2ACCJB188Mobile WiFi

V1.0 | MW63 CJB73U0LCAGA EN - 2 Overview  Power button • Press and hold for 3 seconds to power on or off your device. • Press and hold for 10 seconds to reboot your device.  Micro USB port Connect to a power supply (5 V/1 A) using the provided USB cable. NOTE The provided USB cable is intended for charging only. Buttons EN - 3  Wi-Fi Indicator • Solid blue: Wi-Fi is enabled. • Off: Wi-Fi is off.  SMS Indicator • Solid blue: new message(s). • Flashing blue: SMS inbox is full. • Off: No new message.  Battery Indicator • Solid blue: battery level: 21% - 100% • Flashing blue: the device is charging • Solid red: battery level is low. Status LED  Signal Indicator • Solid blue: the device is connected to network. • Solid red: SIM card or network service is not available. • Blinking blue: the device is diconnected from the network. EN - 4  Micro SIM card slot Insert a micro SIM card into the slot.  Reset buttonUse a paperclip to press the button for 3 seconds to reset the device. EN - 5 Insert the SIM Card & Battery Note: Heed the orientation of your SIM card. Make sure you align the SIM card with the slot and slide it into the slot until it sits properly. EN - 6 Press and hold the power button for 3 seconds to turn on your LinkZone. 3s Power On EN - 7 Connect to the Network Note: The default Wi-Fi name and password can be found on the label inside your LINKZONE. Security Key: *********** Cancel OK MW63-xxxx ********* xxxxxxxxx xxxxxxxxx xxxxxxxxx xxxxxxxxx MW63-xxxx Select network password *********** MW63-XXXX SSID: MW63-xxxx WIFI Key: *********** EN - 8 Configure the Network Note: For the default login information, refer to the label inside your LinkZone. To configure the LINKZONE Wi-Fi network: 1. Open a web browser on the device connected to the LINKZONE network. 2. Go to the login website and follow the on-screen instructions. The login website can be found on the label beneath the battery. Note: For a full user manual, check the Help section on the login website. EN - 9 General Information • Manufacturer: TCL Communication Ltd. • Address: 5/F, Building 22E, 22 Science Park East Avenue, Hong Kong Science Park, Shatin, NT, Hong Kong • Visit the TCL website at https://www.tcl.com/mx for tutorials and answers to frequently asked questions, and to download the User Manual. • To get support for your device, visit the TCL website (https://www.tcl.com/mx/es/service-support-mobile.html), or dial the number listed below: Argentina: 0810-999-1099 Chile: +56 22 958 96 94 Colombia: 18009520823 Ecuador: 800000635 Mexico: 8008909908 Peru: 080000698 The Dominican Republic: 8887600164 Uruguay: 405296624 Venezuela: 08001005368 EN - 10 Important Safety Information Read all the safety information before using your device. Failure to follow these safety instructions could result in injury, or damage to your device or other property. The manufacturer disclaims any liability for damage, which may result as a consequence of improper use or use contrary to the instructions contained herein. Safety and handling instructions • Do not use the device in areas where wireless devices are prohibited. • When the device is switched on, it should be kept at least 15 cm from any medical device such as a pacemaker, a hearing aid, or an insulin pump. Consult your physician and medical device manufacturer for information specific to your medical device. • Do not let children use the device and its accessories without supervision. • Always handle your device with care, and keep it in a clean and dust-free place. • Do not attempt to repair the device yourself. • Do not drop, throw, or bend your device. • Do not dispose of the device and its accessories in a fire. EN - 11 Power adapter Charge your device with the supplied USB cable. Only charge with an adapter that is compliant with the applicable international and regional safety standards. The adapter shall be CE-approved. Using other adapters could cause damage to the device or pose a risk of injury or death. Keep the adapter in a well- ventilated area when it is plugged into an electrical outlet. Don’t use damaged power adapters. Recommended adapter specifications Input voltage/AC frequency100~240 V, 50/60 Hz Output voltage/current/power5.0 V/1.0 A/5.0 W Battery CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS. EN - 12 In accordance with air regulations, the battery of your product is not fully charged. Please charge it first. • Do not attempt to open the battery (due to the risk of toxic fumes and burns). • Do not puncture, disassemble, or short circuit the battery. • The battery must be recycled or disposed of separately from household waste. Dispose of batteries according to your local environmental laws and guidelines. • Replace the battery only with another qualified battery. Use of an unqualified battery may present a risk of fire, explosion, leakage, or other hazard. • Do not use damaged battery. Operating environment Your device is designed to work best in ambient temperatures between 0 °C and 45 °C (32 °F and 113 °F), and should be stored in ambient temperatures between –10 °C and 70 °C (14 °F and 158 °F). Your device may malfunction if operated or stored outside of these temperature ranges. Avoid exposing the device to dramatic changes in temperature or humidity. EN - 13 Waste disposal and recycling The device, accessory and battery must be disposed of in accordance with locally applicable environmental regulations. This symbol on your device, the battery, and the accessories means that these products must be taken to: • Municipal waste disposal centres with specific bins. • Collection bins at points of sale. They will then be recycled, preventing substances being disposed of in the environment. Radio waves THIS DEVICE MEETS THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES. The exposure standard for devices employs a unit of measurement known as the Specific Absorption Ra…

Text truncated - open the document above for the full version.

