1 English - CJB34N601AAA Quick Start Guide Thank you for buying ALCATEL ONETOUCH 5065W. We hope you will enjoy your high-quality mobile communication experience. For more information about how to use your cellphone, for answers to frequently asked questions, and to download the complete user manual please visit www.alcatelonetouch.us.


 5065W Pop3-5 4G_5065W_USA_QG_20150901.indd 12015/9/1 17:45:20 23 PROTECT YOUR HEARING To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use. www.sar-tick.com This product meets applicable national SAR limits of 1.6 W/kg. The specific maximum SAR values can be found on page 30 of this user guide. When carrying the product or using it while worn on your body, either use an approved accessory such as a holster or otherwise maintain a distance of 10 mm from the body to ensure compliance with RF exposure requirements. Note that the product may be transmitting even if you are not making a phone call. 1 Your mobile ������������������ 1�1 Keys and connectors Micro-USB Connector Front camera Headset connector Proximity & Light Sensor Home key Touch screen Back key Menu key Table of contents 1 Your mobile ���������������������������������������������������������������������3 2 Text input ����������������������������������������������������������������������14 3 Phone call ����������������������������������������������������������������������15 4 Contacts ������������������������������������������������������������������������17 5 Messaging�����������������������������������������������������������������������18 6 Email ������������������������������������������������������������������������������19 7 Getting connected ��������������������������������������������������������20 8 Find my location using GPS satellites ������������������������22 9 Data backup ������������������������������������������������������������������23 10 Factory data reset ��������������������������������������������������������23 11 Applications & Internal storage ����������������������������������24 12 Making the most of your phone ����������������������������������25 Safety and use �������������������������������������������������������������������������26 General information ��������������������������������������������������������������34 Warranty ���������������������������������������������������������������������������������35 Troubleshooting����������������������������������������������������������������������38 LED indicator Pop3-5 4G_5065W_USA_QG_20150901.indd 2-32015/9/1 17:45:20 45 Camera Camera Flash/ Flashlight Power key Volume key Back key • Touch to go back to the previous screen, or to close a dialog box, options menu, the notification panel, etc. Home key • From any application or screen, touch to return to the Home screen. • Long press to pop up Google search icon. Slide your finger to the icon to open Google search. Menu key • Touch to view recently used applications. Power key • Press: Lock the screen/Light up the screen. • Press and hold: Show the popup menu to select from Power off/Restart/Airplane mode. • Press and hold the Power key and Volume up key to reset. • Press and hold the Power key and Volume down key to capture a screenshot. • Press and hold the power key for at least 10 seconds to force reboot or hold it longer to power off. Volume Keys • In call mode, adjusts the earpiece or headset volume. • In Music/Video/Streaming mode, adjusts the media volume. • In general mode, adjusts the ringtone volume. • Mutes the ringtone of an incoming call. • In camera preview mode, press Volume up or down key to enter burst shoot. Pop3-5 4G_5065W_USA_QG_20150901.indd 4-52015/9/1 17:45:21 67 1�2 Getting started 1�2�1 Set up Removing or installing the back cover Inserting or removing the SIM card You must insert your SIM card to make phone calls. Place the SIM card with the chip facing downwards and slide it into its housing. Make sure that it is correctly inserted. To remove the SIM card, press and slide it out. Your phone only supports micro-SIM card. Do not attempt to insert other SIM types like mini and nano cards, otherwise you may damage your phone. Installing the microSD card Place the microSD card with the chip facing downwards and slide it into its housing. Make sure that it is correctly inserted. To remove the microSD card, press and slide it out. Charging the battery To charge the battery, connect the charger to your phone and outlet. You can also charge your phone via a USB cable. To reduce power consumption and energy waste, when the battery is fully charged, disconnect your charger; switch off Wi-Fi, GPS, Bluetooth or background-running applications when not in use; reduce the backlight time, etc. 1�2�2 Power on your phone Hold down the Power key until the phone powers on. It will take a few seconds before the screen lights up. Set up your phone for the first time The first time you power on the phone, you should set the following options: Language, Google account, etc. Even if no SIM card is installed, your phone will still power on and you will be able to connect to a Wi-Fi network, sign into your Google account and use some of the phone's features. 1�2�3 Power off your phone Hold down the Power key from the Home screen until the phone options appear, select Power off. Pop3-5 4G_5065W_USA_QG_20150901.indd 6-72015/9/1 17:45:38 89 1�3 Home screen You can move all of the items (applications, shortcuts, folders and widgets) you use most frequently to your Home screen for quick access. Touch the Home key to switch to the Home screen. Touch to enter application list. Status bar • Status/Notification indicators • Touch and drag down to open the notification panel. Touch an icon to open an application, folder, etc. Favorite tray applications • Touch to enter the application. • Long press to move or change applications. Search bar • Touch  to en…

Text truncated - open the document above for the full version.

