2ACCJA004HSUPA/HSDPA/UMTS quadbands / GSM quadbands/LTE Six -band mobile phone

1 Quick Start Guide Thank you for buying ALCATEL ONETOUCH 5065A. We hope you will enjoy your high-quality mobile communication experience. For more information about how to use your cellphone, please visit www.alcatelonetouch.com to download the complete user manual. From the website, you can consult the FAQ, perform software upgrades, etc.


 5065A English - CJB34N1ALAAA 23 PROTECT YOUR HEARING To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use. www.sar-tick.com This product meets applicable national SAR limits of 1.6 W/kg. The specific maximum SAR values can be found on page 30 of this user guide. When carrying the product or using it while worn on your body, either use an approved accessory such as a holster or otherwise maintain a distance of 10 mm from the body to ensure compliance with RF exposure requirements. Note that the product may be transmitting even if you are not making a phone call. 1 Your mobile ������������������ 1�1 Keys and connectors Micro-USB Connector Front camera Headset connector Proximity & Light Sensor Home key Touch screen Back key Menu key Indice 1 Your mobile ���������������������������������������������������������������������3 2 Text input ����������������������������������������������������������������������14 3 Phone call ����������������������������������������������������������������������15 4 Contacts ������������������������������������������������������������������������17 5 Messaging�����������������������������������������������������������������������18 6 Email ������������������������������������������������������������������������������19 7 Getting connected ��������������������������������������������������������20 8 Find my location using GPS satellites ������������������������22 9 Data backup ������������������������������������������������������������������22 10 Factory data reset ��������������������������������������������������������23 11 Applications & Internal storage ����������������������������������23 12 Making the most of your phone ����������������������������������24 Safety and use �������������������������������������������������������������������������26 General information ��������������������������������������������������������������33 Warranty ���������������������������������������������������������������������������������35 Troubleshooting����������������������������������������������������������������������36 LED indicator 45 Camera Camera Flash/ Flashlight Power key Volume key Back key • Touch to go back to the previous screen, or to close a dialog box, options menu, the notification panel, etc. Home key • From any application or screen, touch to return to the Home screen. • Touch and hold to pop up Google search icon. Slide your finger to the icon to open Google search. Menu key • Touch to view recently used applications. Power key • Press: Lock the screen/Light up the screen. • Press and hold: Show the pop-up menu to select from Power off/Restart/Airplane mode. • Press and hold the Power key and Volume up key to reset. • Press and hold the Power key and Volume down key to capture a screenshot. • Press and hold the power key for at least 10 seconds to force reboot or hold it longer to power off. Volume Keys • In call mode, adjusts the earpiece or headset volume. • In Music/Video/Streaming mode, adjusts the media volume. • In general mode, adjusts the ringtone volume. • Mutes the ringtone of an incoming call. • In camera preview mode, press Volume up or down key to enter burst shoot. 67 1�2 Getting started 1�2�1 Set up Removing or installing the back cover Inserting or removing the SIM card You must insert your SIM card to make phone calls. Place the SIM card with the chip facing downwards and slide it into its housing. Make sure that it is correctly inserted. To remove the SIM card, press and slide it out. Your phone only supports micro-SIM card. Do not attempt to insert other SIM types like mini and nano cards, otherwise you may damage your phone. Installing the microSD card Place the microSD card with the chip facing downwards and slide it into its housing. Make sure that it is correctly inserted. To remove the microSD card, press and slide it out. Charging the battery To charge the battery, connect the charger to your phone and mains socket. You can also charge your phone via a USB cable. To reduce power consumption and energy waste, when the battery is fully charged, disconnect your charger; switch off Wi-Fi, GPS, Bluetooth or background-running applications when not in use; reduce the backlight time, etc. 1�2�2 Power on your phone Hold down the Power key until the phone powers on. It will take a few seconds before the screen lights up. Set up your phone for the first time The first time you power on the phone, you should set the following options: Language, Google account, etc. Even if no SIM card is installed, your phone will still power on and you will be able to connect to a Wi-Fi network, sign into your Google account and use some of the phone's features. 1�2�3 Power off your phone Hold down the Power key from the Home screen until the phone options appear, select Power off. 89 1�3 Home screen You can move all of the items (applications, shortcuts, folders and widgets) you use most frequently to your Home screen for quick access. Touch the Home key to switch to the Home screen. Touch to enter application list. Status bar • Status/Notification indicators • Touch and drag down to open the notification panel. Touch an icon to open an application, folder, etc. Favourite tray applications • Touch to enter the application. • Touch and hold to move or change applications. Search bar • Touch  to enter text search screen. • Touch  to enter voice search screen. The Home screen is provided in an extended format to allow more space for adding applications, shortcuts etc. Slide the Home screen …

Text truncated - open the document above for the full version.

