2ACCJB132Mobile WiFi

TCL Communication Ltd.

Click to zoom

Application Details

Equipment Class: PCB - PCS Licensed Transmitter
Date of Grant: Aug 04, 2020
Application Purpose: Original Equipment
Date of Application: Aug 03, 2020
Equipment Note: Mobile WiFi
Frequency Range: 709.00000000 - 711.00000000
Company: TCL Communication Ltd.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

1 CJBXXXXALAAA Quick Start Guide 2 www.sar-tick.com This product meets applicable national SAR limits of 1.6 W/kg. The specific maximum SAR values can be found in the Radio Waves section of this user guide. When carrying the product or using it while worn on your body, either use an approved accessory such as a holster or otherwise maintain a distance of 10 mm from the body to ensure compliance with RF exposure requirements. Note that the product may be transmitting even if you are not surfing the Internet. Safety and use We recommend that you read this chapter carefully before using this device. The manufacturer disclaims any liability for damage, which may result as a consequence of improper use of this device or of use contrary to the instructions contained herein. Do not switch on your device when its use is prohibited or when using the device may cause interference or danger. Follow rules or regulations in hospitals and health care facilities. Switch off your device near medical apparatuses. 3 Switch off your device when on an aircraft. The device may cause interference to aircraft control signals. Switch off your device near high-precision electronic devices. The device may affect the performance of these devices. Do not attempt to disassemble your device or its accessories. Only qualified personnel are allowed to service or repair the device. Do not place your device or its accessories in containers with a strong electromagnetic field. Do not place magnetic storage media near your device. Radiation from the device may erase the information stored on them. Do not subject your device to high temperatures or use it in a place with flammable gas such as a gas station. Keep your device and its accessories away from children. Do not allow children to use your device without guidance. Only use approved batteries and chargers to avoid the risk of explosion. Observe the laws or regulations on device use. Respect others’ privacy and legal rights when using your device. It is recommended that the equipment only be used in an environment where the temperature is between 0°C and 45°C and humidity is between 10% to 90%. 4 CHARGERS Main powered chargers will operate within the temperature range of: 0°C to 40°C. The chargers designed for your device meet with the standard for safety of information technology equipment and office equipment use. Due to different applicable electrical specifications, a charger you purchased in one jurisdiction may not work in another jurisdiction. They should be used for this purpose only. Overview LinkZone is a portable wireless router, providing a simple way to share 4G with any Wi-Fi embedded device. Package contents LinkZoneUSB cable Quick start guideCharger 5 Application LinkZone PC PAD Smart phone Getting to Know Your Device Power key LED indicator WPS key USB jack 6 LED Description PartDescription Power keyHold the “Power” key for 3 seconds to power the device on/ off. WPS keyHold “WPS” key for 3 seconds to activate the WPS function. Once activated, the Wi-Fi LED indicator will flash every two seconds. If the network is not accessed within 2 minutes device will automatically exit WPS mode. LED indicatorsDisplays signal, Wi-Fi, SMS, and battery charge status. Charging / USB Port Use the USB jack to charge your device and connect your device to the client via the USB cable. Reset Hold both “Power” and “WPS” keys simultaneously for 6 seconds. All LED indicators will flash blue 4 times to indicate that the device has been reset to factory mode. RebootHold “Power” key for 10 seconds to restart device. 7 PartDescription Power saving mode • If no buttons are pressed for a period of 30 seconds, all LED lights will turn off automatically. Press any button, charge device, or connect to a computer, to turn on LED lights again. • If no Wi-Fi is accessed for a period of 10 minutes, network dialing ceases automatically. Press any button, or access the device, to turn on Wi-Fi again. • If no Wi-Fi is accessed for a period of 30 minutes, the Wi-Fi AP function will turn off automatically. Press any button to turn on Wi-Fi AP again. Indicators When the hotspot is powered on, the following icons will illuminate. For a description of the icons, please refer to the table below: 8 Network Indicator (Red or Blue LED) Wi-Fi Indicator (Blue LED) SMS Indicator (Blue LED) Battery Indicator (Red or Blue LED) LEDDescription Network Indicator Solid BlueRegistered and connected to network. Flashing BlueNetwork disconnected. Solid RedNo network, no SIM card or SIM card error, limited or no service. Wi-FiSolid BlueWi-Fi is active. SMSSolid BlueNew message Flashing BlueMessage inbox is full. BatterySlow Flashing Blue Working Quick Flashing Blue The battery is charging and is plugged into a power source. Solid BlueThe battery is fully charged and is plugged into a power source. Flashing RedThe battery level is less than 10%. 9 Turning On Your Device Step 1: Remove back cover: Slot Note: Find the slot on the front cover to open. Step 2: Install Micro SIM Card and SD Card: Micro SIM Card 10 Step 3: Install battery: Step 4: Close back cover: Position the back cover so that locating nub is inserted into corresponding indentation (please refer to illustration below) Step 5: Power device on: Long Press the “Power” key until all LED indicators illuminate in blue. Connecting in Wi-Fi mode SSID: locate the SSID information on the sticker on the Back Cover. Step 1: Use the Wi-Fi manager on the Wi-Fi embedded device to select network name (SSID). • From a Windows PC: Right-click Wireless network connection on the task bar, and select: View Available Networks. 11 Choose SSID from the list of available networks. • From a Mac computer: Select System Preferences -> Network -> Airport. Click “Advanced” to choose SSID from the list of available networks. • From an iOS device: Settings -> Wi-Fi. Choose SSID from the available networks. • From an android device: Settings -> Wireless controls -> Wi-Fi settings. C…

