2ACCJB001CDMA 1X/EVDO tri-band mobile phone

TCL Communication Ltd.

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: Oct 21, 2014
Application Purpose: Original Equipment
Date of Application: Oct 15, 2014
Equipment Note: CDMA 1X/EVDO tri-band mobile phone
Frequency Range: 817.90000000 - 823.10000000
Company: TCL Communication Ltd.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

User Guide [Boost_Alcatel_Soul4 EVDO_UG_EN_20140911_Draft1] [UG template version 13b] TOC i Table of Contents Your Phone at a Glance .......................................................................................................... 1 Set Up Your Phone ................................................................................................................. 1 Activation and Service ............................................................................................................. 2 Create Your Account and Pick Your Plan ....................................................................... 2 Activate Your Phone ........................................................................................................ 3 Manage Your Account ..................................................................................................... 3 Re-Boost .......................................................................................................................... 4 Additional Information ...................................................................................................... 4 Complete the Setup Screens .................................................................................................. 4 Set Up Voicemail ..................................................................................................................... 5 Your Phone’s Layout ............................................................................................................... 7 Turn Your Phone On and Off .................................................................................................. 8 Turn Your Screen On and Off ................................................................................................. 9 Touchscreen Navigation .......................................................................................................... 9 Your Home Screen ................................................................................................................ 12 Home Screen Overview ................................................................................................. 13 Customize the Home Screen ......................................................................................... 13 Status Bar .............................................................................................................................. 14 Enter Text .............................................................................................................................. 15 Touchscreen Keyboards ................................................................................................ 15 Android Keyboard .......................................................................................................... 16 Swype ............................................................................................................................. 17 Google Voice Typing ...................................................................................................... 17 Tips for Editing Text ....................................................................................................... 18 Make Phone Calls ................................................................................................................. 20 Call Using the Phone Dialer ........................................................................................... 20 Call from Call Logs ......................................................................................................... 21 Call from Contacts ......................................................................................................... 21 Call a Number in a Text Message or Email Message ................................................... 22 Call Emergency Numbers .............................................................................................. 22 TOC ii Receive Phone Calls ............................................................................................................. 22 Voicemail ............................................................................................................................... 24 Voicemail Setup ............................................................................................................. 24 Voicemail Notification ..................................................................................................... 24 Retrieve Your Voicemail Messages ............................................................................... 25 Visual Voicemail .................................................................................................................... 25 Listen to Multiple Voicemail Messages ......................................................................... 25 Phone Call Options ............................................................................................................... 26 In-call Options ................................................................................................................ 26 Caller ID ......................................................................................................................... 27 Call Waiting .................................................................................................................... 27 Conference Calling ........................................................................................................ 29 Call Forwarding .............................................................................................................. 30 Call Logs ................................................................................................................................ 30 Call Settings .......................................................................................................................... 31 Voicemail Settings ............................................…

Text truncated - open the document above for the full version.

Cover Letter(s)

5F, C building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 TEL: +86(0)21 61460666 FAX: +86(0)21 61460602 Date 2014- 10-10 To: Federal Communications Commission, Authorization & Evaluation Division, 7345 Oakland Mills Road Columbia, MD 21046 And American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: TMC (Telecommunication Metrology Center of MIIT) is authorized to act on our behalf, until otherwise notified, for applications to American Telecommunications Certification Body, Inc. (ATCB). We certify that we are not subject to denial of federal benefits, which includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR1.2002 (b) to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you. Regards, Gong Zhizhou Approval Team Leader TCT Mobile Limited

Cover Letter(s)

5F, C building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 TEL: +86(0)21 61460666 FAX: +86(0)21 61460602 2014-10-10 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: 2ACCJB001 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: - Block Diagram - Schematics - Operational Description - BOM list The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Yours Sincerely, Zhizhou Gong Approval Team Leader TCT Mobile Limited

External Photos

EUT photograph Mobile Phone Mobile Phone Mobile Phone Mobile Phone Mobile Phone Mobile Phone Mobile Phone Battery AE1 Battery AE1 Charger AE2 Label of Charger AE2 Data Cable AE3

Internal Photos

EUT Interior photograph Mobile Phone Mobile Phone Disassembly Mobile Phone Disassembly Mobile Phone Disassembly