TCL Communication Ltd. 5F, C building, No. 232, Liang Jing Road, ZhangJiang High-Tech Park, Pudong Shanghai, P.R. China. 201203 Tel: +86 21 6146 0666 Fax: +86 21 6146 0602 http://tclcom.tcl.com Date 2015-08-13 To: Federal Communications Commission, Authorization & Evaluation Division, 7345 Oakland Mills Road Columbia, MD 21046 And American Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: CTTL-Terminals Test Lab of China Academy of Telecommunication Research of MIIT is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, which includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR1.2002 (b) to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you. Regards, Zhizhou GONG Product Certification Manager TCL Communication Ltd.

TCL Communication Ltd. 5F, C building, No. 232, Liang Jing Road, ZhangJiang High-Tech Park, Pudong Shanghai, P.R. China. 201203 Tel: +86 21 6146 0666 Fax: +86 21 6146 0602 http://tclcom.tcl.com 2015-08-13 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: 2ACCJA006 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: - Block Diagram - Schematics - Operational Description - BOM list/Tune-Up-Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Yours Sincerely, Zhizhou GONG Product Certification Manager TCL Communication Ltd.

EUT photograph

EUT Interior photograph Mobile Phone Mobile Phone Disassembly Mobile Phone Disassembly Mobile Phone Disassembly Mobile Phone Disassembly Mobile Phone Disassembly Mobile Phone Disassembly

©Copyright. All rights reserved by CTTL. SAR TEST REPORT No. I15Z42002-SEM01 For TCL Communication Ltd. HSUPA/HSDPA/UMTS quadbands / GSM quadbands/LTE Six -band mobile phone Model name: 5065W With Hardware Version: PIO Software Version: A5X FCC ID: 2ACCJA006 Issued Date: 2015-08-31 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of CTTL. Test Laboratory: CTTL, Telecommunication Technology Labs, Academy of Telecommunication Research, MIIT No. 51 Shouxiang Science Building, Xueyuan Road, Haidian District, Beijing, P. R. China100191 Te l:+86(0)10-62304633-2512,Fax:+86(0)10-62304633-2504 Email: [email protected], website:www.chinattl.com TESTING CNAS L0570 No. I15Z42002-SEM01 Page 2 of 209 ©Copyright. All rights reserved by CTTL. REPORT HISTORY Report Number Revision Issue Date Description I15Z42002-SEM01 Rev.0 2015-08-31 Initial creation of test report No. I15Z42002-SEM01 Page 3 of 209 ©Copyright. All rights reserved by CTTL. TABLE OF CONTENT 1 TEST LABORATORY ................................................................................................................. 5 1.1 TESTING LOCATION ........................................................................................................................................ 5 1.2 TESTING ENVIRONMENT ................................................................................................................................. 5 1.3 PROJECT DATA ............................................................................................................................................... 5 1.4 SIGNATURE ..................................................................................................................................................... 5 2 STATEMENT OF COMPLIANCE ................................................................................................ 