2ACCJB016GSM quad band mobile phone

1 8 2 9 3 10 4 11 5 12 6 13 7 14 English - XXXXXXXXXXXX Quick Start Guide www.sar-tick.com This product meets applicable national SAR limits of 1.6 W/kg. The specific maximum SAR values can be found on page 19 of this user guide. When carrying the product or using it while worn on your body, either use an approved accessory such as a holster or otherwise maintain a distance of 1.0 cm from the body to ensure compliance with RF exposure requirements. Note that the product may be transmitting even if you are not making a phone call. The mobile phone is in compliance with the requirement of EN 60950-1: 2006 amendment A12: 2011. There will appear a warning box when the volume level is over 4. If the user selects left soft key in the warning box, the volume can be increased and the phone will repeat the acknowledgement more than once every 20h of cumulative listening time. PROTECT YOUR HEARING To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use. 1 Your mobile ������������������� 1 Left soft key 2 Call logs (idle screen) Send call 3 Voice mail (long key-press) 4 Lock Key (long press key) 5 Right soft key 6 Power on/Power off End call 7 Vibrate alert 8 Navigation key : Menu/Confirm an option Increase volume Decrease volume New SMS Profiles 1 26 3 5 74 8 1�1 Keys Navigation key Confirm an option (press the middle of the key) Send call Access to call log (idle screen) Power on/off the handset (long press) End call Return to idle Left soft key Right soft key Dial the voice mail number (long press) From Idle screen - Press: enter zero - Press and hold: input +, "+" are used for dialing an international call. In Edit mode: - Press: access the Symbols table 0 (add numbers) From Idle screen - Press: input * - Long press: lock keypad In Edit mode: - Press: change input methods From Idle screen - Press: input # - Press and hold: activate/deactivate the vibrator In Edit mode: - Press: input space 1�2 Idle screen icons Battery charge level. Meeting mode: your phone vibrates, but neither rings nor beeps. Silence mode: your phone neither rings, beeps nor vibrates. Flight mode. Headset connected. Alarm clock programmed. Missed calls. Roaming. Level of network reception. Unread SMS. Unread MMS. Message full. Call divert. 2 Getting started ������������ 2�1 Set-up Removing and installing the back cover Removing and installing the battery Inserting and removing TF card Inserting and removing SIM Charging the battery Connect the battery charger to your phone and outlet respectively. • The charging may take about 20 minutes to start if the battery is flat. • Be careful not to force the plug into the socket. • Make sure the battery is correctly inserted before connecting the charger. • The outlet must be near to the phone and easily accessible (avoid electric extension cables). • When using your telephone for the first time, charge the battery fully (approximately 3 hours). You are advised to fully charge the battery ( ). • To reduce power consumption and energy waste, when battery is fully charged, disconnect your charger from the plug; reduce the backlight time, etc. The charge is complete when the animation stops. 2�2 Power on your phone Hold down the key until the phone powers on. 2�3 Power off your phone Hold down the key from the idle screen. 3 Calls ������������������������������� 3�1 Making a call Dial the desired number, press the key to place the call. If you make a mistake, you can delete the incorrect digits by pressing the key. To hang up the call, press the key. Making an emergency call If your phone is covered by the network, dial emergency number and press the key to make an emergency call. This works even without a SIM card and without typing the PIN code or unlocking the keypad. 3�2 Calling your Voice mail (1) You can see SIM voice mail in this menu. 3�3 Receiving a call When you receive an incoming call, press the key to talk and then hang up using the key. 3�4 Available functions during the call During a call, you can use your directory, your calendar, text messages, etc. without hanging up or dropping the call. (1) Contact your network operator to check service availability. 4 Camera ������������������� This function enables you to take pictures. Press to take the picture. 5 Call history ������������� You can access your call memory by pressing from the idle screen, or press the key and select the icon from the menu. In this menu, you will see all call history. 6 Audio player ����������� Use this function to play audio files. Press to play/pause the audio player, short press or to last or next audio, in audio player interface, press and to tune volume. 7 Tools ������������������������ 7�1 Alarm Your mobile phone has a built-in alarm clock with snooze feature. 7�2 Calculator Press the up, down, left, right and OK key to select +, - ×, ÷ and = respectively. Press to delete the figure. 7�3 Calendar Once you enter this menu, there is a monthly-view calendar for you to view the date; you can go to any day you want. 7�4 Notes You can create a note in text format by accessing “Notes” from the main menu. 7�5 Bluetooth You can transfer data, such as music to other device using Bluetooth. Search the device and accept/transfer data. The received data is automatically stored in the directory. 7�6 Unit conversion Unit conversion support weight conversion and length conversion. 7�7 Fake Call You can create fake call through this function. 7�8 Call filter You can create blacklist through this function. 7�9 Torch Turn on/off the torch as per your need. In idle screen, press and hold 5 key to activate/deactivate the torch light. 7�10 Internet service This function enables you to surf the Internet using the mobile phone. Note: Consulting the local network operator for related fee and specific setup. 7�11 STK STK service is the tool kit of SIM card. This phone supports the service function.…

Text truncated - open the document above for the full version.

