MOZART SERIES –FM Exciters/Transmitters - U SER’S MANUAL 1 /87 MOZART Series FM Exciters/Transmitters User’s Manual Release 1.0.3 - DB ELETTRONICA TELECOMUNICAZIONI S.p.A. - - Riviera Maestri del Lavoro, 20/1 - 35127 Z.I. SUD PADOVA ITALY -- Ph. (049) 870-0588 - Fax. (049) 870-0747 - - http://www.dbbroadcast.com - MOZART SERIES –FM Exciters/Transmitters - U SER’S MANUAL 2 /87 The constructor reserves the right to modify the information in this manual at any time without advising update. Document History Rev. Date Name Details 1.0 September 2013 IC 1.0.1 October 2013 IC Integration and correction of the menu and technical parameters 1.0.2 October 2013 IC Complete Series user manual 1.0.3 February 2014 AB+DS Updated the menu description chapter Issued: February 2014 – Version 1.0.3 © 2013. Copyright by: DB Elettronica Telecomunicazioni SpA Riviera Maestri del Lavoro, 20/1 35127 Z.I. SUD PADOVA ITALY All rights reserved. All specifications, characteristics and circuit descriptions indicated in this manual are subject to change without notice. MOZART SERIES –FM Exciters/Transmitters - U SER’S MANUAL 3 /87 INDEX 1 GENERAL INFORMATION ................................................................................................................................ 8 1.1 SAFETY NOTICES ............................................................................................................................................. 8 1.2 FIRST AID IN CASE OF ELECTROCUTION .................................................................................................... 9 1.3 WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE) ............................................................ 10 1.4 MANUFACTURE LABELS .............................................................................................................................. 10 1.5 IC RSS-GEN, SEC 7.1.2 WARNING STATEMENT- (REQUIRED FOR TRANSMITTERS) ........................................... 11 1.6 IC RSS-102, SEC 2.6 WARNING STATEMENTS .................................................................................................... 11 2 FM EXCITER GENERAL DESCRIPTION ...................................................................................................... 12 3 TECHNICAL SPECIFICATIONS ...................................................................................................................... 18 4 INSTALLATION AND ACTIVATION .............................................................................................................. 21 4.1 INITIAL CHECK ............................................................................................................................................... 21 4.2 CONNECTIONS ................................................................................................................................................ 22 5 MENU DESCRIPTION ........................................................................................................................................ 23 5.1 VISUALIZATION ............................................................................................................................................. 23 5.1.1 START PAGE ............................................................................................................................................ 23 5.1.2 Main menu ................................................................................................................................................ 23 5.2 VMETERS AND INFO MENU .......................................................................................................................... 24 5.2.1 Output Modulation .................................................................................................................................... 25 5.2.2 Left and Right channels level .................................................................................................................... 25 5.2.3 AES-EBU Left and Right channels level ................................................................................................... 25 5.2.4 Auxiliary channels level ............................................................................................................................ 26 5.2.5 Voltages and current ................................................................................................................................. 26 5.2.6 Heatsink temperature ................................................................................................................................ 27 5.2.7 Device information ................................................................................................................................... 27 5.3 SETTINGS MENU............................................................................................................................................. 28 5.3.1 Frequency Set menu .................................................................................................................................. 29 5.3.2 Power Set menu ........................................................................................................................................ 29 5.3.3 Operative Mode menu ............................................................................................................................... 30 5.3.4 Audio Selection menu ................................................................................................................................ 32 5.3.5 Sensitivity menu ........................................................................................................................................ 35 5.3.6 Presetting menu ........................................................................................................................................ 36 5.3.7 Alarms menu ..............................................................................…

Text truncated - open the document above for the full version.