6 3 CLIENT INFORMATION.............................................................................................................. 8 3.1 APPLICANT INFORMATION .............................................................................................................................. 8 3.2 MANUFACTURER INFORMATION ..................................................................................................................... 8 4 EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ................................ 9 4.1 ABOUT EUT ................................................................................................................................................... 9 4.2 INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST .......................................................................... 9 4.3 INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ........................................................................... 10 5 TEST METHODOLOGY ............................................................................................................ 10 5.1 APPLICABLE LIMIT REGULATIONS ................................................................................................................ 10 5.2 APPLICABLE MEASUREMENT STANDARDS .................................................................................................... 10 6 SPECIFIC ABSORPTION RATE (SAR) .................................................................................... 11 6.1 INTRODUCTION ............................................................................................................................................. 11 6.2 SAR DEFINITION .......................................................................................................................................... 11 7 TISSUE SIMULATING LIQUIDS ............................................................................................... 12 7.1 TARGETS FOR TISSUE SIMULATING LIQUID .................................................................................................... 12 7.2 DIELECTRIC PERFORMANCE ......................................................................................................................... 12 8 SYSTEM VERIFICATION .......................................................................................................... 19 8.1 SYSTEM SETUP ............................................................................................................................................. 19 8.2 SYSTEM VERIFICATION ................................................................................................................................. 20 8.3 JUSTIFICATION FOR EXTENDED SAR DIPOLE CALIBRATIONS ....................................................................... 20 9 MEASUREMENT PROCEDURES ............................................................................................ 21 9.1 TESTS TO BE PERFORMED ............................................................................................................................. 21 9.2 GENERAL MEASUREMENT PROCEDURE ........................................................................................................ 23 9.3 WCDMA MEASUREMENT PROCEDURES FOR SAR ...................................................................................... 