TCL Communication Ltd. 5F, C building, No. 232, Liang Jing Road, ZhangJiang High-Tech Park, Pudong Shanghai, P.R. China. 201203 Tel: +86 21 6146 0666 Fax: +86 21 6146 0602 http://tclcom.tcl.com Date 2015-06-10 To: Federal Communications Commission, Authorization & Evaluation Division, 7345 Oakland Mills Road Columbia, MD 21046 And American Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: CTTL (Telecommunication Technology Labs,Academy of Telecommunication Research,MIIT) is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, which includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR1.2002 (b) to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you. Regards, Zhizhou GONG Product Certification Manager TCL Communication Ltd.

TCL Communication Ltd. 5F, C building, No. 232, Liang Jing Road, ZhangJiang High-Tech Park, Pudong Shanghai, P.R. China. 201203 Tel: +86 21 6146 0666 Fax: +86 21 6146 0602 http://tclcom.tcl.com 2015-07-01 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: 2ACCJA004 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: - Block Diagram - Schematics - Operational Description - BOM list/Tune-Up-Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Yours Sincerely, Zhizhou GONG Product Certification Manager TCL Communication Ltd.

EUT photograph

Label Placement

EUT Interior photograph Mobile Phone Mobile Phone Disassembly Mobile Phone Disassembly Mobile Phone Disassembly Mobile Phone Disassembly Mobile Phone Disassembly

©Copyright. All rights reserved by CTTL. SAR TEST REPORT No. I15Z41083-SEM01 For TCL Communication Ltd. HSUPA/HSDPA/UMTS quadbands / GSM quadbands/LTE Six -band mobile phone Model name: 5065A With Hardware Version: PIO Software Version: A5X FCC ID: 2ACCJA004 Issued Date: 2015-07-01 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of CTTL. Test Laboratory: CTTL, Telecommunication Technology Labs, Academy of Telecommunication Research, MIIT No. 51 Shouxiang Science Building, Xueyuan Road, Haidian District, Beijing, P. R. China100191 Tel:+86(0)10-62304633-2512,Fax:+86(0)10-62304633-2504 Email:[email protected] , website:www.chinattl.com TESTING CNAS L0570 No. I15Z41083-SEM01 Page 2 of 168 ©Copyright. All rights reserved by CTTL. REPORT HISTORY Report Number Revision Issue Date Description I15Z41083-SEM01 Re v.0 2015-07-01 Initial creation of test report No. I15Z41083-SEM01 Page 3 of 168 ©Copyright. All rights reserved by CTTL. TABLE OF CONTENT 1 TEST LABORATORY .................................................................................................................... 5 1.1 TESTING LO C AT I O N ........................................................................................................................................ 5 1.2 TESTING ENVIRONMENT ................................................................................................................................. 5 1.3 PROJECT DATA ............................................................................................................................................... 5 1.4 SIGNATURE ..................................................................................................................................................... 5 2 STATEMENT OF COMPLIANCE .................................................................................................. 6 3 CLIENT INFORMATION ................................................................................................................ 8 3.1 APPLICANT INFORMATION .............................................................................................................................. 8 3.2 MANUFACTURER INFORMATION ..................................................................................................................... 8 4 EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ................................. 9 4.1 ABOUT EUT ................................................................................................................................................... 9 4.2 INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST .......................................................................... 9 4.3 INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ............................................................................ 9 5 TEST METHODOLOGY .............................................................................................................. 10 5.1 APPLICABLE LIMIT REGULATIONS ................................................................................................................ 10 5.2 APPLICABLE MEASUREMENT STANDARDS .................................................................................................... 10 6 SPECIFIC ABSORPTION RATE (SAR) ...................................................................................... 11 6.1 INTRODUCTION ............................................................................................................................................. 11 6.2 SAR DEFINITION .......................................................................................................................................... 11 7 TISSUE SIMULATING LIQUIDS ................................................................................................. 12 7.1 TARGETS FOR TISSUE SIMULATING LIQUID .................................................................................................... 12 7.2 DIELECTRIC PERFORMANCE ......................................................................................................................... 12 8 SYSTEM VERIFICATION ............................................................................................................ 18 8.1 SYSTEM SETUP ............................................................................................................................................. 18 8.2 SYSTEM VERIFICATION ................................................................................................................................. 19 9 MEASUREMENT PROCEDURES .............................................................................................. 20 9.1 TESTS TO BE PERFORMED ............................................................................................................................. 20 9.2 GENERAL MEASUREMENT PROCEDURE ........................................................................................................ 21 9.3 WCDMA MEASUREMENT PROCEDURES FOR SAR ...................................................................................... 22 9.4 SAR MEASUREMENT FOR LT E ..................................................................................................................... 23 9.5 BLUETOOTH & WI-FI MEASUREMENT PROCEDURES FOR SAR .................................................................... 24 9.6 POWER DRIFT ............................................................................................................................................... 24 10 AREA SCAN BASED 1-G SAR ................................................................................................. 25 10.1 REQUIREMENT OF KDB .............................................................................................................................. 25 10.2 FAST SAR A…