16 /87 Fig. 2.3 – MOZART 50/120/300/500/1000 FRONT VIEW 1. RF Monitor connector 2. Status leds a. ALARM: in case of a temporary alarm (it returns aut omatically to the normal status at next attempt of the unit) – RED led b. WARNING: in case of a warning is present - YELLOW l ed c. ON: in case the unit is connected to the mains and switched on – GREEN led 3. LCD Display 4. Navigation keys (UP / DOWN / RIGHT / LEFT / OK) 5. ESCAPE key 6. AUDIO and CONTROL leds a. RDS/AUX: it is ON in case the RDS/SCA/AUX are on b. MPX: it is ON in case the MPX EXT mode is selected c. NO AUDIO: it is ON in case of alarm/warning on audi o signal d. AES-EBU: it is ON in case the AES-EBU is on e. LIM: it is ON in case the limiter is set to on f. STEREO: it is ON in case the MPX INT mode is select ed g. PRE EMPH: it is ON in case the pre-emphasis is on h . MONO: it is ON in case the MONO mode is selected i. PREF: no actually available j. PLL LOCK: it is ON in case the PLL is correctly loc ked k. AUTO: no actually available l. INTLK: it is ON in case the ENABLE is closed 7. Command keys (Reset Alarms, Local/Remote, ON/OFF) a nd leds (Fault, Local, RF ON) 4 2 3 6 7 5 1 17 /87 Fig. 2.4 – MOZART 50/120/300/500/1000 REAR VIEW 1. AC input 2. LAN port 3. Cooling FAN 4. RF output connector (N) 5. Left XLR connector 6. Right XLR connector 7. AES/EBU XLR connector 8. 19kHz / MPX OUT BNC connector 9. AUX BNC connector 10. MOD OUT BNC connector 11. SCA BNC connector 12. MPX BNC connector 13. RDS BNC connector 14. ENABLE connector 15. RS 485 MASTER connector 16. RS 485 SLAVE connector 17. REMOTE connector 18. Fuse 19. Switching on button 2 1 5 3 4 6 7 15 16 17 12 9 11 13 10 14 8 18 19

LABEL EXAMPLES: LABEL SAMPLE - MOZART 500: FCC ID: 2ACBVMOZART500 Brand Name or Manufacturer’s Name DB ELETTRONICA TELECOMUNICAZIONI SPA IC: M/N: MOZART 500 S/N

DB ELETTRONICA TELECOMUNICAZIONI S.p.A. Riviera Maestri del Lavoro 20/1 - 35127 Z.I. SUD PADOVA ITALY Ph. (049) 870-0588 - Fax. (049) 870-0747 http://www.dbbroadcast.com FRONT AND REAR VIEWS OF THE BOARDS INSTALLED IN THE MOZART UNITS 1. LCD DISPLAY METER (200-000178) 2. BUTTONS AND LEDS BOARD (200-000179) DB ELETTRONICA TELECOMUNICAZIONI S.p.A. Riviera Maestri del Lavoro 20/1 - 35127 Z.I. SUD PADOVA ITALY Ph. (049) 870-0588 - Fax. (049) 870-0747 http://www.dbbroadcast.com 3. CONTROL BOARD (200-000166) DB ELETTRONICA TELECOMUNICAZIONI S.p.A. Riviera Maestri del Lavoro 20/1 - 35127 Z.I. SUD PADOVA ITALY Ph. (049) 870-0588 - Fax. (049) 870-0747 http://www.dbbroadcast.com 4. PLL & VCO BOARD (200-000181) DB ELETTRONICA TELECOMUNICAZIONI S.p.A. Riviera Maestri del Lavoro 20/1 - 35127 Z.I. SUD PADOVA ITALY Ph. (049) 870-0588 - Fax. (049) 870-0747 http://www.dbbroadcast.com 5. DC-DC POWER SUPPLY (200-000185) DB ELETTRONICA TELECOMUNICAZIONI S.p.A. Riviera Maestri del Lavoro 20/1 - 35127 Z.I. SUD PADOVA ITALY Ph. (049) 870-0588 - Fax. (049) 870-0747 http://www.dbbroadcast.com 1. RF FINAL AMPLIFIER MODULE FOR MOZART 50 (200-000183) DB ELETTRONICA TELECOMUNICAZIONI S.p.A. Riviera Maestri del Lavoro 20/1 - 35127 Z.I. SUD PADOVA ITALY Ph. (049) 870-0588 - Fax. (049) 870-0747 http://www.dbbroadcast.com 1. RF FINAL AMPLIFIER MODULE FOR MOZART 500 (200-000192) MOZART SERIES – Low Power FM Exciters/Transmitters - T ECHNICAL MANUAL 40 /127 6.3 MPX INPUT (200-000167) This board process the input audio from MPX connector to modulate it and so to give the best quality in the transmitted signal. Fig. 