd., Suite 100, Toronto, ON M9W 6L9 Tel (416) 675-1201|Toll (866) 768-4771|Fax (416) 679-8992 www.bsmwireless.com

Internal Photos LABEL INFORMATION FOR MODEL : ASYDORINWLAN FCC ID : 2AC9T-DORIN16MB TOP VIEW 75 International Blvd., Suite 100, Toronto, ON M9W 6L9 Tel (416) 675-1201|Toll (866) 768-4771|Fax (416) 679-8992 www.bsmwireless.com BOTTOM VIEW 2 75 International Blvd., Suite 100, Toronto, ON M9W 6L9 Tel (416) 675-1201|Toll (866) 768-4771|Fax (416) 679-8992 www.bsmwireless.com External Photos BOTTOM VIEW OF ENCLOSURE FCC ID will be placed in the RED highlighted area on the outside of the aluminum enclosure which contains the Module FCC ID : 2AC9T-DORIN16MB 3 75 International Blvd., Suite 100, Toronto, ON M9W 6L9 Tel (416) 675-1201|Toll (866) 768-4771|Fax (416) 679-8992 www.bsmwireless.com TOP VIEW OF ENCLOSURE 4 75 International Blvd., Suite 100, Toronto, ON M9W 6L9 Tel (416) 675-1201|Toll (866) 768-4771|Fax (416) 679-8992 www.bsmwireless.com ANTENNA SIDE PANEL VIEW 5 75 International Blvd., Suite 100, Toronto, ON M9W 6L9 Tel (416) 675-1201|Toll (866) 768-4771|Fax (416) 679-8992 www.bsmwireless.com I/O SIDE PANEL VIEW 6 75 International Blvd., Suite 100, Toronto, ON M9W 6L9 Tel (416) 675-1201|Toll (866) 768-4771|Fax (416) 679-8992 www.bsmwireless.com RIGHT SIDE VIEW 7 75 International Blvd., Suite 100, Toronto, ON M9W 6L9 Tel (416) 675-1201|Toll (866) 768-4771|Fax (416) 679-8992 www.bsmwireless.com LEFT SIDE VIEW 8 75 International Blvd., Suite 100, Toronto, ON M9W 6L9 Tel (416) 675-1201|Toll (866) 768-4771|Fax (416) 679-8992 www.bsmwireless.com

BOTTOM VIEW 2 75 International Blvd., Suite 100, Toronto, ON M9W 6L9 Tel (416) 675-1201|Toll (866) 768-4771|Fax (416) 679-8992 www.bsmwireless.com

Internal Photos LABEL INFORMATION FOR MODEL : ASYDORINWLAN FCC ID : 2AC9T-DORIN16MB TOP VIEW 75 International Blvd., Suite 100, Toronto, ON M9W 6L9 Tel (416) 675-1201|Toll (866) 768-4771|Fax (416) 679-8992 www.bsmwireless.com BOTTOM VIEW 2 75 International Blvd., Suite 100, Toronto, ON M9W 6L9 Tel (416) 675-1201|Toll (866) 768-4771|Fax (416) 679-8992 www.bsmwireless.com 2 75 International Blvd., Suite 100, Toronto, ON M9W 6L9 Tel (416) 675-1201|Toll (866) 768-4771|Fax (416) 679-8992 www.bsmwireless.com