24 9.4 SAR MEASUREMENT FOR LT E ..................................................................................................................... 25 9.5 BLUETOOTH & WI-FI MEASUREMENT PROCEDURES FOR SAR .................................................................... 25 9.6 POWER DRIFT ............................................................................................................................................... 26 10 AREA SCAN BASED 1-G SAR .............................................................................................. 26 10.1 REQUIREMENT OF KDB ..........................................…

Text truncated - open the document above for the full version.

No. I15Z42002-SEM01 Page 74 of 209 ©Copyright. All rights reserved by CTTL. Combined standard uncertainty ∑ = = 21 1 22' i iic ucu 9.25 9.12 257 Expanded uncertainty (confidence interval of 95 %) ce uu2= 18.5 18.2 16.2 Measurement Uncertainty for Normal SAR Tests (3~6GHz) No. Error Description Type Uncertainty value Probably Distribution Div. (Ci) 1g (Ci) 10g Std. Unc. (1g) Std. Unc. (10g) Degree of freedo m Measurement system 1 Probe calibration B 6.5 N 1 1 1 6.5 6.5 ∞ 2 Isotropy B 4.7 R 3 0.7 0.7 1.9 1.9 ∞ 3 Boundary effect B 2.0 R 3 1 1 1.2 1.2 ∞ 4 Linearity B 4.7 R 3 1 1 2.7 2.7 ∞ 5 Detection limit B 1.0 R 3 1 1 0.6 0.6 ∞ 6 Readout electronics B 0.3 R 3 1 1 0.3 0.3 ∞ 7 Response time B 0.8 R 3 1 1 0.5 0.5 ∞ 8 Integration time B 2.6 R 3 1 1 1.5 1.5 ∞ 9 RF ambient conditions-noise B 0 R 3 1 1 0 0 ∞ 10 RF ambient conditions-reflection B 0 R 3 1 1 0 0 ∞ 11 Probe positioned mech. restrictions B 0.8 R 3 1 1 0.5 0.5 ∞ 12 Probe positioning with respect to phantom shell B 6.7 R 3 1 1 3.9 3.9 ∞ 13 Post-processing B 4.0 R 3 1 1 2.3 2.3 ∞ Test sample related 14 Test sample positioning A 3.3 N 1 1 1 3.3 3.3 71 15 Device holder uncertainty A 3.4 N 1 1 1 3.4 3.4 5 16 Drift of output power B 5.0 R 3 1 1 2.9 2.9 ∞ Phantom and set-up 17 Phantom uncertainty B 4.0 R 3 1 1 2.3 2.3 ∞ 18 Liquid conductivity (target) B 5.0 R 3 0.64 0.43 1.8 1.2 ∞ 19 Liquid conductivity (meas.) A 2.06 N 1 0.64 0.43 1.32 0.89 43 No. I15Z42002-SEM01 Page 75 of 209 ©Copyright. All rights reserved by CTTL. 20 Liquid permittivity (target) B 5.0 R 3 0.6 0.49 1.7 1.4 ∞ 21 Liquid permittivity (meas.) A 1.6 N 1 0.6 0.49 1.0 0.8 521 Combined standard uncertainty ∑ = = 21 1 22' i iic ucu 10.8 10.7 257 Expanded uncertainty (confidence interval of 95 %) ce uu2= 21.6 21.4 16.3 Measurement Uncertainty for Fast SAR Tests (300MHz~3GHz) No. Error Description Type Uncertainty value Probably Distribution Div. (Ci) 1g (Ci) 10g Std. Unc. (1g) Std. Unc. (10g) Degree of freedo m Measurement system 1 Probe calibration B 5.5 N 1 1 1 5.5 5.5 ∞ 2 Isotropy B 4.7 R 3 0.7 0.7 1.9 1.9 ∞ 3 Boundary effect B 1.0 R 3 1 1 0.6 0.6 ∞ 4 Linearity B 4.7 R 3 1 1 2.7 2.7 ∞ 5 Detection limit B 1.0 R 3 1 1 0.6 0.6 ∞ 6 Readout electronics B 0.3 R 3 1 1 0.3 0.3 ∞ 7 Response time B 0.8 R 3 1 1 0.5 0.5 ∞ 8 Integration time B 2.6 R 3 1 1 1.5 1.5 ∞ 9 RF ambient conditions-noise B 0 R 3 1 1 0 0 ∞ 10 RF ambient conditions-reflection B 0 R 3 1 1 0 0 ∞ 11 Probe positioned mech. Restrictions B 0.4 R 3 1 1 0.2 0.2 ∞ 12 Probe positioning with respect to phantom shell B 2.9 R 3 1 1 1.7 1.7 ∞ 13 Post-processing B 1.0 R 3 1 1 0.6 0.6 ∞ 14 Fast SAR z-Approximation B 7.0 R 3 1 1 4.0 4.0 ∞ Test sample related 15 Test sample positioning A 3.3 N 