6.10 – MPX IN BOARD LAYOUT (L02-000167) MOZART SERIES – Low Power FM Exciters/Transmitters - T ECHNICAL MANUAL 74 /127 10. WEB SERVER BOARD (200-000106) Fig. 10.1 – WEB SERVER PHOTOS MOZART SERIES – Low Power FM Exciters/Transmitters - T ECHNICAL MANUAL 75 /127 MOZART SERIES – Low Power FM Exciters/Transmitters - T ECHNICAL MANUAL 29 /127 Fig. 6.2 – LEFT AND RIGHT BOARD FRONT VIEW Fig. 6.3 – LEFT AND RIGHT BOARD REAR VIEW MOZART SERIES – Low Power FM Exciters/Transmitters - T ECHNICAL MANUAL 17 /127 Fig. 3.2 – MOZART 50 TOP VIEW 1. AC Mains input 2. AC/DC power supply SPV 300-24 3. RS 75-48 AC/DC power supply 4. AMP30 board (200-000108) 5. Remote I/O board (200-000187) 6. WebServer board (200-000106) 7. PLL-VCO board (200-000181) 8. Coder stereo board (200-000186) 9. Left & Right audio board (200-000168) 10. Control Board (200-000166) 11. LCD Display board (200-000178) 12. Buttons & led board (200-000179) 13. Directional coupler + Monitor (200-000156 + 200-000161) 14. MPX audio board (200-000167) 15. DC-DC converter (200-000185) 1 2 4 5 3 6 7 8 10 11 12 13 9 14 15

MOZART SERIES – Low Power FM Exciters/Transmitters - TECHNICAL MANUAL 102 /127 Circuit description of the Mozart transmitter. The Mozart line of transmitters share several circuits between models. The transmitter itself consists of a VCO/PLL board, control board and RF amplifier board. The VCO PLL board, contains all the frequency generation circuitry and is followed by the RF amplifier board which also contains the harmonic filtering circuitry. The power supply voltage for the RF amplifier stage of the board is 48Vdc. The RF amplifier board also contains RF protection and monitoring circuits that measure current draw, voltage output, SWR, and RF power output. The difference between models is the model of RF MOSFET used in this final stage. The VCO consists of a varactor tuned Colpitts oscillator with 2 buffer stages and an additional series voltage regulator for the VCO/ buffer. The PLL/ VCO board not only is responsible for frequency control but has the driver stage for the power amplifier. The PLL uses a voltage tuned TCXO at 10 MHz as its reference. MOZART SERIES – Low Power FM Exciters/Transmitters - TECHNICAL MANUAL 103 /127 RF AMPLIFIER MODULE FOR MOZART UP TO 3000W GENERAL DESCRIPTION Technical Specification Summary Frequency Range 87.5 – 108 MHz Temperature R ange -10 to +60 °C Pout (min) 1100W Max VSWR 65:1 Typ Gain 20.4 dB Working Class C Typ. Efficiency 80% Supply Voltage 50V Device: MRFE6VP61K25 H General D escription Designed for FM radio transmitters, thi s ampl ifier incorpo rates microstrip technolog y and LDMOS device to enhance ruggedness and reliability. With mor e than 1100W power capability, thi s pallet can be us ed in compact 1k W transmitter or it can be combi ned with ot her on es to have hi gher power FM amplifiers only adding a power s plitter a nd an output c oupler. It ne eds to be mounted to a pr oper he atsink suitabl e to excha ng e its di ssipa ted power gua rant eeing an adequate airfl ow also in the upper side to cool the matchi ng component s Power A mplifier picture Electrical Specification s Parameter Min. Typ. Max. Units Notes Frequency 87.5 108 MHz Output power 1100 W Fundamental output power Power Input 10 W Power Gain 20 20.4 23 dB @ 1100W and Pin = 10W Drain BIAS Current 0.2 A Collector Efficiency 80 % Load @ 50 Ω with variable VDC to maximize the eff iciency Input VSWR 65:1 Power Gain Variation ± 1 dB F2 Second Harmonic -45 -48 dB All specifications are valid for load impedance 50 Ohm Charts With input and outpu t power c ons tant and variation of the VDD v oltage t o optimize t he e fficiency Fre q. (MHz) Power IN (W) Ref. IN (W) Power OUT (W) Gain (d B) ID (A) VDD (V) Ef fic. (%) 88.00 10 3.5 1100 20.41 28 47.2 83.2 98.00 10 1.5 1100 20.41 29.5 45.18 82.5 108.00 10 2.5 1100 20.41 27.5 49.8 80.3