Authorization Letter FCC ID: 2ACCJB016 Date: 13 May, 2015 To whom it may concern: We, the undersigned, hereby authorize The State Radio_monitoring_center Testing Center (SRTC) to act on our behalf, as our agent, in the following matters related to the FCC approval of our product: Product Name: GSM quad band mobile phone Product Model: 1017D Report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by The State Radio_monitoring_center Testing Center (SRTC) within the scope of this authorization shall have the same effects as our own. This authorization shall expire 2 months from original date. If you have any question regarding the authorization, please don’t hesitate to contact with me. Thank you. Sincerely, Certification Manager TCL Communication Ltd. 5F, E building, No. 232, Liang Jing Road, ZhangJiang High-Tech Park, Pudong Area,Shanghai,201203,P.R.China Tel: +86(0)21 61460666 Fax: +86-021-61460602

TCL Communication Ltd. 5F, C building, No. 232, Liang Jing Road, ZhangJiang High-Tech Park, Pudong Shanghai, P.R. China. 201203 Tel: +86 21 6146 0666 Fax: +86 21 6146 0602 http://tclcom.tcl.com 2015-04-29 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: 2ACCJB012 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: - Block Diagram - Schematics - Operational Description - BOM list/Tune-Up-Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Yours Sincerely, Zhizhou GONG Product Certification Manager TCL Communication Ltd. 0504 2ACCJB016

1017D External Photo Charger view (CBA3002AG0C1) Charger view (CBA0053AG0C4) Headset CCB0010A10C7 View Headset CCB0010A11C7 View The data cable of 1017D (CDA0000030C3) The data cable of 1017D(CDA0000049C3) The battery view (CAB0400000C1) The battery view (CAB0400000C1)

1017D_Australia YES Distribution 包装指导文件 1017D_Australia YES Distribution Packaging Instruction Packaging Instruction IMEI Label IMEI Label 机身标 手机图示仅作参考 Packaging Instruction CU Label (Box) CU Label (Box) Packaging Instruction Group carton label 卡通箱标应当贴在没有卡通箱料号一侧

