2ACC7RKE232E1RKE-Transceiver

1/6 User Manual Statements RKE232E1 Date: Nov. 19 th , 2020 Technical information Model: RKE232E1 Frequency Band: Channel 1: 433.47 MHz Channel 2: 434.37 MHz Channel 3: 433.92 MHz Output Power: < 10 dBm Manufacturer: Continental Advanced Antenna GmbH Address: Römerring 1, 31137 Hildesheim, Germany Phone: +49 5121 99814-0 Safety and Recommendations Each device is individually tested and factory set. WARNING: The Module is designed for in-car use only. It MUST be well integrated into the automotive environment (Tambient min. -40 °C to max. +105 °C) and needs to be installed by the OEM (car-manufacturer) or in case of replacement by a professional garage. WARNING: The product is maintenance-free and needs no adjustment of the end user. You must not remove the device from the car nor use it as intended. Any modification of the device will cause the cease of the device`s operating license. WARNING: The fuse used in the vehicle for electrical protection of the control unit must comply with MBN 10430 (2011-11) and an amperage of 7,5 amperes! WARNING: The insolation of the used conductors with a cross-sectional area of 0,5 mm 2 or greater must comply with IEC 60332-1-2 and IEC 60332-1-3. The insolation of the used conductors with a cross-sectional area of less than 0,5 mm 2 , must comply with IEC 60332-2-2. Changes or modifications not expressly approved by Continental Advanced Antenna GmbH could void the authority to operate this equipment. Interior 2/6 Country Label / Information Australia Brazil Este equipamento não tem direito à proteção contra interferência prejudicial e não pode causar interferência em sistemas devidamente autorizados. Para maiores informações, consulte o site da ANATEL – www.anatel.gov.br Hong Kong Korea South Mexico Singapore South Africa R-C-Ca3- RKE232Ewe will receive the complete TA-2020/5151 IFT: xxx 3/6 Taiwan 低功率電波輻射性電機管理辦法： •第十二條 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使 用者均不得擅自變更頻率、加大功率或變更原設計之特性及功 能。 •第十四條 低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發 現有干擾現象時，應立即停用，並改善至無干擾時方得繼續使 用。 前項合法通信，指依電信法規定作業之無線電通信。 低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射 性電機設備之干擾。 Japan Model: RKE223J1 Frequency Band: 312 MHz – 315,05 MHz This device is granted pursuant to the Japanese Radio Law. This device should not be modified (otherwise the granted designation number will become invalid) United Arab Emirates TRA REGISTERED No: ER79898/20 DEALER No: DA65993/17 4/6 USA/Canada Legal Radiofrequency radiation exposure Information: This equipment complies with FCC and ISED radiation exposure limits set forth for an uncontrolled environment. Any antenna used with this device must be located at least 8 inches (20,3 cm) from all persons. NOTE: This device complies with Part 15 of the FCC Rules and contains license-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence- exempt RSS standard(s). Operation is subject to the following two conditions: 1. this device may not cause harmful interference, and 2. this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:  Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.  Consult the dealer or an experienced radio/TV technician for help. Cet équipement est conforme aux limites d'exposition aux radiations de la FCC et de l'ISDE établies pour un environnement non contrôlé. Toute antenne utilisée avec cet appareil doit être située au moins 8 pouces (20,3 cm) de toutes les personnes. REMARQUER: L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: 1. l'appareil ne doit pas produire de brouillage, et 2. l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. NOTICE: Changes or modifications made to this equipment not expressly approved by manufacturer may void the FCC / ISED authorization to operate this equipment. 5/6 Europe European Union: Declaration of Conformity Hereby, Continental Advanced Antenna GmbH declares that the radio equipment type "RKE232E1" is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://www.continental-homologation.com/ ANNEX VII of the Official Journal of the European Union SIMPLIFIED EU DECLARATION OF CONFORMITY The simplified EU declaration of conformity referred to in Article 10(9) shall be provided as follows: EN Hereby, Continental Advanced Antenna GmbH declares that the radio equipment type "RKE232E1" is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://www.continental-homologation.com/ BG С настоящото Continental Advanced Antenna GmbH декларира, че този тип радиосъоръжение "RKE232E1" е в съответствие с Директива 2014/53/ЕС. Цялостният текст на ЕС…

Text truncated - open the document above for the full version.