Text truncated - open the document above for the full version.

No. I15Z41083-SEM01 Page 57 of 168 ©Copyright. All rights reserved by CTTL. 15 SAR Measurement Variability SAR measurement variability must be assessed for each frequency band, which is determined by the SAR probe calibration point and tissue-equivalent medium used for the device measurements. When both head and body tissue-equivalent media are required for SAR measurements in a frequency band, the variability measurement procedures should be applied to the tissue medium with the highest measured SAR, using the highest measured SAR configuration for that tissue-equivalent medium. The following procedures are applied to determine if repeated measurements are required. 1) Repeated measurement is not required when the original highest measured SAR is < 0.80 W/kg; steps 2) through 4) do not apply. 2) When the original highest measured SAR is ≥ 0.80 W/kg, repeat that measurement once. 3) Perform a second repeated measurement only if the ratio of largest to smallest SAR for the original and first repeated measurements is > 1.20 or when the original or repeated measurement is ≥ 1.45 W/kg (~ 10% from the 1-g SAR limit). 4) Perform a third repeated measurement only if the original, first or second repeated measurement is ≥ 1.5 W/kg and the ratio of largest to smallest SAR for the original, first and second repeated measurements is > 1.20. Table 15.1: SAR Measurement Variability for Body GSM850 (1g) Frequency Test Position Spacing (mm) Original SAR (W/kg) First Repeated SAR (W/kg) The Ratio Second Repeated SAR (W/kg) MHz Ch. 824.2 128 Rear 10 0.887 0.871 1.02 / Table 15.2: SAR Measurement Variability for Body WCDMA1900 (1g) Frequency Test Position Spacing (mm) Original SAR (W/kg) First Repeated SAR (W/kg) The Ratio Second Repeated SAR (W/kg) MHz Ch. 1852.4 9262 Rear 10 1.16 1.14 1.02 / Table 15.3: SAR Measurement Variability for Body LTE Band 2 (1g) Frequency Test Position Spacing (mm) Original SAR (W/kg) First Repeated SAR (W/kg) The Ratio Second Repeated SAR (W/kg) MHz Ch. 1860 18700 Rear 10 1.18 1.17 1.01 / Table 15.4: SAR Measurement Variability for Body LTE Band 4 (1g) Frequency Test Position Spacing (mm) Original SAR (W/kg) First Repeated SAR (W/kg) The Ratio Second Repeated SAR (W/kg) MHz Ch. 1732.5 20175 Rear 10 1.00 0.989 1.01 / No. I15Z41083-SEM01 Page 58 of 168 ©Copyright. All rights reserved by CTTL. 16 Measurement Uncertainty 16.1 Measurement Uncertainty for Normal SAR Tests (300MHz~3GHz) No. Error Description Type Uncertainty value Probably Distribution D iv. (Ci) 1g (Ci) 10g Std. Unc. (1g) Std. Unc. (10g) Degree of freedo m Measurement system 1 Probe calibration B 5.5 N 1 1 1 5.5 5.5 ∞ 2 Isotropy B 4.7 R 3 0.7 0.7 1.9 1.9 ∞ 3 Boundary effect B 1.0 R 3 1 1 0.6 0.6 ∞ 4 Linearity B 4.7 R 3 1 1 2.7 2.7 ∞ 5 Detection limit B 1.0 R 3 1 1 0.6 0.6 ∞ 6 Readout electronics B 0.3 R 3 1 1 0.3 0.3 ∞ 7 Response time B 0.8 R 3 1 1 0.5 0.5 ∞ 8 Integration time B 2.6 R 3 1 1 1.5 1.5 ∞ 9 RF ambient conditions-noise B 0 R 3 1 1 0 