Text truncated - open the document above for the full version.

Users Manual

User Manual 2 Contents Safety precautions ......................................................................................................................3 1.. Web.UI.configuration ............................................................................................................4 1.1. Log.into.the.configuration.page .......................................................................................4 1.2. Icon.description ................................................................................................................4 2. Connection ............................................................................................................................4 2.1 Connection information ....................................................................................................4 2.2 Usage information ............................................................................................................5 2.3 Signal & technology information ......................................................................................5 2.4 Battery information ...........................................................................................................5 2.5 Connected devices information........................................................................................5 3.. Usage .....................................................................................................................................5 3.1 Usage information ............................................................................................................5 3.2 Usage setting ...................................................................................................................5 3.3 Clear history .....................................................................................................................6 4.. Message.................................................................................................................................6 5.. Settings..................................................................................................................................6 6. More .......................................................................................................................................7 7. Help ........................................................................................................................................7 8.. Battery.charging ...................................................................................................................8 9. Warranty ................................................................................................................................8 10. FAQ ........................................................................................................................................9 11.. Warning.and.precautions ...................................................................................................11 www.sar-tick.com This.product.meets.applicable.national.SAR.limits.of.1.6 W/kg. The. specific.maximum.SAR. values.can. be. found. in. the. Radio. Waves.section. of this user guide. When. carrying.the. product.or. using. it. while. worn. on. your. body,. either. use. an. approved.accessory.such. as. a. holster.or. otherwise.maintain.a. distance.of. 10. mm. from. the. body. to. ensure.compliance.with. RF. exposure.requirements.. Note. that. the. product.may. be. transmitting.even. if. you. are. not. Surfing.the. Internet. 3 Safety precautions Read. the. safety.precautions.carefully.to. ensure.the. correct.and. safe. use. of. your. wireless.device. Do. not. switch.on. your. device.when. the. device.use. is. prohibited.or. when. the. device. use may cause interference or danger. Follow.the. rules. or. regulations.in. hospitals.and. health.care. facilities..Switch.off. your. device.near.medical.apparatuses. Switch off your device when on an aircraft. The device may cause interference to control signals of the aircraft. Switch.off. your. device.near. high-precision.electronic.devices..The. device.may. affect. the.performance.of.these.devices. Do. not. attempt.to. disassemble.your. device.or. its. accessories..Only. qualified. personnel.are.allowed.to.service.or.repair.the.device. Do. not. place. your. device.or. its. accessories.in. containers.with. strong.electromagnetic. field. Do. not. place. magnetic.storage.media.near. your. device..Radiation.from. the. device. may erase the information stored on them. Do. not. put. your. device.in. a. high-temperature.place. or. use. it. in. a. place. with. flammable. gas such as a gas station. Keep. your. device.and. its. accessories.away. from. children..Do. not. allow. children.to. use your device without guidance. Use.approved.batteries.and.chargers.only.to.avoid.explosion. Observe.the. laws. or. regulations.on. device.use.. Respect.others’.privacy.and. legal. rights when using your device. It. is. recommended.that. the. equipment.only. be. used. in. the. environment.where.temperature. is. between.0°C. and. 45°C. and. humidity.is. between.10%. to. 90%.. Keep. the. equipment.in. the. environment.where.temperature.is. between.-10°C. and. 60°C. or. humidity.is. between.10%. to. 90%. CHARGERS Main.powered.chargers.will.operate.within.the.temperature.range.of:.0°C.to.40°C. The. chargers.designed.for. your. device.meet. with. the. safety.standard.of. technology.equipment. and.office.equipment.use.. Due. to. different.applicable.electrical.specifications,.a. charger.you. purchased.in. one. jurisdiction. may.not.work.in.another.jurisdiction..They.should.be.used.for.this.purpose.only. 4 1. Web.UI.configuration 1.1 Log.into.the.configuration.page Open.the.browser.and.enter.this.address.http://192.168.1.1. Enter.password.and.click.“Log.In”..The.default.login.password.is.admin. To.prevent.unauthorized.access.to.the.management.page,.change.the.login.password. 1. Choose Settings > Login.setting > Mod…