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 15 th January, 2021 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b) (4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2ACC7RKE232E1 RKE232E1 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos 45 Internal Photos 45 Block Diagram Schematics Test Setup Photos 45 User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, ______________________ Contact name: Thomas Schuhbeck Company: Continental Advanced Antenna GmbH IC Company Number: 11980A Address: Römerring 1, 31137 Hildesheim, Germany Phone: +49 8031 35 08 878 Email: [email protected]

Confidential 1 Photo Documentation RKE232E1 Date: 19.01.2021 Christian Magg Continental AdvancedAntennaGmbH top bottom Confidential 2 Photo Documentation RKE232E1 Date: 19.01.2021 Christian Magg Continental AdvancedAntennaGmbH left right Confidential 3 Photo Documentation RKE232E1 Date: 19.01.2021 Christian Magg Continental AdvancedAntennaGmbH front rear Confidential 4 Photo Documentation RKE232E1 Date: 19.01.2021 Christian Magg Continental AdvancedAntennaGmbH PCB bottom Confidential 5 Photo Documentation RKE232E1 Date: 19.01.2021 Christian Magg Continental AdvancedAntennaGmbH PCB top –RF shieldingclosed Confidential 6 Photo Documentation RKE232E1 Date: 19.01.2021 Christian Magg Continental AdvancedAntennaGmbH PCB top –RF shieldingopen

The test results relate only to the individual items which have been tested. This report shall not be reproduced in parts without the written approval of the testing laboratory © Copyright: All rights reserved by CETECOM Annex 3: External photographs to Test Report 19-1-0173601T07a-C2 Number of pages: 5 Date of Report: 2020-Dec-14 Testing company: CETECOM GmbH Im Teelbruch 116 45219 Essen Germany Tel. + 49 (0) 20 54 / 95 19-0 Fax: + 49 (0) 20 54 / 95 19-150 Applicant: Continental Advanced Antenna GmbH Test Object / Tested Device(s): RKE-Transceiver/ RKE232E1 FCC ID: 2ACC7RKE232E1 ISED ID: 11980A-RKE232E1 Testing has been carried out in accordance with: Title 47 CFR, Chapter I FCC Regulations, Subchapter A Subpart B: §15.109 (Class B limits) ISED Regulations RSS-Gen, Issue 5 ICES-003, Issue 6 (Class B limits) Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method and limit". 19-1-0173601T07a-C2-A3 CETECOM_TR19_1_0173601T07a_C2_A3 2 / 5 Table of Contents 1 External photographs of Main device under test (EUT/DUT) ..................................................................................................3 2 External photographs of Accessories .......................................................................................................................................4 19-1-0173601T07a-C2-A3 CETECOM_TR19_1_0173601T07a_C2_A3 3 / 5 1 External photographs of Main device under test (EUT/DUT) Photograph 1: EUT 1_Top view Photograph 2: EUT 1_Rear side view 19-1-0173601T07a-C2-A3 CETECOM_TR19_1_0173601T07a_C2_A3 4 / 5 2 External photographs of Accessories Photograph 3: AE1 Photograph 4: AE2 19-1-0173601T07a-C2-A3 CETECOM_TR19_1_0173601T07a_C2_A3 5 / 5 Photograph 5: AE3 Photograph 6: AE1 End Of Annex 3

Confidential 1 Photo Documentation RKE232J1 Date: 19.01.2021 Christian Magg Continental AdvancedAntennaGmbH top bottom Confidential 2 Photo Documentation RKE232J1 Date: 19.01.2021 Christian Magg Continental AdvancedAntennaGmbH left right Confidential 3 Photo Documentation RKE232J1 Date: 19.01.2021 Christian Magg Continental AdvancedAntennaGmbH front rear Confidential 4 Photo Documentation RKE232J1 Date: 19.01.2021 Christian Magg Continental AdvancedAntennaGmbH PCB bottom Confidential 5 Photo Documentation RKE232J1 Date: 19.01.2021 Christian Magg Continental AdvancedAntennaGmbH PCB top –RF shieldingclosed Confidential 6 Photo Documentation RKE232J1 Date: 19.01.2021 Christian Magg Continental AdvancedAntennaGmbH PCB top –RF shieldingopen