RF Exposure Info

No.I14Z47644-SEM01 Page 1 of 106 ©Copyright. All rights reserved by TMC Beijing. SAR TEST REPORT No. I14Z47644-SEM01 For TCL Communication Ltd. CDMA 1X/EVDO tri-band mobile phone Model Name: 4037V With Hardware Version: VC Software Version: V5HT3-5 FCC ID: 2ACCJB001 Issued Date: 2014-09-29 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. Test Laboratory: TMC Beijing, Telecommunication Metrology Center of MIIT No. 52, Huayuan Bei Road, Haidian District, Beijing, P. R. China 100191. Tel:+86(0)10-62304633-2079, Fax:+86(0)10-62304633 Email:[email protected]. www.emcite.com No. I14Z47644-SEM01 Page 2 of 106 Revision Version Report Number Revision Date Memo I14Z47644-SEM01 0 2014-09-29 Initial creation of test report No. I14Z47644-SEM01 Page 3 of 106 TABLE OF CONTENT 1 TEST LABORATORY .................................................................................................................... 5 1.1 TESTING LO C AT I O N ........................................................................................................................................ 5 1.2 TESTING ENVIRONMENT ................................................................................................................................. 5 1.3 PROJECT DATA ............................................................................................................................................... 5 1.4 SIGNATURE ..................................................................................................................................................... 5 2 STATEMENT OF COMPLIANCE .................................................................................................. 6 3 CLIENT INFORMATION ................................................................................................................ 7 3.1 APPLICANT INFORMATION .............................................................................................................................. 7 3.2 MANUFACTURER INFORMATION ..................................................................................................................... 7 4 EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ................................. 8 4.1 ABOUT EUT ................................................................................................................................................... 8 4.2 INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST .......................................................................... 8 4.3 INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ............................................................................ 8 5 TEST METHODOLOGY ................................................................................................................ 9 5.1 APPLICABLE LIMIT REGULATIONS .................................................................................................................. 9 5.2 APPLICABLE MEASUREMENT STANDARDS ...................................................................................................... 9 6 SPECIFIC ABSORPTION RATE (SAR) ...................................................................................... 10 6.1 INTRODUCTION ............................................................................................................................................. 10 6.2 SAR DEFINITION .......................................................................................................................................... 10 7 TISSUE SIMULATING LIQUIDS ................................................................................................. 11 7.1 TARGETS FOR TISSUE SIMULATING LIQUID .................................................................................................... 11 7.2 DIELECTRIC PERFORMANCE ......................................................................................................................... 11 8 SYSTEM VERIFICATION ............................................................................................................ 15 8.1 SYSTEM SETUP ............................................................................................................................................. 15 8.2 SYSTEM VERIFICATION ................................................................................................................................. 16 9 MEASUREMENT PROCEDURES .............................................................................................. 17 9.1 TESTS TO BE PERFORMED ............................................................................................................................. 17 9.2 GENERAL MEASUREMENT PROCEDURE ........................................................................................................ 18 9.3 BLUETOOTH & WI-FI MEASUREMENT PROCEDURES FOR SAR .................................................................... 19 9.4 POWER DRIFT ............................................................................................................................................... 20 10 AREA SCAN BASED 1-G SAR ................................................................................................. 20 10.1 REQUIREMENT OF KDB .............................................................................................................................. 20 10.2 FAST SAR ALGORITHMS ............................................................................................................................ 20 11 CONDUCTED OUTPUT POWER .............................................................................................. 21 11.1 MANUFACTURING TOLERANCE ................................................................................................................... 21 No. I14Z47644-SEM01 Page 4 of 106 11.2 …

Text truncated - open the document above for the full version.