TCL Communication Ltd. 022818 – 11 Authority to Act as Agent Date: _2022/11/25_ American Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: ______Shenzhen Academy of Information and Communication Technology______ is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Expiration Date: _____(Typically 8 – 12 months)_____ By: ______Annie.jiang_____ (Signature 1 ) (Print name) Title: ____Project Manager___ On behalf of: ___TCL Communication Ltd.___ (Company Name) Telephone: __+86 755 36611621__ 1 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead. TCL Communication Ltd. 022818 – 11 Request for Confidentiality Date: _2022/11/25_ Subject: Confidentiality Request for: _____2ACCJB188_____ Pursuant to FCC 47 CFR 0.457(d) and 0.459 the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit ☐ Short Term ☒ Permanent Block Diagrams ☒ Short Term External Photos ☒ Short Term ☐ Permanent * 2 Internal Photos ☐ Short Term ☒ Permanent Operation Description/Theory of Operation ☐ Short Term ☒ Permanent Tune-Up Procedure ☐ Short Term ☒ Permanent Schematics ☒ Short Term Test Setup Photos ☒ Short Term ☐ Permanent * 3 User’s Manual ___TCL Communication Ltd.__ has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public before the requested period has expired. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: IC currently only distinguishes Permanent Confidentiality exhibits as shown above. Short Term confidentiality is not considered applicable to IC applications. Sincerely, By: _______Annie.jiang_______ (Signature/Title 3 ) (Print name) 2 - The asterisked items (*) require further information to be provided to ACB before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 and the specific Document link for D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding specific information that must accompany these requests. 3 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

5F, C building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 TEL: +86(0)21 61460666 FAX: +86(0)21 61460602 Declaration of changes from Initial (R228t) to Variant (MW63AF) ⚫ SOFTWARE MODIFICATIONS: ➢ Protocol Stack changes: NO ➢ MMS/STK/USAT/USIM changes: NO ➢ DM/SUPL/VT/FUMO/SWP/HCI: NO ➢ Other changes detailed: NO ⚫ HARDWARE MODIFICATIONS: ➢ Baseband changes: NO ➢ Band changes: Yes Product GSM UMTS LTE R228t 900/1800 Band 1,3,8 Band 1/3/7/8/20/28/32/38/40/41 MW63AF NO Band 1, 2, 4, 5, 8 Band 2/4/5/7/28/66 ➢ Antenna changes: NO ➢ PCB Layout changes: YES ➢ Main components changes: Base Band Transceiver ASM Power Amplifier Tx SAW Filter Rx SAW Filter（SAW Duplexer） UMTS FDD I NO NO NO NO NO NO UMTS FDD II NO NO NO NO New New UMTS FDD IV NO NO NO NO New New UMTS FDD V NO NO NO NO New New UMTS FDD VIII NO NO NO NO NO NO Base Band Transceiver ASM Power Amplifier Tx SAW Filter Rx SAW Filter（SAW Duplexer） LTE B2 NO NO NO NO New New LTE B4 NO NO NO NO New New LTE B5 NO NO NO NO New New LTE B7 NO NO NO NO NO NO LTE B28 NO NO NO NO NO NO LTE B66 NO NO NO NO New New Antenna AP MODEM Transceiver Balun Band pass filter diplexer WiFi NO NO NO NO NO NO NO ➢ WiFi changes: MW63AF&R228T WIFI non-change, below pictures red part are circuit diagram for WiFi, MW63AF and R228t WiFi are unchanged. LTE B7：Below pictures red part are circuit diagram for LTE B7, MW63AF and R228t B7 are unchanged. ➢ Other components changes: NO ➢ Other changes detailed: No Accessories R228t MW63AF Remark Charger UC11EU UC11US UC11US Battery TLi021F7 TLi021FA TLi021F7 TLi021FA USB cable CDA0000177C1 CDA0000167C1 CDB0000082C1 ➢ MECHANICAL MODIFICATIONS: ⚫ Use new metal front/back cover or keypad: NO ⚫ Mechanical shell changes: NO Whole size of EUT: NO Distance of Ear reference point to bottom of handset: NO Other trinkets to change the surface of handset: NO ⚫ Other changes detailed: R228t FCC ID is 2ACCJB182, MW63AF FCC ID is 2ACCJB188 APPROVED BY: Project Manager: Hui-Zhu Signature: Date:2022.12.7