MOZART SERIES – Low Power FM Exciters/Transmitters - T ECHNICAL M ANUAL 101 /127 13.1 120-150-300-500W RF AMPLIFIER BOARD (200-000149) - PART LIST MOZART SERIES – Low Power FM Exciters/Transmitters - T ECHNICAL M ANUAL 57 /127 7.2 CONTROL BOARD (200-000166) – PART LIST Designator Comment Value CODICE FORNITORE Quantity BT1 CR2032 litio +3V NC PORTABATTERIA CR2032 1 C1, C7 C0805 10pF 2 C2 C0805 12pF 1 C3, C5, C6, C8, C9, C10, C79, C93, C94, C95 C0805 220nF 10 C4 C0805 100pF 1 C11, C12, C13, C14, C15, C16, C17, C18, C19, C20, C0805 100nF 47 C21, C24, C25, C26, C27, C28, C29, C32, C33, C46, C47 C56, C57, C58, C59, C60, C61, C62, C66, C67, C68, C69 C70, C71, C72, C76, C77, C78, C85, C86, C87, C88, C89 C96, C97, C98, C99 C22, C23, C34, C37, C40, C90, C91, C92 CAPACITOR E.SMD 5x6 10uF / 35V 8 C30, C31 C0805 39pF 2 C35, C36, C38, C39 C0805 2u2 4 C41 CAPACITOR E.SMD 8,2 x 9,6mm 220uF / 35V 1 C42, C43 C0805 NC 2 C44, C45, C48, C49, C50, C51, C52, C53, C54, C55 C0805 1nF 10 C63, C64, C65, C73, C74, C75, C80, C81, C82, C83, C84, C102 C0805 10nF 12 C100 C0805 1uF 1 C101 C0805 10uF / 10V 1 CN1, CN2, CN5, CN8 FLAT10 a VASCHETTA 4 CN3 FLAT34 a VASCHETTA 1 CN4 AMP-16 1 CN6 FLAT 14 a VASCHETTA 1 CN7, CN9 FLAT 10 a VASCHETTA 2 MOZART SERIES – Low Power FM Exciters/Transmitters - T ECHNICAL M ANUAL 36 /127 6.2 LEFT AND RIGHT BOARD (200-000168) – PART LIST Designator Comment CodiceFornitore Footprint Value Quantity C1, C14 0805 0805 150p NPØ 2 C2, C5, C6, C13, C15, C18, C19, C26, C30, C31, C32, C34, C35, C40, C43, C44, C45, C51, C52, C53, C54, C61, C62, C63, C64, C65, C66, C67, C77, C78, C79, C157, C158, C165, C168, C170 0805 0805 100nF 36 C3, C4, C7, C8, C9, C10, C11, C16, C17, C20, C21, C22, C23, C24, C68, C72, R29, R58 0805 0805 2n2 1% 18 C27 0805 0805 10nF 1 C28, C82, C83, C84 0805 0805 39pF 4 C29 0805 0805 220pF 1 C33, C42, C56, C60 0805 0805 10pF 4 C36, C39, C57, C59 1210 1210 10uF 4 C37, C47, C85, C86, C163, C164, R83, R92, R122, R129, R134, R153, R154, R189, R190, R191, R220 0805 0805 NC 17 C38, C46, C48, C49, C50, C58, C70, C71, C74, C75, C159, C160, C161, C162 0805 0805 1uF 14 C41, C55 0805 0805 2p2 2 C69, C73 0805 0805 47pF 1% 2 C76, C81 CAPACITOR E. SMD 6.3X7.7mm 100uF / 35V 2 C80, C166, C167 CAPACITOR E. SMD C.E 5.5x5.5 10uF / 50V 3 C171 CAPACITOR E. SMD 6.3X6.3 22uF / 35V 1 CN1 BNC_DOPPIO BNC_RA CON 1 CN2, CN12 PIN STRIP FEM. 6 POLI HDR1X6 2 CN3, CN4, CN6 XLR_FEM XLR XLR_FEM 3 CN5 PIN STRIP FEM. 4 POLI HDR1X4 1 CN7, CN11 PIN STRIP FEM. 12 POLI HDR1X12, HDR1X12a 2 CN8 PIN STRIP MALE 90° 5X2 SM-PHD3210-10P 1 MOZART SERIES – Low Power FM Exciters/Transmitters - T ECHNICAL M ANUAL 37 /127 CN9 PIN STRIP MALE 90° 17X2 SM-PHD3210-34P 1 CN10 PIN STRIP MALE 90° 13X2 SM-PHD3210-26P 1 D2, D3, D4, D7, D8, D9, D10, D11, D12, D13, D14, D15, D16 SOT23 SOT23 BAS 40-04 13 FL1, FL2, FL3, FL4, FL5 EMI FILTER RS: 725-7458 EMI_FILTER NFW31SP106X1E4L 5 L1 ELC08D100E ELC08D470E 10uH 1 L2 RESISTENZA 0.47R 1W 1 L3 1812 1812 10uH 1 LD1, LD2 LED SMD VERDE LED_0805 2 R1, R2, R30, R31 0805 0805 10K 1% 4 