0 ∞ 10 RF ambient conditions-reflection B 0 R 3 1 1 0 0 ∞ 11 Probe positioned mech. restrictions B 0.4 R 3 1 1 0.2 0.2 ∞ 12 Probe positioning with respect to phantom shell B 2.9 R 3 1 1 1.7 1.7 ∞ 13 Post-processing B 1.0 R 3 1 1 0.6 0.6 ∞ Test sample related 14 Test sample positioning A 3.3 N 1 1 1 3.3 3.3 71 15 Device holder uncertainty A 3.4 N 1 1 1 3.4 3.4 5 16 Drift of output power B 5.0 R 3 1 1 2.9 2.9 ∞ Phantom and set-up 17 Phantom uncertainty B 4.0 R 3 1 1 2.3 2.3 ∞ 18 Liquid conductivity (target) B 5.0 R 3 0.64 0.43 1.8 1.2 ∞ 19 Liquid conductivity (meas.) A 2.06 N 1 0.64 0.43 1.32 0.89 43 20 Liquid permittivity (target) B 5.0 R 3 0.6 0.49 1.7 1.4 ∞ 21 Liquid permittivity (meas.) A 1.6 N 1 0.6 0.49 1.0 0.8 521 No. I15Z41083-SEM01 Page 59 of 168 ©Copyright. All rights reserved by CTTL. Combined standard uncertainty ∑ = = 21 1 22' i iic ucu 9.25 9.12 257 Expanded uncertainty (confidence interval of 95 %) ce uu2= 18.5 18.2 16.2 Measurement Uncertainty for Normal SAR Tests (3~6GHz) No. Error Description Type Uncertainty value Probably Distribution D iv. (Ci) 1g (Ci) 10g Std. Unc. (1g) Std. Unc. (10g) Degree of freedo m Measurement system 1 Probe calibration B 6.5 N 1 1 1 6.5 6.5 ∞ 2 Isotropy B 4.7 R 3 0.7 0.7 1.9 1.9 ∞ 3 Boundary effect B 2.0 R 3 1 1 1.2 1.2 ∞ 4 Linearity B 4.7 R 3 1 1 2.7 2.7 ∞ 5 Detection limit B 1.0 R 3 1 1 0.6 0.6 ∞ 6 Readout electronics B 0.3 R 3 1 1 0.3 0.3 ∞ 7 Response time B 0.8 R 3 1 1 0.5 0.5 ∞ 8 Integration time B 2.6 R 3 1 1 1.5 1.5 ∞ 9 RF ambient conditions-noise B 0 R 3 1 1 0 0 ∞ 10 RF ambient conditions-reflection B 0 R 3 1 1 0 0 ∞ 11 Probe positioned mech. restrictions B 0.8 R 3 1 1 0.5 0.5 ∞ 12 Probe positioning with respect to phantom shell B 6.7 R 3 1 1 3.9 3.9 ∞ 13 Post-processing B 4.0 R 3 1 1 2.3 2.3 ∞ Test sample related 14 Test sample positioning A 3.3 N 1 1 1 3.3 3.3 71 15 Device holder uncertainty A 3.4 N 1 1 1 3.4 3.4 5 16 Drift of output power B 5.0 R 3 1 1 2.9 2.9 ∞ Phantom and set-up 17 Phantom uncertainty B 4.0 R 3 1 1 2.3 2.3 ∞ 18 Liquid conductivity (target) B 5.0 R 3 0.64 0.43 1.8 1.2 ∞ 19 Liquid conductivity (meas.) A 2.06 N 1 0.64 0.43 1.32 0.89 43 No. I15Z41083-SEM01 Page 60 of 168 ©Copyright. All rights reserved by CTTL. 20 Liquid permittivity (target) B 5.0 R 3 0.6 0.49 1.7 1.4 ∞ 21 Liquid permittivity (meas.) A 1.6 N 1 0.6 0.49 1.0 0.8 521 Combined standard uncertainty ∑ = = 21 1 22' i iic ucu 10.8 10.7 257 Expanded uncertainty (confidence interval of 95 %) ce uu2= 21.6 21.4 16.3 Measurement Uncertainty for Fast SAR Tests (300MHz~3GHz) No. Error Description Type Uncertainty value Probably Distribution D iv. (Ci) 1g (Ci) 10g Std. Unc. (1g) Std. Unc. (10g) Degree of freedo m Measurement system 1 Probe calibration B 5.5 N 1 1 1 5.5 5.5 ∞ 2 Isotropy B 4.7 R 3 0.7 0.7 1.9 1.9 ∞ 3 Boundary effect B 1.0 R 3 1 1 0.6 0.6 ∞ 4 Linearity B 4.7 R 3 1 1 2.7 2.7 ∞ 5 Detection limit B 1.0 R 3 1 1 0.6 0.6 ∞ 6 Readout electronics B 0.3 R 3 1 1 0.3 0.3 ∞ 7 Response time B 0.8 R 3 1 1 0.5 0.5 ∞ 8 Integration time B 2.6 R 3 1 1 1.5 1.5…