1017D Internal Photo

D-PL-12111-01-01 CNAS L0447 Registration No.910917 TEST REPORT Report No.: SRTC2015-9003(F)-0001 Product Name: GSM quad band mobile phone Model Name: 1017D Applicant: TCL Communication Ltd. Manufacturer: TCL Communication Ltd. Specification: FCC Part15B (Certification) (October 1, 2009 edition) FCC ID: 2ACCJB016 The State Radio_monitoring_center Testing Center (SRTC) No.80 Beilishi Road Xicheng District Beijing, China Tel: 86-10-68009202 Fax: 86-10-68009205 No.: SRTC2015-9003(F)-0001 FCC ID: 2ACCJB016 The State Radio_monitoring_center Testing Center (SRTC) Page number: 2 of 27 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC CONTENTS 1. General information ......................................................................................... 3 1.1 Notes of the test report ............................................................................................................ 3 1.2 Information about the testing laboratory ................................................................................ 3 1.3 Applicant’s details ..................................................................................................................... 3 1.4 Manufacturer’s details .............................................................................................................. 3 1.5 Application details ..................................................................................................................... 4 1.6 Reference specification............................................................................................................ 4 1.7 Information of EUT.................................................................................................................... 4 1.7.1 General information ....................................................................................................... 4 1.7.2 EUT details ..................................................................................................................... 5 1.7.3 Auxiliary equipment details ........................................................................................... 5 2. Test information ............................................................................................... 7 2.1 Summary of the test results ..................................................................................................... 7 2.2 Test result ................................................................................................................................... 8 2.2.1 Conducted Emissions-FCC Part15.107 ..................................................................... 8 2.2.2 Radiated Emissions-FCC Part15.109 ...................................................................... 18 2.3. List of test equipments .......................................................................................................... 26 Appendix ........................................................................................................... 27 No.: SRTC2015-9003(F)-0001 FCC ID: 2ACCJB016 The State Radio_monitoring_center Testing Center (SRTC) Page number: 3 of 27 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC 1. General information 1.1 Notes of the test report The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written permission of The State Radio_monitoring_center Testing Center (SRTC). The test results relate only to individual items of the samples which have been tested. 1.2 Information about the testing laboratory Company: The State Radio_monitoring_center Testing Center (SRTC) Address: No.80 Beilishi Road, Xicheng District, Beijing China City: Beijing Country or Region: China Contacted person: Wang Junfeng Tel: +86 10 68009181 +86 10 68009202 Fax: +86 10 68009195 +86 10 68009205 Email: [email protected] / [email protected] 1.3 Applicant’s details Company: TCL Communication Ltd. Address: 5F, E building, No. 232, Liang Jing Road, ZhangJiang High-Tech Park, Pudong Area,Shanghai,201203,P.R.China City: Shanghai Country or Region: P.R.China Grantee Code: 2ACCJ Contacted person: Houhua.FAN Tel: +86-21- 61460666 Fax: +86-21- 61460602 Email: [email protected] 1.4 Manufacturer’s details Company: TCL Communication Ltd. Address: 5F, E building, No. 232, Liang Jing Road, ZhangJiang High-Tech Park, Pudong Area,Shanghai,201203,P.R.China City: Shanghai Country or Region: P.R.China Contacted person: Houhua.FAN Tel: +86-21- 61460666 Fax: +86-21- 61460602 Email: [email protected] No.: SRTC2015-9003(F)-0001 FCC ID: 2ACCJB016 The State Radio_monitoring_center Testing Center (SRTC) Page number: 4 of 27 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC 1.5 Application details Date of reception of test sample: 21 st April 2015 Date of test: 21 st April 2015 to 24 th April 2015 1.6 Reference specification FCC Part 15B October 1, 2009 (Certification) 1.7 Information of EUT 1.7.1 General information Name of EUT GSM quad band mobile phone FCC ID 2ACCJB016 Frequency Range GSM850: Tx:824~849MHz Rx:869~894MHz PCS1900: Tx:1850~1910MHz Rx:1930~1990MHz Rated Output Power GSM850:33.0dBm PCS1900:30.0dBm E.R.P. & E.I.R.P. E.R.P.:31.98dBm E.I.R.P.:29.29dBm Modulation Type GSM/GPRS:GMSK Emission Designator GSM/GPRS Duplex Mode FDD Equipment Class Class B Duplex Spacing GSM850:45MHz PCS1900:80MHz Antenna Type Fixed Internal Power Supply Battery or Charger Rated Power Supply Voltage 3.7V Extreme Temperature Lowest: -30°C Highest: +50°C Extreme Voltage Minimum: 3.5V Maximum: 4.2V HW Version 1203_MB_PCB_V0.1 SW Version 1017D_L3EN_V01_150408_MCP32+32_FM_LATAM_AL No.: SRTC2015-9003(F)-0001 FCC ID: 2ACCJB016 The State Radio_monitoring_center Testing Center (SRTC) Page number: 5 of 27 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC 1.7.2 EUT details Product Name Model Name IMEI GSM quad band mobile phone 1017D …

Text truncated - open the document above for the full version.