R3, R18, R19, R20, R32, R47, R48, R49, R119, R123, R126, R127, R130, R131 0805 0805 4K7 1% 14 R4, R34 0805 0805 6K19 1% 2 R5, R35 0805 0805 360R 1% 2 R6, R36, R56, C12, C25 0805 0805 5K62 1% 5 R7, R9, R24, R25, R26, R37, R39, R53, R54, R55 0805 0805 665R 1% 10 R8, R14, R38, R43 0805 0805 3K6 1% 4 R10, R33 0805 0805 3K3 1% 2 R11, R40 0805 0805 2K7 1% 2 R12, R15, R41, R44 0805 0805 270K 1% 4 R13, R42 0805 0805 0R 1% 2 R16, R45, R84, R95, R111, R112 0805 0805 100K 1% 6 R17, R46 0805 0805 750R 1% 2 R21, R22, R23, R50, R51, R52 0805 0805 4K02 1% 6 R27 0805 0805 5K62K 1% 1 R28, R57 0805 0805 3K9 1% 2 R59, R70, R81, R97, R104, R151 0805 0805 1K 1% 6 R60, R63 1206 1206 1K 2 R61 0805 0805 39K 1 MOZART SERIES – Low Power FM Exciters/Transmitters - T ECHNICAL M ANUAL 38 /127 R62, R69, R78, R80, R88, R99, R103, R105, R124, R125, R132, R133, R135, R144, R145, R146, R147, R148, R149, R150, R152, R192, R193, R194, R195, R196 0805 0805 10K 26 R64 1206 1206 150R 1 R65, R74, R90, R100 1206 1206 100R 4 R66, R72, R91, R101 0805 0805 100R 4 R67, R93 0805 0805 20K 1% 2 R68, R75, R94, R102, R136, R137, R138, R139 0805 0805 3K32 1% 8 R71, R98, R118, R120 1206 1206 20K 1% 4 R73, R96 1206 1206 68R 1% 2 R76, R86 2512 2512 560R 2 R77, R85 0805 0805 56K2 1% 2 R79, R87 0805 0805 220R 2 R82, R89 TRIMMER MULT. REG. V TRIMMER3 2K 2 R106, R117, R121, R128 0805 0805 1K5 4 R107, R116 0805 0805 820R 1% 2 R108, R115 0805 0805 24K 1% 2 R109, R114 0805 0805 13K3 1% 2 R110, R113 0805 0805 220K 1% 2 R142, R143 0805 0805 2K 1% 2 R140, R141, R155, R156, R197, R198, R199, R200 0805 0805 0R 8 R205, R206 0805 0805 2K7 2 RL1, RL2, RL3 DIP8 DIP8 ASSR4128 3 U1, U2, U3, U4 SO-14 SO-14 LF347 4 U5, U16 SO-8 SO-8 INA137 2 U6, U7, U17 SO-8 SO-8 OPA2134 3 U8, U14 SO-8 SO-8 AD8066 2 U9, U19, U22 SO-16 SO-16 DG409 3 U10, U15 TSOP-8 TSOP-8 AD5452 2 U11 DPAK dpak 78M05 1 U12 D2PAK d2pak 7812 1 MOZART SERIES – Low Power FM Exciters/Transmitters - T ECHNICAL M ANUAL 39 /127 U13 D2PAK D2PAK 7912 1 U18 SO-8 SO-8 LF353 1 U20, U23 SO-14 SO-14 TL074 2 CS: 001-000168-01 331 MOZART SERIES – Low Power FM Exciters/Transmitters - T ECHNICAL M ANUAL 58 /127 CN10, CN13 AMP-6 2 CN11 AMP-16 1 CN12 AMP-2 1 D1, D2, D3, D20, D21, D22, D23, D24, D25, D26, D30, D31 SOT143B BAS40-07 14 D41, D42 D4, D5, D6, D7, D8, D9, D10, D12, D17, D18 SOD80 LL4148 23 D19, D27, D28, D29, D32, D33, D34, D35, D36, D37 D38, D39, D40 D11 SOD80 NC 1 D13, D14, D15, D16 BAS16 4 J1 STRIP MASCHIO 2 POLI 1 L1 FBR0805/600R/200mA/201209-601 600R 200mA 1 L2 PANASONIC 'ELC08D470E 10uH 1 P1 STRIP MASCHIO 8pin NC 1 Q1, Q2, Q3, Q4, Q5, Q6, Q7, Q8, Q9, Q10, Q11 SOT23 BC847 11 Q12 SOT23 BC817 1 R1, R2, R14, R15, R21, R59, R61, R62, R63, R86 R0805 10K 27 R93, R107, R108, R109, R135, R146, R147, R166 R167, R168, R169, R170, R171, R176, R177, R178, R186 R5, R8, R11 R0805 20K 1% 3 R3, R4, R9, R10 R0805 22K 4 R6, R34, R35, R36, R37, R38, R39, R40, R41, R67 R0805 1K 24 R68, R69, R71, R72, R73, R89, R103, R104, R105 R106, R113, R115, R131, R175…

Text truncated - open the document above for the full version.