RF Exposure Info

No. I14Z47644-SEM01 Page 71 of 106 ANNEX F System Validation The SAR system must be validated against its performance specifications before it is deployed. When SAR probes, system components or software are changed, upgraded or recalibrated, these must be validated with the SAR system(s) that operates with such components. Table F.1: System Validation Probe SN. Liquid name Validation date Frequency point Status (OK or Not) 3846 Head 750MHz Mar. 06, 2014 750 MHz OK 3846 Head 850MHz Mar. 06, 2014 850 MHz OK 3846 Head 900MHz Mar. 01, 2014 900 MHz OK 3846 Head 1750MHz Mar. 03, 2014 1750 MHz OK 3846 Head 1810MHz Mar. 03, 2014 1810 MHz OK 3846 Head 1900MHz Mar. 07, 2014 1900 MHz OK 3846 Head 1950MHz Mar. 04, 2014 1950 MHz OK 3846 Head 2000MHz Mar. 04, 2014 2000 MHz OK 3846 Head 2100MHz Mar. 05, 2014 2100 MHz OK 3846 Head 2300MHz Mar. 05, 2014 2300 MHz OK 3846 Head 2450MHz Mar. 02, 2014 2450 MHz OK 3846 Head 2550MHz Mar. 08, 2014 2550 MHz OK 3846 Head 2600MHz Mar. 08, 2014 2600 MHz OK 3846 Head 3500MHz Mar. 09, 2014 3500 MHz OK 3846 Head 3700MHz Mar. 09, 2014 3700 MHz OK 3846 Head 5200MHz Mar. 10, 2014 5200 MHz OK 3846 Head 5500MHz Mar. 10, 2014 5500 MHz OK 3846 Head 5800MHz Mar. 10, 2014 5800 MHz OK 3846 Body 750MHz Mar. 06, 2014 750 MHz OK 3846 Body 850MHz Mar. 06, 2014 850 MHz OK 3846 Body 900MHz Mar. 01, 2014 900 MHz OK 3846 Body 1750MHz Mar. 03, 2014 1750 MHz OK 3846 Body 1810MHz Mar. 03, 2014 1810 MHz OK 3846 Body 1900MHz Mar. 07, 2014 1900 MHz OK 3846 Body 1950MHz Mar. 04, 2014 1950 MHz OK 3846 Body 2000MHz Mar. 04, 2014 2000 MHz OK 3846 Body 2100MHz Mar. 05, 2014 2100 MHz OK 3846 Body 2300MHz Mar. 05, 2014 2300 MHz OK 3846 Body 2450MHz Mar. 02, 2014 2450 MHz OK 3846 Body 2550MHz Mar. 08, 2014 2550 MHz OK 3846 Body 2600MHz Mar. 08, 2014 2600 MHz OK 3846 Body 3500MHz Mar. 09, 2014 3500 MHz OK 3846 Body 3700MHz Mar. 09, 2014 3700 MHz OK 3846 Body 5200MHz Mar. 10, 2014 5200 MHz OK 3846 Body 5500MHz Mar. 10, 2014 5500 MHz OK 3846 Body 5800MHz Mar. 10, 2014 5800 MHz OK No. I14Z47644-SEM01 Page 72 of 106 ANNEX G Probe Calibration Certificate Probe 3801 Calibration Certificate No. I14Z47644-SEM01 Page 73 of 106 No. I14Z47644-SEM01 Page 74 of 106 No. I14Z47644-SEM01 Page 75 of 106 No. I14Z47644-SEM01 Page 76 of 106 No. I14Z47644-SEM01 Page 77 of 106 No. I14Z47644-SEM01 Page 78 of 106 No. I14Z47644-SEM01 Page 79 of 106 No. I14Z47644-SEM01 Page 80 of 106 No. I14Z47644-SEM01 Page 81 of 106 No. I14Z47644-SEM01 Page 82 of 106 No. I14Z47644-SEM01 Page 83 of 106 ANNEX H Dipole Calibration Certificate 835 MHz Dipole Calibration Certificate No. I14Z47644-SEM01 Page 84 of 106 No. I14Z47644-SEM01 Page 85 of 106 No. I14Z47644-SEM01 Page 86 of 106 No. I14Z47644-SEM01 Page 87 of 106 No. I14Z47644-SEM01 Page 88 of 106