Date: 2022.11.29 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Request permission to use WIFI/LTE/DFS test results from model R228t in our applications for model MW63AF. FCC ID: 2ACCJB188 To whom it may concern: We request permission to use WIFI /LTE /DFS test results from model R228t (FCC ID: 2ACCJB182 date of grant: 09/14/2022) in our applications for model MW63AF (FCC ID: 2ACCJB188). And follow the KDB 484596 instruction Changes: you can find details of changes in “Declaration of changes” attached in this document. For the above, we performed some test as below: ⚫ full test for SAR ⚫ full test for W1900/W1700/W850 and LTE B2/B5/B66 ⚫ spot check of conducted power for 15C WIFI. ⚫ conducted power for and LTE B7 ⚫ full test for 15B You can find more detailed data in our reports. Sincerely yours, ————————————— Name:

TEST REPORT No.I22N02153-SAR For TCL Communication Ltd. Mobile WiFi Model Name: MW63AF With Hardware Version: FG11_AF_MB_V1.1 Software Version: MW63AF_V01.18b01 FCC ID: 2ACCJB188 Issued Date: 2022-11-28 Designation Number: CN1210 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of SAICT. Test Laboratory: SAICT, Shenzhen Academy of Information and Communications Technology Building G, Shenzhen International Innovation Center, No.1006 Shennan Road, Futian District, Shenzhen, Guangdong, P. R. China 518000. Tel:+86(0)755-33322000, Fax:+86(0)755-33322001 Email: [email protected]. www.saict.ac.cn No.I22N02153-SAR ©Copyright. All rights reserved by SAICT Page 2 of 146 REPORT HISTORY Report Number Revision Description Issue Date I22N02153-SAR Rev.0 1st edition 2022-11-28 No.I22N02153-SAR ©Copyright. All rights reserved by SAICT Page 3 of 146 CONTENTS 1. SUMMARY OF TEST REPORT ................................................................................................... 5 1.1. TEST ITEMS ............................................................................................................................... 5 1.2. TEST STANDARDS ...................................................................................................................... 5 1.3. TEST RESULT ............................................................................................................................ 5 1.4. TESTING LOCATION .................................................................................................................... 5 1.5. PROJECT DATA .......................................................................................................................... 5 1.6. SIGNATURE ............................................................................................................................... 5 2. STATEMENT OF COMPLIANCE ................................................................................................. 6 3. CLIENT INFORMATION ............................................................................................................... 7 3.1. APPLICANT INFORMATION ............................................................................................................ 7 3.2. MANUFACTURER INFORMATION .................................................................................................... 7 4. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ................................ 