2ACAS63100114Multipurpose Secturity Remote

GARAGE AMOUR OPERATION INSTRUCTION G2 Syncing your new Remote Control to your Control Module 1. Press and release the “Learning Switch” located on the right side of the Control Module. You may need a pen to push this. 2. Indicator on the Module will turn Yellow and will beep once. 3. Press and release the “0” button on your new Remote. The indicator on the Module will turn off and will beep once. This confirms proper programing of the Remote Control to the Control Module. Note that this must be done within 10 seconds or the system will exit. 4. Up to 10 Remotes can be programmed to one Control Module. Program your Password 1. Press and release the “Learning Switch” on the Control Module. 2. Press and release the “#” button on the Remote Control you wish to program that has already been synced with your Control Module and Indicator will turn Red. 3. Enter your 3 to 8 digit code (using number 0 to 9) then press enter. 4. Indicator will turn off and beep twice to confirm entry. 5. To change password simply repeat. Using Remote to Open your Door Among Three Doors 1. Input your new 3 to 8 digit code. 2. Press enter. 3. Input door no.1 or no.2 or no.3 at the same time and press Enter 4. Buzzer will beep twice, indicator will turn green and door will open. 5. Press Enter to reverse. Note: For security purpose, 5 incorrect entries will result in a long warning beep and require resynchronization. Using Remote to Open your Two Doors Among Three Doors At The Same Time 6. Input your new 3 to 8 digit code. 7. Press enter. 8. Input door no.1 no.2 or no.2 no.3 or no.1 no.3 or no.1 no.2 no.3 and then press Enter 9. Buzzer will beep twice, indicator will turn green and door will open. 10. Press Enter to reverse. Note: For security purpose, 5 incorrect entries will result in a long warning beep and require resynchronization. You might enter any series of digits prior to your real code so as long as your last inputted digits are correct, then enter and the door will open. Pressing Enter again within 15 seconds will stop the operation of the opening of your garage door. You may hit Enter repeatedly to open and stop the opening. Press the “#” button to stop this function. To Erase Password from Remote Control Memory 1. Press and hold “Learning Switch” for 3 seconds. 2. Buzzer will beep 3 times, indicator light will turn off. The Button on Receiver: The button on the receiver is only functional for the door no. 1. NOTICE : The changes or modifications not expressly approved by the party responsible for compliance could void user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est

Date: May 30, 2014 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 c.c. UL Verification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize ELECTRONICS TESTING CENTER, TAIWAN, and hereafter referred to as ETC, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by ELECTRONICS TESTING CENTER, TAIWAN, on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing ETC as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Sean Tien President Kmp Taiwan Co. Ltd.

Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: 2ACAS63100114 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards Sean Tien President Km p Taiwan Co. Ltd. May 30, 2014

Label Here Defender Key Fob Model: TKC GEN2 FCC ID:2ACAS63100114 IC: 11990A‐63100114 20 mm x 15 mm

ETC Report No.:14-04-RBF-057-01 Sheet 4 of 5 Sheets FCC ID:2ACAS63100114 Rev. No 1.0 CONSTRUCTED PHOTOS of EUT 7. 8. ETC Report No.:14-04-RBF-057-01 Sheet 5 of 5 Sheets FCC ID:2ACAS63100114 Rev. No 1.0 CONSTRUCTED PHOTOS of EUT 9.

ETC Report No.:14-04-RBF-057-01 Sheet 18 of 22 Sheets FCC ID:2ACAS63100114 Rev. No 1.0 4.9 Radiated Measurement Photos
