2ACCJB134Neo - the smart kids watch

Safety and Warranty information EN | DE | ES | IT | PT | GR Model ID (VKW001) Product Safety Information Please read this safety information before you use the device. Following the warnings will help prevent injury to yourself or others and damage to your device. Additional safety warnings may be given for the operation of specific Apps on your device, you should also follow these instructions. Pictograms and Graphic Symbols Read the Safety Information section of this user guide before using this device. Failure to comply with safety warnings can result in serious injury. Do not use while driving. This device is not intended for use by young children. If you allow a child to use it ensure the child is strictly supervised. This device contains small parts which are a choking hazard. Keep away from pacemakers and other personal medical devices. Switch off when instructed in hospitals and medical facilities. Switch off when instructed in aircrafts and airport. Do not take this device near explosive environments. Do not use while refuelling or near gas or flammable liquids. Do not dispose of this device or its battery in a fire. Avoid contact with magnetic media. EN Avoid Extreme Temperatures. Do not try and disassemble. This device will not communicate with emergency services. Do not rely on this watch for emergency communications Only use approved accessories. This device may produce a bright or flashing light. This device may produce a loud sound. Switch off in explosive environments. Do not to use this device whilst walking across a road or cycling. This device is not suitable for children under 3 years of age. The toy is only to be connected to Class II equipment bearing the symbol RF ExPoSuRE This watch contains a radio transmitter and a receiver. When it is ON, it receives and transmits RF energy. When you communicate with your watch, the system handling your call controls the power level at which your device transmits. RADIo WAVES: THIS PHONE MEETS THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES. Your device is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radio-frequency (RF) energy. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. These guidelines include a substantial safety margin designed to ensure the safety of all persons, regardless of age and health. The exposure standard for phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by public authorities such as the Federal Communications Commission of the US Government (FCC), or by Innovation, Science and Economic Development Canada (ISED), is 1.6 W/kg averaged over 1 gram of body tissue, and Limbs is 4.0 W/Kg averaged over 10 grams. Tests for SAR are conducted using standard operating positions with the device transmitting at its highest certified power level in all tested frequency bands. This device is complied with SAR for general population / uncontrolled exposure limits in ANSI/IEEE C95.1-1992 and had been tested in accordance with the measurement methods and procedures specified in IEEE1528. Although the SAR is determined at the highest certified power level, the actual SAR level of the device while operating can be well below the maximum value. This is because the device is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output of the device. Before a device model is available for sale to the public, compliance with national regulations and standards must be shown. The highest SAR value for this model device when tested is 0.54 W/Kg for use close to the body, and 0.67 W/Kg for Limbs. During SAR testing, this is set to transmit at its highest certified power level in all tested frequency bands, and placed in positions that simulate RF exposure in usage near the body with the separation of 10 mm, and the Limbs with the separation of 0 mm. Although the SAR is determined at the highest certified power level, the actual SAR level of the device while operating can be well below the maximum value. This is because the device is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output. Additional information on SAR can be found on the Cellular Telecommunications & Internet Association (CTIA) Web site: http://www.ctia.org/ Note: This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/ TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. For the receiver devices associated with the operation of a licensed radi…

Text truncated - open the document above for the full version.

TCL Communication Ltd. 5F, C building, No. 232, Liang Jing Road, ZhangJiang High-Tech Park, Pudong Shanghai, P.R. China. 201203 Tel: +86 21 6146 0666 Fax: +86 21 6146 0602 http://tclcom.tcl.com Date 2020-11-02 To: Federal Communications Commission, Authorization & Evaluation Division, 7345 Oakland Mills Road Columbia, MD 21046 And American Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: CTTL-Telecommunication Technology Labs, Academy of Telecommunication Research, MIIT is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, which includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR1.2002 (b) to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you. Regards, Zhizhou GONG Product Certification Manager TCL Communication Ltd.

TCL Communication Ltd. 5F, C building, No. 232, Liang Jing Road, ZhangJiang High-Tech Park, Pudong Shanghai, P.R. China. 201203 Tel: +86 21 6146 0666 Fax: +86 21 6146 0602 http://tclcom.tcl.com 2020-11-02 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: SHORT-TERM Confidentiality request for FCC ID: 2ACCJB134 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 180 days: - External Photos - Internal Photos - Test Setup Photos - User manual The applicant also acknowledges that they will also provide appropriate notice to ACB should either of the following occur: a) if the applicant requires additional 45 days extension periods they will notify ACB with a new request letter at least 7 days prior to the short-term confidentiality expiration date – [Note: up to a maximum of 3 extensions only are allowed], or b) Immediately notify ACB in the event the information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Yours Sincerely, Zhizhou GONG Product Certification Manager TCL Communication Ltd.

TCL Communication Ltd. 5F, C building, No. 232, Liang Jing Road, ZhangJiang High-Tech Park, Pudong Shanghai, P.R. China. 201203 Tel: +86 21 6146 0666 Fax: +86 21 6146 0602 http://tclcom.tcl.com 2020-11-02 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: 2ACCJB134 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: - Block Diagram - Schematics - Operational Description - BOM list/Tune-Up-Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Yours Sincerely, Zhizhou GONG Product Certification Manager TCL Communication Ltd.