1 1 1 3.3 3.3 71 16 Device holder uncertainty A 3.4 N 1 1 1 3.4 3.4 5 17 Drift of output power B 5.0 R 3 1 1 2.9 2.9 ∞ No. I15Z42002-SEM01 Page 76 of 209 ©Copyright. All rights reserved by CTTL. Phantom and set-up 18 Phantom uncertainty B 4.0 R 3 1 1 2.3 2.3 ∞ 19 Liquid conductivity (target) B 5.0 R 3 0.64 0.43 1.8 1.2 ∞ 20 Liquid conductivity (meas.) A 2.06 N 1 0.64 0.43 1.32 0.89 43 21 Liquid permittivity (target) B 5.0 R 3 0.6 0.49 1.7 1.4 ∞ 22 Liquid permittivity (meas.) A 1.6 N 1 0.6 0.49 1.0 0.8 521 Combined standard uncertainty ∑ = = 22 1 22' i iic ucu 10.1 9.95 257 Expanded uncertainty (confidence interval of 95 %) ce uu2= 20.2 19.9 16.4 Measurement Uncertainty for Fast SAR Tests (3~6GHz) No. Error Description Type Uncertainty value Probably Distribution Div. (Ci) 1g (Ci) 10g Std. Unc. (1g) Std. Unc. (10g) Degree of freedo m Measurement system 1 Probe calibration B 6.5 N 1 1 1 6.5 6.5 ∞ 2 Isotropy B 4.7 R 3 0.7 0.7 1.9 1.9 ∞ 3 Boundary effect B 2.0 R 3 1 1 1.2 1.2 ∞ 4 Linearity B 4.7 R 3 1 1 2.7 2.7 ∞ 5 Detection limit B 1.0 R 3 1 1 0.6 0.6 ∞ 6 Readout electronics B 0.3 R 3 1 1 0.3 0.3 ∞ 7 Response time B 0.8 R 3 1 1 0.5 0.5 ∞ 8 Integration time B 2.6 R 3 1 1 1.5 1.5 ∞ 9 RF ambient conditions-noise B 0 R 3 1 1 0 0 ∞ 10 RF ambient conditions-reflection B 0 R 3 1 1 0 0 ∞ 11 Probe positioned mech. Restrictions B 0.8 R 3 1 1 0.5 0.5 ∞ 12 Probe positioning with respect to phantom shell B 6.7 R 3 1 1 3.9 3.9 ∞ 13 Post-processing B 1.0 R 3 1 1 0.6 0.6 ∞ 14 Fast SAR z-Approximation B 14.0 R 3 1 1 8.1 8.1 ∞ Test sample related No. I15Z42002-SEM01 Page 77 of 209 ©Copyright. All rights reserved by CTTL. 15 Test sample positioning A 3.3 N 1 1 1 3.3 3.3 71 16 Device holder uncertainty A 3.4 N 1 1 1 3.4 3.4 5 17 Drift of output power B 5.0 R 3 1 1 2.9 2.9 ∞ Phantom and set-up 18 Phantom uncertainty B 4.0 R 3 1 1 2.3 2.3 ∞ 19 Liquid conductivity (target) B 5.0 R 3 0.64 0.43 1.8 1.2 ∞ 20 Liquid conductivity (meas.) A 2.06 N 1 0.64 0.43 1.32 0.89 43 21 Liquid permittivity (target) B 5.0 R 3 0.6 0.49 1.7 1.4 ∞ 22 Liquid permittivity (meas.) A 1.6 N 1 0.6 0.49 1.0 0.8 521 Combined standard uncertainty ∑ = = 22 1 22' i iic ucu 13.3 13.2 257 Expanded uncertainty (confidence interval of 95 %) ce uu2= 26.6 26.4 17 MAIN TEST INSTRUMENTS Table 17.1: List of Main Instruments No. Name Type Serial Number Calibration Date Valid Period 01 Network analyzer E5071C MY46110673 February 03, 2015 One year 02 Power meter NRVD 102196 March 03, 2015 One year 03 Power sensor NRV-Z5 100596 04 Signal Generator E4438C MY49071430 February 02, 2015 One Year 05 Amplifier 60S1G4 0331848 No Calibration Requested 06 BTS E5515C MY50263375 January 30, 2015 One year 07 BTS CMW500 129942 March 03, 2015 One year 08 E-field Probe SPEAG EX3DV4 3846 September 24, 2014 One year 09 DAE SPEAG DAE4 777 September 17, 2014 One year 10 Dipole Validation Kit SPEAG D750V3 1017 August 28, 2014 One year 11 Dipole Validation Kit SPEAG D835V2 4d069 August 28, 2014 One year 12 Dipole Validation Kit SPEAG D1750V2 1003 August 18, 2014 One year 13 Dipole Validation Kit SPEAG D1900V2 5d142 June 23, 2015 One year 14 Dipole Validation Kit SPEAG D2450V2 853 July 24, 2014 One year 15 Dipole Validation Kit SPEAG D2600V2 1012 July 16, 2014 Two year ***END OF REPORT BODY*** No. I15Z42002-SEM01 Page 78 of 209 ©Copyright. …

Text truncated - open the document above for the full version.

