1 English - CJB35HEALAAA Quick Start Guide Thank you for buying ALCATEL ONETOUCH 5054S. We hope you will enjoy your high-quality mobile communication experience. For more information about how to use your cellphone, please visit www.alcatelonetouch.com to download the complete user manual. From the website, you can consult the FAQ, perform software upgrades, etc.




TM 5054S 23 PROTECT YOUR HEARING To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use. www.sar-tick.com This product meets applicable national SAR limits of 1.6 W/kg. The specific maximum SAR values can be found on page 31 of this user guide. When carrying the product or using it while worn on your body, either use an approved accessory such as a holster or otherwise maintain a distance of 15 mm from the body to ensure compliance with RF exposure requirements. Note that the product may be transmitting even if you are not making a phone call. 1 Your mobile ������������������ 1�1 Keys and connectors Micro-USB Connector Front camera Headset connector Proximity & Light Sensor Home key Touch screen Back key Menu key Table of Contents 1 Your mobile ���������������������������������������������������������������������3 2 Text input ����������������������������������������������������������������������14 3 Phone call ����������������������������������������������������������������������15 4 Contacts ������������������������������������������������������������������������17 5 Messaging�����������������������������������������������������������������������18 6 Email ������������������������������������������������������������������������������19 7 Getting connected ��������������������������������������������������������20 8 Find my location using GPS satellites ������������������������22 9 Data backup ������������������������������������������������������������������22 10 Factory data reset ��������������������������������������������������������23 11 Applications & Internal storage ����������������������������������23 12 Making the most of your phone ����������������������������������24 Safety and use �������������������������������������������������������������������������26 General information ��������������������������������������������������������������35 Warranty ���������������������������������������������������������������������������������36 Troubleshooting����������������������������������������������������������������������38 LED indicator 45 Camera Camera Flash/ Flashlight Power key Volume key Back key • Touch to go back to the previous screen, or to close a dialog box, options menu, the notification panel, etc. Home key • From any application or screen, touch to return to the Home screen. • Long press to pop up Google search icon. Slide your finger to the icon to open Google search. Menu key • Touch to view recently used applications. • Touch to close any appliaction. • Touch the brush icon on the bottom of the screen to close all applications. Power key • Press: Lock the screen/Light up the screen. • Press and hold: Show the popup menu to select from Power off/Restart/Aeroplane mode. • Press and hold the Power key and Volume down key to capture a screenshot. • Press and hold the power key for 8 seconds to power off or hold it for 10 seconds or more to force reboot. Volume Keys • In call mode, adjusts the earpiece or headset volume. • In Music/Video/Streaming mode, adjusts the media volume. • In general mode, adjusts the ringtone volume. • Mutes the ringtone of an incoming call. • In camera preview mode, press Volume up or down key to enter burst shoot. 67 1�2 Getting started 1�2�1 Set up Removing or installing the back cover Inserting or removing the SIM card You must insert your SIM card to make phone calls. Place the SIM card with the chip facing downwards and slide it into its housing. Make sure that it is correctly inserted. To remove the SIM card, press and slide it out. Your phone only supports micro-SIM card. Do not attempt to insert other SIM types like mini and nano cards, otherwise you may damage your phone. Installing the microSD card Place the microSD card with the chip facing downwards and slide it into its housing. Make sure that it is correctly inserted. To remove the microSD card, press and slide it out. Charging the battery To charge the battery, connect the charger to your phone and mains socket. You can also charge your phone via a USB cable. To reduce power consumption and energy waste, when the battery is fully charged, disconnect your charger; switch off Wi-Fi, GPS, Bluetooth or background-running applications when not in use; reduce the backlight time, etc. 1�2�2 Power on your phone Hold down the Power key until the phone powers on. It will take a few seconds before the screen lights up. Set up your phone for the first time The first time you power on the phone, you should set the following options: Language, Date and time, etc. Even if no SIM card is installed, your phone will still power on and you will be able to connect to a Wi-Fi network, set up screen lock and use some of the phone's features. 1�2�3 Power off your phone Hold down the Power key from the Home screen until the phone options appear, select Power off. 89 1�3 Home screen You can move all of the items (applications, shortcuts, folders and widgets) you use most frequently to your Home screen for quick access. Touch the Home key to switch to the Home screen. Touch to enter application list. Status bar • Status/Notification indicators • Touch and drag down to open the notification panel. Touch an icon to open an application, folder, etc. Favorite tray applications • Touch to enter the application. • Long press to move or change applications. Search bar • Touch  to enter text search screen. • Touch  to enter voice search screen. The Home screen is provided in an extended format to allow more space for adding…

Text truncated - open the document above for the full version.

TCL Communication Ltd. 5F, C building, No. 232, Liang Jing Road, ZhangJiang High-Tech Park, Pudong Shanghai, P.R. China. 201203 Tel: +86 21 6146 0666 Fax: +86 21 6146 0602 http://tclcom.tcl.com Date 2015-08-26 To: Federal Communications Commission, Authorization & Evaluation Division, 7345 Oakland Mills Road Columbia, MD 21046 And American Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: CTTL-Terminals Test Lab of China Academy of Telecommunication Research of MIIT is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, which includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR1.2002 (b) to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you. Regards, Zhizhou GONG Product Certification Manager TCL Communication Ltd.

TCL Communication Ltd. 5F, C building, No. 232, Liang Jing Road, ZhangJiang High-Tech Park, Pudong Shanghai, P.R. China. 201203 Tel: +86 21 6146 0666 Fax: +86 21 6146 0602 http://tclcom.tcl.com 2015-08-26 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: 2ACCJA010 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: - Block Diagram - Schematics - Operational Description - BOM list/Tune-Up-Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Yours Sincerely, Zhizhou GONG Product Certification Manager TCL Communication Ltd.