Mozart series calibrating procedure 1 /19 PROCEDURE TO CALIBRATE A MOZART Release 1.0 - DB ELETTRONICA TELECOMUNICAZIONI S.p.A. - - Riviera Maestri del Lavoro, 20/1 - 35127 Z.I. SUD PADOVA ITALY -- Ph. (049) 870-0588 - Fax. (049) 870-0747 - - http://www.dbbroadcast.com - Mozart series calibrating procedure 2 /19 The constructor reserves the right to modify the information in this manual at any time without advising update. Document History Rev. Date Name Details 1.0 June 2014 AB Issued: June 2014 – Version 1.0 © 2014. Copyright by: DB Elettronica Telecomunicazioni SpA Riviera Maestri del Lavoro, 20/1 35127 Z.I. SUD PADOVA ITALY All rights reserved. All specifications, characteristics and circuit descriptions indicated in this manual are subject to change without notice. Mozart series calibrating procedure 3 /19 INDEX STEP 1: FILTER CHECK .............................................................................................................................................. 4 STEP 2: POWER SUPPLY CHECK .............................................................................................................................. 5  POWER SUPPLY ...................................................................................................................................................... 5  001-000185-01 POWER SUPPLY BOARD ........................................................................................................... 6 STEP 3: PROGRAMMING THE BOARDS .................................................................................................................. 7 STEP 4: RF POWER CHECK ........................................................................................................................................ 9 RF AMPLIFIER MODULE ......................................................................................................................................... 10 30W RF DRIVER MODULE ...................................................................................................................................... 12 STEP 5: STARTING THE AMPLIFIER ..................................................................................................................... 15 CHECK FOR RF SPURIOUS AND HARMONICS .................................................................................................... 16 SET THE FOLDBACK REFL AND REFL WARNING ALARMS ............................................................................ 16 F IGURES INDEX FIG. 1 – OUTPUT FILTER RESULT NR.1 ................................................................................................................................. 4 FIG. 2 – OUTPUT FILTER RESULT NR.2 ................................................................................................................................ 4 FIG. 3 – RS 150-48 OUTPUT VOLTAGE ................................................................................................................................ 5 FIG. 4 – 001-000185-01 DC-DC CONVERTER .................................................................................................................... 6 FIG. 5 – MPX BOARD PROGRAMMER CONNECTOR ............................................................................................................. 7 FIG. 6 – CONTROL BOARD PROGRAMMER CONNECTOR ...................................................................................................... 7 FIG. 7 – 50OHM LOAD CONNECTION ................................................................................................................................... 8 FIG. 8 – ENABLE SHORT CIRCUIT (INTERLOCK) ........................................................................................................... 