2ACAACRT-603Card Reader

SPECIFICATION Model No. CRT-603-DB1 Date 2012/11/24 User Manual File Ver. 1.0 Page 1/48 User Manual (V1.0.0.2) CREATOR (CHINA) TECH CO., LTD ADD: 2/F, M-10 Building, Center Area, High-tech Industrial Park Shenzhen, Guangdong, China. Tel: +86-755-26710345 Fax: +86-755-26710105 EMAIL: [email protected] Http://www.china-creator.com SPECIFICATION Model No. CRT-603-DB1 Date 2012/11/24 User Manual File Ver. 1.0 Page 2/48 Version Date Note 1.0.0.0 2012.12.20 First release 1.0.0.1 2013.08.20 Add more than one card of TYPEB identified function Add more than one card of TYPEA and TYPEB identified function 1.0.0.2 2013.12.24 add functions of mode set for checking collision and inquiring status to support TYPEA&TYPEB cards SPECIFICATION Model No. CRT-603-DB1 Date 2012/11/24 User Manual File Ver. 1.0 Page 3/48 Firmware Version Version Date Note 1.0.0.0 2012.12.20 First release 1.0.0.1 20120718 Replacement of card slot changing, lamp control, buzzer set and control, SAM card board and SAM card slot detection, write EEPROM, read EEPROM, write P/N, read P/N, write Serial Number, read Serial Number, write Vendor MFG Date, read Vendor MFG Date, write Vendor MFG P/F , write Vendor MFG P/F command, revise FW version format. 1.0.0.2 20120810 Add new extend instruction protocol， LED mode changing instruction, LED mode inquiry instruction, LED host control instruction and inquiry instruction. Diebold MFG Date read & write instruction, Diebold MFG P/F read & write instruction revise FW version format 1.0.0.3 20120903 Changing single reader mode into dual readers mode Testing aim to function of hardware, PCSC, RF card library, SAM card library and extend Add 70 °C-- 20°C test 1.0.0.4 20120924 Clear up blue lamp status when card collision occurs Add lamp inquiry function under CCR lamp automation control LED lamp indicates only in successful connection Buzzer responses only in successful connection Clear up error status of card slot changing operation with card in SAM card slot (report card moving out) 1.0.0.5 20121016 SAM reader reports card information only in successful changing APDU control LED lamp and buzzer Deactive card, green lamp will be on when the reader is standing by Download identification key of mifare one card to ROM, actually save it into EEPROM in RF IC (Key No. is 1) Once contactless CPU card is actived, it will be not done again in its middle stage, support break operation. Once S50/S70 card key is verified, it will be not actived again in its SPECIFICATION Model No. CRT-603-DB1 Date 2012/11/24 User Manual File Ver. 1.0 Page 4/48 middle stage, support break operation 1.0.0.6 20121023 When SAM card reader executes command for card slot changing， prior to change slot, then reports information of card inserting and pulling, finally executes return command APDU is of EEPROM operation, reboot, gain FW version, skip to IAP mode After RF actived, keep the state and prevent interfering from another RF card 1.0.0.7 20121030 Fail to modify RF verifying password without changing card state, go on verfying password untill success to read data 1.0.0.8 20121107 Add automatically green lamp on function（if red lamp on, green lamp off) optimize the judgement of "connect reader" operation 1.0.0.9 20121113 Clear up the appearance of reader halted when reader feed back some RF length data Clear up the appearance of reader halted when reader feed back some SAM card length data Clear up the error of unable to send special APDU command to RF reader in V1.0.0.8 Clear up the error of unable to send any command to RF reader in V1.0.0.8 1.0.1.0 20121121 support Shang Hai commute system operation Clear up return empty information bug 1.0.1.1 20130613 close led lamp PWM control function 1.0.1.2 20130708 Add more than one card of TYPEB identified function Add more than one card of TYPEA and TYPEB identified function 1.0.1.3 20131213 1. Improve SPI data transmit function and RF data transmit and receiving function, both functions add timing close 2. Improve the configure information of ISO14443-4 SFGI 1.0.1.4 20131224 add functions of mode set for checking collision and inquiring status to support TYPEA&TYPEB cards SPECIFICATION Model No. CRT-603-DB1 Date 2012/11/24 User Manual File Ver. 1.0 Page 5/48 CONTENT 1 Overview ................................................................................................................................................................ 7 1.1 Product Description ..................................................................................................................................... 7 1.2 Features ........................................................................................................................................................ 7 1.3 USB Interface .............................................................................................................................................. 7 2 Product Hardware ................................................................................................................................................... 8 2.1 Product components ..................................................................................................................................... 8 Note: ②SAM card board is an optional choice for customerImages of boards ............................................... 8 Images of boards ................................................................................................................................................ 9 2.2 Reader function ........................................................................................................................................... 11 2.2.1 Contactless Card interface function ................................................................................................. 11 2.2.2 SAM card reader interface function: ................................................................................................ 11 3 Card Operat…

Text truncated - open the document above for the full version.