The test results relate only to the individual items which have been tested. This report shall not be reproduced in parts without the written approval of the testing laboratory © Copyright: All rights reserved by CETECOM Annex 1: Measurement diagrams to Test Report 19-1-0173601T07a-C2 Number of pages: 5 Date of Report: 2020-Dec-14 Testing company: CETECOM GmbH Im Teelbruch 116 45219 Essen Germany Tel. + 49 (0) 20 54 / 95 19-0 Fax: + 49 (0) 20 54 / 95 19-150 Applicant: Continental Advanced Antenna GmbH Test Object / Tested Device(s): RKE-Transceiver/ RKE232E1 ISED ID: 2ACC7RKE232E1 ISED ID: 11980A-RKE232E1 Testing has been carried out in accordance with: Title 47 CFR, Chapter I FCC Regulations, Subchapter A Subpart B: §15.109 (Class B limits) ISED Regulations RSS-Gen, Issue 5 ICES-003, Issue 6 (Class B limits) Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method and limit". 19-1-0173601T07a-C2-A1 CETECOM_TR19_1_0149402T01a_C2_A1 2 / 5 1 Measurement diagrams 3.01 Common Information Test Description: Electric Fieldstrength Measurement Test Spec.: FCC 109 Class B limits / ICES-003, Issue 6/ RSS-Gen, Issue 5 Antenna: receiving antenna is directed to all sides Operating Mode: Polling mode Environmental Conditions:: Humidity : 40%rH; Temperature: 20°C Operator: HLa/JRi Verdict: Passed Comment: Laying EUT Information EUT Information PMT number: 19-1-01736S18_C01 Manufacturer: Continental Advanced Antenna GmbH Product: RKE Transceiver Model: RKE232E1 ------------------------------- ------------------------------- HW version: 13620027B02V02 SW version: V11.31 Power Supply: 12 V DC Final_Result Frequency (MHz) QuasiPeak (dBμV/m) Limit (dBμV/m) Margin (dB) Meas. Time (ms) Bandwidth (kHz) Height (cm) Pol Azimuth (deg) Corr. (dB/m) 928.408000 38.10 46.00 7.90 1000.0 120.000 360.0 V 187.0 27.0 0 10 20 30 40 50 60 30M 5060 80 100M200300400 500 8001G L e v e l i n d B μ V / m Frequency in Hz Full Spectrum FCC15.109 QP Class B 35,460000 MHz 22,140 dBμV/m 125,130000 MHz 12,552 dBμV/m 547,650000 MHz 26,753 dBμV/m 19-1-0173601T07a-C2-A1 CETECOM_TR19_1_0149402T01a_C2_A1 3 / 5 3.02 Common Information Test Description: Electric Fieldstrength Measurement Test Spec.: FCC 109 Class B limits / ICES-003, Issue 6/ RSS-Gen, Issue 5 Antenna: receiving antenna is directed to all sides Operating Mode: Polling mode Environmental Conditions:: Humidity : 40%rH; Temperature: 20°C Operator: HLa/JRi Verdict: Passed Comment: Standing EUT Information PMT number: 19-1-01736S18_C01 Manufacturer: Continental Advanced Antenna GmbH Product: RKE Transceiver Model: RKE232E1 ------------------------------- ------------------------------- HW version: 13620027B02V02 SW version: V11.31 Power Supply: 12 V DC 0 10 20 30 40 50 60 30M 5060 80 100M200300400 500 8001G L e v e l i n d B μ V / m Frequency in Hz Full Spectrum FCC15.109 QP Class B 33,840000 MHz 23,086 dBμV/m 144,000000 MHz 14,129 dBμV/m 204,780000 MHz 16,536 dBμV/m 581,040000 MHz 29,626 dBμV/m 19-1-0173601T07a-C2-A1 CETECOM_TR19_1_0149402T01a_C2_A1 4 / 5 4.01_Standing Common Information Test Description: Radiated field strength emission in 3m distance Test Site: Fully Anechoic Chamber (FAC1) - EMC32 V10.50.0 Test Standard: FCC 109 Class B limits / ICES-003, Issue 6/ RSS-Gen, Issue 5 Antenna polarisation: horizontal/vertical Operating Mode: OP. mode1 Operator: HEl Environmental Conditions:: Humidity : 42%rH; Temperature: 22°C Verdict: Passed EUT Information PMT number: 19-1-01736S18_C01 Manufacturer: Continental Advanced Antenna GmbH Product: RKE Transceiver Model: RKE232E1 ------------------------------- ------------------------------- HW version: 13620027B02V02 SW version: V11.31 Power Supply: 12 V DC Final_Result Frequency (MHz) MaxPeak (dBμV/m) Limit (dBμV/m) Margi n (dB) Meas. Time (ms) Bandwidt h (kHz) Heigh t (cm) Pol Azimut h (deg) Elevatio n (deg) Corr. (dB/m) 4629.655000 41.65 74.00 32.35 100.0 1000.000 155.0 V 118.0 0.0 5 5858.648333 47.99 74.00 26.01 100.0 1000.000 155.0 H 140.0 90.0 9 25 30 35 40 45 50 55 60 65 70 75 80 85 1G2G3G4G5G6G L e v e l i n d B μ V / m Frequency in Hz Full Spectrum FCC15_109_PK FCC15_109_AV 19-1-0173601T07a-C2-A1 CETECOM_TR19_1_0149402T01a_C2_A1 5 / 5 4.02_laying Common Information Test Description: Radiated field strength emission in 3m distance Test Site: Fully Anechoic Chamber (FAC1) - EMC32 V10.50.0 Test Standard: FCC 109 Class B limits / ICES-003, Issue 6/ RSS-Gen, Issue 5 Antenna polarisation: horizontal/vertical Operating Mode: OP. mode1 Operator: HEl Environmental Conditions:: Humidity : 42%rH; Temperature: 22°C Verdict: Passed EUT Information PMT number: 19-1-01736S18_C01 Manufacturer: Continental Advanced Antenna GmbH Product: RKE Transceiver Model: RKE232E1 ------------------------------- ------------------------------- HW version: 13620027B02V02 SW version: V11.31 Power Supply: 12 V DC Final_Result Frequency (MHz) MaxPeak (dBμV/m) RMS (dBμV/m) Limit (dBμV/m) Margi n (dB) Meas. Time (ms) Bandwidt h (kHz) Heigh t (cm) Pol Azimut h (deg) Elevatio n (deg) Corr. (dB/m) 2987.007000 39.61 --- 74.00 34.39 100.0 1000.000 155.0 V 20.0 90.0 1 4714.919334 43.13 --- 74.00 30.87 100.0 1000.000 155.0 V 51.0 90.0 6 5856.320000 47.03 --- 74.00 26.97 100.0 1000.000 155.0 V 42.0 90.0 10 End Of Annex 1 25 30 35 40 45 50 55 60 65 70 75 80 85 1G2G3G4G5G6G L e v e l i n d B μ V / m Frequency in Hz Full Spectrum FCC15_109_PK FCC15_109_AV