Text truncated - open the document above for the full version.

Cover Letter(s)

TCL Communication Ltd. 5F, C building, No. 232, Liang Jing Road, ZhangJiang High-Tech Park, Pudong Shanghai, P.R. China. 201203 Tel: +86 21 6146 0666 Fax: +86 21 6146 0602 http://tclcom.tcl.com 2020-07-28 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: SHORT-TERM Confidentiality request for FCC ID: 2ACCJB132 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 180 days: - External Photos - Internal Photos - Test Setup Photos - User manual The applicant also acknowledges that they will also provide appropriate notice to ACB should either of the following occur: a) if the applicant requires additional 45 days extension periods they will notify ACB with a new request letter at least 7 days prior to the short-term confidentiality expiration date – [Note: up to a maximum of 3 extensions only are allowed], or b) Immediately notify ACB in the event the information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Yours Sincerely, Zhizhou GONG Product Certification Manager TCL Communication Ltd.

ID Label/Location Info

WIFI45A Commercial Sticker and CU Sticker ABSTRACT: The purpose of this document is to define all the information on commercial sticker and CU sticker for WIFI45A HISTORY NameDateVersionComments 2020/6/5 15:37:43v01Creation of the document (draft file) minglu.zho ng 2020/6/12 9:35:50v02Add CU label formats minglu.zho ng 2020/7/28 15:22:30v03Update FCC ID of MW45AN minglu.zho ng 2020/8/3 14:59:25v04Remove MW45AD label information BandCu Ref PrefixTACFACSNMEIDCertification CECertification FCC3CBluetooth QD ID 3G- WCDMA:B2/B4/ B5,4G-FDD LTE:B2/B3/B4/B 5/B7/B13/B17/B2 8A/B28B MW45ANTAC:3504 2693 ///FCC ID:2ACCJB132 // 1.COMMERCIAL LABEL MARKING (IMEI sticker) 1.1 Printing Zone definition (CPE000410AC0--------For general 39.5×20.9 mm) SignificationRemark Manufacturer address 2D CodeIMEI No./Manufacturing site/PTS/Date Code/COM.REF Logos Code name CU Ref. IMEI1 TEXT MAC IMEI1 Barcode SSID Date 1.2 Samples for Commercial Label MW45AN- 2AALMX1 IMEI Sample V02-1 39 2 UNIT BOX LABEL MARKING (CU sticker) 2.1 Printing Zone definition (CPF000364AC0--------65×30+24.8×6.8 mm) 2.2 Blank Label Size SignificationRemark Alcatel Log MAC IMEI1 TEXT FCC ID Code name Made In 5V logo Band Importer address CU Ref. ColorRefer to ERP EAN CodeText+1D Code CE/NOMLogos SSID WEEE IMEI1 Barcode 2.3 Samples for CU Label MW45AN- 2AALMX1 CU Sample 65_36 Appendix 1: Location of PCBA label. PCBA Location is NONE Appendix 2: Location of IMEI label. IMEI label is NONE Appendix 3: Specail Image Specail Image is NONE