Text truncated - open the document above for the full version.

No. I15Z41083-SEM01 Page 113 of 168 ©Copyright. All rights reserved by CTTL. Picture D.3 Tilt position of the wireless device on the left side of SAM D.2 Body-worn device A typical example of a body-worn device is a mobile phone, wireless enabled PDA or other battery operated wireless device with the ability to transmit while mounted on a person’s body using a carry accessory approved by the wireless device manufacturer. Picture D.4 Test positions for body-worn devices D.3 Desktop device A typical example of a desktop device is a wireless enabled desktop computer placed on a table or desk when used. The DUT shall be positioned at the distance and in the orientation to the phantom that corresponds to the intended use as specified by the manufacturer in the user instructions. For devices that employ an external antenna with variable positions, tests shall be performed for all antenna positions specified. Picture 8.5 show positions for desktop device SAR tests. If the intended use is not specified, the device shall be tested directly against the flat phantom. No. I15Z41083-SEM01 Page 114 of 168 ©Copyright. All rights reserved by CTTL. Picture D.5 Test positions for desktop devices D.4 DUT Setup Photos Picture D.6 No. I15Z41083-SEM01 Page 115 of 168 ©Copyright. All rights reserved by CTTL. ANNEX E Equivalent Media Recipes The liquid used for the frequency range of 800-3000 MHz consisted of water, sugar, salt, preventol, glycol monobutyl and Cellulose. The liquid has been previously proven to be suited for worst-case. The Table E.1 shows the detail solution. It’s satisfying the latest tissue dielectric parameters requirements proposed by the IEEE 1528 and IEC 62209. Table E.1: Composition of the Tissue Equivalent Matter Frequency (MHz) 835 Head 835 Body 1900 Head 1900 Body 2450 Head 2450 Body 5800 Head 5800 Body Ingredients (% by weight) Water 41.45 52.5 55.242 69.91 58.79 72.60 65.53 65.53 Sugar 56.0 45.0 \ \ \ \ \ \ Salt 1.45 1.4 0.306 0.13 0.06 0.18 \ \ Preventol 0.1 0.1 \ \ \ \ \ \ Cellulose 1.0 1.0 \ \ \ \ \ \ Glycol Monobutyl \ \ 44.452 29.96 41.15 27.22 \ \ Diethylenglycol monohexylether \ \ \ \ \ \ 17.24 17.24 Triton X-100 \ \ \ \ \ \ 17.24 17.24 Dielectric Parameters Target Value ε=41.5 σ=0.90 ε=55.2 σ=0.97 ε=40.0 σ=1.40 ε=53.3 σ=1.52 ε=39.2 σ=1.80 ε=52.7 σ=1.95 ε=35.3 σ=5.27 ε=48.2 σ=6.00 Note: There are a little adjustment respectively for 750, 1750, 2600, 5200, 5300 and 5600 based on the recipe of closest frequency in table E.1. No. I15Z41083-SEM01 Page 116 of 168 ©Copyright. All rights reserved by CTTL. ANNEX F System Validation The SAR system must be validated against its performance specifications before it is deployed. When SAR probes, system components or software are changed, upgraded or recalibrated, these must be validated with the SAR system(s) that operates with such components. Table F.1: System Validation Probe SN. Liquid name Validation date Frequency point Status (OK or Not) 3846 Head 750MHz