2ACCJA001Connected wristband with Bluetooth technology

5F, C building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 TEL: +86(0)21 61460666 FAX: +86(0)21 61460602 Date 2015-02-15 To: Federal Communications Commission, Authorization & Evaluation Division, 7345 Oakland Mills Road Columbia, MD 21046 And American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: CTTL, Telecommunication Technology labs, Academy of Telecommunication Research, MIIT is authorized to act on our behalf, until otherwise notified, for applications to American Telecommunications Certification Body, Inc. (ATCB). We certify that we are not subject to denial of federal benefits, which includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR1.2002 (b) to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you. Regards, Zhizhou GONG Product Certification Manager TCT Mobile Limited

Mobile Phone Mobile Phone Mobile Phone Mobile Phone Mobile Phone Mobile Phone USB Cable

Smartband2_back cover_Marking File_140919 Frame Mask Pantone Black C (Printed on 2nd surface) CE Marking Laser etching 4.24mm 6mm 1.56mm 7.7mm 10.42mm 1.0mm 11.4mm 17.37mm 8.2mm 11mm 8.2mm for sample

©Copyright. All rights reserved by CTTL. . RF Exposure REPORT No. I15Z40139-GPM01 for TCT Mobile Limited Connected wristband with Bluetooth technology Model Name: SM 02 with Hardware Version: G Software Version: v1 Issued Date: 2015-02-11 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of CTTL. Test Laboratory: CTTL, Telecommunication Technology Labs, Academy of Telecommunication Research, MIIT No. 52, Huayuan North Road, Haidian District, Beijing, P. R. China 100191. Tel:+86(0)10-62304633-2512, Fax:+86(0)10-62304633-2504 Email: [email protected], website: www.chinattl.com TESTING CNAS L0570 No.I15Z40139-GPM02 Page 2 of 6 ©Copyright. All rights reserved by CTTL. . CONTENTS 1. TEST LABORATORY ......................................................................................................................... 3 1.1. TESTING LOCATION .................................................................................................................... 3 1.2. TESTING ENVIRONMENT ........................................................................................................... 3 1.3. PROJECT DATA .............................................................................................................................. 3 1.4. SIGNATURE ..................................................................................................................................... 3 2. CLIENT INFORMATION ................................................................................................................... 4 2.1. APPLICANT INFORMATION ....................................................................................................... 4 2.2. MANUFACTURER INFORMATION ............................................................................................ 4 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................. 5 3.1. ABOUT EUT ..................................................................................................................................... 5 3.2. INTERNAL IDENTIFICATION OF EUT ..................................................................................... 5 3.3. INTERNAL IDENTIFICATION OF AE ........................................................................................ 5 4. REFERENCE DOCUMENTS ............................................................................................................. 6 4.1. REFERENCE DOCUMENTS FOR TESTING ............................................................................. 6 5. RF EXPOSURE LIMIT ....................................................................................................................... 6 No.I15Z40139-GPM02 Page 3 of 6 ©Copyright. All rights reserved by CTTL. . 1. Test Laboratory 1.1. Testing Location Company Name: Location : CTTL(Shouxiang) Address: No. 51 Shouxiang Science Building, Xueyuan Road, Haidian District, Beijing, P. R. China Postal Code: 100191 1.2. Testing Environment Normal Temperature: 15-35°C Relative Humidity: 20-75% 1.3. Project data Project Leader: Xue Zhen Testing Start Date: 2015-01-27 Testing End Date: 2015-01-30 1.4. Signature Xue Zhen (Prepared this test report) Song Chongwen (Reviewed this test report) Lu Bingsong Deputy Director of the laboratory (Approved this test report) No.I15Z40139-GPM02 Page 4 of 6 ©Copyright. All rights reserved by CTTL. . 2. Client Information 2.1. Applicant Information Company Name: TCT Mobile Limited Address /Post: 5F, C building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 City: Shanghai Postal Code: 201203 Country: China Contact Person: Gong Zhizhou Contact Email [email protected] Telephone: 0086-21-61460890 Fax: 0086-21-61460602 2.2. Manufacturer Information Company Name: TCT Mobile Limited Address /Post: 5F, C building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 City: Shanghai Postal Code: 201203 Country: China Contact Person: Gong Zhizhou Contact Email [email protected] Telephone: 0086-21-61460890 Fax: 0086-21-61460602 No.I15Z40139-GPM02 Page 5 of 6 ©Copyright. All rights reserved by CTTL. . 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description Connected wristband with Bluetooth technology Model Name SM 02 Marketing Name N/A Frequency Band ISM 2400MHz~2483.5MHz Type of Modulation GFSK (Bluetooth Low Energy) Number of Channels 40 Extreme Temperature -10/+55°C Normal Voltage 3.8V Peak antenna gain -6 dBi Note1: Photographs of EUT are shown in ANNEX A of this test report. 3.2. Internal Identification of EUT EUT ID* IMEI HW Version SW Version EUT1 / G v1 *EUT ID: is used to identify the test sample in the lab internally. 3.3. Internal Identification of AE AE ID* Description SN AE1 Battery / AE2 RF cable / *AE ID: is used to identify the test sample in the lab internally. No.I15Z40139-GPM02 Page 6 of 6 ©Copyright. All rights reserved by CTTL. . 4. Reference Documents 4.1. Reference Documents for testing The following documents listed in this section are referred for testing. Reference Title Version RSS-102 Radio Frequency Exposure Compliance of Radio communication Apparatus (All Frequency Bands) Issue 4 KDB447498 D01 Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies v05r02 5. RF Exposure Limit According to RSS-102 Issue 2, section 2.5 and FCC KDB447498, and the maximum output power listed below, the device is exempt from the routine evaluation and is fulfill RF exposure compliance with FCC and IC requirement. The output power and operating frequency of the device are: mode Maximum Output Power Conducted Radiated 2.4GHz Bluetooth 0.52dBm -5.48dBm Estimated SAR for Bluetooth: F（GHz） Distance(mm) Upper limit of power* Estimated 1g (W/kg) dBm mW 2.48 5 -5.48 0.28 0.01 * - Maximum poss…

Text truncated - open the document above for the full version.