8 4.1. ABOUT EUT .............................................................................................................................. 8 4.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST............................................................. 8 4.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ............................................................... 8 5. TEST METHODOLOGY ............................................................................................................... 9 5.1. APPLICABLE LIMIT REGULATIONS ................................................................................................. 9 5.2. APPLICABLE MEASUREMENT STANDARDS ..................................................................................... 9 6. SPECIFIC ABSORPTION RATE (SAR) ..................................................................................... 10 6.1. INTRODUCTION .........................................................................................................................10 6.2. SAR DEFINITION .......................................................................................................................10 7. TISSUE SIMULATING LIQUIDS ................................................................................................ 11 7.1. TARGETS FOR TISSUE SIMULATING LIQUID ..................................................................................... 11 7.2. DIELECTRIC PERFORMANCE ....................................................................................................... 11 8. SYSTEM VERIFICATION ........................................................................................................... 15 8.1. SYSTEM SETUP ........................................................................................................................15 8.2. SYSTEM VERIFICATION ..............................................................................................................16 9. MEASUREMENT PROCEDURES ............................................................................................. 17 9.1. TESTS TO BE PERFORMED ..........................................................................................................17 9.2. GENERAL MEASUREMENT PROCEDURE .......................................................................................19 9.3. WCDMA MEASUREMENT PROCEDURES FOR SAR .......................................................................20 9.4. SAR MEASUREMENT FOR LTE ...................................................................................................21 9.5. WLAN MEASUREMENT PROCEDURES FOR SAR...........................................................................22 9.6. POWER DRIFT ..........................................................................................................................22 10. CONDUCTED OUTPUT POWER............................................................................................. 23 No.I22N02153-SAR ©Copyright. All rights reserved by SAICT Page 4 of 146 10.1. WCDMA MEASUREMENT RESULT .............................................................................................23 10.2. LTE MEASUREMENT RESULT ....................................................................................................25 10.3. WLAN MEASUREMENT RESULT .................................…

Text truncated - open the document above for the full version.