FCC Part 15, Subpart C, Section 15.247 – DTS Page 126 of 129 DORIN Module, Model ASYDORINWLAN FCC ID: 2AC9T-DORIN16MB ULTRATECH GROUP OF LABS File #: HGI-010Q_F15C247 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 September 29, 2014 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) 5.7. RF EXPOSURE REQUIRMENTS [§§ 15.247(i), 1.1310 & 2.1091] The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation. FCC 47 CFR § 1.1310: 5.7.1. Method of Measurements Refer to Sections 1.1310, 2.1091 In order to demonstrate compliance with MPE requirements (see Section 2.1091), the following information is typically needed: (1) Calculation that estimates the minimum separation distance (20 cm or more) between an antenna and persons required to satisfy power density limits defined for free space. (2) Antenna installation and device operating instructions for installers (professional/unskilled users), and the parties responsible for ensuring compliance with the RF exposure requirement (3) Any caution statements and/or warning labels that are necessary in order to comply with the exposure limits (4) Any other RF exposure related issues that may affect MPE compliance FCC Part 15, Subpart C, Section 15.247 – DTS Page 127 of 129 DORIN Module, Model ASYDORINWLAN FCC ID: 2AC9T-DORIN16MB ULTRATECH GROUP OF LABS File #: HGI-010Q_F15C247 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 September 29, 2014 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) Calculation Method of RF Safety Distance: 22 44r EIRP r GP S       Where: P: power input to the antenna in mW EIRP: Equivalent (effective) isotropic radiated power S: power density mW/cm 2 G: numeric gain of antenna relative to isotropic radiator r: distance to centre of radiation in cm 5.7.2. RF Evaluation Evaluation of RF Exposure Compliance Requirements RF Exposure Requirements Compliance with FCC Rules Minimum calculated separation distance between antenna and persons required: 3.6 cm Manufacturer’ instruction for separation distance between antenna and persons required: 20 cm Antenna installation and device operating instructions for installers (professional/unskilled users), and the parties responsible for ensuring compliance with the RF exposure requirement Antenna installation and device operating instructions shall be provided to installers to maintain and ensure compliance with RF exposure requirements. Caution statements and/or warning labels that are necessary in order to comply with the exposure limits Refer to user’s manual for RF exposure Information. Any other RF exposure related issues that may affect MPE compliance None *The minimum separation distance between the antenna and bodies of users are calculated using the following formula: S EIRP S GP r      44 S = 1.0 mW/cm 2 EIRP = 22.1 dBm = 10 (22.1/10) mW = 162.2 mW (Worst Case) (Minimum Safe Distance, r) = cm S EIRP 6.3 )0.1(4 162.2 4     