Test Report 19-1-0173601T07a-C2 Number of pages: 14 Date of Report: 2020-Dec-14 Testing company: CETECOM GmbH Im Teelbruch 116 45219 Essen Germany Tel. + 49 (0) 20 54 / 95 19-0 Fax: + 49 (0) 20 54 / 95 19-150 Applicant: Continental Advanced Antenna GmbH Test Object / Tested Device(s): RKE-Transceiver/ RKE232E1 FCC ID: 2ACC7RKE232E1 ISED ID: 11980A-RKE232E1 Testing has been carried out in accordance with: Title 47 CFR, Chapter I FCC Regulations, Subchapter A Subpart B: §15.109 (Class B limits) ISED Regulations RSS-Gen, Issue 5 ICES-003, Issue 6 (Class B limits) Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method and limit". Test Results: ☒ The EUT complies with the requirements in respect of all parameters subject to the test. The test results relate only to devices specified in this document Test report 19-1-0173601T01a-C2, dated 2020-12-14 is replacing the original test report 19-1-0173601T01a-C1, dated 2020-11-03. The replaced test report gets invalid herewith Signatures: Dipl.-Ing. Ninovic Perez Wolfgang Markus Test Lab Manager Test manager Authorization of test report Responsible of test report Test Report 19-1-0173601T07a-C2 CETECOM_TR19_1_0173601T07a_C2 2 / 14 Table of Contents Table of Annex...................................................................................................................................................................................3 1.1 Disclaimer and Notes .........................................................................................................................................................4 1.2 Summary of Test Results ...................................................................................................................................................5 1.3 Summary of Test Methods ................................................................................................................................................5 2.1 Identification of the Testing Laboratory ............................................................................................................................6 2.2 General limits for environmental conditions .....................................................................................................................6 2.3 Test Laboratories sub-contracted ......................................................................................................................................6 2.4 Organizational Items .........................................................................................................................................................6 2.5 Applicant’s details .............................................................................................................................................................6 2.6 Manufacturer’s details ......................................................................................................................................................6 2.7 EUT: Type, S/N etc. and short descriptions used in this test report ..................................................................................7 2.8 Auxiliary Equipment (AE): Type, S/N etc. and short descriptions ......................................................................................7 2.9 Connected cables ..............................................................................................................................................................7 2.10 EUT set-ups ..................................................................................................................................................................7 2.11 EUT operation modes ...................................................................................................................................................7 3.1 General Data of Main EUT as Declared by Applicant .........................................................................................................8 3.2 Modifications on Test sample............................................................................................................................................8 4.1 Radiated field strength emissions 30 MHz – 1 GHz ...........................................................................................................9 4.2 Radiated field strength emissions above 1 GHz ..............................................................................................................11 4.3 Results from external laboratory .....................................................................................................................................13 4.4 Opinions and interpretations ..........................................................................................................................................13 Test Report 19-1-0173601T07a-C2 CETECOM_TR19_1_0173601T07a_C2 3 / 14 Table of Annex Annex No. Contents Reference Description Total Pages Annex 1 Test result diagrams CETECOM_TR19_1_0173601T07a_C2_A1 5 Annex 2 Internal photographs of EUT N/A -- Annex 3 External photographs of EUT CETECOM_TR19_1_0173601T07a_C2_A3 5 Annex 4 Test set-up photographs CETECOM_TR19_1_0173601T07a_C2_A4 3 The listed attachments are separate documents. Test Report 19-1-0173601T07a-C2 CETECOM_TR19_1_0173601T07a_C2 4 / 14 1 General information 1.1 Disclaimer and Notes The test results of this test report relate exclusively to the test item specified in this test report as specified in chapter 2.7. CETECOM does not assume responsibility for any conclusions and generalizations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of CETECOM. The testing service provided by CETE…