ID Label/Location Info

条码区

RF Exposure Info

©Copyright. All rights reserved by CTTL. SAR TEST REPORT No. I20Z60996-SEM01 For TCL Communication Ltd. Mobile WiFi Model Name: MW45AN With Hardware Version: V2.0 Software Version: MW45A_ZZ_02.00_01 FCC ID: 2ACCJB132 Issued Date: 2020-7-15 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of CTTL. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the U.S.Government. Test Laboratory: CTTL, Telecommunication Technology Labs, CAICT No. 51, Xueyuan Road, Haidian District, Beijing, P. R. China 100191. Tel:+86(0)10-62304633-2512, Fax:+86(0)10-62304633-2504 Email: [email protected], website: www.caict.ac.cn No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 2 of 162 REPORT HISTORY Report Number Revision Issue Date Description I20Z60996-SEM01 Rev.0 2020-7-15 Initial creation of test report No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 3 of 162 TABLE OF CONTENT 1 TEST LABORATORY .................................................................................................................... 5 1.1 TESTING LOCATION ........................................................................................................................................ 5 1.2 TESTING ENVIRONMENT................................................................................................................................. 5 1.3 PROJECT DATA ............................................................................................................................................... 5 1.4 SIGNATURE ..................................................................................................................................................... 5 2 STATEMENT OF COMPLIANCE .................................................................................................. 6 3 CLIENT INFORMATION ................................................................................................................ 7 3.1 APPLICANT INFORMATION .............................................................................................................................. 7 3.2 MANUFACTURER INFORMATION ..................................................................................................................... 7 4 EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ................................. 8 4.1 ABOUT EUT ................................................................................................................................................... 8 4.2 INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST .......................................................................... 8 4.3 INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ............................................................................ 8 5 TEST METHODOLOGY ................................................................................................................ 9 5.1 APPLICABLE LIMIT REGULATIONS .................................................................................................................. 9 5.2 APPLICABLE MEASUREMENT STANDARDS ..................................................................................................... 9 6 SPECIFIC ABSORPTION RATE (SAR) ...................................................................................... 10 6.1 INTRODUCTION ............................................................................................................................................. 10 6.2 SAR DEFINITION .......................................................................................................................................... 10 7 TISSUE SIMULATING LIQUIDS ................................................................................................. 11 7.1 TARGETS FOR TISSUE SIMULATING LIQUID .................................................................................................... 11 7.2 DIELECTRIC PERFORMANCE ......................................................................................................................... 11 8 SYSTEM VERIFICATION ............................................................................................................ 15 8.1 SYSTEM SETUP ............................................................................................................................................. 15 8.2 SYSTEM VERIFICATION ................................................................................................................................. 16 9 MEASUREMENT PROCEDURES .............................................................................................. 16 9.1 TESTS TO BE PERFORMED ............................................................................................................................. 16 9.2 GENERAL MEASUREMENT PROCEDURE ........................................................................................................ 18 9.3 WCDMA MEASUREMENT PROCEDURES FOR SAR ...................................................................................... 19 9.4 SAR MEASUREMENT FOR LTE ..................................................................................................................... 20 9.5 WI-FI MEASUREMENT PROCEDURES FOR SAR ............................................................................................ 21 9.6 POWER DRIFT ............................................................................................................................................... 21 10 AREA SCAN BASED 1-G SAR ................................................................................................. 22 10.1 REQUIREMENT OF KDB ..............................................................................................................…

Text truncated - open the document above for the full version.