No.I22N02153-SAR ©Copyright. All rights reserved by SAICT Page 116 of 146 No.I22N02153-SAR ©Copyright. All rights reserved by SAICT Page 117 of 146 No.I22N02153-SAR ©Copyright. All rights reserved by SAICT Page 118 of 146 1900MHz Dipole No.I22N02153-SAR ©Copyright. All rights reserved by SAICT Page 119 of 146 No.I22N02153-SAR ©Copyright. All rights reserved by SAICT Page 120 of 146 No.I22N02153-SAR ©Copyright. All rights reserved by SAICT Page 121 of 146 No.I22N02153-SAR ©Copyright. All rights reserved by SAICT Page 122 of 146 No.I22N02153-SAR ©Copyright. All rights reserved by SAICT Page 123 of 146 No.I22N02153-SAR ©Copyright. All rights reserved by SAICT Page 124 of 146 2450MHz Dipole No.I22N02153-SAR ©Copyright. All rights reserved by SAICT Page 125 of 146 No.I22N02153-SAR ©Copyright. All rights reserved by SAICT Page 126 of 146 No.I22N02153-SAR ©Copyright. All rights reserved by SAICT Page 127 of 146 No.I22N02153-SAR ©Copyright. All rights reserved by SAICT Page 128 of 146 No.I22N02153-SAR ©Copyright. All rights reserved by SAICT Page 129 of 146 No.I22N02153-SAR ©Copyright. All rights reserved by SAICT Page 130 of 146 2550MHz Dipole No.I22N02153-SAR ©Copyright. All rights reserved by SAICT Page 131 of 146 No.I22N02153-SAR ©Copyright. All rights reserved by SAICT Page 132 of 146 No.I22N02153-SAR ©Copyright. All rights reserved by SAICT Page 133 of 146 No.I22N02153-SAR ©Copyright. All rights reserved by SAICT Page 134 of 146 No.I22N02153-SAR ©Copyright. All rights reserved by SAICT Page 135 of 146 No.I22N02153-SAR ©Copyright. All rights reserved by SAICT Page 136 of 146 No.I22N02153-SAR ©Copyright. All rights reserved by SAICT Page 137 of 146 No.I22N02153-SAR ©Copyright. All rights reserved by SAICT Page 138 of 146 5GHz Dipole No.I22N02153-SAR ©Copyright. All rights reserved by SAICT Page 139 of 146 No.I22N02153-SAR ©Copyright. All rights reserved by SAICT Page 140 of 146 No.I22N02153-SAR ©Copyright. All rights reserved by SAICT Page 141 of 146 No.I22N02153-SAR ©Copyright. All rights reserved by SAICT Page 142 of 146 No.I22N02153-SAR ©Copyright. All rights reserved by SAICT Page 143 of 146 No.I22N02153-SAR ©Copyright. All rights reserved by SAICT Page 144 of 146 No.I22N02153-SAR ©Copyright. All rights reserved by SAICT Page 145 of 146 No.I22N02153-SAR ©Copyright. All rights reserved by SAICT Page 146 of 146 ANNEX J: Extended Calibration SAR Dipole Referring to KDB865664 D01, if dipoles are verified in return loss (<-20dBm, within 20% of prior calibration), and in impedance (within 5 ohm of prior calibration), the annual calibration is not necessary and the calibration interval can be extended. Justification of Extended Calibration SAR Dipole D835V2 - serial no. 4d057 Head Date of Measurement Return-Loss (dB) Delta (%) Real Impedance (ohm) Delta (ohm) Imaginary Impedance (johm) Delta (johm) 2021-10-18 -27.5 / 49.8 / -4.19 / 2022-10-18 -26.8 2.5 51.4 1.6 -3.97 0.22 Justification of Extended Calibration SAR Dipole D1900V2 - serial no. 5d088 Head Date of Measurement Return-Loss (dB) Delta (%) Real Impedance (ohm) Delta (ohm) Imaginary Impedance (johm) Delta (johm) 2021-10-18 -22.6 / 53.7 / 6.80 / 2022-10-18 -22.2 1.8 54.6 0.9 6.93 0.13 Justification of Extended Calibration SAR Dipole D2450V2 - serial no. 873 Head Date of Measurement Return-Loss (dB) Delta (%) Real Impedance (ohm) Delta (ohm) Imaginary Impedance (johm) Delta (johm) 2021-10-21 -28.8 / 53.6 / 1.26 / 2022-10-20 -28.1 2.4 54.9 1.3 1.43 0.17 Justification of Extended Calibration SAR Dipole D2550V2– serial no.1010 Head Date of Measurement Return-Loss (dB) Delta (%) Real Impedance (ohm) Delta (ohm) Imaginary Impedance (johm) Delta (johm) 2021-05-21 -26.8 / 52.8 / -3.80 / 2022-05-20 -26.3 1.9 53.6 0.8 -3.64 0.16 The Return-Loss is <-20dB, and within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the value result should support extended cabration. ***END OF REPORT***