No. I15Z42002-SEM01 Page 122 of 209 ©Copyright. All rights reserved by CTTL. Wifi 802.11b Left Tilt Channel 6 Date: 2015-5- 18 Electronics: DAE4 Sn777 Medium: Head 2450 MHz Medium parameters used (interpolated): f = 2437 MHz; σ = 1.804 mho/m; ε r = 38.302; ρ = 1000 kg/m 3 Ambient Temperature: 22.5 o C Liquid Temperature: 22.0 o C Communication System: WLan 2450 Frequency: 2437 MHz Duty Cycle: 1:1 Probe: EX3DV4 - SN3846 ConvF(6.56, 6.56, 6.56) Tilt Middle/Area Scan (81x141x1): Interpolated grid: dx=1.000 mm, dy=1.000 mm Maximum value of SAR (interpolated) = 1.18 W/kg Tilt Middle/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 12.21 V/m; Power Drift = 0.07 dB Peak SAR (extrapolated) = 2.42 W/kg SAR(1 g) = 0.981 W/kg; SAR(10 g) = 0.423 W/kg Maximum value of SAR (measured) = 1.18 W/kg Fig.23 2450 MHz No. I15Z42002-SEM01 Page 123 of 209 ©Copyright. All rights reserved by CTTL. Fig. 23-1 Z-Scan at power reference point (2450 MHz) No. I15Z42002-SEM01 Page 124 of 209 ©Copyright. All rights reserved by CTTL. Wifi 802.11b Body Rear Channel 6 Date: 2015-5- 18 Electronics: DAE4 Sn777 Medium: Body 2450 MHz Medium parameters used (interpolated): f = 2437 MHz; σ = 1.936 mho/m; ε r = 52.773; ρ = 1000 kg/m 3 Ambient Temperature: 22.5 o C Liquid Temperature: 22.0 o C Communication System: WLan 2450 Frequency: 2437 MHz Duty Cycle: 1:1 Probe: EX3DV4 - SN3846 ConvF(6.90, 6.90, 6.90) Rear Middle/Area Scan (121x81x1): Interpolated grid: dx=1.000 mm, dy=1.000 mm Maximum value of SAR (interpolated) = 0.597 W/kg Rear Middle/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 5.544 V/m; Power Drift = -0.06 dB Peak SAR (extrapolated) = 1.28 W/kg SAR(1 g) = 0.606 W/kg; SAR(10 g) = 0.262 W/kg Maximum value of SAR (measured) = 0.813 W/kg Fig.24 2450 MHz No. I15Z42002-SEM01 Page 125 of 209 ©Copyright. All rights reserved by CTTL. Fig. 24-1 Z-Scan at power reference point (2450 MHz) No. I15Z42002-SEM01 Page 126 of 209 ©Copyright. All rights reserved by CTTL. ANNEX B System Verification Results 750MHz Date: 2015-8- 13 Electronics: DAE4 Sn777 Medium: Head 750 MHz Medium parameters used: f = 750 MHz; σ = 0.917 mho/m; ε r = 43.02; ρ = 1000 kg/m 3 Ambient Temperature: 23.0 o C Liquid Temperature: 22.5 o C Communication System: CW Frequency: 750 MHz Duty Cycle: 1:1 Probe: EX3DV4 - SN3846 ConvF(9.53, 9.53, 9.53) System Validation /Area Scan (81x191x1): Interpolated grid: dx=1.000 mm, dy=1.000 mm Reference Value = 49.677 V/m; Power Drift = 0.08 dB Fast SAR: SAR(1 g) = 2.09 W/kg; SAR(10 g) = 1.37 W/kg Maximum value of SAR (interpolated) = 2.24 W/kg System Validation /Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 49.677 V/m; Power Drift = 0.08 dB Peak SAR (extrapolated) = 2.93 W/kg SAR(1 g) = 2.06 W/kg; SAR(10 g) = 1.35 W/kg Maximum value of SAR (measured) = 2.22 W/kg 0 dB = 2.22 W/kg = 3.46 dB W/kg Fig.B.1 validation 750MHz 250mW No. I15Z42002-SEM01 Page 127 of 209 ©Copyright. All rights reserved by CTTL. 750MHz