9 FIG. 9 – AMPER-METER DIAGRAM ..................................................................................................................................... 10 FIG. 10 – AMPER-METER IN SERIES ................................................................................................................................... 10 FIG. 11 – RF ON/OFF BUTTON ........................................................................................................................................ 11 FIG. 12 – SET POUT MENU ................................................................................................................................................ 11 FIG. 13 – 500W RF AMPLIFIER MODULE ........................................................................................................................... 12 FIG. 14 – 1KW RF AMPLIFIER MODULE ............................................................................................................................ 12 FIG. 15 – 30W RF MODULE RT4 ADJUST .......................................................................................................................... 13 FIG. 16 – 30W RF MODULE RT2 ADJUST .......................................................................................................................... 13 FIG. 17 – 30W RF MODULE RT1 ADJUST .......................................................................................................................... 14 FIG. 18 – CONTROL BOARD RT7 ADJUST .......................................................................................................................... 15 FIG. 19 – VOLTAGE AND CURRENT MENU ......................................................................................................................... 16 FIG. 20 – SET FOLD BACK REFL ....................................................................................................................................... 16 FIG. 21 – SET REFL WARNING .......................................................................................................................................... 17 FIG. 22 – CONTROL BOARD RT5 ADJUST ...........................…

Text truncated - open the document above for the full version.

MOZART SERIES – Low Power FM Exciters/Transmitters - T ECHNICAL MANUAL 51 /127 Fig. 7.3 – CONTROL BOARD (E02-000166) – MAIN ELECTRICAL DIAGRAM MOZART SERIES – Low Power FM Exciters/Transmitters - T ECHNICAL M ANUAL 70 /127 Fig. 9.3 – STEREO CODER BOARD (E02-000186) – ELECTRICAL DIAGRAM MOZART SERIES – Low Power FM Exciters/Transmitters - T ECHNICAL M ANUAL 63 /127 Fig. 8.3 – PLL & VCO BOARD (E02-000181) – CIRCUIT ELECTRICAL DIAGRAM MOZART SERIES – Low Power FM Exciters/Transmitters - T ECHNICAL MANUAL 41 /127 Fig. 6.11 – MPX IN BOARD (E02-000167) – MAIN ELECTRICAL DIAGRAM MOZART SERIES – Low Power FM Exciters/Transmitters - T ECHNICAL MANUAL 42 /127 Fig. 6.12 – MPX IN BOARD (E02-000167) – INPUTS SWITCH CIRCUIT ELECTRICAL DIAGRAM MOZART SERIES – Low Power FM Exciters/Transmitters - T ECHNICAL MANUAL 43 /127 Fig. 6.13 – MPX IN BOARD (E02-000167) – INPUTS CIRCUIT ELECTRICAL DIAGRAM MOZART SERIES – Low Power FM Exciters/Transmitters - T ECHNICAL MANUAL 44 /127 Fig. 6.14 – MPX IN BOARD (E02-000167) – LIMITER CIRCUIT ELECTRICAL DIAGRAM MOZART SERIES – Low Power FM Exciters/Transmitters - T ECHNICAL MANUAL 45 /127 Fig. 6.15 – MPX IN BOARD (E02-000167) – MICRO CIRCUIT ELECTRICAL DIAGRAM MOZART SERIES – Low Power FM Exciters/Transmitters - T ECHNICAL MANUAL 46 /127 Fig. 6.16 – MPX IN BOARD (E02-000167) – REVEALERS ELECTRICAL DIAGRAM MOZART SERIES – Low Power FM Exciters/Transmitters - T ECHNICAL MANUAL 30 /127 Fig. 6.4 – LEFT AND RIGHT BOARD (E02-000168) – MAIN ELECTRICAL DIAGRAM MOZART SERIES – Low Power FM Exciters/Transmitters - T ECHNICAL MANUAL 31 /127 Fig. 6.5 – LEFT AND RIGHT BOARD (E02-000168) – INPUT PART ELECTRICAL DIAGRAM MOZART SERIES – Low Power FM Exciters/Transmitters - T ECHNICAL MANUAL 32 /127 Fig. 6.6 – LEFT AND RIGHT BOARD (E02-000168) – LEFT & RIGHT INPUTS ELECTRICAL DIAGRAM MOZART SERIES – Low Power FM Exciters/Transmitters - T ECHNICAL MANUAL 33 /127 Fig. 6.7 – LEFT AND RIGHT BOARD (E02-000168) – PRE-EMPHASIS PART ELECTRICAL DIAGRAM MOZART SERIES – Low Power FM Exciters/Transmitters - T ECHNICAL MANUAL 34 /127 Fig. 6.8 – LEFT AND RIGHT BOARD (E02-000168) – MONO FILTER ELECTRICAL DIAGRAM MOZART SERIES – Low Power FM Exciters/Transmitters - T ECHNICAL MANUAL 35 /127 Fig. 6.9 – LEFT AND RIGHT BOARD (E02-000168) – REVEALING PART ON THE CODER BOARD ELECTRICAL DIAGRAM MOZART SERIES – Low Power FM Exciters/Transmitters - T ECHNICAL MANUAL 100 /127 Fig. 13.2 –20-150-300W RF AMPLIFIER BOARD (E02-000149) – ELECTRICAL DIAGRAM MOZART SERIES – Low Power FM Exciters/Transmitters - T ECHNICAL MANUAL 52 /127 Fig. 7.4 – CONTROL BOARD (E02-000166) – CONNECTORS ELECTRICAL DIAGRAM MOZART SERIES – Low Power FM Exciters/Transmitters - T ECHNICAL MANUAL 53 /127 Fig. 7.5 – CONTROL BOARD (E02-000166) – MICRO BOARD ELECTRICAL DIAGRAM MOZART SERIES – Low Power FM Exciters/Transmitters - T ECHNICAL MANUAL 54 /127 Fig. 7.6 – CONTROL BOARD (E02-000166) – MEASURES CIRCUIT ELECTRICAL DIAGRAM MOZART SERIES – Low Power FM Exciters/Transmitters - T ECHNICAL MANUAL 55 /127 Fig. 7.7 – CONTROL BOARD (E02-000166) – PROTECTIONS CIRCUIT ELECTRICAL DIAGRAM MOZART SERIES – Low Power FM Exciters/Transmitters - T ECHNICAL MANUAL 56 /127 Fig. 7.8 – CONTROL BOARD (E02-000166) – PEAK REVEALING CIRCUIT ELECTRICAL DIAGRAM

FCC PART 73.801 FM BROADCAST STATIONS (LPFM) TEST REPORT APPLICANT DB ELETTRONICA TELECOMUNICAZIONI S.P.A. ADDRESS RIVIERA MAESTRI DEL LAVORO 20/1 PADOVA ITALY FCC ID 2ACBVMOZART500 MODEL NUMBER MOZART 500 PRODUCT DESCRIPTION 500W FM BROADCAST TRANSMITTER DATE SAMPLE RECEIVED March 12, 2014 DATE TESTED March 24 to 28, 2014 REPORT ISSUE DATE March 31, 2014 TESTED BY Mario de Aranzeta APPROVED BY Mario de Aranzeta TIMCO REPORT NO. 365AUT14TestReport.docx TEST RESULTS PASS FAIL THE ATTACHED REPORT SHALL NOT BE REPRODUCED EXCEPT IN FULL WITHOUT THE WRITTEN APPROVAL OF TIMCO ENGINEERING, INC. 849 NW STATE ROAD 45 NEWBERRY, FL 32669 USA PH: 888.472.2424 OR 352.472.5500 FAX: 352.472.2030 EMAIL: [email protected] HTTP://WWW.TIMCOENGR.COM Applicant: DB ELETTRONICA TELECOMUNICAZIONI SPA TABLE OF CONTENTS FCC ID: 2ACBVMOZART500 Report: D\ DB ELETTRONICA\365AUT14\365AUT14TestReport.docx Page 2 of 53 Table of Contents GENERAL REMARKS .................................................................................................... 3 GENERAL INFORMATION ............................................................................................. 4 TEST PROCEDURE ....................................................................................................... 5 RF POWER OUTPUT ..................................................................................................... 6 MODULATION CHARACTERISTICS ....................…