Oct.25,2014 750 MHz OK 3846 Head 850MHz Oct.25,2014 850 MHz OK 3846 Head 900MHz Oct.26,2014 900 MHz OK 3846 Head 1750MHz Oct.27,2014 1750 MHz OK 3846 Head 1810MHz Oct.27,2014 1810 MHz OK 3846 Head 1900MHz Oct.28,2014 1900 MHz OK 3846 Head 1950MHz Oct.28,2014 1950 MHz OK 3846 Head 2000MHz Oct.28,2014 2000 MHz OK 3846 Head 2100MHz Oct.28,2014 2100 MHz OK 3846 Head 2300MHz Oct.29,2014 2300 MHz OK 3846 Head 2450MHz Oct.29,2014 2450 MHz OK 3846 Head 2550MHz Oct.29,2014 2550 MHz OK 3846 Head 2600MHz Oct.29,2014 2600 MHz OK 3846 Head 3500MHz Oct.30,2014 3500 MHz OK 3846 Head 3700MHz Oct.30,2014 3700 MHz OK 3846 Head 5200MHz Oct.24,2014 5200 MHz OK 3846 Head 5500MHz Oct.24,2014 5500 MHz OK 3846 Head 5800MHz Oct.24,2014 5800 MHz OK 3846 Body 750MHz Oct.25,2014 750 MHz OK 3846 Body 850MHz Oct.25,2014 850 MHz OK 3846 Body 900MHz Oct.26,2014 900 MHz OK 3846 Body 1750MHz Oct.27,2014 1750 MHz OK 3846 Body 1810MHz Oct.27,2014 1810 MHz OK 3846 Body 1900MHz Oct.28,2014 1900 MHz OK 3846 Body 1950MHz Oct.28,2014 1950 MHz OK 3846 Body 2000MHz Oct.28,2014 2000 MHz OK 3846 Body 2100MHz Oct.28,2014 2100 MHz OK 3846 Body 2300MHz Oct.29,2014 2300 MHz OK 3846 Body 2450MHz Oct.29,2014 2450 MHz OK 3846 Body 2550MHz Oct.29,2014 2550 MHz OK 3846 Body 2600MHz Oct.29,2014 2600 MHz OK 3846 Body 3500MHz Oct.30,2014 3500 MHz OK 3846 Body 3700MHz Oct.30,2014 3700 MHz OK 3846 Body 5200MHz Oct.24,2014 5200 MHz OK 3846 Body 5500MHz Oct.24,2014 5500 MHz OK 3846 Body 5800MHz Oct.24,2014 5800 MHz OK No. I15Z41083-SEM01 Page 117 of 168 ©Copyright. All rights reserved by CTTL. ANNEX G Probe Calibration Certificate Probe 3846 Calibration Certificate No. I15Z41083-SEM01 Page 118 of 168 ©Copyright. All rights reserved by CTTL. No. I15Z41083-SEM01 Page 119 of 168 ©Copyright. All rights reserved by CTTL. No. I15Z41083-SEM01 Page 120 of 168 ©Copyright. All rights reserved by CTTL. No. I15Z41083-SEM01 Page 121 of 168 ©Copyright. All rights reserved by CTTL. No. I15Z41083-SEM01 Page 122 of 168 ©Copyright. All rights reserved by CTTL. No. I15Z41083-SEM01 Page 123 of 168 ©Copyright. All rights reserved by CTTL. No. I15Z41083-SEM01 Page 124 of 168 ©Copyright. All rights reserved by CTTL. No. I15Z41083-SEM01 Page 125 of 168 ©Copyright. All rights reserved by CTTL. No. I15Z41083-SEM01 Page 126 of 168 ©Copyright. All rights reserved by CTTL. No. I15Z41083-SEM01 Page 127 of 168 ©Copyright. All rights reserved by CTTL. No. I15Z41083-SEM01 Page 128 of 168 ©Copyright. All rights reserved by CTTL. ANNEX H Dipole Calibration Certificate 835 MHz Dipole Calibration Certificate No. I15Z41083-SEM01 Page 129 of 168 ©Copyright. All rights reserved by CTTL. No. I15Z41083-SEM01 Page 130 of 168 ©Copyright. All rights reserved by CTTL. No. I15Z41083-SEM01 Page 131 of 168 ©Copyright. All rights reserved by CTTL. No. I15Z41083-SEM01 Page 132 of 168 ©Copyright. All rights reserved by CTTL. No. I15Z41083-SEM01 Page 133 of 168 ©Copyright. All rights reserved by CTTL. No. I15Z41083-SEM01 Page 134 of 168 ©Copyright. All rights reserved by CTTL. No. I15Z41083-…