Date: 2015-8- 13 Electronics: DAE4 Sn777 Medium: Body750 MHz Medium parameters used: f = 750 MHz; σ = 0.951 mho/m; ε r = 56.84; ρ = 1000 kg/m 3 Ambient Temperature: 23.0 o C Liquid Temperature: 22.5 o C Communication System: CW Frequency: 750 MHz Duty Cycle: 1:1 Probe: EX3DV4 - SN3846 ConvF(9.18, 9.18, 9.18) System Validation/Area Scan (81x191x1): Interpolated grid: dx=1.000 mm, dy=1.000 mm Reference Value = 51.77 V/m; Power Drift = -0.09 dB Fast SAR: SAR(1 g) = 2.23 W/kg; SAR(10 g) = 1.49 W/kg Maximum value of SAR (interpolated) = 2.38 W/kg System Validation/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 51.77 V/m; Power Drift = -0.09 dB Peak SAR (extrapolated) = 3.11 W/kg SAR(1 g) = 2.21 W/kg; SAR(10 g) = 1.47 W/kg Maximum value of SAR (measured) = 2.36 W/kg 0 dB = 2.36 W/kg = 3.73 dB W/kg Fig.B.2 validation 750MHz 250mW No. I15Z42002-SEM01 Page 128 of 209 ©Copyright. All rights reserved by CTTL. 835MHz Date: 2015-8- 15 Electronics: DAE4 Sn777 Medium: Head 850 MHz Medium parameters used: f = 835 MHz; σ = 0.925 S/m; ε r = 42.27; ρ = 1000 kg/m 3 Ambient Temperature: 23.0 o C Liquid Temperature: 22.5 o C Communication System: CW Frequency: 835 MHz Duty Cycle: 1:1 Probe: EX3DV4 - SN3846 ConvF(9.18, 9.18, 9.18) System Validation /Area Scan (81x161x1): Interpolated grid: dx=1.000 mm, dy=1.000 mm Reference Value = 54.109 V/m; Power Drift = -0.04 dB Fast SAR: SAR(1 g) = 2.38 W/kg; SAR(10 g) = 1.57 W/kg Maximum value of SAR (interpolated) = 2.59 W/kg System Validation /Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 54.109 V/m; Power Drift = -0.04 dB Peak SAR (extrapolated) = 3.66 W/kg SAR(1 g) = 2.40 W/kg; SAR(10 g) = 1.58 W/kg Maximum value of SAR (measured) = 2.61 W/kg 0 dB = 2.61 W/kg = 4.17 dBW/kg Fig.B.3 validation 835MHz 250mW No. I15Z42002-SEM01 Page 129 of 209 ©Copyright. All rights reserved by CTTL. 835MHz Date: 2015-8- 15 Electronics: DAE4 Sn777 Medium: Body 850 MHz Medium parameters used: f = 835 MHz; σ = 0.962 S/m; ε r = 55.98; ρ = 1000 kg/m 3 Ambient Temperature: 23.0 o C Liquid Temperature: 22.5 o C Communication System: CW Frequency: 835 MHz Duty Cycle: 1:1 Probe: EX3DV4 - SN3846 ConvF(9.09, 9.09, 9.09) System Validation /Area Scan (81x171x1): Interpolated grid: dx=1.000 mm, dy=1.000 mm Reference Value = 52.279 V/m; Power Drift = -0.06 dB Fast SAR: SAR(1 g) = 2.28 W/kg; SAR(10 g) = 1.51 W/kg Maximum value of SAR (interpolated) = 2.49 W/kg System Validation /Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 52.279 V/m; Power Drift = -0.06 dB Peak SAR (extrapolated) = 3.47 W/kg SAR(1 g) = 2.31 W/kg; SAR(10 g) = 1.53 W/kg Maximum value of SAR (measured) = 2.51 W/kg 0 dB = 2.51 W/kg = 4.00 dBW/kg Fig.B.4 validation 835MHz 250mW No. I15Z42002-SEM01 Page 130 of 209 ©Copyright. All rights reserved by CTTL. 1750MHz Date: 2015-8- 12 Electronics: DAE4 Sn777 Medium: Head 1750 MHz Medium parameters used: f=17…

Text truncated - open the document above for the full version.