EUT photograph VKW001

VKW001 Label Location

EUT Interior photograph VKW001

©Copyright. All rights reserved by CTTL. TEST REPORT No. I20Z61600-EMC04 for TCL Communication Ltd. Neo – the smart kids watch Model Name: VKW001 FCC ID: 2ACCJB134 with Hardware Version: V4.0 Software Version: MT45_ZZ_00.01_01 Issued Date: 2020-11-04 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of CTTL. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the U.S.Government. Test Laboratory: CTTL-Telecommunication Technology Labs, CAICT No. 52, Huayuan North Road, Haidian District, Beijing, P. R. China 100191. Tel:+86(0)10-62304633-2512, Fax:+86(0)10-62304633-2504 Email: [email protected], website: www.caict.ac.cn No.I20Z61600-EMC04 ©Copyright. All rights reserved by CTTL. Page 2 of 20 REPORT HISTORY Report Number Revision Description Issue Date I20Z61600-EMC04 Rev.0 1 st edition 2020-10-22 I20Z61600-EMC04 Rev.1 add the information of PC on page 6 2020-11-04 Note: the latest revision of the test report supersedes all previous version. No.I20Z61600-EMC04 ©Copyright. All rights reserved by CTTL. Page 3 of 20 CONTENTS 1. TEST LABORATORY ............................................................................................................... 4 1.1. INTRODUCTION & ACCREDITATION ................................................................................. 4 1.2. TESTING LOCATION ........................................................................................................... 4 1.3. TESTING ENVIRONMENT ................................................................................................... 4 1.4. PROJECT DATA ................................................................................................................... 4 1.5. SIGNATURE .......................................................................................................................... 4 2. CLIENT INFORMATION ........................................................................................................... 5 2.1. APPLICANT INFORMATION ................................................................................................ 5 2.2. MANUFACTURER INFORMATION ...................................................................................... 5 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................ 6 3.1. ABOUT EUT .......................................................................................................................... 6 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ................................... 6 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ...................................... 6 3.4. EUT SET-UPS ....................................................................................................................... 6 4. REFERENCE DOCUMENTS .................................................................................................... 8 4.1. REFERENCE DOCUMENTS FOR TESTING....................................................................... 8 5. LABORATORY ENVIRONMENT .............................................................................................. 9 6. SUMMARY OF TEST RESULTS ............................................................................................ 10 7. TEST EQUIPMENTS UTILIZED ............................................................................................. 11 ANNEX A: MEASUREMENT RESULTS ....................................................................................... 12 ANNEX B: PERSONS INVOLVED IN THIS TESTING ................................................................. 20 No.I20Z61600-EMC04 ©Copyright. All rights reserved by CTTL. Page 4 of 20 1. Test Laboratory 1.1. Introduction & Accreditation Telecommunication Technology Labs, CAICT is an ISO/IEC 17025:2005 accredited test laboratory under NATIONAL VOLUNTARY LABORATORY ACCREDITATION PROGRAM (NVLAP) with lab code 600118-0, and is also an FCC accredited test laboratory (CN5017), and ISED accredited test laboratory (CN0066). The detail accreditation scope can be found on NVLAP website. 1.2. Testing Location CTTL (BDA) Address: No. 52, Huayuan North Road, Haidian District, Beijing, P. R. China 100191 1.3. Testing Environment Normal Temperature: 15-35ºC Relative Humidity: 20-75% 1.4. Project data Testing Start Date: 2020-10-14 Testing End Date: 2020-10-22 1.5. Signature Wang Xue (Prepared this test report) Zhang Ying (Reviewed this test report) Liu Baodian Deputy Director of the laboratory (Approved this test report) No.I20Z61600-EMC04 ©Copyright. All rights reserved by CTTL. Page 5 of 20 2. Client Information 2.1. Applicant Information Company Name: TCL Communication Ltd. Address: 5/F, Building 22E, 22 Science Park East Avenue, Hong Kong Science Park, Shatin, NT, Hong Kong Contact Person Gong Zhizhou Contact Email [email protected] Telephone: 0086-755-36611722 Fax: 0086-755-36612000-81722 2.2. Manufacturer Information Company Name: TCL Communication Ltd. Address: 5/F, Building 22E, 22 Science Park East Avenue, Hong Kong Science Park, Shatin, NT, Hong Kong Contact Person Gong Zhizhou Contact Email [email protected] Telephone: 0086-755-36611722 Fax: 0086-755-36612000-81722 No.I20Z61600-EMC04 ©Copyright. All rights reserved by CTTL. Page 6 of 20 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description Neo – the smart kids watch Model Name VKW001 FCC ID 2ACCJB134 Extreme vol. Limits 3.6VDC to 4.3VDC (nominal: 3.8VDC) Note: Components list, please refer to documents of the manufacturer; it is also included in the original test record of CTTL, Telecommunication Technology Labs, CAICT. 3.2. Internal Identification of EUT used during the test EUT ID* SN or IMEI HW Version SW Version 26a 355810970202472 V4.0 MT45_ZZ_00.01_01 *EUT ID: is used t…

Text truncated - open the document above for the full version.

VKW001 Setup photos