Tel：0755-26551151 Address of R&D Center： Shenzhen：South Area, 1st Floor, Phoenix Building, Keji North 1st Road, Nanshan District, Shenzhen Shanghai：1st Floor, Building C5, No. 2555 Xiupu Road, Pudong New Area, Shanghai Xi'an ：Room 101, Block A11, Phase II Software R&D Base, Software New Town, Xi'an Hi tech Zone Beijing :Building 21, No. 8, Dongbei Wangxi Road, Haidian District, Beijing www.haitongele.com Operating frequency band：AF WCDMA 1/8 FDD B2/4/7/28/66 AU FDD B1/B3/B5/B7/B8/B20/B28/B38/B40 Project name：WIFI63-AU+AF Zhejiang Haitong Communication Electronics Co., Ltd Antenna specification Test equipment 880-960 800-900 Machine state 1450-1500 Circuit matching： (Aglient E5071C) MAIN Antenna passive parameters 1710-2690 Antenna bom ANT-matching-ANT switch Software version Other Motherboard version PA bom ANT switch-matching-PA Antenna version Read Account engineer Test environmentTemperature22°CTemperature 65% RF engineer侯杰 Structural engineer Test engineer RF 33PF 18NH 3NH 0.5PF 3.3NH 700-800 f(MHz) EfficiencyAverage gainMax gain f(MHz) EfficiencyAverage gainMax gian f(MHz) EfficiencyAverage gainMax gian 70034% -4.6-0.6 79036% -4.4-1.4 88044% -3.50.9 71036% -4.4-0.2 80038% -4.2-1.4 89045% -3.41.2 72037% -4.30.1 81040% -4.0-1.7 90045% -3.51.4 73037% -4.30.5 82040% -3.9-2.0 91043% -3.61.0 74036% -4.40.7 83041% -3.9-1.7 92041% -3.90.4 75036% -4.40.8 84042% -3.8-1.9 93039% -4.00.0 76037% -4.30.7 85042% -3.8-2.2 94038% -4.2-0.2 77038% -4.20.7 86041% -3.9-2.4 95038% -4.2-0.4 78037% -4.30.7 87040% -4.0-2.4 96040% -4.0-0.5 79036% -4.50.3 140032% -4.9-0.4 171055% -2.63.7 80035% -4.6-0.1 141032% -4.9-0.5 173057% -2.43.5 142032% -5.0-0.2 175057% -2.53.2 143031% -5.1-0.1 177057% -2.53.5 144030% -5.2-0.1 179058% -2.43.8 145028% -5.5-0.1 181058% -2.43.4 146026% -5.9-0.3 183056% -2.53.5 147025% -6.0-0.4 185058% -2.43.7 148025% -6.1-0.5 187057% -2.52.8 149025% -6.0-0.5 189054% -2.72.2 150026% -5.8-0.4 191055% -2.62.4 193052% -2.92.4 195048% -3.22.1 197049% -3.12.6 199048% -3.22.8 201044% -3.62.7 203042% -3.72.3 205043% -3.62.6 207047% -3.32.5 209050% -3.02.2 211052% -2.82.3 213055% -2.62.1 215057% -2.41.5 217055% -2.61.2 219054% -2.70.7 221052% -2.80.3 223051% -2.90.1 225051% -3.00.2 227050% -3.00.3 229047% -3.30.3 231047% -3.30.5 233047% -3.30.3 235046% -3.30.4 237042% -3.80.3 239039% -4.10.3 241037% -4.40.0 243035% -4.50.0 245033% -4.80.3 247033% -4.90.8 249034% -4.71.1 251037% -4.41.3 253039% -4.11.7 255041% -3.91.9 257043% -3.62.0 259046% -3.42.0 261047% -3.32.3 263045% -3.41.9 265045% -3.41.7 267045% -3.41.9 269048% -3.21.9 Passive efficiency Main Antenna passive parameters Efficiency test results Test equipment Satimo SG24 Test equipment Machine state 1800-2700 Circuit matching： (Aglient E5071C) DIV Antenna passive parameters 700-960 Antenna bom ANT-matching-ANT switch Software version Other Motherboard version PA bom ANT switch-matching-PA Antenna version Read Account engineer Test environmentTemperature22°CTemperature 65% RF engineer侯杰 Structural engineer Test engineer RF 15NH 0Ω 0.5PF 3NH f(MHz) EfficiencyAverage gainMax gain f(MHz) EfficiencyAverage gainMax gain 91028% -5.5-2.1 180045% -3.53.5 92032% -4.9-1.3 182046% -3.43.8 93036% -4.4-0.6 184043% -3.73.4 94040% -4.00.3 186038% -4.32.5 95043% -3.70.8 188033% -4.92.1 96045% -3.51.3 190029% -5.31.6 192027% -5.60.5 194027% -5.70.2 196027% -5.7-0.2 198027% -5.7-0.3 200027% -5.8-1.0 202026% -5.8-1.2 204025% -6.0-1.3 