RF Exposure Info

No. I14Z47644-SEM01 Page 89 of 106 No. I14Z47644-SEM01 Page 90 of 106 No. I14Z47644-SEM01 Page 91 of 106 1900 MHz Dipole Calibration Certificate No. I14Z47644-SEM01 Page 92 of 106 No. I14Z47644-SEM01 Page 93 of 106 No. I14Z47644-SEM01 Page 94 of 106 No. I14Z47644-SEM01 Page 95 of 106 No. I14Z47644-SEM01 Page 96 of 106 No. I14Z47644-SEM01 Page 97 of 106 No. I14Z47644-SEM01 Page 98 of 106 No. I14Z47644-SEM01 Page 99 of 106 2450 MHz Dipole Calibration Certificate No. I14Z47644-SEM01 Page 100 of 106 No. I14Z47644-SEM01 Page 101 of 106 No. I14Z47644-SEM01 Page 102 of 106 No. I14Z47644-SEM01 Page 103 of 106 No. I14Z47644-SEM01 Page 104 of 106 No. I14Z47644-SEM01 Page 105 of 106 No. I14Z47644-SEM01 Page 106 of 106

Test Report

No.I14Z47644-CTE01 Page1 of 43 TEST REPORT No. I14Z47644-CTE01 for TCL Communication Ltd. CDMA 1X/EVDO tri-band mobile phone Model Name: 4037V FCC ID: 2ACCJB001 with Hardware Version: VC Software Version: V5HT3-5 Issued Date: 2014-10-10 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. Test Laboratory: DAR accreditation (DIN EN ISO/IEC 17025): No. D-PL-12123-01-01 FCC 2.948 Listed: No.733176 IC O.A.T.S listed: No.6629B TMC Beijing, Telecommunication Metrology Center of Ministry of Industry and Information Technology 3/F Shou Xiang Technology Building, No.51 Xueyuan Road, Hai Dian District, Beijing, P. R. China,100191. Tel:+86(0)10-62304633-2604, Fax:+86(0)10-62304793, Email:[email protected], web: www.emcite.com No.I14Z47644-CTE01 Page2 of 43 CONTENTS 1. TEST LABORATORY ......................................................................................................................... 3 1.1. TESTING LOCATION .................................................................................................................... 3 1.2. TESTING ENVIRONMENT ........................................................................................................... 3 1.3. PROJECT DATA .............................................................................................................................. 3 1.4. SIGNATURE ..................................................................................................................................... 3 2. CLIENT INFORMATION ................................................................................................................... 4 2.1. APPLICANT INFORMATION ....................................................................................................... 4 2.2. MANUFACTURER INFORMATION ............................................................................................ 4 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................. 5 3.1. ABOUT EUT ..................................................................................................................................... 5 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST .................................... 5 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ....................................... 5 3.4. GENERAL DESCRIPTION ............................................................................................................ 6 4. REFERENCE DOCUMENTS ............................................................................................................. 6 4.1. REFERENCE DOCUMENTS FOR TESTING ............................................................................. 6 5. LABORATORY ENVIRONMENT ..................................................................................................... 7 6. SUMMARY OF TEST RESULTS ....................................................................................................... 8 7. TEST EQUIPMENTS UTILIZED ...................................................................................................... 8 ANNEX A: MEASUREMENT RESULTS .................................................................................................. 9 A.1 OUTPUT POWER (§22.913(A)/§24.232(B)/§27.50(D)(2)) ......................................................... 9 A.2 FREQUENCY STABILITY (§2.1055/§24.235/§27.54) ................................................................ 10 A.3 OCCUPIED BANDWIDTH (§2.1049(H)(I)) ................................................................................. 13 A.4 EMISSION BANDWIDTH (§22.917(B)/§24.238(B)) .................................................................. 17 A.5 BAND EDGE COMPLIANCE (§22.917(B)/§24.238(B)/ §27.53(G)) ........................................... 21 A.6 CONDUCTED SPURIOUS EMISSION (§2.1057/§22.917/§24.238/§27.53(G)) .......................... 23 No.I14Z47644-CTE01 Page3 of 43 1. Test Laboratory 1.1. Testing Location Company Name: TMC Beijing, Telecommunication Metrology Center of MIIT Address: 3/F Shou Xiang Technology Building, No.51 Xueyuan Road, Hai Dian District, Beijing, P. R. China Postal Code: 100191 Telephone: 00861062304633 Fax: 00861062304793 1.2. Testing Environment Normal Temperature: 15-35°C Relative Humidity: 20-75% 1.3. Project data Testing Start Date: Sept 17th,2014 Testing End Date: Sept 24th,2014 1.4. Signature Zi Xiaogang (Prepared this test report) Sun Xiangqian (Reviewed this test report) Lu Bingsong Deputy Director of the laboratory (Approved this test report) No.I14Z47644-CTE01 Page4 of 43 2. Client Information 2.1. Applicant Information Company Name: TCL Communication Ltd. Address /Post: 12F/B, TCL Tower, Gaoxin Nanyi Road, Nanshan District, Shenzhen, Guangdong,P.R. China City: Shenzhen Postal Code: 518057 Country: China Contact Person: Lv Meixian Contact Email: [email protected] Telephone: 0086 755 33956929 Fax: 0086 755 36645072 2.2. Manufacturer Information Company Name: TCL Communication Ltd. Address /Post: 12F/B, TCL Tower, Gaoxin Nanyi Road, Nanshan District, Shenzhen, Guangdong,P.R. China City: Shenzhen Postal Code: 518057 Country: China Contact Person: Lv Meixian Contact Email: [email protected] Telephone: 0086 755 33956929 Fax: 0086 755 36645072 No.I14Z47644-CTE01 Page5 of 43 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description CDMA 1X/EVDO tri-band mobile phone Model 4037V FCC ID 2ACCJB001 Frequency CDMA800MHz(BC0);CDMA1900MHz(BC1);Secondary800MHz(BC10) Antenna Internal Power supply Battery or Charger (AC Adaptor) Extreme vol. Limits 3.5VDC to 4.2VDC (nominal: 3.7 VDC) Extreme temp. Tolerance -30°C to +50°C Note: Components list, please refer to documents of the manufacturer; it is also included in the original test record of Telecommunication Metrology Center of MIIT of People’s Republic of C…