No. I15Z42002-SEM01 Page 184 of 209 ©Copyright. All rights reserved by CTTL. No. I15Z42002-SEM01 Page 185 of 209 ©Copyright. All rights reserved by CTTL. 1900 MHz Dipole Calibration Certificate No. I15Z42002-SEM01 Page 186 of 209 ©Copyright. All rights reserved by CTTL. No. I15Z42002-SEM01 Page 187 of 209 ©Copyright. All rights reserved by CTTL. No. I15Z42002-SEM01 Page 188 of 209 ©Copyright. All rights reserved by CTTL. No. I15Z42002-SEM01 Page 189 of 209 ©Copyright. All rights reserved by CTTL. No. I15Z42002-SEM01 Page 190 of 209 ©Copyright. All rights reserved by CTTL. No. I15Z42002-SEM01 Page 191 of 209 ©Copyright. All rights reserved by CTTL. No. I15Z42002-SEM01 Page 192 of 209 ©Copyright. All rights reserved by CTTL. No. I15Z42002-SEM01 Page 193 of 209 ©Copyright. All rights reserved by CTTL. 2450 MHz Dipole Calibration Certificate No. I15Z42002-SEM01 Page 194 of 209 ©Copyright. All rights reserved by CTTL. No. I15Z42002-SEM01 Page 195 of 209 ©Copyright. All rights reserved by CTTL. No. I15Z42002-SEM01 Page 196 of 209 ©Copyright. All rights reserved by CTTL. No. I15Z42002-SEM01 Page 197 of 209 ©Copyright. All rights reserved by CTTL. No. I15Z42002-SEM01 Page 198 of 209 ©Copyright. All rights reserved by CTTL. No. I15Z42002-SEM01 Page 199 of 209 ©Copyright. All rights reserved by CTTL. No. I15Z42002-SEM01 Page 200 of 209 ©Copyright. All rights reserved by CTTL. No. I15Z42002-SEM01 Page 201 of 209 ©Copyright. All rights reserved by CTTL. 2600 MHz Dipole Calibration Certificate No. I15Z42002-SEM01 Page 202 of 209 ©Copyright. All rights reserved by CTTL. No. I15Z42002-SEM01 Page 203 of 209 ©Copyright. All rights reserved by CTTL. No. I15Z42002-SEM01 Page 204 of 209 ©Copyright. All rights reserved by CTTL. No. I15Z42002-SEM01 Page 205 of 209 ©Copyright. All rights reserved by CTTL. No. I15Z42002-SEM01 Page 206 of 209 ©Copyright. All rights reserved by CTTL. No. I15Z42002-SEM01 Page 207 of 209 ©Copyright. All rights reserved by CTTL. No. I15Z42002-SEM01 Page 208 of 209 ©Copyright. All rights reserved by CTTL. No. I15Z42002-SEM01 Page 209 of 209 ©Copyright. All rights reserved by CTTL. ANNEX I Accreditation Certificate

SUPA/HS est results in duced except Laboratory: , Telecommun 2, HuayuanNo 86(0)10-62304 :cttl_terminals N SDPA/UM this test rep in full without nication Techn orth Road, Haid 4633-2512,Fax [email protected], we FCC TES No. I15 TCL C MTS quad m MOD FCC Hardw Softw Issued ort relate onl the written a p ology Labs, A dian District, B x:+86(0)10-62 bsite:www.chi C PAR STRE Z4200 for Communi dbands / mobile p DEL NAM with C ID: 2AC ware Ver ware Vers d Date: 2 y to the devi pproval of CTT Academy of Te Beijing, P. R. C 2304633-2504 inattl.com C RT 15 EPOR 02-SR ication L GSM qu phone ME: 5065W h CCJA006 rsion: PI sion: A5 2015-08-2 ces specified TL. elecommunica China 100191 4 TESTING CNAS L0570 ©Copyright. A 5C RT RD01 Ltd. uadbands W 6 O 5X 24 in this repor tion Research . All rights reser s/LTE Six rt. This report h, MIIT rved by CTTL. x -band t shall not be . e REP Repo I15Z4 PORT H ort Number 42002-SRD HISTORY r 01 Y Revision Rev.0 D 1 Description st edition No. I1 ©Copyright. A 15Z42002 Page2 All rights reser Issue Date 2015-08-24 2-SRD01 2 of 94 rved by CTTL. e 4 . CO 1. T 1.1. 1.2. 1.3. 1.4. 2. C 2.1. 2.2. 3. E 3.1. 3.2. 3.3. 3.4. 3.5. 4. R 4.1. 4.2. 5. T 5.1. 5.2. 5.3. 6. T ANN A.1. A.2. A. 2 A.2 A.3. A.4. A.5. A.6. T NTENTS TEST LABO TESTING TESTING PROJECT SIGNATU CLIENTINF APPLIC A MANUFA EQUIPMEN ABOUT E INTERNA INTERNA GENERA INTERPR REFERENC DOCUME REFEREN TEST RESU SUMMAR STATEME TEST CO TEST FACIL EX A: DETA MEASUREM MAXIMUM 2.1. PEAK OU 2.2. AVERAG PEAK POW DTS 6-DB S BAND EDG TRANSMIT S ORATORY .. GLOCATION GENVIRONM T DATA ...... URE ............ ORMATIO N ANT INFO…