Text truncated - open the document above for the full version.

TEST REPORT No. I14Z41083-GTE03 for TCL Communication Ltd. HSUPA/HSDPA/UMTS quadbands / GSM quadbands/LTE Six -band mobile phone Model Name: 5065A FCC ID: 2ACCJA004 with Hardware Version: PIO Software Version: A5X Issued Date: 2015-06-08 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of CTTL. Test Laboratory: FCC 2.948 Listed: No.525429 CTTL,Telecommunication Technology Labs, Academy of Telecommunication Research, MIIT No. 52, Huayuan North Road, Haidian District, Beijing, P. R. China 100191 Tel:+86(0)10-62304633-2512, Fax:+86(0)10-62304633-2504 Email: [email protected] , website: www.chinattl.com No. I14Z41083-GTE03 Page 2 of 86 ©Copyright. All rights reserved by CTTL. REPORT HISTORY Report Number Revision Description Issue Date I15Z41083-GTE03 Rev.0 1st edition 2015-06-08 No. I14Z41083-GTE03 Page 3 of 86 ©Copyright. All rights reserved by CTTL. CONTENTS 1. TEST LABORATORY .............................................................................................................. 4 1.1. TESTING LOCATION .......................................................................................................... 4 1.2. TESTING ENVIRONMENT .................................................................................................. 4 1.3. PROJECT DATA .................................................................................................................. 4 1.4. SIGNATURE ........................................................................................................................ 4 2. CLIENT INFORMATION .......................................................................................................... 5 2.1. APPLICANT INFORMATION............................................................................................... 5 2.2. MANUFACTURER INFORMATION ..................................................................................... 5 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................ 6 3.1. ABOUT EUT ........................................................................................................................ 6 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ................................... 6 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ...................................... 6 3.4. GENERAL DESCRIPTION .................................................................................................. 7 4. REFERENCE DOCUMENTS .................................................................................................. 8 4.1. REFERENCE DOCUMENTS FOR TESTING ...................................................................... 8 5. LABORATORY ENVIRONMENT ............................................................................................ 9 6. SUMMARY OF TEST RESULTS ........................................................................................... 10 6.1. SUMMARY OF TEST RESULTS ....................................................................................... 10 6.2. STATEMENTS ................................................................................................................... 11 7. TEST EQUIPMENTS UTILIZED ............................................................................................ 12 ANNEX A: MEASUREMENT RESULTS ...................................................................................... 13 A.1 OUTPUT POWER ............................................................................................................. 13 A.2 EMISSION LIMIT ...................................................…