Text truncated - open the document above for the full version.

Test Report

No. I14Z47644-CTE02 Page1 of 23 TEST REPORT No. I14Z47644-CTE02 for TCL Communication Ltd. CDMA 1X/EVDO tri-band mobile phone Model Name: 4037V FCC ID: 2ACCJB001 with Hardware Version: VC Software Version: V5HT3-5 Issued Date: 2014-10-10 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. Test Laboratory: DAR accreditation (DIN EN ISO/IEC 17025): No. D-PL-12123-01-01 FCC 2.948 Listed: No.733176 IC O.A.T.S listed: No.6629B TMC Beijing, Telecommunication Metrology Center of Ministry of Industry and Information Technology 3/F Shou Xiang Technology Building, No.51 Xueyuan Road, Hai Dian District, Beijing, P. R. China,100191. Tel:+86(0)10-62304633-2604, Fax:+86(0)10-62304793, Email:[email protected], web: www.emcite.com No. I14Z47644-CTE02 Page2 of 23 CONTENTS 1. TEST LABORATORY ......................................................................................................................... 3 1.1. TESTING LOCATION .................................................................................................................... 3 1.2. TESTING ENVIRONMENT ........................................................................................................... 3 1.3. PROJECT DATA .............................................................................................................................. 3 1.4. SIGNATURE ..................................................................................................................................... 3 2. CLIENT INFORMATION ................................................................................................................... 4 2.1. APPLICANT INFORMATION ....................................................................................................... 4 2.2. MANUFACTURER INFORMATION ............................................................................................ 4 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................. 5 3.1. ABOUT EUT ..................................................................................................................................... 5 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST .................................... 5 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ....................................... 5 3.4. NORMAL ACCESSORY SETTING ............................................................................................... 5 3.5. GENERAL DESCRIPTION ............................................................................................................ 5 4. REFERENCE DOCUMENTS ............................................................................................................. 6 4.1. REFERENCE DOCUMENTS FOR TESTING ............................................................................. 6 5. LABORATORY ENVIRONMENT ..................................................................................................... 7 6. SUMMARY OF TEST RESULTS ....................................................................................................... 8 7. TEST EQUIPMENTS UTILIZED ...................................................................................................... 9 ANNEX A: MEASUREMENT RESULTS ................................................................................................ 10 A.1 OUTPUT POWER ............................................................................................................................. 10 A.2 FREQUENCY STABILITY ................................................................................................................ 11 A.3 OCCUPIED BANDWIDTH .............................................................................................................. 13 A.4 EMISSION BANDWIDTH ................................................................................................................ 15 A.5 CONDUCTED SPURIOUS EMISSION............................................................................................ 17 No. I14Z47644-CTE02 Page3 of 23 1. Test Laboratory 1.1. Testing Location Company Name: TMC Beijing, Telecommunication Metrology Center of MIIT Address: 3/F Shou Xiang Technology Building, No.51 Xueyuan Road, Hai Dian District, Beijing, P. R. China Postal Code: 100191 Telephone: 00861062304633 Fax: 00861062304793 1.2. Testing Environment Normal Temperature: 15-35°C Relative Humidity: 20-75% 1.3. Project data Testing Start Date: Sept 17th,2014 Testing End Date: Sept 24th,2014 1.4. Signature Zi Xiaogang (Prepared this test report) Sun Xiangqian (Reviewed this test report) Lu Bingsong Deputy Director of the laboratory (Approved this test report) No. I14Z47644-CTE02 Page4 of 23 2. Client Information 2.1. Applicant Information Company Name: TCL Communication Ltd. Address /Post: 12F/B, TCL Tower, Gaoxin Nanyi Road, Nanshan District, Shenzhen, Guangdong,P.R. China City: Shenzhen Postal Code: 518057 Country: China Contact Person: Lv Meixian Contact Email: [email protected] Telephone: 0086 755 33956929 Fax: 0086 755 36645072 2.2. Manufacturer Information Company Name: TCL Communication Ltd. Address /Post: 12F/B, TCL Tower, Gaoxin Nanyi Road, Nanshan District, Shenzhen, Guangdong,P.R. China City: Shenzhen Postal Code: 518057 Country: China Contact Person: Lv Meixian Contact Email: [email protected] Telephone: 0086 755 33956929 Fax: 0086 755 36645072 No. I14Z47644-CTE02 Page5 of 23 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description CDMA 1X/EVDO tri-band mobile phone Model 4037V FCC ID 2ACCJB001 Frequency CDMA800MHz(BC0);CDMA1900MHz(BC1);Secondary800MHz(BC10) Antenna Internal Power supply Battery or Charger (AC Adaptor) Extreme vol. Limits 3.5VDC to 4.2VDC (nominal: 3.7 VDC) Extreme temp. Tolerance -30°C to +50°C Note: Components list, please refer to docume…