©Copyright. All rights reserved by CTTL. FCC PART 15C TEST REPORT BLUETOOTH LOW ENERGY (BLE) PART No. I15Z40139-SRD02 for TCT Mobile Limited Connected wristband with Bluetooth technology Model Name: SM 02 FCC ID: 2ACCJA001 with Hardware Version: G Software Version: V1 Issued Date: 2015-03-17 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of CTTL. Test Laboratory: CTTL, Telecommunication Technology Labs, Academy of Telecommunication Research, MIIT. No.52, HuayuanNorth Road, Haidian District, Beijing, P. R. China 100191. Tel:+86(0)10-62304633-2512,Fax:+86(0)10-62304633-2504 Email:[email protected], website:www.chinattl.com TESTING CNAS L0570 No. I15Z40139-SRD02 Page2 of 40 ©Copyright. All rights reserved by CTTL. REPORT HISTORY Report Number Revision Description Issue Date I15Z40139-SRD02 Rev.0 1st edition 2015-02-15 I15Z40139-SRD02 Rev.1 Revised section 5.1 2015-03-17 I15Z40139-SRD02 Rev.2 Add section A.8 2015-03-17 No. I15Z40139-SRD02 Page3 of 40 ©Copyright. All rights reserved by CTTL. CONTENTS 1. TEST LABORATORY .............................................................................................................. 4 1.1. TESTING LOCATION .......................................................................................................... 4 1.2. TESTING ENVIRONMENT .................................................................................................. 4 1.3. PROJECT DATA .................................................................................................................. 4 1.4. SIGNATURE ........................................................................................................................ 4 2. CLIENT INFORMATION .......................................................................................................... 5 2.1. APPLICANT INFORMATION............................................................................................... 5 2.2. MANUFACTURER INFORMATION ..................................................................................... 5 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................ 6 3.1. ABOUT EUT ........................................................................................................................ 6 3.2. INTERNAL IDENTIFICATION OF EUT ............................................................................... 6 3.3. INTERNAL IDENTIFICATION OF AE .................................................................................. 6 3.4. N ORMAL ACCESSORY SETTING ............................................................................................ 6 3.5. G ENERAL DESCRIPTION ...................................................................................................... 6 4. REFERENCE DOCUMENTS .................................................................................................. 7 4.1. DOCUMENTS SUPPLIED BY APPLICANT ........................................................................ 7 4.2. REFERENCE DOCUMENTS FOR TESTING ...................................................................... 7 5. TEST RESULTS ...................................................................................................................... 8 5.1. S UMMARY OF TEST RESULTS .............................................................................................. 8 5.2. S TATEMENTS ...................................................................................................................... 8 6. TEST FACILITIES UTILIZED .................................................................................................. 9 ANNEX A: DETAILED TEST RESULTS ...................................................................................... 10 A.1. MEASUREMENT METHOD ...................................................................................................... 10 A.2. PEAK OUTPUT POWER - CONDUCTED .................................................................................... 11 A.3. FREQUENCY BAND EDGES - CONDUCTED .............................................................................. 12 A.4. TRANSMITTER SPURIOUS EMISSION - CONDUCTED ................................................................ 14 A.5. TRANSMITTER SPURIOUS EMISSION - RADIATED .................................................................... 23 A.6. 6DB BANDWIDTH .................................................................................................................. 31 A.7. MAXIMUM POWER SPECTRAL DENSITY LEVEL ........................................................................ 34 A.8. AC POWERLINE CONDUCTED EMISSION ................................................................................ 37 ANNEX B: ACCREDITATION CERTIFICATE .............................................................................. 40 No. I15Z40139-SRD02 Page4 of 40 ©Copyright. All rights reserved by CTTL. 1. Test Laboratory 1.1. Testing Location Location 1:CTTL(huayuan North Road) Address: No. 52, Huayuan North Road, Haidian District, Beijing, P. R. China100191 Location 2:CTTL(Shouxiang) Address: No. 51 Shouxiang Science Building, Xueyuan Road, Haidian District, Beijing, P. R. China100191 1.2. Testing Environment Normal Temperature: 15-35°C Extreme Temperature: -10/+55Ԩ Relative Humidity: 20-75% 1.3. Project data Testing Start Date: 2015-01-19 Testing End Date: 2015-02-06 1.4. Signature Xu Zhongfei (Prepared this test report) Li Zhibin (Reviewed this test report) Lv Songdong (Approvedthis test report) No. I15Z40139-SRD02 Page5 of 40 ©Copyright. All rights reserved by CTTL. 2. Client Information 2.1. Applicant Information Company Name: TCT Mobile Limited Address /Post: 5F, E building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 City: Shanghai Postal Code: 201203 Count…

Text truncated - open the document above for the full version.