This Te s Tri M. Lu Vice Pre UltraTec Date: Se Report P Issued D  The resul  This repo 91038 Digital Mo st report is Iss uu esident of Eng ch Group of La eptember 29, Prepared by: D Date: Septemb lts in this Test Re rt must not be us Web 1309 F Federal P a dulation Sy Ultra sued under th gineering abs 2014 Dharmajit Sol ber 29, 2014 eport apply only t sed by the client 300 bsite: www.ultratech 46390-204 DOR Model: A FCC ID: 2A A BSM 75 Internati o Toronto In Acc Communic art 15, Subp ystems (DTS aTech's File e Authority o f lanki to the sample(s) to claim produc t Ult 00 Bristol Circle, O Tel.: (905) 829-1 5 h-labs.com, Email: 49 NV COD RIN Module ASYDORINW AC9T-DORI Applicant: Wireless In onal Blvd, S o, ON, M9W cordance Wi cations Com part C, Secti S) Operatin No.: HGI-010 f Tested Test D a tested, and the t endorsement by traTech akville, Ontario, C a 570 Fax.: (905 vic@ultratech-labs VLAP LAB DE 200093-0 e WLAN IN16MB nc. uite 100 6L9 ith mmission (F ion 15.247 g in 2400 – 0Q_F15C247 by: Hung Trin ates: Aug 11 sample tested is y NVLAP or any h anada, L6H 6G4 5) 829-8050 s.com, Email: tri@u SL2-IN-E- 1119R FCC) 2483.5 MH z 7 nh & Sept 02 to s randomly select agency of the U ultratech-labs.com Korea KCC- RRA CA2049 z Band 09, 2014 ted. US Government. TL363_B T D A PTDP A1300 FCC Part 15, Subpart C, Section 15.247 – DTS Contents i DORIN Module, Model ASYDORINWLAN FCC ID: 2AC9T-DORIN16MB ULTRATECH GROUP OF LABS File #: HGI-010Q_F15C247 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 September 29, 2014 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) TABLE OF CONTENTS EXHIBIT 1. INTRODUCTION ......................................................................................................................................... 1 1.1. SCOPE ......................................................................................................................................................................... 1 1.2. RELATED SUBMITTAL(S)/GRANT(S) ................................................................................................................... 1 1.3. NORMATIVE REFERENCES ................................................................................................................................... 1 EXHIBIT 2. PERFORMANCE ASSESSMENT .............................................................................................................. 2 2.1. CLIENT INFORMATION .......................................................................................................................................... 2 2.2. EQUIPMENT UNDER TEST (EUT) INFORMATION ............................................................................................. 2 2.3. EUT’S TECHNICAL SPECIFICATIONS .................................................................................................................. 3 2.4. ASSOCIATED ANTENNA DESCRIPTION ............................................................................................................. 3 2.5. LIST OF EUT’S PORTS ............................................................................................................................................. 3 2.6. ANCILLARY EQUIPMENT ...................................................................................................................................... 3 EXHIBIT 3. EUT OPERATING CONDITIONS AND CONFIGURATIONS DURING TESTS ............................... 5 3.1. CLIMATE TEST CONDITIONS ................................................................................................................................ 5 3.2. OPERATIONAL TEST CONDITIONS & ARRANGEMENT FOR TESTS ............................................................. 5 EXHIBIT 4. SUMMARY OF TEST RESULTS ............................................................................................................... 6 4.1. LOCATION OF TESTS .............................................................................................................................................. 6 4.2. APPLICABILITY & SUMMARY OF EMC EMISSION TEST RESULTS .............................................................. 6 4.3. MODIFICATIONS INCORPORATED IN THE EUT FOR COMPLIANCE PURPOSES ....................................... 6 EXHIBIT 5. TEST DATA ................................................................................................................................................... 7 5.1. POWER LINE CONDUCTED EMISSIONS [§15.207(A)] ........................................................................................ 7 5.2. OCCUPIED BANDWIDTH [§ 15.247(A)(2)] .......................................................................................................... 10 5.3. PEAK CONDUCTED OUTPUT POWER - DTS [§ 15.247(B)(3)] ......................................................................... 60 5.4. TRANSMITTER BAND-EDGE & SPURIOUS CONDUCTED EMISSIONS [§ 15.247(D)] ................................ 62 5.5. RADIATED SPURIOUS EMISSIONS AT 3 METERS [§§ 15.247(D), 15.209 & 15.205] ..................................... 95 5.6. POWER SPECTRAL DENSITY [§ 15.247(E)] ...................................................................................................... 100 5.7. RF EXPOSURE REQUIRMENTS [§§ 15.247(I), 1.1310 & 2.1091] ..................................................................... 126 EXHIBIT 6. TEST EQUIPMENT LIST ....................................................................................................................... 128 EXHIBIT 7. MEASUREMENT UNCERTAINTY ....................................................................................................... 129 7.1. LINE CONDUCTED EMISSION MEASUREMENT UNCERTAINTY .............................................................. 129 7.…

Text truncated - open the document above for the full version.

ANNEX 1 - TEST SETUP PHOTOS BSM Wireless Inc. DORIN MODULE, Model: ASYDORINWLAN FCC ID: 2AC9T-DORIN16MB A1 - 1 Power Line Conducted Emissions ANNEX 1 - TEST SETUP PHOTOS BSM Wireless Inc. DORIN MODULE, Model: ASYDORINWLAN FCC ID: 2AC9T-DORIN16MB A1 - 2 Power Line Conducted Emissions ANNEX 1 - TEST SETUP PHOTOS BSM Wireless Inc. DORIN MODULE, Model: ASYDORINWLAN FCC ID: 2AC9T-DORIN16MB A1 - 3 Radiated Emissions @ 3 m, Orthogonal Position 1 ANNEX 1 - TEST SETUP PHOTOS BSM Wireless Inc. DORIN MODULE, Model: ASYDORINWLAN FCC ID: 2AC9T-DORIN16MB A1 - 4 Radiated Emissions @ 3 m, Orthogonal Position 2 ANNEX 1 - TEST SETUP PHOTOS BSM Wireless Inc. DORIN MODULE, Model: ASYDORINWLAN FCC ID: 2AC9T-DORIN16MB A1 - 5 Radiated Emissions @ 3 m, Orthogonal Position 3