EUT photograph Mobile Phone Mobile Phone Mobile Phone Mobile Phone Mobile Phone Mobile Phone Mobile phone Charger AE1 Label of Charger AE1 USB Cable AE2 USB Cable AE3 Battery AE4 Battery AE4-1 Headset AE5 Headset AE6

EUT Interior photograph Mobile Phone Mobile Phone Disassembly Mobile Phone Disassembly Mobile Phone Disassembly Mobile Phone Disassembly Mobile Phone Disassembly

©Copyright. All rights reserved by CTTL. TEST REPORT No. I15Z41929-EMC01 for TCL Communication Ltd GSM Quad-band / UMTS Tri-band / LTE Six-band mobile phone Model Name: 5054S FCC ID: 2ACCJA010 with Hardware Version: 05 Software Version: 010 01 Issued Date: 2015-08-26 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of CTTL. Test Laboratory: FCC 2.948 Listed: No.525429 IC O.A.T.S listed: No.12389A-1 CTTL,Telecommunication Technology Labs, Academy of Telecommunication Research, MIIT No. 52, Huayuan North Road, Haidian District, Beijing, P. R. China 100191. Te l:+86(0)10-62304633-2512, Fax:+86(0)10-62304633-2504 Email: [email protected], website: www.chinattl.com No.I15Z41929-EMC01 Page 2 of 21 ©Copyright. All rights reserved by CTTL. REPORT HISTORY Report Number Revision Description Issue Date I15Z41929-EMC01 Rev.0 1 st edition 2015-08-26 No.I15Z41929-EMC01 Page 3 of 21 ©Copyright. All rights reserved by CTTL. CONTENTS 1. TEST LABORATORY .............................................................................................................. 4 1.1. TESTING LOCATION .......................................................................................................... 4 1.2. TESTING ENVIRONMENT .................................................................................................. 4 1.3. PROJECT DATA .................................................................................................................. 4 1.4. SIGNATURE ........................................................................................................................ 4 2. CLIENT INFORMATION .......................................................................................................... 5 2.1. APPLICANT INFORMATION............................................................................................... 5 2.2. MANUFACTURER INFORMATION ..................................................................................... 5 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................ 6 3.1. ABOUT EUT ........................................................................................................................ 6 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ................................... 6 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ...................................... 6 3.4. EUT SET-UPS ..................................................................................................................... 7 4. REFERENCE DOCUMENTS .................................................................................................. 8 4.1. REFERENCE DOCUMENTS FOR TESTING ...................................................................... 8 5. LABORATORY ENVIRONMENT ............................................................................................ 9 6. SUMMARY OF TEST RESULTS ........................................................................................... 10 7. TEST EQUIPMENTS UTILIZED ............................................................................................ 11 ANNEX A: MEASUREMENT RESULTS ...................................................................................... 12 No.I15Z41929-EMC01 Page 4 of 21 ©Copyright. All rights reserved by CTTL. 1. Test Laboratory 1.1. Testing Location Location 1: CTTL(huayuan North Road) Address: No. 52, Huayuan North Road, Haidian District, Beijing, P. R. China 100191 1.2. Testing Environment Normal Temperature: 15-35°C Relative Humidity: 20-75% 1.3. Project data Testing Start Date: 2015-08-19 Testing End Date: 2015-08-25 1.4. Signature Wang Junqing (Prepared this test report) Qu Pengfei (Reviewed this test report) Liu Baodian Deputy Director of the laboratory (Approved this test report) No.I15Z41929-EMC01 Page 5 of 21 ©Copyright. All rights reserved by CTTL. 2. Client Information 2.1. Applicant Information Company Name: TCL Communication Ltd Address /Post: 5F, C building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 City: Shanghai Postal Code: 201203 Country: P. R. China Contact Person: Gong Zhizhou Contact Email [email protected] Telephone: 0086-21-51798260 Fax: 0086-21-61460602 2.2. Manufacturer Information Company Name: TCL Communication Ltd Address /Post: 5F, C building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 City: Shanghai Postal Code: 201203 Country: P. R. China Telephone: 0086-21-51798260 Fax: 0086-21-61460602 No.I15Z41929-EMC01 Page 6 of 21 ©Copyright. All rights reserved by CTTL. 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description GSM Quad-band / UMTS Tri-band / LTE Six-band mobile phone Model Name 5054S FCC ID 2ACCJA010 Extreme vol. Limits 3.5VDC to 4.35VDC (nominal: 3.8VDC) Note: Components list, please refer to documents of the manufacturer; it is also included in the original test record of CTTL,Telecommunication Technology Labs, Academy of Telecommunication Research, MIIT. 3.2. Internal Identification of EUT used during the test EUT ID* SN or IMEI HW Version SW Version EUT1 014452000010857 05 010 01 *EUT ID: is used to identify the test sample in the lab internally. 3.3. Internal Identification of AE used during the test AE ID* Description SN Remarks AE1 Battery / Inbuilt AE2 Travel / 15TCT-CH-0917 AE3 USB cable / 15TCT-DC-0231 AE4 USB cable / 15TCT-DC-0099 AE1 Model CAC2500028C2 Manufacturer SCUD(LG) Capacitance 2500 mAh Nominal voltage 3.7 V AE2 Model CBA0057AG0C1 Manufacturer BYD Length of cable / AE3 Model CDA3122002C2 Manufacturer Shenhua Length of cable 92cm AE4 Model CDA3122002C8 Manufacturer Puan Length of cable 93cm *AE ID: is used to identify the test sample in the lab internally. No.I15Z41929-EMC01 Page 7 of 21 ©Copyright. All rights reserved by CTTL.…