RF Exposure Info

No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 90 of 162 ANNEX F System Validation The SAR system must be validated against its performance specifications before it is deployed. When SAR probes, system components or software are changed, upgraded or recalibrated, these must be validated with the SAR system(s) that operates with such components. Table F.1: System Validation for 3617 Probe SN. Liquid name Validation date Frequency point Status (OK or Not) 3617 Head 750MHz January 30,2020 750 MHz OK 3617 Head 850MHz January 30,2020 835 MHz OK 3617 Head 900MHz January 30,2020 900 MHz OK 3617 Head 1750MHz January 30,2020 1750 MHz OK 3617 Head 1810MHz January 30,2020 1810 MHz OK 3617 Head 1900MHz January 30,2020 1900 MHz OK 3617 Head 2000MHz January 30,2020 2000 MHz OK 3617 Head 2100MHz January 30,2020 2100 MHz OK 3617 Head 2300MHz January 30,2020 2300 MHz OK 3617 Head 2450MHz January 30,2020 2450 MHz OK 3617 Head 2600MHz January 30,2020 2600 MHz OK 3617 Head 3500MHz January 30,2020 3500 MHz OK 3617 Head 3700MHz January 30,2020 3700 MHz OK 3617 Head 5200MHz January 30,2020 5250 MHz OK 3617 Head 5500MHz January 30,2020 5600 MHz OK 3617 Head 5800MHz January 30,2020 5800 MHz OK 3617 Body 750MHz January 30,2020 750 MHz OK 3617 Body 850MHz January 30,2020 835 MHz OK 3617 Body 900MHz January 30,2020 900 MHz OK 3617 Body 1750MHz January 30,2020 1750 MHz OK 3617 Body 1810MHz January 30,2020 1810 MHz OK 3617 Body 1900MHz January 30,2020 1900 MHz OK 3617 Body 2000MHz January 30,2020 2000 MHz OK 3617 Body 2100MHz January 30,2020 2100 MHz OK 3617 Body 2300MHz January 30,2020 2300 MHz OK 3617 Body 2450MHz January 30,2020 2450 MHz OK 3617 Body 2600MHz January 30,2020 2600 MHz OK 3617 Body 3500MHz January 30,2020 3500 MHz OK 3617 Body 3700MHz January 30,2020 3700 MHz OK 3617 Body 5200MHz January 30,2020 5250 MHz OK 3617 Body 5500MHz January 30,2020 5600 MHz OK 3617 Body 5800MHz January 30,2020 5800 MHz OK No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 91 of 162 ANNEX G Probe Calibration Certificate Probe 3617 Calibration Certificate No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 92 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 93 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 94 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 95 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 96 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 97 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 98 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 99 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 100 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 101 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 102 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 103 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 104 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 105 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 106 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 107 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 108 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 109 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 110 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 111 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 112 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 113 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 114 of 162 ANNEX H Dipole Calibration Certificate 750 MHz Dipole Calibration Certificate No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 115 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 116 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 117 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 118 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 119 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 120 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 121 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 122 of 162 835 MHz Dipole Calibration Certificate No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 123 of 162

RF Exposure Info

No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 124 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 125 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 126 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 127 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 128 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 129 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 130 of 162 1750 MHz Dipole Calibration Certificate No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 131 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 132 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 133 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 134 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 135 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 136 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 137 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 138 of 162 1900 MHz Dipole Calibration Certificate No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 139 of 162

RF Exposure Info

No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 140 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 141 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 142 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 143 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 144 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 145 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 146 of 162 2450 MHz Dipole Calibration Certificate No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 147 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 148 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 149 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 150 of 162 No.I20Z60996-SEM01 ©Copyright. All rights reserved by CTTL. Page 151 of 162 No.I20Z60996-SEM01 ©Copyright.…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Annie Jiang

[email protected]+8675536611621Fax: +8675536612000-81722

Technical Contact

CTTLXue Zhen

[email protected]

China

Test Firm

Telecommunication Technology Labs, CAICTYaqin Shen

[email protected]8610-62304633Fax: 8610-62300586

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
25	27	709 MHz - 711 MHz	51.90 mW	8M99W7D	0.1 ppm

Confidentiality

Long Term

Grant Notes

Power output is ERP for Part 22/27 and EIRP for Part 24/27. Body-worn operations are restricted to belt-clips, holsters or similar accessories that have no metallic component in the assembly. End users must be informed of the body worn requirements for satisfying RF Exposure compliance. The highest reported SAR for product specific (wireless router) and simultaneous transmission exposure conditions are 1.26 W/kg and 1.57 W/kg, respectively. This device contains LTE function that is not operational in U.S. Territories. This filing is only applicable for 700 MHz MBS, 850 MHz Cell, 1700 MHz AWS, 1900 MHz PCS and 2600 MHz IMT operations. This device has 1.4 MHz, 3 MHz, 5 MHz, 10 MHz, 15MHz and 20 MHz bandwidth modes for LTE Bands 2/4; 1.4 MHz, 3 MHz, 5 MHz and 10 MHz bandwidth modes for LTE Band 5; 5 MHz, 10 MHz, 15MHz and 20 MHz bandwidth modes for LTE Band 7 and 5 MHz and 10 MHz bandwidth modes for LTE Bands 13/17. This device also contains 2.4GHz WLAN transmitter.