Text truncated - open the document above for the full version.

The test results relate only to the individual items which have been tested. This report shall not be reproduced in parts without the written approval of the testing laboratory © Copyright: All rights reserved by CETECOM Annex 4: Test setup photographs to Test Report 19-1-0173601T07a-C2 Number of pages: 3 Date of Report: 2020-Dec-14 Testing company: CETECOM GmbH Im Teelbruch 116 45219 Essen Germany Tel. + 49 (0) 20 54 / 95 19-0 Fax: + 49 (0) 20 54 / 95 19-150 Applicant: Continental Advanced Antenna GmbH Test Object / Tested Device(s): RKE-Transceiver/ RKE232E1 Contains FCC ID: 2ACC7RKE232E1 Contains IC ID: 11980A-RKE232E1 Testing has been carried out in accordance with: Title 47 CFR, Chapter I FCC Regulations, Subchapter A Subpart B: §15.109 (Class B limits) ISED Regulations RSS-Gen, Issue 5 ICES-003, Issue 6 (Class B limits) Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method and limit". 19-1-0173601T07a-C2-A4 CETECOM_TR19_1_0173601T07a_C2_A4 2 / 3 1 Test setup photographs Photograph 1: EUT Test Setup in the semi anechoic chamber, Electric Field Strength Photograph 2: EUT Test Setup in the semi anechoic chamber, Electric Field Strength strength 19-1-0173601T07a-C2-A4 CETECOM_TR19_1_0173601T07a_C2_A4 3 / 3 Photograph 3: EUT Test Setup in the fully anechoic chamber, Electric Field Strength Photograph 4: EUT Test Setup in the fully anechoic chamber, Electric Field Strength End Of Annex 4