Text truncated - open the document above for the full version.

Test Report

No. I14Z47644-SEM02 Page 1 of 52 ©Copyright. All rights reserved by TMC Beijing. HAC RF TEST REPORT No. I14Z47644-SEM02 For TCL Communication Ltd. CDMA 1X/EVDO tri-band mobile phone Model Name: 4037V With Hardware Version: VC Software Version: V5HT3-5 FCC ID: 2ACCJB001 Results Summary: M Category = M3 Issued Date: 2…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Ting Wang

[email protected]+8613502294537Fax: +8675536612000-81722

Technical Contact

TMC Beijing, Telecommunication Metrology Center ofXue Zhen

[email protected]86-10-62304633

No. 52, Huayuan Bei Road, Haidian District, · Bei Jing · China

Test Firm

TMC-Telecommunication Metrology Center of M.I.I.TChongwen Song

[email protected]0086-10-62303288Fax: 0086-10-62304793

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
3	9	817.9 MHz - 823.1 MHz	214.30 mW	1M27F9W	0.1 ppm

Confidentiality

Long Term

Grant Notes

Power Output is ERP for Part 22, EIRP for Part 24 and conducted for Part 90. Body-worn operations are restricted to belt-clips, holsters or similar accessories that have no metallic component in the assembly and which provide at least 1.0 cm separation between the device and the users body. End users must be informed of the body worn requirements for satisfying RF Exposure compliance. The highest reported SAR values are: Head: 1.06 W/kg; Body-worn 1.39 W/kg; Product Specific (Wireless Router): 1.39 W/kg; Simultaneous Transmission SAR: 1.57 W/kg. This device contains GSM functions that are not operational in U.S. Territories. This filing is only applicable for 850 MHz Cell and 1900 MHz PCS operations. This device contains Bluetooth, BLE and WLAN transmitter. HAC Rating: M3/T4 - 2011