DATE : 2014-04-23 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2ACAACRT-603 Product Name: Card Reader Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) • Schematics • Block diagram • Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this Day of 20 A gency agreement expiration date:2014-04-23 to 2015-04-22 By: Donghuo Liu Signature Printed Title: Manager On behalf of : CREATOR (CHINA) TECH CO., LTD Telephone: 13590434471

FCC label information & location:

Report No. : EESZG04100008 Page 1 of 29 TEST REPORT Product : Card Reader Module Trade mark : N/A Model/Type reference : CRT-603 Serial Number : N/A FCC ID : 2ACAACRT-603 Ratings : DC 5V 300mA Report Number : EESZG04100008 Date : Apr. 21, 2014 Regulations : See below Prepared for CREATOR (CHINA) TECH CO., LTD 2F, M-10 Building, Center Area, Hi-tech Industrial Park, Nanshan District, Shenzhen, Guangdong Province, China Prepared by Centre Testing International (Shenzhen) Corporation Hongwei Industrial Zone, 70 Area, Bao’an District, Shenzhen, Guangdong, China TEL: +86-755-3368 3668 FAX: +86-755-3368 3385 Tested by: Reviewed by: Approved by: Date: Apr. 21, 2014 Jimmy Li Lab manager Check No.: 1702035248 Standards Results 47 CFR FCC Part 15 Subpart C 15.225:2013 PASS Report No. : EESZG04100008 Page 2 of 29 TABLE OF CONTENTS 1. GENERAL INFORMATION ......................................................................................... 4 2. TEST SUMMARY ........................................................................................................ 4 4. PRODUCT INFORMATION ......................................................................................... 5 5. TEST EQUIPMENT LIST ............................................................................................. 5 6. SUPPORT EQUIPMENT LIST .................................................................................... 5 7. AC CONDUCTED EMISSIONS ................................................................................... 6 7.1 LIMITS ....................................................................................................... 6 7.2 BLOCK DIAGRAM OF TEST SETUP ....................................................... 6 7.3 TEST PROCEDURE .................................................................................. 6 7.4 TEST RESULT ........................................................................................... 7 8. TRANSMITTER FUNDAMENTAL FIELD STRENGTH ............................................... 9 8.1 LIMITS ....................................................................................................... 9 8.2 BLOCK DIAGRAM OF TEST SETUP ....................................................... 9 8.3 TEST PROCEDURE .................................................................................. 9 8.4 TEST RESULT ........................................................................................... 9 9. TRANSMITTER RADIATED SPURIOUS EMISSIONS ............................................. 11 9.1 LIMITS .......................................................................................................... 11 9.2 BLOCK DIAGRAM OF TEST SETUP .......................................................... 11 9.3 TEST PROCEDURE ..................................................................................... 12 9.4TEST RESULT ............................................................................................... 13 10 TRANSMITTER BAND EDGE RADIATED EMISSIONS ......................................... 18 10.1 LIMITS ........................................................................................................ 18 10.2 BLOCK DIAGRAM OF TEST SETUP ........................................................ 18 10.3 TEST PROCEDURE ................................................................................... 18 10.4 TEST RESULT ............................................................................................ 19 11. TRANSMITTER 20 DB BANDWIDTH ..................................................................... 21 11.1 LIMITS ....................................................................................................... 21 11.2 BLOCK DIAGRAM OF TEST SETUP ........................................................ 21 11.3 TEST PROCEDURE ................................................................................... 21 11.4 TEST RESULT ............................................................................................ 21 12. TRANSMITTER FREQUENCY STABILITY ............................................................ 22 12.1 LIMITS ........................................................................................................ 22 12.2 BLOCK DIAGRAM OF TEST SETUP ........................................................ 22 Report No. : EESZG04100008 Page 3 of 29 12.3 TEST PROCEDURE ................................................................................... 22 12.4 TEST RESULT ............................................................................................ 22 APPENDIX 1 PHOTOGRAPHS OF TEST SETUP ....................................................... 24 APPENDIX 2 PHOTOGRAPHS OF EUT ...................................................................... 26 (Note: N/A means not applicable) Report No. : EESZG04100008 Page 4 of 29 1. GENERAL INFORMATION The above equipment was tested by Centre Testing International (Shenzhen) Corporation for compliance with the requirements set forth in the FCC Rules and the measurement procedure according to ANSI C63.4:2009. 2. TEST SUMMARY The complete list of measurements is given below: No. Test Item Rule Result 1 AC Conducted Emissions Part 15.207 PASS 2 Transmitter Fundamental Field Strength Part 15.225(a)(b)(c)(d) PASS 3 Transmitter Radiated Spurious Emissions Part 15.209(a), 15.225(d) PASS 4 Transmitter Band Edge Radiated Emissions Part 15.209(a), 15.225(c)(d) PASS 5 Transmitter 20 dB Bandwidth Part 2.1049 PASS 6 Transmitter Frequency Stability (Temperature & Voltage Variation) Part 15.225(e) PASS 7 Antenna Requirements * Part 15.203 PASS *: According to Section 15.203, an intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. The EUT has a built in antenna which is a short wire solder on the PCB, this is permanently attached antenna and meets the requirements of this section. Appl…