206024% -6.2-1.2 208025% -6.0-1.5 210026% -5.9-1.2 212028% -5.5-0.6 214030% -5.20.1 216034% -4.70.6 218036% -4.51.3 220039% -4.12.1 222040% -3.92.2 224041% -3.82.7 226041% -3.92.8 228041% -3.93.2 230041% -3.83.5 232040% -4.03.6 234040% -4.04.0 236041% -3.94.1 238041% -3.93.9 240040% -4.03.7 242041% -3.93.5 244041% -3.93.2 246041% -3.93.1 248038% -4.22.9 250037% -4.32.5 252037% -4.41.9 254036% -4.51.8 256033% -4.81.5 258033% -4.81.3 260033% -4.80.9 262032% -4.90.7 264029% -5.4-0.1 266027% -5.7-0.5 268026% -5.9-0.6 270024% -6.1-0.7 DIV Antenna passive parameters Efficiency test results Test equipment Satimo SG24 Passive efficiency Test equipment Machine state Circuit matching WIFI1： WIFI2 2.4G 5G WIFI1 2.4G (Aglient E5071C) WIFI Antenna passive parameters Circuit matching WIFI2： Antenna bom ANT-matching-ANT switch Software version Other Motherboard version PA bom ANT switch-matching-PA Antenna version Read Account engineer Test environmentTemperature22°CTemperature 65% RF engineer侯杰 Structural engineer Test engineer RF NC 0Ω NC RF NC 1.5NH NC f(MHz) EfficiencyAverage gainMax gain f(MHz) EfficiencyAverage gainMax gain 240065% -1.93.1 515056% -2.53.2 241065% -1.93.1 520053% -2.72.8 242065% -1.92.9 525055% -2.62.9 243064% -1.92.9 530052% -2.82.9 244065% -1.92.9 535045% -3.42.9 245066% -1.82.9 540039% -4.02.8 246066% -1.82.9 545044% -3.63.0 247066% -1.82.8 550043% -3.63.1 248065% -1.92.5 555045% -3.43.2 249064% -1.92.3 560045% -3.42.8 250064% -1.92.5 565046% -3.42.8 570045% -3.42.5 575051% -3.02.7 580060% -2.23.6 585054% -2.72.8 f(MHz) EfficiencyAverage gainMax gain f(MHz) EfficiencyAverage gainMax gain 240032% -4.94.2 515032% -4.90.4 241033% -4.84.4 520033% -4.80.2 242034% -4.74.5 525033% -4.80.0 243034% -4.74.4 530033% -4.80.7 244034% -4.64.4 535034% -4.70.6 245035% -4.64.3 540036% -4.40.4 246035% -4.64.2 545034% -4.60.2 247034% -4.64.1 550033% -4.80.0 248034% -4.74.1 555036% -4.40.1 249034% -4.73.9 560035% -4.60.0 250035% -4.63.7 565036% -4.40.2 570035% -4.5-0.4 575036% -4.50.6 580036% -4.40.7 585039% -4.11.4 Satimo SG24 Passive efficiency WiFi WIFI2WIFI12 WIFI1 WIFI1 Efficiency test results Test equipment 5G

©Copyright. All rights reserved by SAICT. TEST REPORT No.I22N02153-RF LTE for TCL Communication Ltd. Mobile WiFi Model Name: MW63AF FCC ID: 2ACCJB188 with Hardware Version: FG11_AF_MB_V1.1 Software Version: MW63AF_V01.18b01 Issued Date: 2022-11-24 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of SAICT. Test Laboratory: SAICT, Shenzhen Academy of Information and Communications Technology Building G, Shenzhen International Innovation Center, No.1006 Shennan Road, Futian District, Shenzhen, Guangdong, P. R. China 518000. Tel:+86(0)755-33322000, Fax:+86(0)755-33322001 Email: [email protected]. www.saict.ac.cn No.I22N02153-RF LTE ©Copyright. All rights reserved by SAICT. Page 2 of 107 REPORT HISTORY Report Number Revision Description Issue Date I22N02153-RF LTE Rev.0 1st edition 2022-11-24 No.I22N02153-RF LTE ©Copyright. All rights reserved by SAICT. Page 3 of 107 CONTENTS 1. SUMMARY OF TEST REPORT ............................................................................................... 4 1.1. TEST ITEMS .......................................................................................................................... 4 1.2. TEST STANDARDS .............................................................................................................. 4 1.3. TEST RESULT ...................................................................................................................... 4 1.4. TESTING LOCATION .......…