D-PL-12111-01-01 CNAS L0447 Registration No.910917 TEST REPORT Report No.: SRTC2015-9003(F)-0002 Product Name: GSM quad band mobile phone Model Name: 1017D Applicant: TCL Communication Ltd. Manufacturer: TCL Communication Ltd. Specification: FCC Part15B (Verification) (October 1, 2009 edition) FCC ID: 2ACCJB016 The State Radio_monitoring_center Testing Center (SRTC) No.80 Beilishi Road Xicheng District Beijing, China Tel: 86-10-68009202 Fax: 86-10-68009205 No.: SRTC2015-9003(F)-0002 FCC ID: 2ACCJB016 The State Radio_monitoring_center Testing Center (SRTC) Page number: 2 of 28 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC CONTENTS 1. General information ......................................................................................... 3 1.1 Notes of the test report ............................................................................................................ 3 1.2 Information about the testing laboratory ................................................................................ 3 1.3 Applicant’s details ..................................................................................................................... 3 1.4 Manufacturer’s details .............................................................................................................. 3 1.5 Application details ..................................................................................................................... 4 1.6 Reference specification ............................................................................................................ 4 1.7 Information of EUT ................................................................................................................... 4 1.7.1 General information ....................................................................................................... 4 1.7.2 EUT details ..................................................................................................................... 5 1.7.3 Auxiliary equipment details ........................................................................................... 5 2. Test information ............................................................................................... 7 2.1 Summary of the test results..................................................................................................... 7 2.2 Test result ................................................................................................................................... 8 2.2.1 Conducted Emissions-FCC Part15.107 ..................................................................... 8 2.2.2 Radiated Emissions-FCC Part15.109 ...................................................................... 19 2.3. List of test equipments .......................................................................................................... 27 Appendix ........................................................................................................... 28 No.: SRTC2015-9003(F)-0002 FCC ID: 2ACCJB016 The State Radio_monitoring_center Testing Center (SRTC) Page number: 3 of 28 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC 1. General information 1.1 Notes of the test report The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written permission of The State Radio_monitoring_center Testing Center (SRTC). The test results relate only to individual items of the samples which have been tested. 1.2 Information about the testing laboratory Company: The State Radio_monitoring_center Testing Center (SRTC) Address: No.80 Beilishi Road, Xicheng District, Beijing China City: Beijing Country or Region: China Contacted person: Wang Junfeng Tel: +86 10 68009181 +86 10 68009202 Fax: +86 10 68009195 +86 10 68009205 Email: [email protected] / [email protected] 1.3 Applicant’s details Company: TCL Communication Ltd. Address: 5F, E building, No. 232, Liang Jing Road, ZhangJiang High-Tech Park, Pudong Area,Shanghai,201203,P.R.China City: Shanghai Country or Region: P.R.China Grantee Code: 2ACCJ Contacted person: Houhua.FAN Tel: +86-21- 61460666 Fax: +86-21- 61460602 Email: [email protected] 1.4 Manufacturer’s details Company: TCL Communication Ltd. Address: 5F, E building, No. 232, Liang Jing Road, ZhangJiang High-Tech Park, Pudong Area,Shanghai,201203,P.R.China City: Shanghai Country or Region: P.R.China Contacted person: Houhua.FAN Tel: +86-21- 61460666 Fax: +86-21- 61460602 Email: [email protected] No.: SRTC2015-9003(F)-0002 FCC ID: 2ACCJB016 The State Radio_monitoring_center Testing Center (SRTC) Page number: 4 of 28 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC 1.5 Application details Date of reception of test sample: 21 st April 2015 Date of test: 21 st April 2015 to 24 th April 2015 1.6 Reference specification FCC Part 15B October 1, 2009 (Verification) 1.7 Information of EUT 1.7.1 General information Name of EUT GSM quad band mobile phone FCC ID 2ACCJB016 Frequency Range GSM850: Tx:824~849MHz Rx:869~894MHz PCS1900: Tx:1850~1910MHz Rx:1930~1990MHz Rated Output Power GSM850:33.0dBm PCS1900:30.0dBm E.R.P. & E.I.R.P. E.R.P.:31.98dBm E.I.R.P.:29.29dBm Modulation Type GSM/GPRS:GMSK Emission Designator GSM/GPRS Duplex Mode FDD Equipment Class Class B Duplex Spacing GSM850:45MHz PCS1900:80MHz Antenna Type Fixed Internal Power Supply Battery or Charger Rated Power Supply Voltage 3.7V Extreme Temperature Lowest: -30°C Highest: +50°C Extreme Voltage Minimum: 3.5V Maximum: 4.2V HW Version 1203_MB_PCB_V0.1 SW Version 1017D_L3EN_V01_150408_MCP32+32_FM_LATAM_AL No.: SRTC2015-9003(F)-0002 FCC ID: 2ACCJB016 The State Radio_monitoring_center Testing Center (SRTC) Page number: 5 of 28 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC 1.7.2 EUT details Product Name Marketing Name IMEI GSM quad band mobile phone 1017…

Text truncated - open the document above for the full version.

D-PL-12111-01-01 CNAS L0447 Registration No.910917 Appendix1 TEST SETUP Report No.: SRTC2015-9003(F)-0001 Product Name: GSM quad band mobile phone Model Name: 1017D Applicant: TCL Communication Ltd. Manufacturer: TCL Communication Ltd. Specification: FCC Part15B (Certification) (October 1, 2009 edition) FCC ID: 2ACCJB016 The State Radio_monitoring_center Testing Center (SRTC) No.80 Beilishi Road Xicheng District Beijing, China Tel: 86-10-68009202 Fax: 86-10-68009205 No.: SRTC2015-9003(F)-0001 FCC ID: 2ACCJB016 The State Radio_monitoring_center Testing Center (SRTC) Page number: 2 of 2 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC Appendix1 Test Setup Radiated Emissions Test Setup Conducted Emissions Test Setup

D-PL-12111-01-01 CNAS L0447 Registration No.910917 Appendix1 TEST SETUP Report No.: SRTC2015-9003(F)-0002 Product Name: GSM quad band mobile phone Model Name: 1017D Applicant: TCL Communication Ltd. Manufacturer: TCL Communication Ltd. Specification: FCC Part15B (Verification) (October 1, 2009 edition) FCC ID: 2ACCJB016 The State Radio_monitoring_center Testing Center (SRTC) No.80 Beilishi Road Xicheng District Beijing, China Tel: 86-10-68009202 Fax: 86-10-68009205 No.: SRTC2015-9003(F)-0002 FCC ID: 2ACCJB016 The State Radio_monitoring_center Testing Center (SRTC) Page number: 2 of 2 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC Appendix1 Test Setup Radiated Emissions Test Setup Conducted Emissions Test Setup
